Split System Submittal Data
System: KE36NKU Indoor: CS-KE36NKU Outdoor: CU-36NKU
Wall Mounted Heat Pump
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
General Data
Power (V/P/Hz)
Circuit Ampacity (A)
Fuse Size, Max.(A)
Compressor
No. Used
R.L. Amps - L.R. (A)
Outdoor Unit
Fan Type
Dia (in.) - No. Speeds
Type Drive
No. Poles (RPM)
No. Motors (W)
F.L. Amps (A)
Coil Type
Fin Type - Pipe Type
Rows - F.P.I.
Rows - F.P.I.
Face Area (sq.ft.)
Tube Size (in.)
Indoor Unit
Fan Type
Dia (in.)
No. Speeds
No. Poles (RPM (Cool / Heat), High)
No. Motors (W)
CFM (Hi/Med/Low) Cooling
CFM (Hi/Med/Low) Heating
Operating Sound-Hi/Me/Lo/ dB-A
(Cool)
Operating Sound-Hi/Me/Lo/ dB-A
(Heat)
F.L. Amps
Coil Type
Fin Type - Pipe Type
Rows - F.P.I.
Face Area (sq. ft.)
Tube Size (in.)
Drain Connection Size (in.)
230/208/1/60
16.5-18.0
45
DC Twin Rotary (Inverter)
1
20.0-31.0
Propeller
19-9/32" Auto (Hi, Me, Lo)
Direct / DC Motor
8-750
1-142
19.6-21.5
Aluminum Fin and Copper Pipe
Slit Plate - Inner Rifled
2-21.2
2 - 18.1
8.05
3/8"
Cross Flow
3-15/16" x 32"
Auto and 3 steps
8-1,370 / 1,450
47
630/530/412
671/559/441
49 / 44 / 39
49 / 44 / 39
0.4
Aluminum Plate Fin & Copper Tube
Slit Plate - Inner Rifled
2-19.5
4.55
3/8"
1-1/4"
Approval:
Date:
Construction:
Unit#:
Drawing#:
Refrigerant
Lbs. - R410a (outdoor unit)
Refrigerant Control
Refrigerant Tubing Connections
Line Length, Max (ft.)
Line Difference, Max (ft.)
Line Size (in. O.D. Discharge)
Line Size (in. O.D. Suction)
Pre-charge, tubing length at
shipment
Dimensions (HxWxD)
Indoor Unit (Crated) (in.)
Indoor Unit (Uncrated) (in.)
Outdoor Unit (Crated) (in.)
Outdoor Unit (Uncrated) (in.)
Weight (lbs.)
(Indoor) Net
(Indoor) Shipping
(Outdoor) Net
(Outdoor) Shipping
(Indoor) Shipping Volume (cu.ft.)
(Outdoor) Shipping Volume (cu.ft.)
R410A
6.5
Electronic Expansion Valve
Flare
165
50 (outdoor lower), 100 (outdoor
higher)
3/8"
5/8"
100'
12-7/32 x 44-7/8 x 14-31/32
11-3/16 x 41-15/16 x 9-1/16
42-3/8 x 40 x 16-3/8
35-13/16 x 37-1/32 x 13-3/8
32.0
39.7
185.2
207.2
4.59
15.88
