Husqvarna 65021CHV Owner's Manual

Husqvarna electric lawn mower owner's manual
Hide thumbs Also See for 65021CHV:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
65021CHV
Owner's Manual
532 41 09-12 12.07.06 BY
Printed in U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna 65021CHV

Summary of Contents for Husqvarna 65021CHV

  • Page 1 65021CHV Owner’s Manual 532 41 09-12 12.07.06 BY Printed in U.S.A.

  • Page 2: Safety Rules

    Safe Operation Practices for Walk-Behind Mowers IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. Look for this symbol to point out im- portant safety precautions.

  • Page 3: Table Of Contents

    (motor) running. Disconnect spark plug wire, and keep WARNING: This lawn mower is equipped with an internal com bustion engine and should not be used on or near any unimproved forest-covered, brush-covered or grass-cov ered land unless the engine’s exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).

  • Page 4: Assembly

    IMPORTANT: THIS LAWN MOWER IS SHIPPED WITH- OUT OIL OR GASOLINE IN THE ENGINE. Your new lawn mower has been as sembled at the factory with the ex ception of those parts left unassembled for ship- ping purposes. All parts such as nuts, washers, bolts, etc., necessary to com plete the as sembly have been placed in the parts bag.

  • Page 5: Operation

    KNOW YOUR LAWN MOWER READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR LAWN MOWER. Compare the illustrations with your lawn mower to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference.

  • Page 6: How To Use Your Lawn Mower

    The operation of any lawn mower can result in foreign objects thrown into the eyes, which can result in severe eye damage. Always wear safety glasses or eye shields while operating your lawn mower or per- forming any adjustments or repairs. We recommend standard safety glasses or a wide vision safety mask over spectacles.

  • Page 7: Before Starting Engine

    1. Mulcher plug installed. 2. Discharge defl ector installed. OPERATION CAUTION: Do not run your lawn mower without mulcher plug or ap proved grass catcher in place. Never at tempt to op- erate the lawn mow er with the rear door removed or propped open.

  • Page 8: Operation

    • For best results, adjust the lawn mower cutting height so that the lawn mower cuts off only the top one-third of the grass blades (See Fig. 9). If the lawn is overgrown it will be necessary to raise the height of cut to reduce pushing effort and to keep from overloading the engine and leaving clumps of mulched grass.

  • Page 9: Maintenance Schedule

    5 - And after each 5 hours of use. GENERAL RECOMMENDATIONS The warranty on this lawn mower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain mower as instructed in this manual.

  • Page 10: Tires, Drive Wheels

    1. Disconnect spark plug wire from spark plug and place wire where it cannot come in contact with plug. 2. Turn lawn mower on its side. Make sure air fi lter and carburetor are up. 3. Use a wood block between blade and mower hous ing to prevent blade from turning when re moving blade bolt.

  • Page 11: To Change Engine Oil

    Change the oil after every 25 hours of operation or at least once a year if the lawn mower is not used for 25 hours in one year. Check the crankcase oil level before starting the engine and after each fi...

  • Page 12: Service And Adjustments

    1. Remove drive cover and belt keeper. 2. Remove belt from gearcase pulley by push ing down on pulley and rolling belt off it. 3. Turn lawn mower on its side with air fi lter and car bu- retor down. 4. Remove blade and debris shield.
  • Page 13 Your engine speed has been factory set. Do not attempt to increase engine speed or it may result in personal injury. If you believe that the engine is running too fast or too slow, take your lawn mower to an authorized service center for repair and adjustment. CARBURETOR Your carburetor is not adjustable.

  • Page 14: Storage

    30 days or more. LAWN MOWER When lawn mower is to be stored for a period of time, clean it thoroughly, remove all dirt, grease, leaves, etc. Store in a clean, dry area.

  • Page 15: Troubleshooting

    1. Depress control bar to upper handle before pulling starter rope. 2. Contact a qualifi ed service center. 3. Replace blade adapter. 4. Move lawn mower to cut grass or other hard surface before starting. 1. Raise cutting height. 2. Replace blade.

  • Page 16: Repair Parts

    ROTARY LAWN MOWER - - MODEL NUMBER 65021CHV (96143001900) - PRODUCT NUMBER 961 43 00-19...

  • Page 17: Warranty

    873 80 05-00 Nut, Hex 5/16-18 IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty. NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm...
  • Page 18 ROTARY LAWN MOWER - - MODEL NUMBER 65021CHV (96143001900) - PRODUCT NUMBER 961 43 00-19...
  • Page 19 (Includes Knob and Bearing) IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts. Failure to do so could be hazardous, damage your lawn mower and void your warranty. NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm...
