FILE NO. SERVICE MANUAL Multimedia Projector Model No. PLC-SU32 PLC-SU33 U.S.A., Canada, Europe, Asia, Africa Original Version PLC-SU33 PLC-SU32 Chassis No. ML8-SU3200 MJ8-SU3300 NOTE: Match the Chassis No. on the unit’s back cover with the Chassis No. in the Service Manual.
I Contents I Safety instructions ________________________________________________3 I Specifications __________________________________________________ 4 I Adjustments after parts replacement ________________________________ 5 I Circuit protections ______________________________________________ 6-7 G Fuse ____________________________________________________ 6 G Thermal switch ____________________________________________ 6 G Interlock switch ____________________________________________ 6 G Warning temperature and power failure protection ________________ 7 I Mechanical disassemblies ______________________________________ 8-13 I Optical parts disassemblies ____________________________________ 14-17 I LCD panel/prism ass’y replacement ________________________________ 19...
I Safety Instructions SAFETY PRECAUTIONS WARNING: The chassis of this projector is isolated (COLD) from AC line by using the converter transformer. Primary side of the converter and lamp power supply unit circuit is connected to the AC line and it is hot, which hot circuit is iden- tified with the line ( ) in the schematic diagram.
Horizontal Resolution 800 TV lines Projection Lens F 1.7 ~ 2.0 lens with f 37.4mm ~ 48.3mm with motor zoom and focus (PLC-SU32) F 1.9 ~ 2.1 lens with f 21.3mm ~ 25.6mm with motor zoom and focus (PLC-SU33) Throw Distance 5.3’...
I Circuit Protections This projector is equipped with the following circuit protections to operate in safety. If the abnormality occurs inside the projector, it will automatically turn off by operating one of the following protection circuits. G Fuse Line Filter Board The fuse is located inside of the projector.
Circuit Protections G Warning temperature and power failure protection The TEMP WARNING indicator flashes red and the projector will automatically turn off when the internal tempera- ture of the projector exceeds the normal temperature or when stopping cooling fans or when the internal power supply lines are failed.
I Mechanical Disassemblies Mechanical disassemble should be made following procedures in numerical order. Following steps show the basic procedures, therefore unnecessary step may be ignored. Caution: The parts and screws should be placed exactly the same position as the original otherwise it may cause loss of performance and product safety.
Page 9
Mechanical Disassemblies AV, DVI, Temp Board and Speaker removal Remove 1 screw to release a grounding wire. Pull the Rear Panel ass’y upward. Remove 4 screws and remove the AV Board. Remove 4 screws and remove the DVI Board. Remove 4 screws and remove the speaker.
Page 10
Mechanical Disassemblies Lamp Ballast Unit removal Remove 1 screw and disconnect the Lamp Socket. Remove 2 screws to take the Lamp Ballast ass’y upward off. Remove 2 screws to take the isolation sheet off. Remove 4 screws to take the lamp ballast board off. Isolation sheet Lamp ballast board Fig.5...
Page 11
Mechanical Disassemblies Power Box Cover and Fans(FN901, FN906) removal Remove 4 screws to take the Fan(FN901) off. Remove 4 screws to take the Fan(FN905) off. Remove 3 screws to take the Power Box Cover upward off. FN906 Power box cover FN901 Fig.7 Optical Unit removal...
Page 12
Mechanical Disassemblies Optical Unit removal Step from previous procedure. Remove 6 screws to take the Optical Unit upward upward off. To mount optical unit, mount optical unit first then mount the Lamp assembly and Lamp Cover. Optical unit Fig.8 Power and P.F. Board removal Remove 8 screws to take the Power Board ass’y upward off.
Page 13
Mechanical Disassemblies Fan (FN905) removal Remove 1 screw and take a Washer, Spring and Interlock Switch lever. Interlock switch lever Pull the Fan and duct ass’y upward, then remove the 2 screws to take the Fan (FN906) off. FN905 Fig.10 Fans (FN902, FN903, FN904) removal Remove 8 screws and to take the Fan Duct...
I Optical Parts Disassemblies Before taking this procedure, remove Cabinet Top and Main Board following to the “Mechanical Disassemblies”. Disassembly requires a 2.0mm hex wrench and a screwdriver. Projection Lens removal Remove the Front Panel following to “Front Panel Removal” on “Mechanical Disassemblies”.
Page 15
Optical Pats Disassemblies Condenser lens disassembly Remove 2 screws and pull the Condenser Lens ass’y upward. Remove 4 screws to take the Lens off from the holder. Condenser Lens Holder * Lens should be placed as the flat Fig.3- surface side comes to the holder side.
Page 16
Optical Parts Disassemblies Relay Lens-Out disassembly Remove 2 screws and pull the Relay Lens-Out ass’y upward. Remove 2 screws to take the Lens off from the holder. Note: There is no mounting direction of the lens. Holder Relay Lens-Out Fig.5- Fig.5- Polarized Glass-In removal Remove each screw and pull the Polarized Glass-In ass’y upward.
Page 17
Optical Parts Disassemblies Polarized Glass-Out/Pre-Polarized Glass removal Remove 4 screws and take the LCD/Prism ass’y off upward from the optical unit. Remove each screw and take the glass off upward. LCD Panel/ Prism Ass’y Note: LCD Panel/Prism Do not replace the LCD panel Ass’y separately otherwise it can not obtain proper picture.
Page 18
Optical Parts Disassemblies Locations and Directions Key No. Description When mounting or assembling the optical parts in the optical unit, the Mirror (W) parts must be mounted in the specified location and direction as Integrator lens (OUT) shown in figure below. Prism beam splitter (PBS) Dichroic mirror (B) Condenser lens (OUT)
I LCD Panel/Prism Ass’y Replacement IMPORTANT NOTICE on LCD Panel/Prism Ass'y Replacement LCD panels used for this model can not be replaced separately. Do not disassemble the LCD Panel/Prism Ass’y. These LCD panels are installed with precision at the factory. When replacing the LCD panel, should be replaced whole of the LCD panels and prism ass’y at once.
I Lamp Replacement WARNING: ORDER REPLACEMENT LAMP - For continued safety, replace with a lamp assembly of the same type. Type No. Service Parts No. - Allow the projector to cool for at least 45 minutes before you open the POA-LMP35 610 293 2751 lamp cover.
I Optical Adjustments Before taking optical adjustments below, remove the Cabinet Top and Main Board following to the “Mechanical Disassemblies” Adjustments require a 2.0mm hex wrench and a slot screwdriver. When you adjust Condenser lens, Condenser lens-out or Relay lens adjustment, you need to disconnect some connectors and FPC cables of LCD panels on the main board.
Optical Adjustments Condenser Lens adjustment Turn the projector on by a state of without FPC cables. Project only green light on the screen. Adjust the adjustment base of condenser lens assy to make color uniformity in green. Green 1) If the shading appears on the left or right of the screen as shown in Fig.2-1, loosen 2 screws with the 2.0mm hex driv- er, and adjust the slot...
Optical Adjustments Condenser Lens-Out adjustment Turn the projector on by a state of without FPC cables. Project green and blue lights on the screen. Adjust the adjustment base of condenser lens-out assy to make color uniformity in cyan. 1) If the shading appears on the left or right of the screen as shown Cyan in Fig.3-1, loosen 1 screw with the 2.0mm hex driver, and...
Optical Adjustments Relay lens-Out adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of relay lens assy to make color unifor- mity in white. 1) If the shading appears on the left or right of the screen as shown White in Fig.4-1, loosen 1 screw with the 2.0mm hex driver, and...
I Electrical Adjustments G Service Adjustment Menu Operation To enter the service mode To enter the “Service Mode”, press and hold the MENU and IMAGE button on the projector at the same time for more than 3 seconds. The service menu appears on the screen as follows. To adjust service data Select the adjustment group no.
Electrical Adjustments G Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the follow- ing adjustments except requiring the readjustments in servicing otherwise it may cause loss of per- formance and product safety.
Page 27
Electrical Adjustments Pedestal adjustment Signal Center adjustment 1. Receive the 16-step grey scale video signal. 1. Receive the 16-step grey scale computer signal. 2. Set to VIDEO mode. 2. Set to COMPUTER mode. 3. Enter the service mode. 3. Enter the service mode. [R-PEDESTAL ADJUSTMENT] [R-SIGNAL CENTER ADJUSTMENT] TP201R...
Page 28
Electrical Adjustments PC Offset adjustment PC Gain adjustment 1. Receive the 16-step gray scale computer signal. 1. Receive the 16-step gray scale computer signal. 2. Set to COMPUTER mode. 2. Set to COMPUTER mode. 3. Enter the service mode. 3. Enter the service mode. [R-OFFSET ADJUSTMENT] [R-GAIN ADJUSTMENT] TP25R1...
Page 29
Electrical Adjustments AV Gain adjustment Gamma Shift adjustment 1. Receive the 16-step gray scale video signal. [PC-GAMMA OFF ADJUSTMENT] 2. Set to VIDEO mode. 1. Receive the 16-step gray scale computer signal. 3. Enter the service mode. 2. Set to COMPUTER mode. 3.
Electrical Adjustments G Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjust- ment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
Page 31
Electrical Adjustments Adjustment Item Initial Value Range Description Group: 2 L3E07050 (Digital Gamma, Color Shading & Timing Controller) DVI,AV R_SUB_BRT 0 ~ 1023 G_SUB_BRT 0 ~ 1023 B_SUB_BRT 0 ~ 1023 ✻ R_SUB_GAIN 0 ~ 1023 Red PC/AV gain adjustment ✻...
I Troubleshooting No Power The possible causes of No Power are listed below. Please - Abnormality on lamp ballast drive signal (BALLAST_AC). check following and refer to power supply and protection cir- BALLAST_AC signal is output from pin 39 of IC801 and cuits diagram in the figure opposite.
Page 36
Troubleshooting Power supply drive and protection diagrams and locations SW902 IC2881 IC4881 F601 SW904 LAMP Ass'y LAMP BALLAST UNIT P.F BOARD F601 SW902 SW904 IC4881 Fuse AC IN Thermal sw. Interlock sw. TEMP. SENS. K48E TSW611 IC611 P.F.CONTROL TEMP. SENSOR BOARD FN905 FN906...
Troubleshooting No Picture The possible causes of No Picture are listed below. Please 3. No picture from DVI source. check following and refer to video signal processing dia- Check power supply voltages on the DVI board. grams in the figure opposite. 5VDVI on pins 39-40, 5VS on pins 35-36, 3.3VS on pins 31-32, 9VMCI on pins 35-8, 5VD on pins 21-22 of K10W 1.
Page 38
Troubleshooting Video Signal processing diagrams -38-...
Troubleshooting No Sound 1. No audio signals at AV input circuit. Check MUTE signal at pin 1 of IC001. Mute On : Low Check audio signals at pins14 and 15 of IC5011 on the AV Check MUTE signal at pin 7 of IC1831, pins 7 and 13 of Board.
I Control Port Functions G System Control & I/O Port Table (IC801) Pin No. Name Function Name Function Action PE5/D5 POWER_SW Power_SW H: On PE6/D6 SYS SW Peripheral IC power supply SW L: on PE7/D7 LAMP_SW Lamp LED H: On PD0/D8 DATA0 Data Bus 0...
Page 41
Control Port Functions Pin No. Name Function Name Function Action Operation mode control 2 Fixed H PF7/¢ ¢ ¢ output PF6/AS AS output PF5/RD Read signal Control for SRAM PF4/HWR Write signal (upper 8 bit) Control for SRAM PF3/LWR/ADTRG/IRQ3 IRO_CS Color uniformity correction (E7050) Chip Select L: active PF2/WAIT...
Control Port Functions G IIC Bus I/O Expander (IC1851) Port Functions Pin No. Name Function Action Reset Open IIC SCL Active “L ” IIC SDA Active “L ” CARD_IN L: CARD H: No CARD VIEWER_ON L: VIEWER Unit exist SCDT1 DVI Sync.
Page 43
Control Port Functions G IIC Bus DA Converter (IC2161) Port Functions Pin No. Name Function Action Reset Fixed “H” IIC SCL Active “L ” IIC SDA Active “L ” RCLP R Signal clamp reference voltage GCLP G Signal clamp reference voltage BCLP B Signal clamp reference voltage AO10...
I Cleaning After long periods of use, dust and other particles will accumulate on the LCD panel, prism, mirror, polarized glass, lens, etc., causing the picture to darken or color to blur. If this occurs, clean the inside of optical unit. Remove dust and other particles using air spray.
I LCD Panel/Prism Ass’y Replacement IMPORTANT NOTICE on LCD Panel/Prism Ass'y Replacement LCD panels used for this model can not be replaced separately. Do not disassemble the LCD Panel/Prism Ass’y. These LCD panels are installed with precision at the factory. When replacing the LCD panel, should be replaced whole of the LCD panels and prism ass’y at once.
Page 55
I Lamp Replacement WARNING: ORDER REPLACEMENT LAMP - For continued safety, replace with a lamp assembly of the same type. Type No. Service Parts No. - Allow the projector to cool for at least 45 minutes before you open the POA-LMP35 610 293 2751 lamp cover.
Page 56
I Optical Adjustments Before taking optical adjustments below, remove the Cabinet Top and Main Board following to the “Mechanical Disassemblies” Adjustments require a 2.0mm hex wrench and a slot screwdriver. When you adjust Condenser lens, Condenser lens-out or Relay lens adjustment, you need to disconnect some connectors and FPC cables of LCD panels on the main board.
Page 57
Optical Adjustments Condenser Lens adjustment Turn the projector on by a state of without FPC cables. Project only green light on the screen. Adjust the adjustment base of condenser lens assy to make color uniformity in green. Green 1) If the shading appears on the left or right of the screen as shown in Fig.2-1, loosen 2 screws with the 2.0mm hex driv- er, and adjust the slot...
Page 58
Optical Adjustments Condenser Lens-Out adjustment Turn the projector on by a state of without FPC cables. Project green and blue lights on the screen. Adjust the adjustment base of condenser lens-out assy to make color uniformity in cyan. 1) If the shading appears on the left or right of the screen as shown Cyan in Fig.3-1, loosen 1 screw with the 2.0mm hex driver, and...
Page 59
Optical Adjustments Relay lens-Out adjustment Turn the projector on by a state of without FPC cables. Project all of lights on the screen. Adjust the adjustment base of relay lens assy to make color unifor- mity in white. 1) If the shading appears on the left or right of the screen as shown White in Fig.4-1, loosen 1 screw with the 2.0mm hex driver, and...
I Electrical Adjustments G Service Adjustment Menu Operation To enter the service mode To enter the “Service Mode”, press and hold the MENU and IMAGE button on the projector at the same time for more than 3 seconds. The service menu appears on the screen as follows. To adjust service data Select the adjustment group no.
Page 61
Electrical Adjustments G Circuit Adjustments CAUTION: The each circuit has been made by the fine adjustment at factory. Do not attempt to adjust the follow- ing adjustments except requiring the readjustments in servicing otherwise it may cause loss of per- formance and product safety.
Page 62
Electrical Adjustments Pedestal adjustment Signal Center adjustment 1. Receive the 16-step grey scale video signal. 1. Receive the 16-step grey scale computer signal. 2. Set to VIDEO mode. 2. Set to COMPUTER mode. 3. Enter the service mode. 3. Enter the service mode. [R-PEDESTAL ADJUSTMENT] [R-SIGNAL CENTER ADJUSTMENT] TP201R...
Page 63
Electrical Adjustments PC Offset adjustment PC Gain adjustment 1. Receive the 16-step gray scale computer signal. 1. Receive the 16-step gray scale computer signal. 2. Set to COMPUTER mode. 2. Set to COMPUTER mode. 3. Enter the service mode. 3. Enter the service mode. [R-OFFSET ADJUSTMENT] [R-GAIN ADJUSTMENT] TP25R1...
Page 64
Electrical Adjustments AV Gain adjustment Gamma Shift adjustment 1. Receive the 16-step gray scale video signal. [PC-GAMMA OFF ADJUSTMENT] 2. Set to VIDEO mode. 1. Receive the 16-step gray scale computer signal. 3. Enter the service mode. 2. Set to COMPUTER mode. 3.
Page 65
Electrical Adjustments G Service Adjustment Data Table These initial values are the reference data written from the CPU ROM to memory IC when replaced new memory IC. The adjust- ment items indicated with “✻” are required to readjust following to the “Electrical adjustments”. Other items should be used with the initial data value.
Page 66
Electrical Adjustments Adjustment Item Initial Value Range Description Group: 2 L3E07050 (Digital Gamma, Color Shading & Timing Controller) DVI,AV R_SUB_BRT 0 ~ 1023 G_SUB_BRT 0 ~ 1023 B_SUB_BRT 0 ~ 1023 ✻ R_SUB_GAIN 0 ~ 1023 Red PC/AV gain adjustment ✻...
Page 70
I Troubleshooting No Power The possible causes of No Power are listed below. Please - Abnormality on lamp ballast drive signal (BALLAST_AC). check following and refer to power supply and protection cir- BALLAST_AC signal is output from pin 39 of IC801 and cuits diagram in the figure opposite.
Page 71
Troubleshooting Power supply drive and protection diagrams and locations SW902 IC2881 IC4881 F601 SW904 LAMP Ass'y LAMP BALLAST UNIT P.F BOARD F601 SW902 SW904 IC4881 Fuse AC IN Thermal sw. Interlock sw. TEMP. SENS. K48E TSW611 IC611 P.F.CONTROL TEMP. SENSOR BOARD FN905 FN906...
Page 72
Troubleshooting No Picture The possible causes of No Picture are listed below. Please 3. No picture from DVI source. check following and refer to video signal processing dia- Check power supply voltages on the DVI board. grams in the figure opposite. 5VDVI on pins 39-40, 5VS on pins 35-36, 3.3VS on pins 31-32, 9VMCI on pins 35-8, 5VD on pins 21-22 of K10W 1.
Page 73
Troubleshooting Video Signal processing diagrams -38-...
Page 74
Troubleshooting No Sound 1. No audio signals at AV input circuit. Check MUTE signal at pin 1 of IC001. Mute On : Low Check audio signals at pins14 and 15 of IC5011 on the AV Check MUTE signal at pin 7 of IC1831, pins 7 and 13 of Board.
Page 75
I Control Port Functions G System Control & I/O Port Table (IC801) Pin No. Name Function Name Function Action PE5/D5 POWER_SW Power_SW H: On PE6/D6 SYS SW Peripheral IC power supply SW L: on PE7/D7 LAMP_SW Lamp LED H: On PD0/D8 DATA0 Data Bus 0...
Page 76
Control Port Functions Pin No. Name Function Name Function Action Operation mode control 2 Fixed H PF7/¢ ¢ ¢ output PF6/AS AS output PF5/RD Read signal Control for SRAM PF4/HWR Write signal (upper 8 bit) Control for SRAM PF3/LWR/ADTRG/IRQ3 IRO_CS Color uniformity correction (E7050) Chip Select L: active PF2/WAIT...
Page 77
Control Port Functions G IIC Bus I/O Expander (IC1851) Port Functions Pin No. Name Function Action Reset Open IIC SCL Active “L ” IIC SDA Active “L ” CARD_IN L: CARD H: No CARD VIEWER_ON L: VIEWER Unit exist SCDT1 DVI Sync.
Page 78
Control Port Functions G IIC Bus DA Converter (IC2161) Port Functions Pin No. Name Function Action Reset Fixed “H” IIC SCL Active “L ” IIC SDA Active “L ” RCLP R Signal clamp reference voltage GCLP G Signal clamp reference voltage BCLP B Signal clamp reference voltage AO10...
Page 80
Waveforms H-SYNC OUT <IC4101-29> V-SYNC OUT <IC4101-28> H-SYNC IN <TP205> H-SYNC DRIVE <TP62H> V-SYNC DRIVE <TP62V> DHS <TPDHS> DVS <TPDVS> NRS <TP3551/TP3581> R-S&H OUT <TP25R1/TP25R2> G-S&H OUT <TP25G1/TP25G2> B-S&H OUT <TP25B1/TP25B2> BALLAST SW <TP28L> -45-...
Page 81
I Cleaning After long periods of use, dust and other particles will accumulate on the LCD panel, prism, mirror, polarized glass, lens, etc., causing the picture to darken or color to blur. If this occurs, clean the inside of optical unit. Remove dust and other particles using air spray.
Page 82
I IC Block Diagrams G AD8183ARU, AD8185ARU <Selector, IC5241, IC5211> G BA6287F <Motor Drive IC5501, IC5551> -47-...
Page 83
IC Block Diagrams G BA7078AF <Selector, IC6241> G CXA2101AQ <RGB Matrix, IC4101> -48-...
Page 84
IC Block Diagrams G CXD2064Q <Digital Comb Filter, IC2101> G L3E01031 <Level Shift, IC3531, IC3561> -49-...
Page 85
IC Block Diagrams G L3E06070 <D/A-Sample & Hold, > IC501, IC531, IC561 G L3E07050 <Color, Gamma Correction & Timing Controller , IC401> -50-...
Page 86
IC Block Diagrams G ML60851 <USB I/F, IC9801> G M62393 <D/A, IC2571> -51-...
Page 87
IC Block Diagrams G TB1274AF <Video Decoder, IC1101> G TA1318N <AFC Detector, IC6171> -52-...
Page 88
IC Block Diagrams G FA7612CA <PWC Controller, IC65A, IC671, IC681> G STR-Z2156 <Switching Controller, IC631> -53-...
Page 89
I Electrical Parts List ML8-SU3200, MJ8-SU3300 Product safety should be considered when a component replacement is made in any area of a projector. Components indicated by a mark in this parts list and the circuit diagram show components whose value have special significance to product safety.
ML8-SU3200, MJ8-SU3300 Electrical Parts List Note: Parts order must contain Chassis No., Part No., and Descriptions. G OUT OF CIRCUIT BOARD Thermal Switch Interlock switch (SW902) (SW904) Lamp Ballast Board F601 Fuse FN906 Line Filter Cooling Fan Board DVI Board FN901 Cooling Fan P.F.
Page 91
ASSEMBLIED BOARDS R6811 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R6812 401 105 7909 MT-GLAZE 0.000 ZA 1/16W For model PLC-SU32 R6816 401 105 1600 MT-GLAZE 15K JA 1/16W 610 292 5609 ASSY,PWB,KEY SW MS6A 1AA0B10C34000 R6817 401 105 6605 MT-GLAZE 6.8K JA 1/16W...
Page 92
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 015 8902 TR 2SC2812-L7-TB IC5011 409 051 2900 IC TC4053BF(EL) 405 163 1602 TR 2SC2812N-L6-TB0 IC5161 409 404 7200 IC TC7SET00FU-(TE85L) 405 163 1701 TR 2SC2812N-L7-TB0 CAPACITOR Q5061...
Page 93
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R1024 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R5034 401 105 1501 MT-GLAZE 1.5K JA 1/16W R1026 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R5041 401 105 7909 MT-GLAZE 0.000 ZA 1/16W...
Page 94
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description L2023 645 044 8836 FILTER,EMI 100MHZ DVI BOARD L2024 645 044 8836 FILTER,EMI 100MHZ L2025 645 045 6183 FILTER,EMI 25MHZ 610 299 7347 ASSY,PWB,DVI MK8A L2041 645 045 6183 FILTER,EMI 25MHZ...
Page 95
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R3071 401 105 0405 MT-GLAZE 100 JA 1/16W 405 014 4608 TR 2SC2412K T146 S R3073 401 105 7909 MT-GLAZE 0.000 ZA 1/16W 405 015 8704 TR 2SC2812-L6-TB R3074 401 105 0405...
Page 96
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 163 1701 TR 2SC2812N-L7-TB0 405 015 8704 TR 2SC2812-L6-TB Q2516 405 014 4509 TR 2SC2412K T146 R 405 015 8902 TR 2SC2812-L7-TB 405 014 4608 TR 2SC2412K T146 S 405 163 1602 TR 2SC2812N-L6-TB0...
Page 97
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description IC1871 410 325 4605 IC TC74LCX244FT IC8061 410 321 8300 IC TC74VCX16244FT IC1881 410 315 5506 IC HD74HCT244TV IC8071 410 321 8300 IC TC74VCX16244FT 410 356 7507 IC SN74HCT244PWR IC8081 410 407 4004...
Page 98
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C1409 403 164 0204 CERAMIC 0.1U Z C231 403 164 0204 CERAMIC 0.1U Z C1411 403 164 0204 CERAMIC 0.1U Z C232 403 164 0204 CERAMIC 0.1U Z C1412...
Page 99
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C3161 403 164 0204 CERAMIC 0.1U Z C4139 403 164 0204 CERAMIC 0.1U Z C317 403 164 0204 CERAMIC 0.1U Z C414 403 164 0204 CERAMIC 0.1U Z C318...
Page 100
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C5241 403 164 0204 CERAMIC 0.1U Z 403 335 0408 ELECT 100U M C5242 403 164 0204 CERAMIC 0.1U Z C6171 403 229 3508 ELECT 100U M C5243 403 164 0204...
Page 101
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description C6652 403 164 0204 CERAMIC 0.1U Z C9804 403 164 0204 CERAMIC 0.1U Z C6653 403 322 7809 ELECT 220U M 6.3V C9806 403 164 0204 CERAMIC 0.1U Z 403 349 4706...
Page 102
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 645 033 2210 R-NETWORK 22X4 1/16W R1141 401 105 5905 MT-GLAZE 560 JA 1/16W RB501 645 037 3107 R-NETWORK 10X4 0.063W R1142 401 105 1501 MT-GLAZE 1.5K JA 1/16W 645 028 5998...
Page 103
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R1586 401 105 0603 MT-GLAZE 10K JA 1/16W R2117 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R1587 401 105 0405 MT-GLAZE 100 JA 1/16W R2118 401 105 7909 MT-GLAZE 0.000 ZA 1/16W...
Page 104
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R2560 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R3127 401 105 1402 MT-GLAZE 150 JA 1/16W R2561 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R313 401 105 7909 MT-GLAZE 0.000 ZA 1/16W...
Page 105
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R356 401 105 0603 MT-GLAZE 10K JA 1/16W R4114 401 105 0603 MT-GLAZE 10K JA 1/16W R3561 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R4116 401 105 6001 MT-GLAZE 5.6K JA 1/16W...
Page 106
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R471 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R5298 401 105 5103 MT-GLAZE 47 JA 1/16W R472 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R534 401 105 7909 MT-GLAZE 0.000 ZA 1/16W...
Page 107
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description R6274 401 105 5103 MT-GLAZE 47 JA 1/16W R834 401 105 0603 MT-GLAZE 10K JA 1/16W R6281 401 105 7909 MT-GLAZE 0.000 ZA 1/16W R836 401 105 0603 MT-GLAZE 10K JA 1/16W...
Page 109
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description 405 014 4608 TR 2SC2412K T146 S 405 163 1602 TR 2SC2812N-L6-TB0 405 015 8704 TR 2SC2812-L6-TB 405 163 1701 TR 2SC2812N-L7-TB0 405 015 8902 TR 2SC2812-L7-TB Q683 405 134 5905...
Page 110
4.7K JA 1/16W R664 401 105 0603 MT-GLAZE 10K JA 1/16W DIODE R67A 401 217 3806 MT-GLAZE 27K FA 1/16W PLC-SU32 R67B 401 105 7909 MT-GLAZE 0.000 ZA 1/16W D5501 407 206 6308 ZD UDZS-TE-175.1B R67C 401 105 7909 MT-GLAZE 0.000 ZA 1/16W...
Page 111
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description D5551 407 222 5903 ZD UDZS3.6B-TE-17 INTEGRATED CIRCUIT 407 179 6305 ZENER DIODE UDZ-TE-173.6B IC611 409 483 3803 IC FA5332M ---------------------------------------------------- CAPACITOR PLC-SU33 C611 403 222 1303 CERAMIC 1000P K D5501...
Page 112
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description MISCELLANEOUS (Model PLC-SU32) FB611 610 229 3531 CORE REMOTE CONTROL FB612 610 229 3531 CORE AA9901 645 052 0433 ASSY,REMOCON CXLA FB613 610 229 3531...
Page 113
ML8-SU3200, MJ8-SU3300 Electrical Parts List Key No. Part No. Description Key No. Part No. Description -78-...
Page 114
I Mechanical Parts List ML8-SU3200, MJ8-SU3300 Note: Parts order must contain Chassis No., Part No., and Descriptions. G CABINET PARTS -79-...
Page 116
I Optical Parts List ML8-SU3200, MJ8-SU3300 -81-...
Page 117
ML8-SU3200, MJ8-SU3300 Optical Parts List 67 (Red) 68 (Green) 69 (Blue) -82-...
Page 118
ML8-SU3200, MJ8-SU3300 Optical Parts List 53-a (Red) 53-b (Green) 53-c (Blue) -83-...
Page 119
ML8-SU3200, MJ8-SU3300 Optical Parts List Model PLC-SU32 52-a Model PLC-SU33 52-a -84-...
Page 120
ML8-SU3200, MJ8-SU3300 Optical Parts List -85-...
Page 121
SANYO Electric Co., Ltd. (ML8A) Aug. 2002 BB 400 Printed in Japan...
Page 122
ML8-SU3200, MJ8-SU3300 Schematic Diagrams Printed Wiring Board Drawings Model Chassis No. PLC-SU32 ML8-SU3200 PLC-SU33 MJ8-SU3300 This model provides the following boards, and the information of part numbers and values indicated on these diagrams are at the beginning of production. To improve the performance, there may be some differences to the actual set.
I Parts description and reading in schematic diagram ML8-SU3200, MJ8-SU3300 1. The parts specification of resistors, capacitors and Resistor Reading coils are expressed in designated code. Please check Example 1/2 D J 10K B the parts description by the following code table. 2.
Page 124
I Pin description of diode, transistor and IC ML8-SU3200, MJ8-SU3300 G Diode G Diode K: Cathode A: Anode G Transistor/FET G Transistor/FET C: Collector D: Drain B: Base G: Gate Index E: Emitter S: Source C1 C2 C1 C2 G IC G IC (GND) RESET...
Printed Wiring Board Diagrams PLC-SU32/SU33 Page P12 [Left] ■ Printed Wiring Board Diagrams CAUTION This projector is isolated from AC line by using the internal converter transformer. Please pay attention to the following notes in servicing 1. Do not touch the part on hot side (primary circuit) or both parts on hot and cold sides (secondary circuit) at the same time.
