  • Page 1 Washing Machine EWF 10190 W...

  • Page 2: Table Of Contents

    2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com Contents Safety information Care and cleaning Product description What to do if… Control panel Technical data First use Consumption values Daily use Installation Washing programmes Electrical connection...
  • Page 3 3 • All packing and transit bolts must be re- • Never use the appliance if the power sup- moved before use. Serious damage can ply cable, the control panel, the working occur to the product and to property if this surface or the base are damaged so that is not adhered to.

  • Page 4: Product Description

    4 electrolux Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Its new washing system allows total use of detergent and reduces water consumption so saving energy. Detergent dispenser drawer...

  • Page 5: Control Panel

    5 Programme Chart user manual assy. The chart in the drawer can be replaced easily: remove the chart Various programme charts in different lan- from the drawer by pulling it towards the right guages are supplied with the appliance. One...
  • Page 6 6 electrolux = Cold = Prewash = Spin button = Economy = Rinse hold = Quick wash = No spin = Extra rinse button = Delay Start Indicator Pilot Light = Washing = Door locked = End of Cycle This option is recommended for heavily Programme Selector Dial soiled laundry.

  • Page 7: First Use

    7 Indicator pilot lights After having pressed the button 6 , the pilot light 8.1 (Washing) illuminates. When the pilot light 8.1 (Washing) comes on this means that the machine is operating. The pilot light 8.2 (Door locked) illuminates when the programme starts and indicates if the door can be opened.
  • Page 8 8 electrolux quired, pour it into the main wash compart- The selector dial can be turned either clock- wise or counterclockwise. Turn to position ment or in the appropriate compartment « O » to reset programme/Switching the ma- if the selected programme/option it requires chine off.
  • Page 9 9 You must select this option after you have set Altering an option or a running the programme and before you start the pro- programme gramme. It is possible to change some options before You can cancel or modify the delay time at the programme carries them out.

  • Page 10: Washing Programmes

    10 electrolux locked to indicate that the water must be At the end of the programme, the light 8.2 emptied out before opening the door. goes off to indicate that the door can be now Follow the below instructions to empty out opened.
  • Page 11 11 Programme - Maximum and Minimum Tempera- Detergent ture - Cycle Description - Maximum Spin Speed Options Compartment - Maximum Fabrics Load - Type of Laundry WOOL SPIN REDUCTION 40° - Cold NO SPIN Main wash - Rinses RINSE HOLD Maximum spin speed 1000 rpm Max.
  • Page 12 12 electrolux Programme - Maximum and Minimum Tempera- Detergent ture - Cycle Description - Maximum Spin Speed Options Compartment - Maximum Fabrics Load - Type of Laundry MINI 30 NO SPIN 30° Main wash - Rinses Maximum spin speed 700 rpm Max.

  • Page 13: Helpful Hints And Tips

    13 2) If you select the Super Quick option by pressing button 4 , we recommend that you reduce the maximum load as indicated (Red. load = reduced load). Full loading is possible however with somewhat reduced cleaning results.

  • Page 14: Care And Cleaning

    14 electrolux If using liquid detergents, a programme • you are washing a small load without prewash must be selected. • the laundry is lightly soiled Your appliance incorporates a recirculation • large amounts of foam form during wash- system which allows an optimal use of the ing.
  • Page 15 15 2. Remove the conditioner insert from the 1. Remove any rust deposits on the drum appropriate compartment. with a cleaning agent for stainless steel. 2. Run a washing cycle without any washing to clean off any cleaning agent residues.
  • Page 16 16 electrolux 8. Refit the cap on the emergency empty- 4. Place a container close to the pump to ing hose and place the latter back in its collect any spillage. seat. 5. Release the emergency emptying hose, 9. Screw the pump fully in.

  • Page 17: What To Do If

    17 2. Unscrew the hose from the tap. on the hose. Empty the bowl. Repeat the 3. Clean the filter in the hose with a stiff procedure until water stops flowing out; brush. 6. clean the pump if necessary as previously 4.
  • Page 18 18 electrolux Problem Possible cause/Solution The door has not been closed (the button 6 red light blinks). • Close the door firmly. The plug is not properly inserted in the power socket. • Insert the plug into the power socket.
  • Page 19 19 Problem Possible cause/Solution The programme is still running. • Wait the end of washing cycle. The door lock has not been released. The door will not open: • Wait until the light 8.2 has gone out. There is water in the drum.

  • Page 20: Technical Data

    20 electrolux Technical data Dimensions Width 60 cm Height 85 cm Depth 63 cm Electrical connection Information on the electrical connection is given on the rating plate, Voltage - Overall power - Fuse on the inner edge of the appliance door.
  • Page 21 21 2. Remove the power supply cable and the draining and inlet hose from the hose holders on the rear of the appliance. 5. Open the porthole and remove the poly- styrene block fitted on the door seal. 3. Unscrew the three bolts.
  • Page 22 22 electrolux Water inlet Warning! This appliance must be connected to a cold water supply. 1. Connect the water inlet hose supplied with the machine to a tap with a 3/4" thread. Always use the hose supplied with the appliance.
  • Page 23 23 Important! Before connecting up the • In a sink drain pipe branch. This branch machine to new pipework or to pipework that must be above the trap so that the bend is has not been used for some time, run off a at least 60 cm above the ground.

  • Page 24: Electrical Connection

    24 electrolux Electrical connection injury through failure to comply with Information on the electrical connection is given on the rating plate on the inner edge of the above safety precaution. the appliance door. The power supply cable must be Check that your domestic electrical installa-...
  • Page 25 25...
  • Page 26 26 electrolux...
  • Page 27 27...
