Hitachi CP-EX250 Technical Specifications

CP-EX250
Technical Specifications
Composite Video
HDMI
Security Bar
Audio In
320 mm
b
(Top)
c
(Bottom)
a
Image size 4:3 (from projector's end)
Screen size Projection distance (a)
(diagonal) Wide (m)
30" (0.8m) 0.9
40" (1.0m) 1.2
50" (1.3m) 1.5
60" (1.5m) 1.8
100" (2.5m) 3.0
200" (5.1m) 6.0
300" (7.6m) 9.1
Image size 16:9 (from projector's end)
Screen size Projection distance (a)
(diagonal) Wide (m)
30" (0.8m) 0.9
40" (1.0m) 1.3
50" (1.3m) 1.6
60" (1.5m) 1.9
100" (2.5m) 3.3
200" (5.1m) 6.6
300" (7.6m) 9.9
HITACHI DIGITAL MEDIA, Hitachi Europe Ltd, Whitebrook Park,
Lower Cookham Road, Maidenhead, Berkshire SL6 8YA UNITED KINGDOM
Tel: +44 (0)1628 585 000 Fax: +44 (0)1628 585 163
www.hitachidigitalmedia.com
*The stated lamp and filter life refers to the average life expected in ideal operating conditions with usage in accordance with the manual. The majority of, but not all lamps and filters should achieve this figure. **Where a lamp fails within warranty and a replacement lamp is taken,
the warranty for the replacement lamp will be a maximum of 3 years (dependent on warranty hours stated). HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. The specification above and photography is for
reference only and may be subject to change.
Computer In 1
Computer In 2/Monitor Out
Control (RS-232C)
Audio Out
a: Projection distance
b: Lens centre to the higher edge of the screen
c: Lens centre to the lower edge of the screen
Screen height (cm)
Tele (m) b (top) c (bottom)
1.0 39 7
1.4 52 9
1.8 65 11
2.1 78 13
3.6 131 22
7.2 261 44
10.9 392 65
Screen height (cm)
Tele (m) b (top) c (bottom)
1.1 36 1
1.5 49 1
1.9 61 1
2.3 73 2
3.9 122 3
7.9 243 6
11.9 365 9

OPTICAL

LCD Panel 0.63" (1.6cm) P-Si TFT x 3
Resolution XGA (1024 x 768)
White light output (brightness) 2700 ANSI Lumens (Bright Mode)/1800 ANSI Lumens (Normal Mode)
Colour light output (colour brightness) 2700 ANSI Lumens (Bright Mode)/1800 ANSI Lumens (Normal Mode)
Contrast ratio 2000:1
Lens Manual focus, Manual zoom x 1.2
Lamp wattage 215W UHP
Lamp life 5000 hours (Bright Mode)/6000 hours (Normal Mode)
Diagonal display size 30~300" (76~762cm)
Number of colours 8 Bit/colour, 16.7M colours
Keystone 6:1 upward shift, fixed
Focus distance 0.8m~9.0m (Wide), 1.0m~10.8m (Tele)
Distance to width ratio 1.5 (Wide), 1.8 (Tele)

COMPATIBILITY

Computer compatibility IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+,
UXGA (compressed), MAC 16"
Composite/S-Video NTSC, PAL, SECAM, PAL-M, PAL-N, NTSC4.43
Component Video 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60),
1125p(1080p@50/60), 750p(720p@50/60)
HDMI Video Signal: 525i(480i), 525p(480p), 625i(576i), 1125i(1080i@50/60),
750p(720p@50/60), 1125p(1080p@50/60)
Plug & Play DDC2B

FEATURES

Speakers 1W x 1 (mono)
Basic functions Freeze, Magnifying, Blank, Auto signal search, Auto eco mode
Picture adjustments Aspect selection (video, data, HDMI), Equalizing digital gamma
correction, Equalizing colour temperature adjustment, 2-3 pull down for
NTSC, Mirror reverse image, Up-side down image, Progressive scan,
Noise reduction, Overscan
Digital keystone correction Vertical ±30° (XGA@60Hz)
Advanced features MyScreen, My Memory, My Button, My Text, My Source, Picture mode
(normal, cinema, dynamic, blackboard, whiteboard greenboard, photo),
Input source naming (English), Resolution setting, Filter timer, Template,
Closed Caption (for NTSC & component 480i only), Framelock, Eco
Mode (normal, eco, intelligent eco, saver), ImageCare
Outward Easy lamp replace from top, Easy access air filter
Power on & off Direct on, Auto off
Security systems Security bar, PIN-lock, MyScreen password, Key lock (key pad and
remote control), Kensington slot, My Text password
OSD languages English, French, German, Spanish, Italian, Norwegian, Dutch,
Japanese, Portuguese, Simplified Chinese, Traditional Chinese, Korean,
Swedish, Russian, Finnish, Polish, Turkish, Arabic, Persian, Czech,
Danish, Hungarian, Romanian, Slovenian, Croatian, Greek, Lithuanian,
Estonian, Latvian, Thai, Portuguese (Brazil), Indonesian, Vietnamese

CONNECTIONS

Digital input 1 x HDMI (HDCP compatible)
Computer input 1 x 15-pin Mini D-sub (shared with analogue component video input)
1 x 15-pin Mini D-sub (shared with analogue component video input
and Monitor Out)
Monitor output 1 x 15-pin Mini D-sub (shared with analogue computer In 2 and
analogue component video input)
Video input 1 x 15-pin Mini D-sub (shared with analogue computer In 1 and
analogue computer In 2)
1 x RCA for composite
Audio input 1 x pair RCA (L/R)
Audio output 1 x pair RCA (L/R)
Control 1 x 9-pin D-sub for RS-232C control
POWER
Power supply 100-120V/220-240V, auto switching
Power Consumption/Standby 300W/<0.5W (AC 220-240V)
PHYSICAL
Dimensions (W x H x D) 320 x 85 x 245mm (excluding feet and extrusions)
Weight 2.9Kg
Noise level 29dB (Normal Mode)/37dB (Bright Mode)
Air filter Urethane (Up to 2000 hours)
MISCELLANEOUS
Indicator lights (lamp, temp, power), Ceiling mount image, Rear projection image, Serial number label on side,
MAC PC support
CERTIFICATION
UL60950-1/cUL, FCC Part 15 subpart B class B, CE Marking: EN61000-3-2, EN61000-3-3, EN55022, EN55024
(EMC Directive), EN60950-1 (Low voltage directive), WEEE, RoHS, ErP (lot6) compliant, c-tick class B
ACCESSORIES SUPPLIED
Remote control with batteries (HL02881), Computer cable, Power cord, User manual (detail & concise)
OPTIONAL ACCESSORIES
Replacement lamp DT01433
WARRANTY
Projector/Lamp 3 Years/3 Years
*
™
**
