Page 1 SERVICE HANDBOOK MULTIFUNCTIONAL DIGITAL SYSTEMS e-STUDIO181/211 Model: DP-1810/2110 Publish Date: December 2009 File No. SHE09000300 R091021I2600-TTEC Ver00_2009-12...
Page 2 © 2009 TOSHIBA TEC CORPORATION All rights reserved Under the copyright laws, this manual cannot be reproduced in any form without prior written permission of TOSHIBA TEC CORPORATION. No patent liability is assumed, however, with respect to the use of the information contained herein.
Page 3: E-Studio181/211
GENERAL PRECAUTIONS REGARDING THE SERVICE FOR e-STUDIO181/211 The installation and service should be done by a qualified service technician. 1) Transportation/Installation When transporting/installing the equipment, remove the drawer, employ two persons and be sure to hold the positions as shown in the figure.The equipment is quite heavy and weighs approxi- mately 34 kg (74.96 lb), therefore pay full attention when handling it.
Page 4 Be sure to handle/install them properly. If these parts are short-circuited and their functions become ineffective, they may result in fatal accidents such as burnout. Do not allow a short-circuit and/or do not use the parts not recom- mended by Toshiba TEC Corporation.
Page 5 4) Cautionary Labels During servicing, be sure to check the rating plate and cautionary labels such as “Unplug the power cable during service”, “CAUTION. HOT”, “CAUTION. HIGH VOLTAGE”, “CAUTION. LASER BEAM”, etc. to see if there is any dirt on their surface and if they are properly stuck to the equipment.
Page 6 5) Disposal of the Equipment, Supplies, Packing Materials, Used Batteries and IC-RAMs Regarding the recovery and disposal of the equipment, supplies, packing materials, used batter- ies and IC-RAMs including lithium batteries, follow the relevant local regulations or rules. Caution: Dispose of used batteries and IC-RAMs including lithium batteries according to this manual. Attention: Se débarrasser de batteries et IC-RAMs usés y compris les batteries en lithium selon ce manuel.
Page 7 ALLEGEMEINE SICHERHEITSMASSNAHMEN IN BEZUG AUF DIE WARTUNG FÜR e-STUDIO181/211 Die Installation und die Wartung sind von einem qualifizierten Service- Techniker durchzuführen. 1) Transport/Installation Zum Transportieren/Installieren des Gerätes werden 2 Personen benötigt. Die Kassette zuerst herausnehmen und nur an den in der Abbildung gezeigten Stellen tragen.
Page 8 Sie müssen unbedingt korrekt gehandhabt und installiert werden. Wenn diese Teile kurzgeschlossen und funktionsunfähig werden, kann dies zu schwerwiegenden Schäden, wie einem Abbrand, führen. Kurzschlüsse sind zu vermeiden, und es sind auss- chließlich Teile zu verwenden, die von der Toshiba TEC Corporation empfohlen sind.
Page 9 4) Warnetiketten Im Rahmen der Wartung unbedingt das Leistungsschild und die Etiketten mit Warnhinweisen überprüfen [z. B. „Unplug the power cable during service“ („Netzkabel vor Beginn der Wartung- sarbeiten abziehen“), „CAUTION. HOT“ („VORSICHT, HEISS“), „CAUTION. HIGH VOLTAGE“ („VORSICHT, HOCHSPANNUNG“), „CAUTION. LASER BEAM“ („VORSICHT, LASER“) usw.], um sicherzustellen, dass sie nicht verschmutzt sind und korrekt am Gerät angebracht sind.
Page 10 5) Entsorgung des Geräts, der Verbrauchs- und Verpackungsmaterialien, alter Akkus und IC-RAMs In Bezug auf die Entsorgung und Wiederverwertung des Geräts, der Verbrauchs- und Verpack- ungsmaterialien, alter Akkus und IC-RAMs, einschließlich Lithiumakkus, sind die einschlägigen nationalen oder regionalen Vorschriften zu befolgen. Caution: Dispose of used batteries and IC-RAMs including lithium batteries according to this manual.
Page 11: Table Of Contents
3.5.5 Setting range correction (Adjustment of text peak) ..........3-29 3.6 Adjustment of High-Voltage Transformer ................3-30 3.6.1 Adjustment ......................3-30 3.6.2 Precautions ......................3-36 3.7 Adjustment of the Scanner Section ................... 3-38 3.7.1 CIS unit........................3-38 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 CONTENTS...
Page 12 4.5 Jig List ..........................4-12 4.6 Grease List ........................4-13 4.7 Precautions for Storing and Handling Supplies ..............4-14 4.7.1 Precautions for storing TOSHIBA supplies ............4-14 4.7.2 Checking and cleaning of photoconductive drum........... 4-15 4.7.3 Checking and cleaning of drum cleaning blade............4-16 4.7.4 Checking and cleaning of fuser roller and pressure roller ........
Page 13 7.2 Fuse............................. 7-2 7.3 Configuration of Power Supply Unit..................7-3 8. WIRE HARNESS CONNECTION.................. 8-1 8.1 AC Wire Harness ......................... 8-1 8.2 DC Wire Harness....................... Appendix 8.3 Electric Parts Layout....................Appendix © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 CONTENTS...
Page 15: Specifications / Accessories / Options / Supplies
Original/Mode: Single side original/A4/LT size. APS/automatic density are not selected. • Number of sheets: 16[20] or more. • Reproduction ratio: 100% © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 1...
Page 16 Toner cartridge replacing method (There is a recovered toner supply mechanism.) Density control......Automatic density mode and manual density mode selectable in 7 steps e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 2...
Page 17 Total counter ......Electronical counter Dimensions of the equipment ..........W 600 x D 643 x H 462.5 (mm): See the figure below Fig. 1-1 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 3...
Page 18: Accessories
MJD: Europe ASU: Asia / Saudi Arabia SAD: Saudi Arabia ARD: Latin America CND: China TWD: Taiwan KRD: Korea JPD: Japan e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 4...
Page 19: Options
MR-2020 Paper Feed Unit (PFU) MY-1027/C Expansion Memory GC-1240 Damp Heater MF-1640U/E Harness Kit GQ-1130 Desk MH-1640 Operator's Manual Pocket KK-1660/C © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 5...
Page 20: Supplies
PS-ZT1810C10k(1)(for China) PS-ZT1810C5k(1)(for China) PS-ZT1810T(1)(for Taiwan) PS-ZT1810T5k(1)(for Taiwan) PS-ZT1810E(1)(for EUROPE) PS-ZT1810E5K(1)(for EUROPE) Developer material D-2320 (except for China) D-2320C (for China) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 6...
Page 21: System List
Platen Cover ( ADF ) KA-1650PC MR-2020 Expansion Memory GC-1240 Paper Feed Unit ( PFU ) MY-1027 Desk MH-1640 Fig. 1-2 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 SPECIFICATIONS / ACCESSORIES / OPTIONS / SUPPLIES 1 - 7...
Page 23: Error Code And Self-Diagnostic Mode
ADF jam access cover open: The ADF jam access P. 5-11 cover has opened during ADF operation. ADF open jam: ADF has opened during ADF P. 5-12 operation. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 1...
Page 24: Service Call
Other service call Invalid backup counter: The value of the total counter is P. 5-20 inconsistent with that of the backup counter. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 2...
Page 25: Self-Diagnosis Modes
*1 Turn OFF the power after using the self-diagnosis modes, and leave the equipment to the user. <Operation procedure> • Input check mode (03): Refer to P.2-5 "2.2.1 Input check (Test mode 03)". © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 3...
Page 26 Press the reproduction ratio button ([200%] or [25%]) to shift the display to the 3 digits of the next lower/higher order. E.g.1) Displaying 1,000,000 Fig. 2-2 E.g. 2) Displaying 80,000 Fig. 2-3 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 4...
Page 27: Input Check (Test Mode 03)
Paper empty sensor No paper Paper present Drawer detection switch Drawer not Drawer installed installed PFU paper empty sensor No paper Paper present © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 5...
Page 28 Registration sensor Paper present No paper Developer unit switch Not connected Connected Fuser unit switch Connected Not connected Externally counter connection Not connected Connected e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 6...
Page 29 ADF original width sensor-1 Original No original present ADF original length sensor Original No original present ADF registration sensor Original No original present © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 7...
Page 30: Output Check (Test Mode 04)
[0][4] Code [POWER] [START] [POWER] [Digital keys] OFF/ON Procedure 3 [0][4] Code Operation [START] [CLEAR] [POWER] [Digital keys] Operation [FUNCTION [POWER] CLEAR] OFF/ON e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 8...
Page 31 ADF feed motor ON/OFF (normal rotation) ADF feed motor ON/OFF (reverse rotation) ADF read motor ON/OFF (normal rotation) Switching regulator cooling fun high speed rotation/low speed rotation © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 9...
Page 32: Test Print Mode (Test Mode 07)
Secondary scanning direction 33 gradation steps Error diffusion Grid pattern Pattern width: 2 dots, Pitch: 10 mm Solid black pattern (Whole area) A3/LD e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 10...
Page 33: List Print Mode (9S)
[0] -> [0] -> [0] -> [0] -> [*] -> [0] -> [0] Size specification (4digits) 0080 [0] -> [0] -> [8] -> [0] © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 11...
Page 35: Access Code Mode (8S)
• If the [START] button is pressed with an access code which has not been registered previously, the display returns to the initial screen. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 13...
Page 36 When an access code Cancel which has not been registered previously [CLEAR] is entered *: Apply the same procedure when the equipment enters the interruption mode. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 14...
Page 37: Function Setting Mode (1*)
Undefined Department Code 0: No This bit setting determines whether or not the setting 1: Yes department control function is available. Undefined Undefined © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 15...
Page 38 Contents Energy saving mode Sets the Energy saving mode. switching Sleep Mode Super Sleep Mode 10-11: Undefine Undefined Undefined Undefined Undefined Undefined Undefined e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 16...
Page 39: Adjustment Mode (05)
[Transfer bias] 220,221,222 Separation [Separation bias] 233,234,235 Process [Toner recycle] [Write starting] 410,411,440,441,442 [Polygonal motor] 401,405 Laser [Laser power] [Sideways deviation] 497-0 to 5 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 17...
Page 40 RAM [Digital keys] * [INTERRUPT] [POWER] OFF/ON Does not store value in RAM [FUNCTION CLEAR] * Press [#] to enter minus (-). e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 18...
Page 41 In that case, turn ON the power normally, leave the equipment for approx. 3 minutes after it has become ready state and then start up the adjustment mode again. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE...
Page 42 2: PFU Test code Types of test pattern Remarks Grid pattern Pattern width: 2 dots, Pitch: 10mm Solid black pattern (whole area) A3/LD e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 20...
Page 43 Laser Laser power adjustment When the value <0-255> increases, the laser output increases correspondingly. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 21...
Page 44 “1”, the reproduction ratio of the secondary scanning direction when using the ADF increases by approx. 0.1%. During this adjustment, the density LED blinks. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 22...
Page 45 Drive Fine PPC/ When the value adjustment of <0-255> increases by “1”, the exit motor rotation becomes faster speed by approx. 0.05%. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 23...
Page 46 <0-63> Short size: adjustment at 451-1 Middle 219 mm or shorter size <0-63> registration 451-2 Short size section (PFU/ <0-63> Plain paper) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 24...
Page 47 Paper aligning Long size feeding amount <0-63> adjustment at 464-1 Middle size <0-63> registration 464-2 Short size section <0-63> (Bypass feeding / Envelope) © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 25...
Page 48 Text <0-255> Image Range Text/Photo When the value correction/ <0-255> decreases, the text Text peak becomes darker. Text adjustment <0-255> Photo <0-255> e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 26...
Page 49 When entering “0” on the ten's place, this value is not displayed on the entry screen. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 27...
Page 50 Adjustment of the image printer image <0-63> density. density With decreasing the 672-1 value, the text becomes <0-63> lighter. 672-2 <0-63> 672-3 <0-63> 672-4 <0-63> e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 28...
Page 51 31-34, reproduction of the 41-44> background density and text density respectively. 1: fixed/fixed 2: varied/fixed 3: fixed/varied 4: varied/varied Background peak/ Text peak © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 29...
Page 52 Image Density Text/Photo When the value adjustment <0-255> increases, the image Fine becomes darker. Text adjustment of <0-255> “automatic Photo density” <0-255> e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 30...
Page 53 Text/Photo When the value adjustment <1-9> decreases, the background becomes Photo darker. <1-9> When the value Text increases, the <1-9> background becomes lighter. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 31...
Page 54: Setting Mode (08)
801-0 to 1,802-0 to 1,804-0 to 1,886,896-0 to 1 [Status counter] Transfer bias [Transfer bias] 830,868,869 Separation bias [Separation bias] 831,870,871 Version [System firmware] 900,921,922,923 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 32...
Page 55 [Jobs clear] [Energy saving mode] [Sorting] [Timer] 204,205,206 [Book type] [External counter] [Default setting] 607,618,642 [Paper size] [Polygonal motor] 483,486 Laser [Power correction] 872,873,875,876,877,883 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 33...
Page 56 [Digital keys] [Digital keys] Value [FUNCTION [POWER] displayed CLEAR] OFF/ON Procedure 15 [0][8] Code Copying [POWER] [START] [POWER] [Digital keys] total counter OFF/ON e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 34...
Page 57 16: 100 min.17:110 min. 18: 120 min. 19: 150 min. 20: 180 min. 21: 210 min. 22: 240 min. 23: Invalid 24: 1 min. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 35...
Page 58 <140- 432> 229-1 widthwise direction <140- 432> 230-0 Paper Paper size feeding feeding (A4-R) direction <140- 432> 230-1 widthwise direction <140- 432> e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 36...
Page 59 <140- 432> 239-1 widthwise direction <140- 432> 240-0 Paper Paper size feeding feeding (13”LG) direction <140- 432> 240-1 widthwise direction <140- 432> © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 37...
Page 60 08-224.) User Maximum number of copy 0: 999 1: 99 interface volume (MAX9) <0-2> 2: 9 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 38...
Page 61 Counts the number of <8 digits> sheets fed from bypass feed Counter Counter for ADF Counts the number of <8 digits> originals fed from ADF © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 39...
Page 62 (Center thermistor) <0-13> 4: 70°C 5: 80°C 6: 90°C 7: 100°C 8: 110°C 9: 120°C 10: 130°C 11: 140°C 12: 150°C 13: 160°C e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 40...
Page 63 <2-60> time setting in 425-1 ready status second <2-60> (Side drop thermistor) 425-2 The third drop <2-60> 425-3 The fourth drop <2-60> © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 41...
Page 64 8: 8 sec. 9: 9 sec. 10: 10 sec. 11: 12 sec. 12: 14 sec. 13: 16 sec. 14: 18 sec. 15: 20 sec. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 42...
Page 65 (driving period of the toner motor) into the developer unit. 0: x1.0 1: x0.75 2: x0.5 3: x0.3 4: x2.0 5: x1.5 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 43...
Page 66 The fourth drop <0-10> Paper Default setting of paper 0: A4/LT feeding source <0-4> 1: Drawer 2: LCF 3: Not used 4: Not used e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 44...
Page 67 (Center thermistor) 4: 160°C 5: 165°C 6: 170°C 7: 175°C 8: 180°C 9: 185°C 10: 190°C 11: 195°C 12: 200°C 13: 205°C 14: 210°C © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 45...
Page 68 8: 8 sec. 9: 9 sec. 10: 10 sec. 11: 12 sec. 12: 14 sec. 13: 16 sec. 14: 18 sec. 15: 20 sec. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 46...
Page 69 0: AUTO 1: Light 3 quality mode <0-7> 2: Light 2 3: Light 1 4: Center 5: Dark 1 6: Dark 2 7: Dark 3 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 47...
Page 70 Automatic Sorting Mode 0: Invalid interface setting (ADF) <0,2> 2: SORT User Default setting of Sorter 0: SORT interface Mode <0,1> 1: GROUP e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 48...
Page 71 4: 150°C 5: 155°C (Envelope) 6: 160°C 7: 165°C 8: 170°C 9: 175°C 804-1 Side 10: 180°C thermistor <0-12> 11: 185°C 12: 120°C © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 49...
Page 72 (Text/OHP film) Develop Developer bias DC correction <0-255> (Photo/OHP film) Image Switching of recycled toner 0: Switched processi saving control <0-1> 1: Not switched e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 50...
Page 73 DC output adjustment (05-222). Separati Separation transformer DC Corrects the value of correction (H) <0-255> the separation transformer DC output adjustment (05-233). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 51...
Page 74 Displays the “xx.xxx” part of the above code as “xx-xxx”. (Press the reproduction ratio buttons to switch the display between “xx- ”and “xxx”.) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 52...
Page 75 (Thick paper 2) <8 digits> registration sensor is 1388 Counter Number of output pages Counts up when the (OHP film) <8 digits> registration sensor is © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 53...
Page 76 Blinks when the value is blinks <0-1> different from the present default value after copying (until auto clear or all clear.) 0: Invalid (Always off) 1: Valid e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 54...
Page 77 • When “0” is set at one of sub-codes 0, 3, 6 and 7, the rest of them are automatically updated to “0”. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 55...
Page 78 (Drawer) Sub-codes 0: 0/0 Sub-code 1: 80,000/80,000 Feed roller 1300-0, 1 <Default values of code 1300 (PFU) Sub-codes 0: 0/0 Sub-code 1: 80,000/80,000 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 56...
Page 79 1336-0, 1, 3, 4, 6, 7 <Default values of code 1336 Sub-codes 0, 3, 6, 7: 0/0 Sub-code 1: 77,000/90,000 Sub-code 4: 180,000/180,000 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 57...
Page 80: Test Mode (13)
FROM is calculated and compared with the one reported in advance. <Key used in operation> [1][3] Code Code "Ch" [START] [Power ON] [Digital Key] (blinks) [Power] Result [CLEAR/STOP] OFF/ON e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 58...
Page 81 [CLEAR] button is pressed during the button test (06), the display returns to the test mode in which the code can be entered.) 4. In the LED test (07), the [ENERGY SAVER] lamp is not included. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ERROR CODE AND SELF-DIAGNOSTIC MODE...
Page 82: Country/Region Code (02)
RAM Warming up [POWER] [Digital keys] [INTERRUPT] Does not stores value in RAM [CLEAR/STOP] <Code> Code (Default) Model e-STUDIO165/205 e-STUDIO167/207/237 ASU/SYD/SAD e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ERROR CODE AND SELF-DIAGNOSTIC MODE 2 - 60...
Page 83: Adjustment
Fig. 3-3 Note: The output voltage of the auto-toner sensor (2.30 V in the above case). The drum, developer unit, etc. are in operation. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 1...
Page 84 The drum, developer unit, etc. are stopped and the following is displayed on the 7-segment LED. [INTERRUPT] Fig. 3-4 Turn the power OFF. (10) Install the toner cartridge. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 2...
Page 85: Image Dimensional Adjustment
(b) Image location of primary scanning direction (c) Reproduction ratio of secondary scanning direc- tion (d) Image location of secondary scanning direction (e) Top margin (f) Right margin (g) Bottom margin © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 3...
Page 86 If the test copy does not satisfy the specified values, return to step 1 and repeat the adjustment procedure. [Power] :Exit the Adjustment Mode. OFF/ON Fig. 3-5 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 4...
Page 87: Paper Alignment At The Registration Roller
1. Long size: 330 mm or longer (13.0 inches or longer) Middle size: 220-239 mm (8.7-12.9 inches) Short size: 219 mm or shorter (8.6 inches or shorter) 2. The adjustment of “Post card” is for Japan only. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 5...
Page 88 * As a tentative countermeasure, the service life of the feed roller can be extended by increasing the aligning amount. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 6...
Page 89: Printer Related Adjustment
After the adjustment for the code 411 is completed, apply the same adjustment value for the code 410. (Adjustment Mode) (Key in the code [410]) [START] (Key in the same value in the step 5 above) Press [INTERRUPT] (Stored in memory). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 7...
Page 90 Press [1] [INTERRUPT] Press [Drawer number] [START] (A grid pattern is printed out.) *The larger the adjustment value is, the longer the distance C becomes (approx. 0.125 mm/step). e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 8...
Page 91 Press [1] [INTERRUPT] Press [Drawer number] [START] (A grid pattern is printed out.) *The larger the adjustment value is, the longer the distance D becomes (approx. 0.4 mm/step). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 9...
Page 92 Key in the same value for 05-410. 05-421 (Drawer, A3/LD) 200±0.5 mm (0.125 mm/step) 05-440 (Drawer, A3/LD), 441 (PFU, A4/LT), 442 (Bypass feed, A4/LT) 50±0.5 mm(0.4 mm/step) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 10...
Page 93: Scanner Related Adjustment
*The larger the adjustment value is, the higher the reproduction ratio and the longer the distance A become (approx. 0.125 mm/step). Copied image of the ruler Feeding direction Fig. 3-8 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 11...
Page 94 *The smaller the adjustment value is, the more the image is shifted to the left and the distance B become narrower (0.169 mm/step). Be sure not to perform any operations while the density LED is blinking. Copied image of the ruler Feeding direction Fig. 3-9 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 12...
Page 95 *The smaller the adjustment value is, the lower the reproduction ratio becomes (0.189 mm/step). Be sure not to perform any operations while the density LED is blinking. Copied image of the ruler Feeding direction Fig. 3-10 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 13...
Page 96 *The larger the adjustment value is, the more the image is shifted to the trailing edge (0.064 mm/ step). Be sure not to perform any operations while the density LED is blinking. Copied image of the ruler Feeding direction Fig. 3-11 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 14...
Page 97 Press the [INTERRUPT] button (stored in memory). (“AJ” is displayed.) *The larger the adjustment value is, the wider the blank area becomes (approx. 0.04 mm/step). Feeding direction Fig. 3-12 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 15...
Page 98 Press the [INTERRUPT] button (stored in memory). (“AJ” is displayed.) *The larger the adjustment value is, the wider the blank area at the right side becomes (approx. 0.04 mm/step). Feeding direction Fig. 3-13 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 16...
Page 99 Press the [INTERRUPT] button (stored in memory). (“AJ” is displayed.) *The larger the adjustment value is, the wider the blank area at the trailing edge becomes (approx. 0.04 mm/step). Feeding direction Fig. 3-14 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 17...
Page 100: Image Quality Adjustment (Copying Function)
The equipment goes back to the ready state. Let the equipment restarted and perform copying job. If the desired image density has not been attained, repeat step (2) to (5). e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 18...
Page 101: Gamma Slope Adjustment
1 to 9: Select the gamma slope angle. (The larger the value is, the larger the angle becomes.) <Procedure> Procedure is same as that of P.3-18 "3.3.1 Density adjustment". © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 19...
Page 102: Sharpness Adjustment
Make a test copy and compare the image obtained with the current settings; if necessary, make adjustment using the following procedure. <Procedure> Procedure is same as that of P.3-18 "3.3.1 Density adjustment". e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 20...
Page 103: Setting Range Correction
Make a test copy and compare the image obtained with the current settings; if necessary, make adjustment using the following procedure. <Procedure> Procedure is same as that of P.3-18 "3.3.1 Density adjustment". © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 21...
Page 104: Setting Range Correction (Adjustment Of Text Peak)
Make a test copy and compare the image obtained with the current settings; if necessary, make adjustment using the following procedure. <Procedure> Procedure is same as that of P.3-18 "3.3.1 Density adjustment". e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 22...
Page 105: Adjustment Of Image Density
For resetting the value, repeat step (2) to (5). Turn the power OFF and then back ON to perform printing job. If the desired image density has not been attained, repeat step (2) to (7). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT...
Page 106: Image Quality Adjustment (Printing Function)
Turn the power OFF and then back ON to perform printing job. If the desired text density has not been attained, repeat step (2) to (5). e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 24...
Page 107: Adjustment Of Image Density
For resetting the value, repeat step (2) to (5). Turn the power OFF and then back ON to perform printing job. If the desired image density has not been attained, repeat step (2) to (7). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT...
Page 108: Image Quality Adjustment (Scanning Function)
Press the [INTERRUPT] button to store the value. The equipment goes back to the ready state. Turn the power OFF and then back ON to perform scanning job. If the desired image density has not been attained, repeat step (2) to (5). e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 26...
Page 109: Sharpness Adjustment
For resetting the value, repeat step (2) to (5). Turn the power OFF and then back ON to perform scanning job. If the desired image density has not been attained, repeat step (2) to (7). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT...
Page 110: Setting Range Correction
Acceptable values: 0 to 255 (Default: text/photo: 32, photo: 16, text: 46) <Procedure> Procedure is same as that of P.3-26 "3.5.1 Density adjustment". e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 28...
Page 111: Setting Range Correction (Adjustment Of Text Peak)
* The image changes slightly in text mode because it is treated as a simple binary format image. <Procedure> Procedure is same as that of P.3-26 "3.5.1 Density adjustment". © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 29...
Page 112: Adjustment Of High-Voltage Transformer
Refer to P.3-33 "[B] Refer to P.3-33 "[C] Refer to P.3-34 "[D] Connection for Connection for main Connection for transfer/ developer bias charger adjustment". separation charger adjustment". adjustment". e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 30...
Page 113 High-voltage transformer jig Fig. 3-16 Fix the green cable of the high-voltage transformer jig to the frame of the equipment. Screw Green cable Fig. 3-17 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 31...
Page 114 Install the cover open switch release jig for Front cover opening/closing switch service. Close the transfer cover. Cover open switch release jig for service Fig. 3-18 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 32...
Page 115 ( green cable ) ( + ) terminal: ( - ) terminal: Connect with the red cable ( thick line ) Connect with the white cable Fig. 3-20 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 33...
Page 116 ( green cable ) ( + ) terminal: ( - ) terminal: Connect with the Connect with the white cable red cable ( thin line ) Fig. 3-21 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 34...
Page 117 Code -566±54mV -566±54mV -391±36mV Adjustment value [INTERRUPT] : Adjusted value is stored in memory. Return to 1 to enter the other adjustment code. [POWER] OFF/ON Fig. 3-22 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 35...
Page 118: Precautions
Approx. 11mm Approx. 5mm Adjustment code "220" "221" "222" Leading edge Trailing edge area of paper area of paper Fig. 3-23 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 36...
Page 119 Adjustment code "233" "235" "234" "235" Leading edge Trailing edge area of paper area of paper Fig. 3-24 * Adjustment code 235 performs the adjustment for 2 areas. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 37...
Page 120: Adjustment Of The Scanner Section
Adjust the tension of the CIS unit drive belt-1 when installing it. <Procedure> Install the CIS unit drive belt-1 after the tension bracket fixing screw are loosened. Tighten the tension bracket fixing screw. Tension bracket Fig. 3-25 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 38...
Page 121: Scan Motor (Cis Unit Drive Belt-2)
Hook the belt tension jig on the motor bracket and frame. Scan motor Belt tension jig Fig. 3-27 Tighten screws A and B where the scan motor pulled by the belt tension jig stops. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 39...
Page 122: Adjustment Of The Paper Feeding System
[Front] [Front] Fig. 3-29 Fig. 3-28 1. Loosen the screen. 2. Move the entire guide to the front or rear side. 3. Tighten the screw. Fig. 3-30 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 40...
Page 123: Adjustment Of Developer Unit
Adjust the screws with the doctor blade to push the doctor sleeve jig lightly. Toner scattering prevention sheet Fig. 3-33 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 41...
Page 124 2 screws. Developer unit upper cover Note: After the developer material has been replaced, adjust the auto-toner sensor. (See P.3-1 "3.1 Adjustment of Auto-Toner Sensor".) Fig. 3-36 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 42...
Page 125: Adjustment Of The Adf (Mr-2020)
ADF). Fig. 3-37 Remove the platen sheet. Fig. 3-38 Close the ADF and check if the positioning pins fit the holes on the ADF. Fig. 3-39 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 43...
Page 126 Fig. 3-40 Remove 2 screws and take off the bracket on the rear side. Fig. 3-41 Loosen the left-hand hinge screw at the rear side. Fig. 3-42 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 44...
Page 127 ADF is closed. Fig. 3-44 Tighten the left-hand hinge screw at the rear side. Fig. 3-45 Install the bracket. Fig. 3-46 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 45...
Page 128 Match the screw hole positions. Fig. 3-48 (10) Install the right-hand hinge screw at the rear side. Fig. 3-49 (11) Loosen the hinge screws at the front side. Fig. 3-50 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 46...
Page 129 (12) Place the platen sheet on the original glass and align it to the top left corner. Close the ADF gently and open it to check if the platen sheet is attached properly. Fig. 3-51 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 47...
Page 130: Adjustment Of Adf Height
“B” from the left hand side of the equipment. If the value is not within the tolerance, perform the adjustment according to the following procedure. [Tolerance of the gap] Rear side: 0 - 0.2 mm Front side: 0 mm Fig. 3-52 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 48...
Page 131 Adjust the gap on the rear side by means of the screw on the hinge on the feed side of the ADF. Turn it clockwisLowered Turn it counterclockwiseHeightened Fig. 3-54 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 49...
Page 132: Adjustment Of Skew
Superimpose the chart on the copy and check the inclination of the copy image. [B] Adjustment Shift the aligning plate with the scale as the guide shown in the figure below to adjust the skew. Fig. 3-56 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 50...
Page 133 “+”, and if “D”, shift it to “-”. Fig. 3-57 Fig. 3-58 Shift the aligning plate in the direction of “+”. Shift the aligning plate in the direction of “-”. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 51...
Page 134: Adjustment Of The Leading Edge Position
If the leading edge (F) margin of the copy image is smaller than the (E) margin of the chart, enter a value larger than the current one. Note: Changing one value shifts the copy image by 0.2 mm. Press the [INTERRUPT] button. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 52...
Page 135: Adjustment Of Horizontal Position
If the center line of the copy image is shifted to the rear side of the equipment, enter a value smaller than the current one. Note: Changing one value shifts the copy image by 0.169 mm. Fig. 3-62 Press the [INTERRUPT] button. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 53...
Page 136: Adjustment Of Copy Ratio
• If the copy image dimension “I” is smaller than the chart dimension, enter a value larger than the current one. Fig. 3-63 Press the [INTERRUPT] button. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved ADJUSTMENT 3 - 54...
Page 137: Adjustment Of Adf Opening/Closing Sensor
Adjust the bracket position so that the sensor is turned ON when the height “A” becomes 100 mm or less (within the empty weight falling limit). Fig. 3-64 Fig. 3-65 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 ADJUSTMENT 3 - 55...
Page 139: Preventive Maintenance (Pm)
After preventive maintenance, set the value of 08-252 (Current value of PM counter Display) to "0". *This turns off the "CALL SERVICE" symbol. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 1...
Page 140: Operational Items In Overhauling
Check the performance of all the switches and sensors. Replace them with new ones if necessary. Clean inside the equipment thoroughly. Check if the harnesses, thermistors, fuses, etc. are damaged. Replace them if necessary. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 2...
Page 141: Preventive Maintenance Checklist
77,000 sheets e-STUDIO211: every 90,000 sheets 2. Value under “Replacement” indicates the replacement cycle for e-STUDIO181/211. 3. The replacement cycle of the parts in the feeding section equals to the number of sheets fed from each paper source.
Page 142 Pickup roller P14-I22 Feed roller P14-I22 Separation pad P13-I22 Bypass tray Drive gear (tooth face and shaft) GCB bushing bearing One side of the plastic bushing e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 4...
Page 143 Ch.4.7.2 Discharge LED Whole cleaner unit Drum cleaning blade 77/90 P20-I5 Separation finger for 77/90 P20-I17 drum Recovery blade 77/90 P20-I6 Ozone filter 77/90 P11-I3 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 5...
Page 144 P23-I19 K. PFU (MY-1027) Replacement Operation Parts list Items to check Cleaning Lubrication Remarks (x 1,000 sheets) check <P-I> Pickup roller P3-I12 Feed roller P3-I16 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 6...
Page 145 Fig. 4-1 Front side Fig. 4-2 Automatic Document Feeder (ADF) Fig. 4-3 Paper Feed Unit (PFU) © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 7...
Page 146 Insert the wire securely into the V-grooves of the front and rear sides. Do not twist the wire. Do not touch the wire with your bare hand. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 8...
Page 147 Oil seal (Developer unit) Mixer unit (Shafts of mixers-1, -2 & -3) 6 pcs. Note: Lubricate the oil seal only when the oil seal is replaced. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 9...
Page 148 Do not deform or damage the thermistor during the cleaning. Replace the thermistor with a new one if it is damaged or deformed regardless of degree. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 10...
Page 149: Pm Kit
HR-1640-U Pressure roller HR-1640-L Separation finger for fuser roller SCRAPER-280 Bush for fuser roller BUSH-HR/RLR DF-KIT-3018 Pickup roller ASYS-ROL-FEED Feed roller ASYS-ROL-FEED Separation roller ASYS-ROL-RET © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 11...
Page 150: Jig List
High-voltage transformer jig Downloading jig (DLM board) Download JIG-2 (6 Flash ROMs) Download JIG-1 (2 Flash ROMs) ROM writer adapter (For 1881) ROM writer adapter (For 1931) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 12...
Page 151: Grease List
ASM-PG-HP300-S 100g Bottle White grease (Molykote HP-300) GREASE-HP300-S Bottle Alvania No.2 ASM-PG-ALV2 100g Tube White grease (Molykote EM-30L) MOLYKOTE-100 100g Tube Floil (GE-334C) ASM-PG-GE334C-S Bottle © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 13...
Page 152: Precautions For Storing And Handling Supplies
Avoid storing paper in places where it may be subjected to high humidity. After a package is opened, be sure to place and store it in a storage bag. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 14...
Page 153: Checking And Cleaning Of Photoconductive Drum
6. Collecting used photoconductive drums Regarding the recovery and disposal of used photoconductive drums, we recommend following the relevant local regulations or rules. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 PREVENTIVE MAINTENANCE (PM) 4 - 15...
Page 154: Checking And Cleaning Of Drum Cleaning Blade
Be careful not to rub the fuser roller and pressure roller surface with your nails or hard objects because it can be easily damaged. Do not use silicone oil on the fuser roller and pressure roller. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved PREVENTIVE MAINTENANCE (PM) 4 - 16...
Page 155: Troubleshooting
2. Check if the aligning amount is appropriate. (See P.3-5 "3.2.2 Paper alignment at the registration roller") An [E01] error occurs both when the amount is too large and too small. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 1...
Page 156 Sensor Test mode / Input check Registration area Transfer cover Registration sensor 03-[INTERRUPT]OFF/[9]/[6] Exit area Transfer cover Exit sensor 03-[INTERRUPT]OFF/[9]/[5] PFU side cover PFU feed sensor 03-[INTERRUPT]OFF/[7]/[5] e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 2...
Page 157 1. Check the condition of the pickup roller of paper source, and replace it if it is worn out. 2. Check the transport roller. Replace it if it is worn out. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211...
Page 158: Paper Misfeeding
5. Replace the bypass pickup solenoid and bypass paper sensor. 6. Replace the MAIN board. Check the bypass pickup roller. Replace it if it is worn out. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 4...
Page 159 4. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 5. Replace the pickup solenoid. 6. Replace the MAIN board. Check the drawer pickup roller. Replace it if it is worn out. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 5...
Page 160 4. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 5. Replace the PFU pickup solenoid. 6. Replace the MAIN board. Check the PFU drawer pickup roller. Replace it if it is worn out. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 6...
Page 161: Cover Open Jam
4. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 5. Replace the MAIN board. Replace the MAIN board. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 7...
Page 162 4. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 5. Replace the MAIN board. Replace the MAIN board. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 8...
Page 163 4. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 5. Replace the PFU cover opening/closing switch. 6. Replace the MAIN board. Replace the MAIN board. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 9...
Page 164: Transport Jam (Adf)
4. Check if the conductor pattern on the ADF board is short circuited or open circuited. 5. Replace the read sensor. 6. Replace the ADF board. Replace the ADF board. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 10...
Page 165 4. Check if the conductor pattern on the ADF board is short circuited or open circuited. 5. Replace the ADF jam access cover switch. 6. Replace the ADF board. Replace the ADF board. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 11...
Page 166 4. Check if the conductor pattern on the ADF board is short circuited or open circuited. 5. Replace the ADF opening/closing sensor. 6. Replace the ADF board. Replace the ADF board. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 12...
Page 167: Drive System Related Service Call
1. Check if the PLL lock signal CN305-B8 output from the MAIN board is always level “L”. 2. Check if the voltage supplied to the CPU input terminal IC24-12 is always “L”. 3. Replace the MAIN board. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING...
Page 168: Scanning System Related Service Call
3. Check if the conductor pattern on the MAIN board is short circuited or open circuited. 4. Replace the MAIN board. 5. Replace the CIS unit. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 14...
Page 169: Fuser Unit Related Service Call
Change the current status counter value “1” or “2” to “0”, then press [ENTER] or [INTERRUPT] (to cancel [C41]). Turn the power OFF and then back ON. Make sure that the equipment enters the normal ready state. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 15...
Page 170 Change the current status counter value “4” to “0”, then press [ENTER] or [INTERRUPT] (to cancel [C43]). Turn the power OFF and then back ON. Make sure that the equipment enters the normal ready state. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 16...
Page 171 Check if the conductor pattern on the board is short circuited or open circuited. Replace the MAIN board. 3. Clear the status counter Change the current status counter value (08-400) “6” to “0”. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 17...
Page 172: Adf Related Service Call
1. Connect the disconnected connectors. 2. Replace the laser optical unit if the harness is open circuited. 1. Replace the MAIN board. 2. Replace the laser optical unit. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 18...
Page 173: Service Call For Others
- The Main PC board for e-STUDIO163/203 in which e-STUDIO166/206 firmware is installed - The Main PC board for e-STUDIO163/166/203/206 in which e-STUDIO181/211 firmware is installed Be sure not to make a mistake in the combination of the Main PC board and the firmware since the error message does not appear if there is an incorrect combination.
Page 174 1. Check if the connector CN2 on the SRAM board and the connector CN2 on the MAIN board are securely connected. 2. Replace the SRAM board. 3. Replace the MAIN board. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 20...
Page 175: Optional Communication Related Service Call
Check if the conductor patterns on the ADF/RADF board and the MAIN board are short circuited or open circuited. Replace the ADF/RADF board. Replace the MAIN board. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 21...
Page 176: Troubleshooting For The Image
Perform troubleshooting for background fogging. Is there a blotch on the image? Perform troubleshooting for blotched image. Is the image transferred normally? Perform troubleshooting for abnormal transfer. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 22...
Page 177 Check the pressure of the drum cleaning blade. Toner dusting Is toner heaped on the seal of the Remove the toner and clean the developer unit? developer unit. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 23...
Page 178 Check the image processing Check the encircled areas A and B in parameters. the image, and change the sharpness intensity in the sharpness adjustment mode. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 24...
Page 179 Using the specified developer Use the specified developer material material? and toner. Scanner Are the original glass (especially the Clean them. position of shading correction plate) and CIS unit dirty? © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 25...
Page 180 Is the exhaust fan operating Check the connection of connector. properly? Replace the ozone exhaust fan. Is the ozone filter stained or Replace the ozone filter. damaged? e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 26...
Page 181 Check the setting and correct it. roller in each paper type normal? 08-413, 437, 438, 451, 452, 453, 520, 521 Using the recommended paper? Use the recommended paper. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 27...
Page 182 MAIN, LDR, SNS boards, Are the connectors securely Connect the connectors securely. CIS unit and harnesses connected? Replace the harness. Check if the harnesses connecting the boards are open circuited. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 28...
Page 183 MAIN, LDR, SNS boards, Are the connectors securely Connect the connectors securely. CIS unit and harnesses connected? Replace the harness. Check if the harnesses connecting the boards are open circuited. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 29...
Page 184 CIS unit dirty? Cleaner Is there any foreign matter, which Remove the foreign matter. contacts the drum on the cleaner stay? e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 30...
Page 185 Is any foreign matter such as paper Remove the foreign matter from the shred sticking to the transfer charger wire. wire? Feed system Is the aligning amount proper? Adjust the aligning amount. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 31...
Page 186 Is the pre-registration guide properly Correct it. installed? CIS unit Is the CIS unit slanted? Replace the CIS case. Feed system Is the aligning amount proper? Adjust the aligning amount. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 32...
Page 187 Are there scratches on the drum Replace the drum. surface? Laser optical unit Is there a foreign matter or stain on Remove the foreign matter or the the slit glass? stain. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 33...
Page 188 Scanner Are the original glass (especially the Clean them. position of shading correction plate) and CIS unit dirty? e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 34...
Page 189 / Transfer charger) Transfer/Separation Is there any foreign matter such as Clean the transfer/separation charger fiber in the paper transport area of charger. the transfer/separation charger? © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 35...
Page 190 Replace the clutch if it is defective. Adjust the rotation speed of the roller. High-voltage transformer Is the high-voltage transformer Adjust the output, or replace the (Transfer charger) output defective? transformer. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 36...
Page 191 Is the platen cover or ADF opened? Close the platen cover or ADF. Are the original glass (especially the Clean them. position of shading correction plate) and CIS unit dirty? © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 37...
Page 192 Replace the high-voltage harness. Is the harness open circuited? Discharge LED Are the connectors of discharge LED Reconnect the harness securely. harness securely connected? e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 38...
Page 193 Pre-registration guide Is the pre-registration guide installed Install the guide properly. properly? Feed system Is the aligning amount proper? Adjust the aligning amount. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 39...
Page 194 Is there any problem with the drive Check the drive system of the drum. system of the drum? Clean or replace the gears if they have stains or scratches. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 40...
Page 195 Check and adjust the mechanism. normal? Is the setting temperature of the fuser Check the setting and correct it. roller normal? 08-407, 410, 411, 450, 515, 516 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 41...
Page 196 Are the original glass (especially the Clean them. position of shading correction plate) and CIS unit dirty? Exposure lamp Is the CIS unit degraded? Replace the CIS unit. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 42...
Page 197 Is the transfer charger wire dirty? Clean the transfer charger wire. High-voltage transformer Is the output from the high-voltage Adjust the output. Replace the (Transfer charger) transformer normal? transformer if necessary. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING 5 - 43...
Page 198: Replacement Of Pc Boards
Perform 08-388 (Copying total counter / MAIN board -> SRAM board) to recover the total counter. While pressing [1], [3] and [#] simultaneously, turn the power ON. (RAM clear) (10) Turn the power OFF. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 44...
Page 199 (14) Be sure to perform "05-310" with the platen cover or the ADF closed after replacing the SRAM board. (15) Turn the power OFF and then start with the setting mode (08). © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING...
Page 200 08-1200_7 (Developer material (Present driving counts for control)) 08-1214_0 (Transfer charger wire (Present number of output pages)) 08-1214_1 (Transfer charger wire (Recommended number of output pages for replacement)) e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved TROUBLESHOOTING 5 - 46...
Page 201 Also, set the setting values which have been changed for servicing. (17) Check that the setting value for 08-203 (Line adjustment mode) is "0" (For factory shipment). If it is “1” (For line), change it to “0”. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 TROUBLESHOOTING...
Page 203: Firmware Updating
( for ROM writer connection ) adapter connection ) connection ) adapter connection ) Fig. 6-1 Jig board: PWA-DWNLD-350-JIG2(48 MB) Fig. 6-2 Jig board: PWA-DWNLD-350-JIG1(16 MB) © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 FIRMWARE UPDATING 6 - 1...
Page 204 P.6-6 "6.1.2 Writing the data to the download jig (PWA-DWNLD-350-JIG)" K-PWA-DLM-320 Connector Mark for ROM installation direction Fig. 6-3 Jig board: K-PWA-DLM-320 Important: Pay attention to the direction of the ROM. e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 2...
Page 205: Pwa-Dwnld-350-Jig
STUDIO181/211. - The Main PC board for e-STUDIO163/203 in which e-STUDIO166/206 firmware is installed - The Main PC board for e-STUDIO163/166/203/206 in which e-STUDIO181/211 firmware is installed Be sure not to make a mistake in the combination of the Main PC board and the firmware since the error message does not appear if there is an incorrect combination.
Page 206 Is the download jig connected properly? • Is the updating data written to the download jig properly? • Do the download jig and the equipment operate properly? e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 4...
Page 207 After the updating is completed, check each data version in the Setting Mode (08) to confirm that the data was overwritten properly. 08-900: System ROM version © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 FIRMWARE UPDATING 6 - 5...
Page 208: Writing The Data To The Download Jig (Pwa-Dwnld-350-Jig)
(or equivalent) (model 1881) Minato Electronics MODEL 1893/1895/1931/1940 PWA-DL-ADP-350-1931 (or equivalent) (model 1931) model 1881 model 1931 ( LV650 ) Fig. 6-10 PWA-DL-ADP-350-1881 Fig. 6-11 PWA-DL-ADP-350-1931 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 6...
Page 209 ROM2 ROM3 ROM4 ROM5 ROM6 Note: Be sure not to confuse different ROM Versions since the file name is identical although the ROM version is different. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 FIRMWARE UPDATING 6 - 7...
Page 210: K-Pwa-Dlm-320
* If rewriting data is failed, turn OFF the power and repeat the procedure. Connector Fig. 6-12 Note: Be sure to print out the list to confirm the firmware version for the ADF. P.2-11 "2.2.4 List Print Mode (9S)" e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 8...
Page 211: Firmware Updating With Software Update Tool
2. Only installation by hardware wizard can recognize e-STUDIO181/211. 3. If the TOSHIBA Viewer USB driver is already installed, the software update tool USB driver cannot be. Delete the corresponding COM port on the Device Manager window and then start the installation of the software update tool USB driver.
Page 212 Select the firmware data file to be updated on the Local Firmware Data window (in the figure below, "rom_L_V52.bin" is selected). Double-click the file or click [Open (O)] to open it. Fig. 6-15 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 10...
Page 213 [ALL]. Fig. 6-17 Note: In e-STUDIO181/211, the downloaded area has two selections; "Program (program data)" and "Function (function data)". Updating is available on each area individually, but it is recommended that you update data on all the areas.
Page 214 Select the program you want to update. (Select either the Program or the Function check box. The Program and Function check boxes are selected in the following example.) Fig. 6-18 Click [Selected Area]. The Attention window appears. Click [Yes]. Fig. 6-19 e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 12...
Page 215 Note: If an error occurs, repeat the procedure from the first step to retry updating. (12) Turn OFF the power of the equipment, and disconnect the USB cable. © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 FIRMWARE UPDATING 6 - 13...
Page 216 After the updating is completed, check each data version in the Setting Mode (08) to confirm that the data were overwritten properly. 08-900:System firmware ROM version 08-921:FROM internal program e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved FIRMWARE UPDATING 6 - 14...
Page 217: Power Supply Unit
The following is an output channel for the cover switch line. 1. +24V +24VCOV-OFF: CN104 Pins 21 and 22 Output to the MAIN board, PFU (via MAIN board) © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 POWER SUPPLY UNIT 7 - 1...
Page 218: Fuse
SOL2 Contact image sensor unit +24VDF F202: 4A +24VCOV-OFF MAIN board Toner motor F201: 4A Main motor Exhaust fan Auto-toner sensor Discharge LED Coin controller e-STUDIO181/211 © 2009 TOSHIBA TEC CORPORATION All rights reserved POWER SUPPLY UNIT 7 - 2...
Page 219: Configuration Of Power Supply Unit
Configuration of Power Supply Unit CN104 CN113 CN108 CN105 Regulator CN101 CN106 Fig. 7-1 © 2009 TOSHIBA TEC CORPORATION All rights reserved e-STUDIO181/211 POWER SUPPLY UNIT 7 - 3...
Page 223: 8.2 Dc Wire Harness
8.2 DC Wire Harness...
Page 224: 8.3 Electric Parts Layout
8.3 Electric Parts Layout [A] Scanner, control panel [B] Power supply section, switches [C] Laser unit, fuser unit, toner cartridge section [D] Developer unit section CTIF THMO2 CTRG LPNL LAMP1 LAMP2 THMS4 THMO1 THMS1 THMS2 THMO3 THMS3 [E] Driving section [F] Drawer section [G] Bypass unit CLT1...

This manual is also suitable for:

E-studio211

Toshiba e-STUDIO181 Service Handbook

Quick Links

Troubleshooting

Related Manuals for Toshiba e-STUDIO181

Summary of Contents for Toshiba e-STUDIO181

This manual is also suitable for:
