Operating Instructions Portable Stereo CD System Model No. RX-DU10 Table of contents Caution for AC mains lead....3 Supplied accessory......4 Safety precautions......4 Power supply........5 Control reference guide....6 General operation......7 CD play..........7 MP3 CD operation......8 Program play........9 USB..........10 Listening to other sources....10 Thank you for purchasing this product.
Page 2
CLASS 1 LASER PRODUCT IEC60825-1:2001 CAUTION This product contains a laser diode of higher class than 1. To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product. Refer all servicing to qualified personnel. WARNING: To reduce the risk of fire, electric shock or product damage, •...
Caution for AC mains lead (When using the moulded three pin Before use Remove the connector cover. mains plug) For your safety, please read the following text How to replace the fuse carefully. The location of the fuse differ according to the This appliance is supplied with a moulded type of AC mains plug(figures A and B).
Supplied accessory Safety precautions • Avoid using or placing this unit near sources of Please check and identify the supplied acces- heat. Do not leave it in an automobile exposed sory. to direct sunlight for a long time with the doors and windows closed as this may deform the AC mains lead cabinet.
Note: Power supply • The installed batteries are automatically disconnected when the mains lead is connected to the unit. AC Power • The function selector switch does not separate Connect the AC mains lead firmly to the unit entire unit from mains even if in “OFF” and the household mains socket.
Control reference guide 1. Bass button (D.BASS) 9. Tuning control (TUNING) 2. Volume control (VOLUME) 10. CD compartment lid (q OPEN/CLOSE) 3. Display 11. Music port jack (MUSIC PORT) 4. Headphones jack ( 12. Repeat/Random button 5. Function selector switch (CD/USB, RADIO, (REPEAT/ RANDOM) MUSIC PORT, OFF) 13.
CD play General operation Use compact discs bearing the Adjusting the volume symbol shown as right. In addi- Turn the VOLUME control. tion to conventional 12cm CDs, this system can be used to play 8cm CDs with- Expanding the bass sound out an adapter.
Pause play MP3 CD operation Press i PLAY/PAUSE] during play. Press the button again to resume play. This unit can play the CD-R/RW that has re- corded music data, MP3 files. Before playing Skip tracks MP3 CD, please read the following. Press [e] or [f].
MP3 CD directory sample: Program play Play order: song01vsong02v... song14 Up to 20 tracks on a disc can be programmed MP3 CD for play in any order. Folder number F01 There is no MP3 file. • Before programming procedure, set function The unit skips it.
Listening to other sources Before use Connect the audio cable (not supplied) from Connect the USB memory device to the USB the audio output socket of a video/auxiliary port of the unit correctly. equipment to the MUSIC PORT jack. (Stereo Mini Plug: ø3.5mm) Set function selector switch to [MUSIC PORT].
Troubleshooting guide Before requesting service, make the following checks. If you are in doubt about some of the check points, or if the solutions indicated in the chart do not solve the problem, consult your dealer for instructions. Common problems ■...
DC 9 V (6 x R14/LR14) Sampling frequency Battery duration time 44.1 kHz Approx. 12 hours 32,44.1,48 kHz *Panasonic alkaline battery LR14 type Bit rate (MP3) 32-320 kbps (Continuation playback of CD the volume at Pick up the time of reproduction is about 70%) Wave length(CD) 790 ±...
