Sanyo PLC-XP41 Service Manual

Multi-media projector
Hide thumbs Also See for PLC-XP41:

Advertisement

Quick Links

Notice
CORRECTION
SERVICE FLASH
Please add this notice to the Service Manual listed below.
Category :
Multi-media Projector
Model :
Destination :
NOTE: Match the Chassis No. on the unit's back cover with the Chassis No. in the Service
Manual.
If the Chassis. No. does not match the unit's, additional service literature is required.
Only the difference service information is given in this manual. For detailed service infor-
mation, refer to the original service manual SM5110329, issued in April 2002, for
Models PLC-XP41/41L.
Differences:
Outline
PLC-XP41,PLC-XP41L
FILE WITH ORIGINAL SERVICE MANUAL (SM5110329)
PRODUCT CODE
PLC-XP41
1 122 110 30
(MB8AB)
1 122 111 30
(PB8AB)
PRODUCTION CHANGE
ADD INFORMATION
PLC-XP41
PLC-XP41L
Canada, U.S./Europe,
Asia, Africa,U.K
Power and Sub Power Board were changed.
PLC-XP41L
1 122 110 90
(MB8AP)
Issued Date :
Chassis No.
Effective from :
REF. NO. :
FILE NO.
REVISION-5
June / 2004
MB8-XP4101
MB8-XP41L01
SM5110329
SM
REFERENCE NO.
5110329-05

Advertisement

Table of Contents
loading

Summary of Contents for Sanyo PLC-XP41

  • Page 1 If the Chassis. No. does not match the unit’s, additional service literature is required. Only the difference service information is given in this manual. For detailed service infor- mation, refer to the original service manual SM5110329, issued in April 2002, for Models PLC-XP41/41L. Differences: Outline PLC-XP41,PLC-XP41L Power and Sub Power Board were changed.
  • Page 2: Specifications

    Adjustable from 31” to 400” Horizontal Resolution 800 TV lines (HDTV) Projection Lens F 1.8 ~2.1 lens with f=48.4mm ~ 62.8mm with motor zoom and focus (PLC-XP41) Throw Distance 4.6’ ~ 47.3’ (1.4m ~ 14.4m) (PLC-XP41) Motorized Lens Shift Up and Down...
  • Page 3: Adjustments After Parts Replacement

    ■ Adjustments after Parts Replacement ● ❍ : Adjustment necessary : Check necessary Disassembly / Replaced Parts LCD/ Polarized glass Condenser Relay Power Sub Power Prism Main Board Lens Lens Board Board Ass’y ❍ ● Condenser lens adjustment ❍ ● Relay lens adjustment Contrast Adjustment ●...
  • Page 4: To Enter The Service Mode

    ■ Electrical Adjustments ● Service Adjustment Menu Operation To enter the service mode To enter the “Service Mode”, press and hold the MENU and IMAGE button on the projector at the same time for more than 3 seconds. The service menu appears on the screen as follows. To adjust service data Select the adjustment group no.
  • Page 5: Output Voltage Adjustment

    Electrical Adjustments ● Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the follow- ing adjustments except requiring the readjustments in servicing otherwise it may cause loss of per- formance and product safety.
  • Page 6: Nrs Adjustment

    Electrical Adjustments Black Level adjustment NRS adjustment 1. Receive the 16-step gray scale computer signal with 1. Receive the a6-step gray scale computer signal with Input 1 [COMPUTER] mode. Input 1 [COMPUTER] mode. 2. Enter the service mode. 2. Enter the service mode. TP531 3.
  • Page 7: Pc Gamma Shift Adjustment

    Electrical Adjustments 8. Select item no. “ and change data value to adjust PC Gamma Shift adjustment the pedestal level and black level to be the same 1. Receive the 16-step gray scale computer signal with level. Input 1 [COMPUTER] mode. 2.
  • Page 8: Hdtv Gain Adjustment

    Electrical Adjustments HDTV Gain adjustment VIDEO Pedestal adjustment 1. Receive the 16-step gray scale component signal 1. Receive the 16-step gray scale video signal with [1080i] with Input 3 [COMPONENT] mode. Input 3 [VIDEO] mode. 2. Enter the service mode. 2.
  • Page 9: Note On White Uniformity Adjustment

    Electrical Adjustments A/D Offset adjustment Video Gamma Shift adjustment 1. Receive the 16-step gray scale video signal with 1. Receive the 16-step gray scale video signal with Input 3 [VIDEO] mode. Input 3 [VIDEO] mode. 2. Enter the service mode. 2.
  • Page 10: Service Adjustment Data Table

    Electrical Adjustments ● Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjust- ment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
  • Page 11: Initial Value

    Electrical Adjustments Adjustment Item Initial Value Range Input source / Description ✻ A/D input Adj. B_DRIVE 31/31/31 0 ~ 63 NT,NT443,PAL,PALM,PALN,480i,575i/ 480p,575p/ 1080i,1035i,720p HSEP_SEL 0 ~ 1 CR_OFFSET1 0 ~ 15 CB_OFFSET1 0 ~ 15 BLK_BOTTOM 0 ~ 15 R-Y/R 12/13/6/6 0 ~ 15 NT,NT443,480i,480p/PAL,PALM,PALN,PAL60,SECAM,575i,575p/1035i/1080i,720p...
  • Page 12: Adjustment Item

    Electrical Adjustments Adjustment Item Initial Value Range Input source / Description Real/Cinema GAMMA 14 488/488 385 ~ 639 Real/Cinema GAMMA 15 512/512 385 ~ 639 r_mid2_level 0 ~ 1023 _C9D r_mid1_level 0 ~ 1023 _C9E r_max_level 0 ~ 1023 _C9F g_mid2_level 0 ~ 1023 _CA1...
  • Page 13 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description Lamp-use time accumulated Read only Net Board Reset 0 ~ 1 0: Invalid , 1: Valid Key Stone Option 0 ~ 1 0: Fixed, 1: Change with inpt signal Logo Off 0 ~ 1 0: follow ro menu setting, 1: No logo display...
  • Page 14 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description NTSC & 480i / PAL & SECAM & 525i / 1035i & 1080i60 / 1080i50 / 720P / 480P / 575P ICS_R4_Fil_Sel 0 ~ 1 ICS_R4_DPA_OS 0 ~ 63 NTSC &...
  • Page 15 Electrical Adjustments Adjustment Item Initial Value Range Input source / Description TOTAL DOTS 1650 0 ~ 2048 DISP DOTS 1248 0 ~ 2048 720p H BACK PORCTH 0 ~ 2048 V BACK PORCTH 0 ~ 2048 DISP LINE 0 ~ 2048 CLAMP 0 ~ 2048 Group: 516 HDTV 575p Gakaku...
  • Page 16: Electrical Parts List

    ■ Electrical Parts List MB8XP4101/MB8-XP41L01 Product safety should be considered when a component replacement is made in any area of a projector. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety.
  • Page 17 MB8XP4101/MB8-XP41L01 Electrical Parts List Note: Parts order must contain Chassis No., Part No., and Descriptions. ● OUT OF CIRCUIT BOARD RC1 Board Sensor1 Board FN901 Cooling Fan FN903 Cooling Fan Drive Board Power Board Sub Power Main Board Board Lamp Ballast FN902 Board Cooling Fan...
  • Page 18 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R6873 401 105 6001 MT-GLAZE 5.6K JA 1/16W ASSEMBLIED BOARDS R6874 401 105 5301 MT-GLAZE 4.7K JA 1/16W R6875 401 105 3307 MT-GLAZE 2.7K JA 1/16W ! 610 293 1815 ASSY,PWB,CONTROL MA8A R6876...
  • Page 19: Main Board

    MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C1691 403 281 5205 CERAMIC 0.22U Z Q4172 405 014 4509 TR 2SC2412K T146 R C1692 403 155 1609 CERAMIC 33P J Q4182 405 014 4509 TR 2SC2412K T146 R C1693 403 155 1609...
  • Page 20 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description IC3611 409 502 3203 IC L3E01031F0A C1114 403 164 0204 CERAMIC 0.1U Z IC362 409 501 9107 IC ICS512MT C1115 403 304 1801 ELECT 100U M 6.3V IC3631 409 502 3203...
  • Page 21 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C1569 403 164 0204 CERAMIC 0.1U Z C228 403 283 6309 CERAMIC 1U Z C1571 403 304 3300 ELECT 47U M C230 403 283 6309 CERAMIC 1U Z C1572 403 164 0204...
  • Page 22 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C2516 403 164 0204 CERAMIC 0.1U Z C3129 403 164 0204 CERAMIC 0.1U Z C2517 403 321 2607 ELECT 10U M C313 403 164 0204 CERAMIC 0.1U Z C2518 403 164 0204...
  • Page 23 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C3636 403 164 0204 CERAMIC 0.1U Z C414 403 164 0204 CERAMIC 0.1U Z C3637 403 164 0204 CERAMIC 0.1U Z C4141 403 149 9208 CERAMIC 0.01U Z C3651 403 164 0204...
  • Page 24 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C4240 403 283 6309 CERAMIC 1U Z C534 403 164 0204 CERAMIC 0.1U Z C4241 403 149 9208 CERAMIC 0.01U Z C537 403 164 0204 CERAMIC 0.1U Z C4242 403 164 0204...
  • Page 25 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C809 403 283 6309 CERAMIC 1U Z R1132 401 105 0504 MT-GLAZE 1K JA 1/16W C811 403 164 0204 CERAMIC 0.1U Z R1133 401 105 2003 MT-GLAZE 1.8K JA 1/16W C812...
  • Page 26 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R1816 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R214 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R1817 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R215 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R1821...
  • Page 27 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R2517 401 105 4601 MT-GLAZE 3.9K JA 1/16W R3122 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R2518 401 105 4700 MT-GLAZE 39K JA 1/16W R3123 401 105 5301 MT-GLAZE 4.7K JA 1/16W R2519...
  • Page 28 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R343 401 105 2003 MT-GLAZE 1.8K JA 1/16W R3651 401 105 0306 MT-GLAZE 10 JA 1/16W R344 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R3652 401 105 0306 MT-GLAZE 10 JA 1/16W R345...
  • Page 29 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R4125 401 105 0504 MT-GLAZE 1K JA 1/16W R4209 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R4126 401 105 0603 MT-GLAZE 10K JA 1/16W R421 401 105 2607 MT-GLAZE 22 JA 1/16W R4127...
  • Page 30 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R444 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R4834 401 105 0603 MT-GLAZE 10K JA 1/16W R446 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R4835 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R447...
  • Page 31 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R8031 401 105 0405 MT-GLAZE 100 JA 1/16W R879 401 105 0603 MT-GLAZE 10K JA 1/16W R8032 401 105 0405 MT-GLAZE 100 JA 1/16W R880 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R8033...
  • Page 32 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description RB404 645 037 0663 R-NETWORK 22X4 0.063W 645 028 5981 R-NETWORK 10X4 1/16W 645 021 4943 R-NETWORK 22X4 1/16W RB8013 645 037 3107 R-NETWORK 10X4 0.063W RB406 645 037 0663 R-NETWORK 22X4 0.063W...
  • Page 33 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description L4501 645 020 1776 INDUCTOR,3.3U M TRANSISTOR L501 645 020 1776 INDUCTOR,3.3U M Q2001 405 134 5905 TR 2SA1037AK-T146-R L502 645 020 1776 INDUCTOR,3.3U M Q2002 405 134 5905 TR 2SA1037AK-T146-R L531...
  • Page 34 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C2008 403 304 3300 ELECT 47U M C7148 403 162 6604 ELECT 2.2U M C2011 403 321 2607 ELECT 10U M C7149 403 162 6208 ELECT 1U M C2012 403 321 2607...
  • Page 35 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R2004 401 260 4102 MT-GLAZE 75 JA 1/3W R5203 401 105 0405 MT-GLAZE 100 JA 1/16W R2005 401 260 4102 MT-GLAZE 75 JA 1/3W R5204 401 037 5608 MT-GLAZE 10K JA 1/10W R2006...
  • Page 36 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description L2006 401 035 4108 MT-GLAZE 0.000 ZA 1/8W D2016 407 221 7106 ZENER DIODE UDZS-TE-1712B L2007 645 044 8836 FILTER,EMI 100MHZ D2017 407 221 7106 ZENER DIODE UDZS-TE-1712B L2008 645 044 8836 FILTER,EMI 100MHZ...
  • Page 37: Power Board

    MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C7026 403 280 1604 ELECT 220U M INTEGRATED CIRCUIT C7041 403 280 1604 ELECT 220U M IC601 409 523 1400 IC FA5502M C7042 403 280 1604 ELECT 220U M IC651...
  • Page 38 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R616 401 105 0504 MT-GLAZE 1K JA 1/16W TRANSFORMER !T601 R617 401 105 1600 MT-GLAZE 15K JA 1/16W 645 051 9369 INDUCTOR,625U !T651 R618 401 105 0306 MT-GLAZE 10 JA 1/16W 645 028 0641...
  • Page 39 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description Q6616 405 014 4509 TR 2SC2412K T146 R C6655 403 391 5706 ELECT 4.7U M Q6617 405 014 4509 TR 2SC2412K T146 R C6661 403 164 0204 CERAMIC 0.1U Z Q6618...
  • Page 40: Drive Board

    MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R6668 401 105 0504 MT-GLAZE 1K JA 1/16W R6787 401 230 2503 MT-GLAZE 1K FA 1/16W R6669 401 105 0603 MT-GLAZE 10K JA 1/16W R6788 401 203 9805 MT-GLAZE 2.7K FA 1/16W R6670...
  • Page 41: Filter Board

    MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description CAPACITOR R1671 401 105 1501 MT-GLAZE 1.5K JA 1/16W R1674 401 105 6506 MT-GLAZE 680 JA 1/16W C1601 403 325 8506 ELECT 1000U M R1680 401 105 8104 MT-GLAZE 56K JA 1/16W C1602...
  • Page 42 MB8XP4101/MB8-XP41L01 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 645 015 3976 CABLE,FXAF 645 039 7196 CABLE,MOUSE MAC 645 054 3098 CABLE,MOUSE MAC 645 054 3104 CABLE,MOUSE MAC 645 039 7202 CABLE,MOUSE PS/2 645 054 3111 CABLE,MOUSE PS/2 645 054 3128 CABLE,MOUSE PS/2...
  • Page 43 ■ Mechanical Parts List MB8-XP4101/MB8-XP41L01 Note: Parts order must contain Chassis No., Part No., and Descriptions. ● CABINET PARTS -43-...
  • Page 44 610 297 3921 CABINET BOTTOM-MA8AA 610 277 2203 CAP LENS-M6SAA OPTICAL PARTS DIRECTORY 610 296 5872 COVER CABINET FRONT SRV-M (Model PLC-XP41 Only) (Including Key No. 9) 645 043 7144 ASSY,LENS,PROJECTION 610 294 5225 DEC RING-MA8A (Including Key No. 51-a, b)
  • Page 45 MB8-XP4101/MB8-XP41L01 Mechanical Parts List * Model PLC-XP41 only 51-b 51-a 23-a 23-b -45-...
  • Page 46 ■ Optical Parts List MB8-XP4101/MB8-XP41L01 Note: Parts order must contain Chassis No., Part No., and Descriptions. 67: Red 68: Green 69: Blue -46-...
  • Page 47 MB8-XP4101/MB8-XP41L01 Optical Parts List 53-a: Red 53-b: Green 53-c: Blue 53-d: Red/Blue 53-e: Green -47-...
  • Page 48 MB8-XP4101/MB8-XP41L01 Optical Parts List CAUTION: Part must be placed in specified direction when replacing the optical parts. Please see “Optical Parts Disassemblies” for further instructions. -48-...
  • Page 49 MB8-XP4101/MB8-XP41L01 Mechanical Parts List -49-...
  • Page 50 MB8-XP4101/MB8-XP41L01 Mechanical Parts List -50-...
  • Page 51 MB8-XP4101/MB8-XP41L01 Mechanical Parts List -51-...
  • Page 52 SANYO Electric Co., Ltd. (MB8AB) Jun. 2004 BB 400 Printed in Japan...
  • Page 53: Schematic Diagrams Printed Wiring Board Drawings

    These schematic diagrams and printed wiring board drawings are part of the service manual notice for chassis No. MB8-XP4101 and MB8-XP41L01, model PLC-XP41 and PLC-XP41L. File with the service manual No. SM5110329. Note: All the information of part numbers and values indicated on these diagrams are at the beginning of production.
  • Page 54: Parts Description And Reading In Schematic Diagram

    ■ Parts description and reading in schematic diagram MB8-XP4101, MB8-XP41L01 1. The parts specification of resistors, capacitors and Resistor Reading coils are expressed in designated code. Please check Example 1/2 D J 10K B the parts description by the following code table. 2.
  • Page 55 ■ Pin description of diode, transistor and IC MB8-XP4101, MB8-XP41L01 ● Diode ● Diode K: Cathode A: Anode ● Transistor/FET ● Transistor/FET C: Collector D: Drain B: Base G: Gate Index E: Emitter S: Source C1 C2 C1 C2 ● IC ●...
  • Page 56 Diagrams & Drawings (PLC-XP41,PLC-XP41L)
  • Page 57: Printed Wiring Board Diagrams

    ■ Printed Wiring Board Diagrams CAUTION This projector is isolated from AC line by using the internal converter transformer. Please pay attention to the following notes in servicing 1. Do not touch the part on hot side (primary circuit) or both parts on hot and cold FILTER (SIDE:A) FILTER (SIDE:B) sides (secondary circuit) at the same time.
  • Page 58 MAIN (SIDE:A) LENS SHIFT CONNECT SUB POWER “K66D” CONTROL “K68A” RC FRONT“K28A” SUB POWER “K66E” “K9C” RB9801 RB9802 TP501 TP1501 R2503 R3666 R2521 R3653 R2504 C2524 R502 TP1561 R3656 R501 R3659 TP561 D4811 C2523 C1508 B-LCD PANEL C4808 R-LCD PANEL C508 TE501 R3658...
  • Page 59 MAIN (SIDE:B) LAMP BALLAST UNIT “K7B” I/F “K70D” SUB POWER “K66F” SENSOR1 “K16I” R2522 L1501 I/F “K70A” R3663 DRIVE “K16R” R1503 R3664 C507 R1504 R3662 R3654 R9804 R3657 C1507 D4816 D4813 C2504 R3661 R3618 C569 C4812 L501 R4862 D4807 R4801 C4816 R3619 C1567...
  • Page 60 POWER (SIDE:A) DRIVE (SIDE:A) DRIVE “CN16C” LAMP BALLAST UNIT “K7A” FILTER “K6AB” SPEAKERS MAIN K6AC (LIVE HEATSINK) “K10T” “K8T” CN6C CAUTION: C609 C608 SHOCK HAZARD. PTH601 DB601 TEST BEFORE TOUCHING L681 DS601 C1642 ZOOM/ K16N DS602 FOCUS R1672 R699 C692 C607 FB601 K16R...
  • Page 61 SUB POWER (SIDE:A) SUB POWER (SIDE:B) POWER FN901 FN903 CONNECT “CN6A” “K66Q” FN902 FN906 K66K K66J C6666 D6615 D6613 K66M K66L C6666 K66G C6659 R6732 R6731 R6724 R6722 D6616 D6612 D6614 R6727 D6610 R6726 R6751 D6619 R6642 Q6624 R6723 D6728 R6721 R6640 C6663...
  • Page 62 A/V (SIDE:A) A/V (SIDE:B) DRIVE “K16S” K10T C5014 K20B K10H K10F “K8A” “K8C” “K8B” MAIN I/F (SIDE:A) I/F (SIDE:B) R7051 R7026 D7021 R7052 C7024 C7026 C7021 C7022 FN904 C7023 R7004 Q7022 IC7001 SUB POWER R7034 R7032 R7003 “K66N” R7033 R7036 C7042 C7044 MAIN “K8Y”...
  • Page 63 ■ Schematic Diagrams K911P K911S D6728 L6611 R6655 J11MC J11MB K66G 020N 020N 1/2GJ DRIVE SOUND R-OUT K16N L2E6470KN L6612 R6642 J10EP 060G J10EP L2M9470KN 1/16GF R6721 POWER R6654 C6752 D6626 R6647 R6621 C6762 D6602 R6623 040G SP901 6.8KC R6624 IC1631 A10B 1/16...
  • Page 64 DIGITAL-INPUT D5201 RB051L L1001 R5201 INPUT-1 INPUT-1 -40G F34DA200G 1/16GJ C5201 100C D1001 CG1-R 02DZ CG1-G 6.2YG R1001 C5212 L1002 R5202 D1002 L5201 25KZ0.1 F34DA200G 1/16GJ CG1-B K10A 02DZ GJ75 GQFY 100C 1/8GZ000 J11B0990N 6.2YG IC5202 CG1-R D1003 C5202 R1002 K10F 02DZ C5209...
  • Page 65 R1112 R1111 1/16GJ 1/16GJ 100C 100C C1128 R1109 3.3V_AV 25KZ0.1 D1101 1/16GJ GQFZ 1SS355 4.7KC C1127 C1124 10KZ 6.3EM 1UGQFZ R1108 47WM 1/16GZ0C C1125 25KZ0.1 GQFZ C1126 IC1161 Q1101 2SC2412 BA033FP-E2 C1101 C1121 R1107 C1123 25KZ0.1 1/16GJ 25KZ0.1 25KZ0.1 GQFZ GQFZ 470C GQFZ...
  • Page 66 R8001 1/16GZ R8002 RB8009 RB8010 1/16GZ R1EA1004G R1EA1004G ;R1A41004G ;R1A41004G RB8012 D_BO7 R1EA1004G ;R1A41004G D_BO6 RB8013 R1EA1004G D_BO5 D8031 ;R1A41004G 1SS355 L8001 D_BO4 L2PD RB8011 2R2MG C8021 5V_DVI 3.3V D_BO3 R1EA1004G IC8003 ;R1A41004G CJ330 C8003 CGQY D_BO2 6.3EM TC4053BF(EL) C8001 100WM C8004 C8022...
  • Page 67 3.3V L6301 1/8GZ C6309 C6308 C6311 25KZ0.1 C6307 3.3V_SG KK1000 GQFZ 1000 25KZ0.1 GQBZ GQBZ GQFZ C6312 25KZ0.1 3.3V GQFZ 3.3V L4201 L4501 C4246 C4248 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51 C4501 L2A73R3MG C4247...
  • Page 68 IC392 NTF-1 SI-3025LSA-TL R391 R392 C394 R395 C396 1/16GZ 6.3EM 100WM 470D R1301 S3.3V S2.5V IC4201 C391 25KZ0.1 R1302 GQFZ C395 R1304 25KZ0.1 R1303 IC391 C392 1/16GZ GQFZ 1/16GJ10KC 6.3EM 100WM 2.5V_REG. CONVERTER BA033FP-E2 R1305 1/16GZ ;UPC2933T-E1 C393 TP1304 25KZ0.1 J30A GQFZ 00102...
  • Page 69 B-LCD Q3601 L3601 2SA1203Y 1/8GJ10 IC301 15.5V 15VL R503 R3601 PANEL C512 1/16GJ 1.5KC STSQEB 25KZ0.1 P-FAIL SCAN R3602 GQFZ R3603 DYOUT R3627 STSQOB 1/16GJ D3601 1/16 1/16GJ 4.7KC R504 GZ0C XFRB 4.7KC 1SS355 CONVERTER C514 C513 L2591 C2502 1/16GZ0C C3601 SHCLKB 25KZ0.1...
  • Page 70 LENS SHIFT LAMP POWER CONTROL RC FROMT TEMP. CONNECT POWER POWER BALLAST DRIVE "K66D" "K68A" "K28A" "K16I" "K9C" "K66F" "K66E" "K10Q" UNIT "K16R" "K10R" "K10P" "K7B" J10EG060G J10EP040G J10EP130G J10EG090G J10EP080G J10EG130G J10EP120G J10EG030G J10EP040G J10ML J10ML J10ML 540G NTR-1 NTR-2 NTL-5 NTS-1...
