Panasonic DVD-S29EG Service Manual
Panasonic DVD-S29EG Service Manual

Panasonic DVD-S29EG Service Manual

Hide thumbs Also See for DVD-S29EG:
Table of Contents

Advertisement

Quick Links

Specifications

Power supply:
Power consumption:
Power consumption in standby mode:
approx. 1 W
Dimensions:
Mass:
Signal system:
Operating temperature range:
Operating humidity range:
Region number:
Discs played [8 cm or 12 cm]:
(1)
DVD-RAM (DVD-VR compatible, JPEG formatted discs)
(2)
DVD-Audio
(3)
DVD-R (DVD-Video compatible)
(4)
CD-Audio (CD-DA)
(5)
Video CD
(6)
SVCD (Conforming to IEC62107)
(7)
CD-R/CD-RW (CD-DA, Video CD, SVCD, MP3, WMA,
JPEG formatted discs)
(8)
MP3/WMA
The total combined maximum number of recognizable
audio and picture contents and groups:
Compatible compression rate:
MP3:
AC230 V, 50 Hz
(DVD-S29EG/E)
AC230-240 V, 50 Hz
(DVD-S29EB only)
9 W
430 (W)×248 (D)×43 (H) mm
2.14 kg
PAL625/50, PAL525/60, NTSC
+5 to +35°C
5 to 90 % RH (no
condensation)
Region No.2
4000 audio and picture
contents and 400 groups.
between 32 kbps and 320 kbps
DVD-S29EG
DVD-S29E
DVD-S29EB
DL4.1 Mechanism Series
Colour
(S).......................Silver Type
(K).......................Black Type (S29EG/E Only)
WMA:
(9)
JPEG
Exif Ver 2.1 JPEG Baseline files
The total combined maximum number of recognizable
audio and picture contents and groups:
Picture resolution:
(10) HighMAT Level 2 (Audio and Image)
Video output:
Output level:
Output terminal:
S video output:
Y output level:
C output level:
Output terminal:
Component video output:
Y output level:
P
output level:
B
P
output level:
R
Output terminal:
Number of terminals:
RGB video output:
R output level:
© 2005 Matsushita Electric Industrial CO., Ltd. All
rights
reserved.
distribution is a violation of law.
ORDER NO.CHM0501001C2

DVD Player

between 48 kbps and 320 kbps
4000 audio and picture
contents and 400 groups.
between 320×240 and
6144×4096 pixels
(Sub sampling is 4:2:2 or 4:2:0)
1 Vp-p (75 Ω)
Pin jack (1 system)/AV
1 Vp-p (75 Ω)
NTSC; 0.286 Vp-p (75 Ω)
PAL; 0.300 Vp-p (75 Ω)
AV
[NTSC: 525(480)p / 525(480)i,
PAL: 625(576)p / 625(576)i]
1 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
0.7 Vp-p (75 Ω)
Pin jack (Y: green, P
: bule,
B
P
: red)
R
1 system
0.7 Vp-p (75 Ω)
Unauthorized
copying
and

Advertisement

Table of Contents
loading

Summary of Contents for Panasonic DVD-S29EG

  • Page 1: Dvd Player

    ORDER NO.CHM0501001C2 DVD Player DVD-S29EG DVD-S29E DVD-S29EB DL4.1 Mechanism Series Colour (S).......Silver Type (K).......Black Type (S29EG/E Only) Specifications Power supply: AC230 V, 50 Hz WMA: between 48 kbps and 320 kbps (DVD-S29EG/E) JPEG AC230-240 V, 50 Hz Exif Ver 2.1 JPEG Baseline files...
  • Page 2: Table Of Contents

    DVD-S29EG / DVD-S29E / DVD-S29EB 0.7 Vp-p (75 Ω) G output level: 0.7 Vp-p (75 Ω) B output level: Output terminal: Note: Audio output: Specifications are subject to change without notice. Output level: 2 Vrms (1 kHz, 0 dB) Mass and dimensions are approximate.
  • Page 3 DVD-S29EG / DVD-S29E / DVD-S29EB 10 ADJUSTMENT PROCEDURES 15 SCHEMATIC DIAGRAM 10.1. Service Tools and Equipment 15.1. POWER SUPPLY SECTION (MOTHER P.C.B. (1/2)) 10.2. Important points in adjustment SCHEMATIC DIAGRAM 10.3. Storing and Handling Test Discs 15.2. FRONT & AV OUT SECTION (MOTHER P.C.B. (2/2)) 10.4.
  • Page 4: Safety Precautions

    DVD-S29EG / DVD-S29E / DVD-S29EB 1 SAFETY PRECAUTIONS 1.1. GENERAL GUIDELINES 1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit. 2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
  • Page 5: Precaution Of Laser Diode

    DVD-S29EG / DVD-S29E / DVD-S29EB Caution Be sure no power is applied to the chassis or circuit, and observe all other safety precautions. 8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise hamless motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to damage an ES device).
  • Page 6: Prevention Of Static Electricity Discharge

    DVD-S29EG / DVD-S29E / DVD-S29EB 5 PREVENTION OF STATIC ELECTRICITY DISCHARGE The laser diode in the traverse unit (optical pickup) may brake down due to static electricity of clothes or human body. Use due caution to electrostatic breakdown when servicing and handling the laser diode.
  • Page 7: Disassembling The Casing And Checking P.c.b.s

    DVD-S29EG / DVD-S29E / DVD-S29EB 6 DISASSEMBLING THE CASING AND CHECKING P.C.B.S 6.1. Disassembly Procedure 6.2. Casing Parts and P.C.B. Positions...
  • Page 8: Top Panel

    DVD-S29EG / DVD-S29E / DVD-S29EB 6.3. Top Panel 1. Unscrew the screws. 6.5. Module P.C.B. 1. Unscrew the screws. 2. Remove the connectors. 3. Press each tab with the nipper to module PCB vertically. 6.4. Front Panel 1. Release the tabs.
  • Page 9: Rear Panel

    DVD-S29EG / DVD-S29E / DVD-S29EB 6.7. Rear panel 1. Unscrew the screws 2. Release the tabs. 6.8. Mother P.C.B. and Power SW P.C.B. 1. Unscrew the screws.
  • Page 10: Service Position

    DVD-S29EG / DVD-S29E / DVD-S29EB 6.9. Service Position 6.9.1. Servicing position of the Module P.C.B. 6.9.2. Servicing position of the Mother P.C.B. 6.9.3. List of the Extension Cables...
  • Page 11: Assembling And Disassembling The Mechanism Unit

    DVD-S29EG / DVD-S29E / DVD-S29EB 7 ASSEMBLING AND DISASSEMBLING THE MECHANISM UNIT 7.1. Disassembly Procedure 4. Remove the traverse unit 7.2. Traverse Unit 1. Slide the lever (A) in the arrow direction (to the opposite side) till it stops. 2. Slide the lever (A) further by bending the tab at the right side of the lever A in the right direction.
  • Page 12: Tray

    DVD-S29EG / DVD-S29E / DVD-S29EB 7.3. Tray 1. Slide the guide tray unit while pressing the stopper in the 5. Remove the drive arm concave phase from the tray slider arrow direction, and remove the guide tray unit. and tray.
  • Page 13: Loading Section

    DVD-S29EG / DVD-S29E / DVD-S29EB 4. Remove the belt. 7.4. Loading section 5. Unlock the tab and remove the pulley. 6. Remove the relay gear. 1. Spread the tabs at the both sides and push out the drive arm shaft.
  • Page 14: Loading Motor P.c.b

    DVD-S29EG / DVD-S29E / DVD-S29EB 9. Pull the lever (B) in the bottom side to your side and remove the change lever. 10. Remove the drive rack, the sub rack and the drive gear. 7.5. Loading motor P.C.B. 1. Unscrew the screws...
  • Page 15: Optical Pickup Unit

    DVD-S29EG / DVD-S29E / DVD-S29EB 7.6. Optical Pickup Unit 7.6.1. Cautions to Be Taken in Handling the Optical Pickup Unit The laser diode in the optical pickup unit may be damaged due to electrostatic discharge generating from clothes or human body.
  • Page 16 DVD-S29EG / DVD-S29E / DVD-S29EB 7.6.2. Procedure for Disassembling the Optical Pickup Unit 1. Move the optical pickup unit in the arrow direction till it stops. 6. Lift the optical pickup unit with the shaft. 2. Unscrew the screws. 7. Remove the optical pickup unit.
  • Page 17: Traverse Motor

    DVD-S29EG / DVD-S29E / DVD-S29EB <Assembling the optical pickup unit> 1. Pass the intermediate FPC through the frame hole. 2. Align the guide section of the optical pickup unit with the 2. Remove the cover while lifting the inner gear.
  • Page 18 DVD-S29EG / DVD-S29E / DVD-S29EB...
  • Page 19: Self-Diagnosis Function And Service Modes

    DVD-S29EG / DVD-S29E / DVD-S29EB 8 Self-Diagnosis Function and Service Modes 8.1. Optical Pickup Breakdown Diagnosis The optical pickup self-diagnosis function and tilt adjustment check function have been included in this unit. When repairing, use the following procedure for effective Self-diagnosis and tilt adjustment.Be sure to use the self-diagnosis function before replacing the optical pickup when "NO DISC"...
  • Page 20: Service Mode Table

    DVD-S29EG / DVD-S29E / DVD-S29EB 8.2. Service Mode Table 1 The service modes can be activated by pressing various button combination on the player and remote control unit. Player buttons Remote control unit buttons Application Note PAUSE Displaying the UHF display F_ _ _ Refer to section 8.3.
  • Page 21: Last Error Code Saved During No Play

    DVD-S29EG / DVD-S29E / DVD-S29EB Error Code Error Content Additional error explanation Defect 1 Defect 2 Defect 3 Defect 4 F611 6626 QCODE don’t Access failure to seek address in CD series (IC8001) read Error F612 Access failure to ID data in DVD series...
  • Page 22: Service Mode Table

    DVD-S29EG / DVD-S29E / DVD-S29EB 8.5. Service mode table 2 Pressing various button combinations on the player and remote control unit can activate the service modes.
  • Page 23 DVD-S29EG / DVD-S29E / DVD-S29EB...
  • Page 24: Sales Demonstration Lock Function

    DVD-S29EG / DVD-S29E / DVD-S29EB 8.6. Sales demonstration lock function This function prevents discs from being lost when the unit is used for sales demonstrations by disabling the disc eject function. "LOC" is displayed on the unit, and ordinary operation is disabled.
  • Page 25: Service Precautions

    DVD-S29EG / DVD-S29E / DVD-S29EB 9 Service Precautions 9.1. Recovery after the dvd player is repaired · When FROM or module P.C.B. is replaced, carry out the recovery processing to optimize the drive. Playback the recovery disk to process the recovery automatically.
  • Page 26: Adjustment Procedures

    DVD-S29EG / DVD-S29E / DVD-S29EB 10 ADJUSTMENT PROCEDURES 10.1. Service Tools and Equipment Application Name Number Tilt adjustment DVD test disc DVDT-S15 or DVDT-S01 TORX screw driver (T6) Available on sales route. (T6) or RFKZ0185 Inspection Extension cable (module P.C.B. to mother P.C.B.) VUC8026 Extension cable (module P.C.B.
  • Page 27: Optical Adjustment

    DVD-S29EG / DVD-S29E / DVD-S29EB 10.4. Optical adjustment 10.4.1. Optical pickup tilt adjustment Measurement point Adjustment point Mode Disc Tangential adjustment screw T01 (inner periphery) play DVDR-S15 or DVDT-S01 Tilt adjustment screw T30 (central periphery) play T43 (outer periphery) play...
  • Page 28 DVD-S29EG / DVD-S29E / DVD-S29EB It is also possible to perform screw lock on the head of an 10.4.1.4. Procedure for screw lock adjustment screw after an adjustment end using an injector etc. Please perform a screw lock in which by the side of the tip or from the hole at the bottom of a product (hole of bottom head of an adjustment screw.
  • Page 29: Abbreviations

    DVD-S29EG / DVD-S29E / DVD-S29EB 11 Abbreviations INITIAL/LOGO ABBREVIATIONS INITIAL/LOGO ABBREVIATIONS A0~UP ADDRESS ERROR TORQUE CONTROL ACLK AUDIO CLOCK ERROR TORQUE CONTROL AD0~UP ADDRESS BUS REFERENCE ADATA AUDIO PES PACKET DATA ENCSEL ENCODER SELECT ADDRESS LATCH ENABLE ETMCLK EXTERNAL M CLOCK (81MHz/40.5MHz)
  • Page 30 DVD-S29EG / DVD-S29E / DVD-S29EB INITIAL/LOGO ABBREVIATIONS INITIAL/LOGO ABBREVIATIONS READ ENABLE VBLANK V BLANKING RFENV RF ENVELOPE COLLECTOR POWER SUPPLY RF PHASE DIFFERENCE OUTPUT VOLTAGE (CD-ROM) REGISTER SELECT VCDCONT VIDEO CD CONTROL (TRACKING RSEL RF POLARITY SELECT BALANCE) RESET DRAIN POWER SUPPLY VOLTAGE...
  • Page 31: Voltage Chart

    DVD-S29EG / DVD-S29E / DVD-S29EB 12 VOLTAGE CHART Note: · Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point, because it may differ from an actual measuring value due to difference of Measuring instrument and its measuringcondition and product itself.
  • Page 32: Module P.c.b

    DVD-S29EG / DVD-S29E / DVD-S29EB 12.2. MODULE P.C.B. IC8001 Ref No. MODE PLAY STOP IC8001 Ref No. MODE PLAY STOP Ref No. IC8001 MODE PLAY STOP IC8001 Ref No. MODE PLAY STOP Ref No. IC8001 MODE PLAY STOP IC8001 Ref No.
  • Page 33 DVD-S29EG / DVD-S29E / DVD-S29EB IC8611 Ref No. MODE PLAY STOP IC8651 Ref No. MODE PLAY STOP Ref No. IC8651 MODE PLAY STOP IC8651 Ref No. MODE PLAY STOP Q8550 Q8551 Q8552 Q8560 Q8561 Ref No. MODE PLAY STOP Ref No.
  • Page 34 DVD-S29EG / DVD-S29E / DVD-S29EB...
  • Page 35: Block Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 13 BLOCK DIAGRAM Note: Circuit voltage and waveform described herein shall be regarded as reference information when probing defect point, because it may differ from an actual measuring value due to difference of Measuring instrument and its measuringcondition and product itself.
  • Page 36: Power Supply Block Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 13.2. POWER SUPPLY BLOCK DIAGRAM PRIMARY CIRCUIT SECONDARY CIRCUIT IC6001 (OPERATION CPU) L1001 D1011,C1011 T1021 AC SOCKET NSW+9V AUDIO P1001 NSW-12V OP AMPS DGT8 VA1002 SURGE LINE RECTIFIER DGT11 KILLER FILTER POWER TRANSFORMER F1001 Q1125 REG.
  • Page 37: Servo Block Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 13.3. SERVO BLOCK DIAGRAM RF SIGNAL MOTOR DRIVE SIGNAL TRACKING ERROR SIGNAL FOCUS ERROR SIGNAL IC8251 IC8001 (DV2) (MOTOR DRIVE) VO2+ VIN9 TRAVERS MOTOR OPTICAL PICK UP UNIT VIN10 TRSDRV VIN2 LEVEL VO2- SHIFT VIN5...
  • Page 38: Video Block Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 13.4. VIDEO BLOCK DIAGRAM IC8001 (DV2) DAC5OUT DAC4OUT OPTICAL RFINN PICK-UP RFINP UNIT Y/PY/G DAC1OUT CB/PB/B DAC2OUT 151 CR/PR/R DAC3OUT IC8651 (16M FLASH ROM) ADDRESS ADDRESS DATA IC8051 (64M SDRAM) IC8001-152 IC8001-151 0.49Vp-p(20usec./div.) 0.49Vp-p(20usec./div.) ADDRESS...
  • Page 39 DVD-S29EG / DVD-S29E / DVD-S29EB VIDEO MAIN SIGNAL IC3501-11 IC3501-12 IC3501-15 IC3501-13 1.2Vp-p(20usec./div.) 1.2Vp-p(20usec./div.) 2.0Vp-p(20usec./div.) 2.0Vp-p(20usec./div.) IC3501 (VIDEO DRIVE) BIAS COUT DRIVER 6.75MHz CVBS JK4401 -6dB DRIVER VIDEO OUT CLAMP YOUT DRIVER 6.75MHz IC3502 BIAS MUTE 1.4V MUTE CLAMP JK4401...
  • Page 40: Audio Block Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 13.5. AUDIO BLOCK DIAGRAM IC8001 (DV2) DACCK AUDIO MAIN SIGNAL IC8421 MCLK (AUDIO D/A CONVERTER) JK4401 DE-EMPHASIS CLOCK IC4301 SMUTE/CSM STBDAC µP CONTROL DIVIDER ACKS/C CLK AOUTL SBT3 MIX L INTERFACE DIF0/CDTI STO3 LRCK ∆Σ...
  • Page 41: Interconnection Schematic Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 14 INTERCONNECTION SCHEMATIC DIAGRAM & SCHEMATIC DIAGRAM NOTES 14.1. INTERCONNECTION SCHEMATIC DIAGRAM OPTICAL PICK UP UNIT FP8501 FP8102 FP3501 DGND DGND D+5V D+5V DGND DGND A+5V A+5V AGND AGND TA(DVD) D+1.2V D+1.2V TB(DVD) DGND DGND...
  • Page 42: Schematic Diagram Notes

    DVD-S29EG / DVD-S29E / DVD-S29EB 14.2. SCHEMATIC DIAGRAM NOTES This schematic diagram may be modified at any time with the development of new technology. Important safety notice: Components identified by mark have special characteristics important for safety. Furthermore, special parts which have purpose of fire-retardant (resistors), high-quality sound (capacitors), low-noise (resistors), etc.
  • Page 43: Schematic Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 15 SCHEMATIC DIAGRAM 15.1. POWER SUPPLY SECTION (MOTHER P.C.B. (1/2)) SCHEMATIC DIAGRAM Q1125 TP1101 2SB14170JA D1121 B0JAMG000013 K1121 (REG.D+1.2V) C1003 D+1.2V ECKMNA471MBV C1121 C1122 C1127 Q1126 6V1000 6V2200 6V1000 C1126 XN0150100L 1000P (REG.D+1.2V) D1011 TL1001...
  • Page 44 DVD-S29EG / DVD-S29E / DVD-S29EB 15.2. FRONT & AV OUT SECTION (MOTHER P.C.B. (2/2)) SCHEMATIC DIAGRAM A+5V D+5V M+9V D+1.2V ADGND AGND MGND :PO(POWER SUPPLY SECTION) DP6081 K3511 K3513 A2BA00000217 :F/AV(FRONT & AV OUT SECTION) K3512 K3514 FLH+ CL6022 Q6085...
  • Page 45 (SWITCHING) S2602 LOADING MOTOR P.C.B. C4751 (AMP) R3825 R4753 K0L1BA000078 25V47 4700 R4755 C4752 QR3821 25V47 B1GBCFLL0035 DVD-S29EG/E/EB (INV.) R4754 R4756 FRONT & AV OUT SECTION (MOTHER P.C.B.(2/2)) SCHEMATIC DIAGRAM DVD-S29EG/E/EB FRONT & AV OUT SECTION (MOTHER P.C.B.(2/2)) SCHEMATIC DIAGRAM...
  • Page 46: Module Schematic Diagram

    DVD-S29EG / DVD-S29E / DVD-S29EB 15.3. MODULE SCHEMATIC DIAGRAM TO FP3501 MOTHER P.C.B. (F/AV SECTION) FP8102 DGND K8103 0 D+5V DGND A+5V AGND K8101 0 D+1.2V DGND CL8235 M+9V R8235 MGND 8200 LB8003 ERJ2GE0R00X TRAY DRV RX8111 LB8004 ERJ2GE0R00X 22KX2...
  • Page 47 DVD-S29EG / DVD-S29E / DVD-S29EB LB8001 J0JHC0000097 LB8002 J0JHC0000097 C8002 C8001 C8028 C8027 C8026 C8025 C8024 C8023 C8022 C8021 C8020 C8019 C8018 4V330 6V100 2200P C8004 RX8014 82X4 MDQ 7 MDQ 8 MDQ 6 MDQ 9 C8016 C8017 C8003 2200P RX8031 4.7KX2...
  • Page 48 DVD-S29EG / DVD-S29E / DVD-S29EB VIDEO MAIN SIGNAL AUDIO MAIN SIGNAL RF SIGNAL C8601 C8611 R8601 RX8611 4.7KX2 (FOR DEBUG) FP8041 TRCCLK TRCCLK TRCDATA0 TRCD(0) TRCDATA1 TRCD(1) TRCDATA2 TRCD(2) TRCDATA3 TRCD(3) TRCST IC8601 TRCST IC8611 2 4 6 8 2 4 6 8...
  • Page 49: Print Circuit Board

    DVD-S29EG / DVD-S29E / DVD-S29EB 16 PRINT CIRCUIT BOARD 16.1. MOTHER P.C.B. MOTHER P.C.B. LOADING MOTOR P.C.B. POWER SW P.C.B. DVD-S29EG/E/EB MOTHER P.C.B.(VEP76107A) POWER SW P.C.B.(VEP76108A) LOADING MOTOR P.C.B.(VEP70114A)
  • Page 50 DVD-S29EG / DVD-S29E / DVD-S29EB 16.2. MOTHER P.C.B. & MODULE P.C.B. ADDRESS INFORMATION MOTHER P.C.B. MODULE P.C.B. Transistors Test Point TL1006 Transistor CL8027 CL8611 Q1045 CL3501 TL1007 Q8550 CL8028 CL8612 Q1051 CL3502 TL4301 Q8551 CL8029 TL8111 Q1081 CL3503 TL4303 Q8552...
  • Page 51: Module P.c.b. (1/2) (Component Side)

    DVD-S29EG / DVD-S29E / DVD-S29EB 16.3. MODULE P.C.B. (1/2) (COMPONENT SIDE) *IC8611 is not supplied in the form of an individual part. When replacing, be sure to replace the module p.c.b. MODULE P.C.B. (1/2) and not IC8611 singly. (COMPONENT SIDE) DVD-S29EG/E/EB MODULE P.C.B.
  • Page 52: Module P.c.b. (2/2) (Foil Side)

    DVD-S29EG / DVD-S29E / DVD-S29EB 16.4. MODULE P.C.B. (2/2) (FOIL SIDE) MODULE P.C.B. (2/2) (FOIL SIDE) DVD-S29EG/E/EB MODULE P.C.B. (2/2) (VEP73122A)
  • Page 53: Exploded Views

    DVD-S29EG / DVD-S29E / DVD-S29EB 17 EXPLODED VIEWS 17.1. CASING PARTS & MECHANISM SECTION EXPLODED VIEW...
  • Page 54: Mechanism Section Exploded View

    DVD-S29EG / DVD-S29E / DVD-S29EB 17.2. MECHANISM SECTION EXPLODED VIEW...
  • Page 55 DVD-S29EG / DVD-S29E / DVD-S29EB 17.3. PACKING & ACCESSORIES SECTION EXPLODED VIEW...
  • Page 56: Replacement Parts List

    DVD-S29EG / DVD-S29E / DVD-S29EB 18 REPLACEMENT PARTS LIST Notes: Ref. Part No. Part Name & Remarks Description *Important safety notice: RMX0247 WASHER Components identified mark have special RWJ6702042 MOTOR CABLE RXQ0946 TRAVERSE MOTOR characteristics important for safety. ASS’Y Furthermore, special parts which have purposes of fire-...
  • Page 57 DVD-S29EG / DVD-S29E / DVD-S29EB Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C1081 ECQB1H102JF 50V 1000P C6005 F2A1H100A236 50V 10U C1082 ECQB1H104JF4 50V 0.1U C6006 ECJ1VB1H103K 50V 0.01U C1083 VCEA1HJC470 50V 47U...
  • Page 58 DVD-S29EG / DVD-S29E / DVD-S29EB Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description C8308 ECJ0EC1H150J 50V 15P C8311 ECJ0EF1C104Z 16V 0.1U IC1021 C0DACZH00007 C8312 ECJ1VB0J105K 6.3V 1U IC1101 C0DAEMB00003 C8421 F2G0J101A083 6.3V 100U...
  • Page 59 DVD-S29EG / DVD-S29E / DVD-S29EB Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description LB8502 J0JHC0000097 COIL R1084 ERDS2FJ223 1/4W 22K LB8503 ERJ2GE0R00X 1/16W 0 R1085 ERDS2FJ104 1/4W 100K LB8504, J0JCC0000371 COIL R1101...
  • Page 60 DVD-S29EG / DVD-S29E / DVD-S29EB Ref. Part No. Part Name & Remarks Ref. Part No. Part Name & Remarks Description Description R6009 ERJ3GEYJ103V 1/10W 10K D0GB103JA002 R8562,6 ERJ2GEJ102X 1/16W 1K ERJ2RMJ102X R6011 ERJ3GEYJ102V 1/10W 1K R8564 ERJ2GEJ220 1/16W 22 R6021...
