Operating Instructions
CD Stereo System
Model No.
Table of contents
Safety precautions ........................... 2
Caution for AC Mains Lead .............. 3
Supplied accessories ....................... 3
Placement of speakers .................... 3
Getting started .................................. 4
Overview of controls ........................ 6
CDs and MP3 - Play ......................... 7
Cassette tape - Play and record ..... 12
Radio - Tune ..................................... 14
Timer .................................................. 15
Sound adjustment ............................ 17
External unit ...................................... 17
Troubleshooting guide ..................... 18
Specifi cations ................................... 20
RQT8043-2B
Advertisement
Table of Contents
Related Manuals for Panasonic SC-PM41
Summary of Contents for Panasonic SC-PM41
-
Page 1: Table Of Contents
Operating Instructions CD Stereo System The above illustration of the unit is an example for the United Kingdom and Continental Europe. SC-PM41 Model No. Table of contents Note: Safety precautions ......2 “EB” on the packaging indicates the United Kingdom. -
Page 2: Sc-Pm41
• E-mail: customer.care@panasonic.co.uk mobile telephones during use. If such interference is apparent, please increase separation between the product Direct Sales at Panasonic UK and the mobile telephone. • Order accessory and consumable items for your product with ease and confi dence by phoning our Customer Care Centre Monday- Friday 9:00am-5:30pm. -
Page 3: Caution For Ac Mains Lead
Caution for AC Mains Lead Supplied accessories (For United Kingdom) Please check and identify the supplied accessories. Use numbers indicated in parentheses when asking for (“EB” area code model only) replacement parts. (As of January 2005) For your safety, please read the following text carefully. 1 x Remote Control 1 x AC mains lead This appliance is supplied with a moulded three pin mains plug for your... -
Page 4: Getting Started
Getting started Step Step 1 1 - Making the connections - Making the connections Connect the AC power supply cord only after all other connections have been made. Preparation Twist and pull off the vinyl tip of the speaker cords. If the speaker cords do not have vinyl tips, directly connect them to the terminals. -
Page 5: Step 2 - Inserting Batteries Into The Remote Control
Optional antenna connections Optional antenna connections FM outdoor antenna AM outdoor antenna FM outdoor antenna AM outdoor antenna (not included) (not included) F M A N A M A N F M A N A M A N L O O P coaxial AM loop antenna cable... -
Page 6: Overview Of Controls
Overview of controls Main unit Main unit Refer numbers in parentheses for page reference. Top of the unit Headphone jack (PHONES) Avoid listening for prolonged periods of time to prevent Cassette lid (12) hearing damage. Plug type: 3.5 mm stereo (not included) 1 Standby/on switch (y/l) (7, 16) Press to switch the unit from on to standby... -
Page 7: Cds And Mp3 - Play
CDs and MP3 – Play Numeric buttons CD trays Playing a disc Playing a disc Play Mode function Play Mode function Press [y] to turn the unit on. Press [CD 6] and then [CLEAR 7]. Press [CD 1 ~ CD 5] to select your desired tray. Press [DISC] and (within 10 seconds) press [1] ~ [5] to select the disc. -
Page 8: Advanced Cds And Mp3 Functions
CDs and MP3 – Play (Continued) C C hecking which CDs are in the trays hecking which CDs are in the trays Advanced CDs and MP3 functions Advanced CDs and MP3 functions (CD CHECK) (CD CHECK) CD-DA Press [CD CHECK]. Creating your CD titles Creating your CD titles CD-DA... - Page 9 Entering characters Entering characters Press [ENTER]. Repeat steps 6 to 8 to program other tracks. Press the numeric buttons repeatedly to select your Example: desired character then press [3/FF/¢] to key in the next character. • You can enter up to 32 characters. •...
- Page 10 CDs and MP3 – Play (Continued) Finding your CD titles Finding your CD titles Repeat play Repeat play CD-DA CD-DA This function allows you to display disc, album and You can repeat program play or other selected track titles, then select to start play. play mode.
- Page 11 Album/Track title search Album/Track title search NOTE on CDs • This unit can access up to 99 tracks. Enable you to search your desired album or track. • Choose CD with this mark. Press [CD 6] and then [CLEAR 7]. •...
-
Page 12: Cassette Tape - Play And Record
Cassette tape – Play and record Top of the unit Cassette lid Basic play Basic play TPS (Tape Program Sensor) TPS (Tape Program Sensor) This function enables you to search the beginning of a track, Press [OPEN 0] on top of the unit. up to a maximum of 9. -
Page 13: Recording The Radio
Recording the radio Recording the radio Other basic operations Other basic operations Action Do the preparatory steps (refer page 12). erase a recorded 1) Insert the cassette to be recorded on. Tune to the required station (refer page 14). 2) Press [TAPE `] and then [CLEAR 7]. sound 3) Press [¶REC/8]. -
Page 14: Radio - Tune
Radio – Tune Numeric buttons Manual tuning Manual tuning Memory preset Memory preset Up to 15 stations each can be set in the FM and AM bands. Press [TUNER/BAND] to select “FM” or “AM”. Preparation Press [PLAY MODE] to select “MANUAL”. Press [TUNER/BAND] to select “FM”... -
Page 15: Timer
Timer Setting the clock Setting the clock Using the sleep timer Using the sleep timer This function enables you to turn off the unit automatically This is a 24-hour clock. after the set time. Press [CLOCK/TIMER] to select “CLOCK”. Press [SLEEP, –AUTO OFF] to select your desired time. Each time you press the button: SLEEP 30 SLEEP 60... -
Page 16: Using The Play Or Record Timer
Timer (Continued) To enjoy the desired source after the timer setting is Using the play or record timer Using the play or record timer completed. The volume level (for play timer) and music source are stored You can set the timer to come on at a certain time to wake in the timer memory and the timer will start in these preset you up (play timer) or to record from the radio or an aux conditions. -
Page 17: Sound Adjustment
Enjoying surround sound Enjoying surround sound Sound adjustment Enable you to add natural width and depth to the stereo sound. To activate Press [SURROUND] to display “ ” indicator. To cancel Press [SURROUND] again to clear “ ” indicator. • Surround sound is less discernible when listening through headphones. -
Page 18: Troubleshooting Guide
Troubleshooting guide Before requesting service, make the below checks. If you can’t fi x the system as described below, or if something not listed here occurs, refer to the enclosed directory to locate an Authorized Service Center convenient to you or contact your dealer. - Page 19 SUOMI CAUTION! THIS PRODUCT UTILIZES A LASER. VAROITUS! CONTROLS ADJUSTMENTS LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ PERFORMANCE OF PROCEDURES OTHER THAN KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA THOSE SPECIFIED HEREIN RESULT ALTIS TAA KÄYTTÄJÄN TURVALLISUUSLUOKAN HAZARDOUS RADIATION EXPOSURE. YLITTÄ VÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF.
-
Page 20: Specifi Cations
Press [y/I] to turn the unit off. Wow and fl utter Below measurable limit Digital fi lter 8 fs Disconnect the AC power supply cord. D/A converter MASH (1 bit DAC) Matsushita Electric Industrial Co., Ltd. Web Site: http://www.panasonic.co.jp/global/ RQT8043-2B L0205CP2035...
