GENERAL
Power supply
Power consumption
Net Weight
External dimensions (W x H x D)
Operating conditions Temperature
Operating humidity
Laser
Tuner FM
FM Tuning Range
FM Intermediate Frequency
AM Tuning Range (optional)
AM Intermediate Frequency
AMPLIFIER
Output Power
T.H.D
SPEAKERS (RBS154V)
Type
Impedance
Rated Input Power
Max. Input Power
Net Dimensions (W x H x D)
Net Weight
Designs and specifications are subject to change without notice.

SPECIFICATIONS

Refer to main label.
Refer to main label.
3.8 kg
202 x 307 x 262 mm
5°C to 35°C, Operation status: Horizontal
5% to 85%
Semiconductor laser, wavelength 650 nm
87.5 ~ 108.0 MHz or 87.50 ~ 108.0 MHz
128 kHz
522 ~ 1,620 kHz or 520 ~ 1,710 kHz or 520 ~ 1,710 kHz
45 kHz
80 W + 80 W
0.5 %
2 Way 2 Speaker
4 Ω
50 W
100 W
165 x 316 x 198 mm
2.8 kg
1-8
