- Page 1 Model ENGLISH+RUSSIA Language 20 PAGE Page Color(cover/body) 190*260 Weight 100G Material Size(W*H) Wangzhenzhong 2006.09.14 Date Designer MFL32930805 MANUAL,OWNERS Part No. Description Chage Record Change content Designer Confirm Date ECO No.
- Page 2 V-C7B71H* V-C7B72H* V-C7B73N* V-C7B81H*...
-
Page 3: Table Of Contents
Table of contents Information for Your Safety..................3 How to Use.........................4 Assembling cleaner .......................4 Using the cleaning head and Accessory Nozzles..............6 Emptying the Dust Chamber ....................8 Cleaning the Filter ........................9 Operating the cleaner ......................10 Cleaning the Exhaust Filter ....................11 How to use elbow tube, turbine brush .................12 User's guide for sani punch vacuum nozzle ............13 Features ..........................13 Cleaning Vacuum Nozzle for Bedding.................15... -
Page 4: Information For Your Safety
Do not use the appliance If the power cord is damaged or faulty. If the power cord is damaged, it must be replaced by an approved LG Electronics Service Agent to avoid a hazard. Always switch the vacuum cleaner off before: Emptying the dust chamber. -
Page 5: How To Use
How to Use Assembling Cleaner Fit the large cleaning head into the end of the tube. Spring latch (depending on model) Telescopic tube The 2 position head,Turbine Brush(depending on model) Telescopic tube (depending on model) Push telescopic tube into • Press the spring latch to release. nozzle outlet. - Page 6 Head Flexible Hose HT** HE** NT** NE** Attachment Point Button Connecting the flexible hose • Push the end of the head on the flexible hose CAUTION into the attachment point on the vacuum cleaner. • To remove the flexible hose from the vacuum •...
-
Page 7: Using The Cleaning Head And Accessory Nozzles
How to Use Using the cleaning head and Accessory Nozzles Tear the vinyl bag and pull out accessories. Attach the accessory holder onto the telescopic tube. And then, fit the Dusting Brush, Crevice Tool and Upholstery Nozzle onto the accessory holder. Fit the accessory onto the end of the tube. Upholstery nozzle Dusting brush Crevice tool... - Page 8 (depending on model) (depending on model) (depending on model) (depending on model) (depending on model) Pedal Extension Pipe for Length Adjustment Suction Hole for Device Protection Sani punch nozzle (depending on model) The 2 position head (depending on model) Suction Hole for Device Protection Sani punch( •...
-
Page 9: Emptying The Dust Chamber
How to Use Emptying the dust chamber Pleat-shaped internal filter Circle-shaped external filter Dust chamber cap Dust chamber cap Dust chamber Dust chamber Plate Button Suction power may be weakened when insignificant dusts • Open the dust chamber cap. are sucked. In this case, clean the filter. •... -
Page 10: Cleaning The Filter
How to Use Cleaning the Filter Button The reusable filters are situated under the dust chamber cap and WARNING! you can use it permanently. • Press the button and pull the dust chamber forward. Gently rinse both parts separately under a cold running water until the water •... -
Page 11: Operating The Cleaner
How to Use Operating the cleaner. Switch button Suction control switch Cord reel button Regulator Plug How to Plug in and Use Adjusting the Suction level(depending on model) Park System • To store after vacuuming and pause • Pull out the power cord to the desired length •... -
Page 12: Cleaning The Exhaust Filter
How to Use Cleaning the Exhaust Filter Filter cover • The exhaust filter is a washable and reusable HEPA filter. • To change the exhaust filter, remove the filter cover on the body by release hook. • Pull out the exhaust filter. •... -
Page 13: How To Use Elbow Tube, Turbine Brush
How to use elbow tube, turbine brush (depending on model) Cleaning Powerful Turbine Brush Open (depending on model) Spring latch Air control lever Open (depending on model) Spring latch Bottom Turbine Brush Elbow tube Elbow tube is for cleaning under the sofa, •... -
Page 14: User's Guide For Sani Punch Vacuum Nozzle
User's guide for sani punch vacuum nozzle (depending on model) Features How to use This nozzle picks up even dust inside through beating. Follow the directions below for proper use. The bottom part can be separated to be cleaned. Since the bottom does not stick to the surface, vacuuming is easy. Assembly Connect the nozzle to the telescopic tube. - Page 15 This Sani Punch nozzle is for effective cleaning of beds and blankets to remove mites and dust. Effective cleaning Bed & blanket Bulky & heavy blanket Light blanket & sheet When using on the bed When using on the floor Lay out the blanket It is easier to clean a light blanket or sheet and vacuum it on the bed...
-
Page 16: Cleaning Vacuum Nozzle For Bedding
User's guide for sani punch vacuum nozzle Cleaning Vacuum Nozzle for Bedding(depending on model) For simple cleaning of the vacuum nozzle, detach the Sani Punch nozzle from the telescopic tube and attach the crevice tool to vacuum dust. Bottom Since the vibrator inside is composed of precision parts, never disassemble the body. Be careful not to let foreign objects clog the air suction part on top of the vacuum nozzle. - Page 17 Follow the instruction below for through washing. (Do not soak the entire body of the vacuum nozzle in water, it may cause the vibrator to malfunction) Bottom plate Bottom plate Punch bar Punch bar Press the button on the Wipe all the soiled parts Wash the removed bottom rear side of the vacuum of the vacuum nozzle...
-
Page 18: What To Do If Your Vacuum Cleaner Does Not Work
What to Do if Your Vacuum Cleaner Does Not Work Check that the vacuum cleaner is correctly plugged in correctly and that the electrical socket is working. What to Do When Suction Performance Decreases • Turn off the vacuum cleaner and unplug it. •... - Page 19 Disposal of your old appliance 1. When this crossed-out wheeled bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately from the municipal waste stream via designated collection facilities appointed by the government or the local authorities.
