HP ProLiant DL140 Quickspecs

Generation 3 (g3)
Hide thumbs Also See for ProLiant DL140:
Table of Contents

Advertisement

Quick Links

See also: User Manual
:: Seite 1 von 29 :: Datenblatt zum Produkt HP ProLiant DL140 (G3) / 1.60G DC mit DC# 128191 ::
QuickSpecs
Overview
Front View:
1. Access panel
2. Two Non-Hot Plug SATA 3.5" Hard Drive Bays or Two
Hot Plug SAS/SATA 3.5" Hard Drive
3. Optional CD- or DVD-ROM drive
4. System LEDs
5. USB Port
6. Power on/off
7. System Fans
8. Quad-Core and Dual-Core Intel® Xeon™ Processors
(Supports up to Two)
9. PC2-5300 Fully Buffered DIMMs (DDR2-667) memory
slots
10. Expansion Slots:
Non-Hot Plug Models - Two available PCI-Express slots
Hot-Plug Models - One available PCI-Express slot
11. Power Supply (650 Watts)
12. SAS/SATA Hot Plug Backplane (Hot Plug SAS/SATA
Model)
What's New
One year of 24 x 7 HP Software Technical Support and Update Service included with Insight Control management
suites and select ProLiant Essentials Licenses.
At A Glance
Fragen zu dem Produkt HP ProLiant DL140 (G3) / 1.60G DC? Kein Problem - wir helfen Ihnen per eMail (info@diskontcomputer.com) gerne weiter!
http://www.diskontcomputer.com/Systeme/Server/HP_ProLiant_DL140_(G3)___1.60G_DC_DC_128191.html
Hot Plug SAS/SATA Models
Rear View:
1. Two GbE LAN ports for NIC 1 and NIC 2 (RJ-45)
2. Low-Profile PCI Express x8/PCI-X riser board slot cover
3. Rear USB ports
4. Video Port
5. Serial Port
6. PS/2 Keyboard Port
7. PS/2 Mouse Port
8. LO100i 10/100 Mbps LAN port for IPMI management (RJ-
9. Standard height/full-height PCI Express x16/PCI-X riser
10. Power Supply Cable Socket
DA - 12509 Worldwide — Version 14 — July 9, 2007
Den aktuellen Preis und Lagerstand finden Sie online auf
HP ProLiant DL140 Generation 3 (G3)
45)
board
diskontcomputer.com
Firma Matzner Michael
Wiener Bundesstraße 38
4061 Pasching, Austria
Page 1
