4-456-782-11(2) LED TV Operating Instructions KDL-42W674A / 42W654A / 32W674A / 32W654A...
Page 2
Manufactured under license from Dolby Laboratories. “BRAVIA” and are trademarks of Sony Corporation. TrackID is a trademark or registered trademark of Sony Mobile Communications AB. Music and video recognition technology and related data are provided by Gracenote®. Gracenote is the industry standard in music recognition technology and related content delivery.
About this manual (Operating Instructions) This manual explains how to set up your TV. For more information on how to use BRAVIA TV, refer to the “Electronic manual”. Operating Instructions Explains how to set up your TV such as connections, initial set-up, and basic operations.
Table of Contents Getting Started Checking the accessories................. 6 Inserting batteries into the remote control..........6 1: Attaching the Table-Top Stand ............. 7 2: Connections ..................8 3: Preventing the TV from toppling over..........10 4: Bundling the cables ................11 5: Connecting the TV to the Internet............
Getting Started Checking the Inserting batteries accessories into the remote control Remote control (1) Size AAA batteries (R03 type) (2) AC power cord (mains lead) (1) AC adapter (1) Cable holder (1) Table-Top Stand (1)* Fixing screws for Table-Top Stand (M5 ×...
1: Attaching the Detaching the Table-Top Table-Top Stand from the TV Stand To detach the Table-Top Stand from the TV, remove the screws fixed in step 2. • Do not remove the Table-Top Stand for any Refer to the supplied Table-Top Stand leaflet for reason other than to install corresponding proper attachment.
2: Connections To connect a Set Top Box/recorder (e.g. DVD recorder) with HDMI • Use an antenna (aerial) cable connector no greater than 14 mm in thickness. • Use an HDMI cable connector within 12 mm (thickness) × 21 mm (width). •...
Page 9
Connecting an antenna (aerial)/cable Connecting audio/video and VCR devices AV cable (not supplied) Antenna (aerial) cable (not supplied) AV cable (not supplied) Antenna (aerial) cable (not supplied) DVD recorder (Continued)
3: Preventing the Connecting MHL device TV from toppling over Soft cloth Use authorized MHL2 cable with MHL logo MHL device (not supplied) The MHL (Mobile High-Definition Link) enables the TV to communicate with a connected MHL-compatible device. The TV can charge the connected MHL-compatible device while playing photo/music/video from it.
4: Bundling the 5: Connecting the cables TV to the Internet • Do not bundle the AC power cord (mains lead) When you connect this TV to the Internet, you together with other cables. can enjoy multiple functions. For details on the functions, refer to the i-Manual.
6: Performing the Preparing a wireless LAN initial set-up KDL-42/32W674A The built-in wireless LAN device allows you to access the Internet and your home network. With this feature, you can connect to a wireless LAN and enjoy the benefits of networking in a cable-free environment.
Page 13
Press V/v/B/b to select an item, then press Follow the instructions on the screen. Programme Sorting: Changes the order of analogue channels stored in the TV. Press V/v to select the channel you want to move to a new position, then press Press V/v to select the new position for the channel, then press •...
Using Your BRAVIA TV Watching TV Turn on the TV. Press =/1 on the TV or remote control to turn on the Select a mode. Select a TV channel or select an input. To select digital channels Use 0-9. For channel numbers 10 and above, press the next digit quickly.
Page 15
Frequently used buttons Subtitle setting You can turn subtitle on/off while watching digital broadcasting. 2 AUDIO You can select the sub sound or secondary language while watching multiplex broadcasts. 3 Colour buttons When the colour buttons are available, an operation guide appears on the screen. 4 GUIDE Displays the digital programme guide.
Selecting various functions and settings (Home Menu) You can select the features of your TV from the Home menu. Here is an example on how to select an item and modify the TV settings. Press HOME. Press V/v to select “Settings” category.
Page 17
Category list Category The categories are available depending on your TV model, region and country. Featured Provides information on available applications and content. If there is no network connection, or the “Featured Display” setting is set to “Off”, the “Featured” category will not be displayed. History Displays recently viewed items.
Watching Internet Video This feature serves as a gateway to Internet content, delivering a variety of on-demand entertainment straight to your TV. You can enjoy video content, including movies and cartoons. You will need to make a broadband Internet connection. For details, see page 11 (5: Connecting the TV to the Internet).
Looking for Instructions Looking for instructions in the electronic manual (i-Manual) Operating instructions are built into your BRAVIA TV and can be displayed on the screen. To learn more about your TV features, access your i-Manual with the touch of a button. Press i-MANUAL.
Page 20
Saving frequently viewed Displaying the page again pages (Bookmark) while operating the TV You can save frequently viewed pages for easy You can switch between the i-Manual screen access anytime. and the TV screen. This feature allows you to refer to the instructions in the i-Manual while To save a page using your BRAVIA TV.
Press "/1 on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre of how the indicator flashes (number of flashes). When the illumination LED is not flashing, check the items in the tables as follows.
Specifications System Panel system LCD (Liquid Crystal Display) Panel TV system Analogue: B/G, I, D/K, M, L Digital: DVB-T2 (Depending on your TV model) DVB-T Colour/video system Analogue: PAL, SECAM, NTSC3.58, NTSC4.43 Digital: Refer to the i-Manual Channel coverage Analogue: UHF/VHF/Cable, Depending on your country/area selection. Digital: UHF/VHF, Depending on your country/area selection.
Page 23
Model name KDL- 42W674A 32W674A 42W654A 32W654A Power and others Power Requirements 19.5 V DC with AC adapter Rating: Input 110 V - 240 V AC, 50/60 Hz Screen size Approx.106.7cm/42 inches Approx. 80.1cm/32 inches (measured diagonally) Display resolution 1,920 dots (horizontal) × 1,080 lines (vertical) 1,920 dots (horizontal) × 1,080 lines (vertical) Power consumption 84 W (when using the AC adapter) 67 W (when using the AC adapter)
– Use only Sony supplied AC power • Two or three people are needed to • Please ensure that the AC power cords (mains lead), not those of transport a large TV set.
Page 25
• If the TV is placed in the changing Ask your dealer or Sony service centre room of a public bath or hot spring, to have it checked by qualified service the TV may be damaged by airborne personnel.
Precautions Handling and cleaning the Optional Equipment screen surface/cabinet of Keep optional components or any equipment emitting electromagnetic the TV set radiation away from the TV set. Be sure to unplug the AC power cord Otherwise picture distortion and/or (mains lead) connected to the TV set Viewing the TV noisy sound may occur.
