Pioneer AVIC-8DVD Operation Manual

Hide thumbs Also See for AVIC-8DVD:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Installation Manual
DVD Navigation Unit
ENGLISH
Operation Manual
AVIC-8DVD

Advertisement

Table of Contents
loading

Related Manuals for Pioneer AVIC-8DVD

Summary of Contents for Pioneer AVIC-8DVD

  • Page 1 DVD Navigation Unit ENGLISH Operation Manual AVIC-8DVD...
  • Page 2 The screen shown in the example may differ from the actual screen. The actual screen may be changed without notice for performance and function improvements.

  • Page 3: Introduction

    Pioneer grants to you a non-transferable, non-exclusive license to use the software installed on the Pioneer products (the “Software”) and the related documentation solely for your own personal use or for internal use by your business, only on such Pioneer products.
  • Page 4 The Software and related documentation are provided to you “AS IS”. PIONEER AND ITS LICENSOR(S) (for the purpose of provisions 2 and 3, Pioneer and its licensor(s) shall be col- lectively referred to as “Pioneer”) MAKES AND YOU RECEIVE NO WARRANTY,...
  • Page 5 This is the entire Agreement between Pioneer and you regarding its subject matter. No change in this Agreement shall be effective unless agreed to in writing by Pioneer. If any pro- vision of this Agreement is declared invalid or unenforceable, the remaining provisions of...

  • Page 6: Terms And Conditions For The Navtech Data

    TERMS AND CONDITIONS for the NAVTECH Data THIS IS A LEGAL AGREEMENT (“AGREEMENT”) BETWEEN YOU, THE END USER, AND NAVIGATION TECHNOLOGIES CORPORATION (NAVTECH) AND ITS SUP- PLIERS, THE TERMS AND CONDITIONS OF WHICH ARE SET FORTH BELOW. BY USING YOUR COPY OF THE NAVTECH DATA, YOU AGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT.
  • Page 7 Termination. NAVTECH and its suppliers may terminate this Agreement at any time upon your breach of any term of this Agreement. Upon any such termination, you shall return your copy of the NAVTECH Data and all related documentation to NAVTECH and/or its suppli- ers.

  • Page 8: Table Of Contents

    Table of Contents Introduction................1 License Agreement......................1 PIONEER AVIC-8DVD ....................1 TERMS AND CONDITIONS for the NAVTECH Data...........4 Table of Contents......................... 6 Important Safety Information..................10 Notes Before Using the System..................11 Precaution ........................11 About the main unit battery ..................13 How to Read This Manual....................14 How to use this manual ....................14...
  • Page 9 Chapter 3 Setting a Route to Your Destination ........41 Basic Flow of Route Calculation..................41 Selecting the country where you want to search ............42 Perform the route calculation of the several route options, and select one ....42 Route Calculation to Your Home Location or to Your Favourite Location ..45 Selecting your Destination from the Address Book..........
  • Page 10 Registering a Password....................71 Setting Areas to Avoid......................72 Registering an Area to Avoid..................72 Changing or deleting an Area to Avoid...............73 Using Traffic Information....................74 Confirming traffic information relevant to the current route ........74 Selecting the radio station ..................76 Using a PC Card.........................78 Initialising a PC card....................78 Storing the data of registered locations in the PC card ..........78 Loading data from a PC card ..................79...
  • Page 11 Appendix .................97 Positioning Technology....................97 Handling Large Errors...................... 99 When the positioning by GPS is impossible .............. 99 Conditions likely to cause noticeable positioning errors .......... 100 Handling and Care of the Disc..................101 Resetting the System .....................102 Troubleshooting ......................103 Messages and how to react to them................106 Route Setting Information .....................109 Route search specifications ..................

  • Page 12: Important Safety Information

    Important Safety Information Before using your Navigation System, be sure to read and fully understand the following safety information: • Read the manual before operating this Navigation System. • This Navigation System is intended solely as an aid to you in the operation of your vehicle. It is not a substitute for your attentiveness, judgement, and care when driving.

  • Page 13: Notes Before Using The System

    CLASS 1 LASER PRODUCT On the top of the unit. • The Pioneer CarStereo-Pass is for use only in Germany. • Always keep the volume low enough for outside sounds to be audible. • Protect this product from moisture. Handbrake interlock Certain functions offered by this Navigation System could be dangerous if used while driving.
  • Page 14 When using this unit, make sure to start your engine first. Using this unit without starting the engine will run down the battery. About this disc For using this unit, use only the disc specified by Pioneer. You cannot use other discs.

  • Page 15: About The Main Unit Battery

    About the main unit battery The main unit of your Navigation System has a lithium battery for memory backup. Please dispose of the battery properly by following the instructions below. WARNING • Keep the lithium battery out of the reach of the children. Should the battery be swallowed, immediately consult a doctor.

  • Page 16: How To Read This Manual

    How to Read This Manual This manual provides all the information you need to make full use of your new Navigation System. The first few sections give an overview of the system and explain how to prepare it for use. The remainder is in the form of a function reference giving full details of every feature. A comprehensive list of all sections of the manual is provided in the table of contents at the begin- ning of this introduction.

  • Page 17: Chapter 1 Getting Started

    Set Switch 1 depending on the display used. ON : This is set if turning this on is recommended for a display used with this unit. OFF : When the following Pioneer displays are used for navigation display: AVX-P7000CD, AVX-7000, AVD-W8000, AVD-W6000, AVD-W6010, AVX-7300, AVX-P7300DVD...

  • Page 18: Inserting The Batteries To The Remote Controller

    sInserting the batteries to the Remote Controller Remove the battery cover, and insert two alkaline (UM-4, AAA, LR03, 1.5V) batteries. Caution • Take care to insert the batteries the right way round as shown by the + and - marks in the diagram.

  • Page 19: Setup 2: Getting To Know The Components And What They Do

    Setup 2: Getting to Know the Components and What They Do Before using this unit, get to know the name of each component and how it is used. sThe Remote Controller (1) Transmitter Signals of the Remote Controller are transmitted from here.
  • Page 20 • When the selection switch is set to “NAVI”, the volume of the voice guidance for naviga- tion is adjusted. • When the selection switch is set to “AUDIO”, the volume for Pioneer’s Head Unit is adjusted. If the dial is pressed, the volume is reduced to around 1/10th of the volume (ATT function).

  • Page 21: Microphone

    (for audio operation) ➲ Each button from (17) to (23) has the same function as the ones for Pioneer’s Head Unit, and so you can operate the Head Unit using the Remote Controller. However, some buttons become invalid depending on the combination of the models.

  • Page 22: Main Unit

    sMain unit (1) Disc loading slot (2) Reset button If the system goes wrong, reset it by pressing this recessed button with a ballpoint pen or sim- ilar pointed object. ( See “Resetting the System” on page 102 (3) Disc ejection button (4) PC card slot (5) PC card ejection button Remove the PC card by pressing this button.
  • Page 23 ➲ Do not try to use discs other than a disc designed for this system. Please use only the disc specified by Pioneer. ➲ Do not attempt to use discs that is cracked, scratched, bent, or otherwise damaged. ➲ Treat your disc carefully. See “Handling and Care of the Disc” on page 101 for advice on proper handling and use.

  • Page 24: Setup 3: Installing The Program

    Setup 3: Installing the Program The program is installed to the main unit of the Navigation System using the disc provided. When installing the program, you carry out the following operations. When all the setup proce- dures are completed, the map of your surroundings appears, and you can use the Navigation System.
  • Page 25 Caution Once the installation of the program starts, do not stop the engine of your vehicle until the installation is completed. 6 Check the details of the cautionary message and click the OK button. You can also proceed to the next step by pressing the TALK button. A message asking to set the clock appears.
  • Page 26 9 If necessary, set to summer time. Summer time is on by default. “Off” is shown on the right-hand side of “British Summer Time”. If summer time is in effect, move the joystick to select “Off” and click the OK button. When the list of selectable options (“On”...

  • Page 27: Chapter 2 Basic Operation

    Chapter Basic Operation Switching On and Off Switching On When the engine of your vehicle is running, the power of the main unit of your Navigation System is turned on. After the opening screen appears for a few seconds, a cautionary mes- sage appears.

  • Page 28: Types Of Menu

    Types of Menu You perform most tasks through using menus. A typical sequence of steps is as follows: “Select a menu, Select a menu item with the joystick, and Click the OK button”. There are two types of menu: the “Main menu” and the “Shortcut menu”. sMain menu With the map displayed, press the MENU button and the Main menu appears.

  • Page 29: Shortcut Menu

    sShortcut menu While the map is shown, click the OK button to show the Shortcut menu. You can do various tasks, such as route calculation for the location pointed by cross pointer, or registering a loca- tion in the Address Book, faster than using the normal menu. Destination You select the destination with cross pointer and the route is set ( see “Finding a destina-...

  • Page 30: Basic Navigation

    Basic Navigation This section describes basic navigation, such as how to select menu items, using setting your destination as an example. There are several methods of setting the destination but, in this example, route calculation by specifying address (Address Search) is explained. Caution For safety reasons, you cannot use these functions while your vehicle is in motion.
  • Page 31 3 Select the method of searching your destination. Select “Address Search” and click the OK button. 4 Select the country where your destination is located. When the destination is in another country, select “Country” and click the OK button. When the list of countries appears, select the desired country and click the OK button. (When searching the destination next time, the Navigation System searches the destina- tion from the data of the country selected here.) For the details of the method of selecting “Country”,...
  • Page 32 How to use text palette Move the joystick up or down, or left or right, to highlight a letter you want to enter. If you click the OK button, the selected letter appears in the text box. As you enter an one letter, your Navigation System narrows down the possible cities, and the items in the list that appears on the right-hand side of the display change accordingly.
  • Page 33 Entering letters using numeric keypad of the Remote Controller Every time you press the key, the letters assigned to the key are displayed in sequence. If you press different keys while the letter to enter to enter is selected, or if you press the OK button on the bottom-right of the numeric keypad, the selected let- ter appears in the text box.
  • Page 34 8 Select the street from the list and click the OK button. If the selected street goes across several cities For example, if the selected street goes across three cities, the list of these cities appears when you click the OK button. Select the location for your destination from the list, click the OK button to proceed to the next step.
  • Page 35 When you cannot enter the house number From the function button at the bottom of the screen, select a method of search and click the OK button. On this display, you can select the following items: Quick Route Cal The route is calculated with the well-known point (mostly, it is the middle point of the street selected previously) as your desti- (Calculation) : nation.

  • Page 36: How To Use The Map

    How to Use the Map Most of the information provided by your Navigation System can be seen on the map. You need to get to know how the information appears on the map. sHow to view the map of the current location The display is like a conventional map, and shows roads of various designations as well as geographical features such as rivers, parks, and forests.
  • Page 37 Arrow mode The direction of travel is shown by a simple arrow. When approaching a guidance point, such as an intersection, the display switches to show the distance and direction to the guidance point. Normal condition (10) (11) (13) When approaching an intersection (14) (12) (13)
  • Page 38 Guidance point* The next turning point is shown by a yellow flag. Destination* The checker-flag indicates your destination (1) Name of the street you drive next.* (2) Distance to the guidance point* (3) Current location The current location of your vehicle. The arrow shows your heading, and the display moves automatically as you drive.

  • Page 39: Changing The Scale Of The Map

    sChanging the scale of the map On the top-right of the map display, the scale of the map is shown. If you move the scale con- troller up or down, you can change the scale of the map through 16 levels: 25m, 50m, 100m, 200m, 500m, 1km, 2km, 5km, 10km, 20km, 50km, 100km, 200km, 500km, 1000km, 2000km (25yd, 50yd, 100yd, 1/4mi, 1/2mi, 3/4mi, 1mi, 2 1/2mi, 5mi, 10mi, 25mi, 50mi, 100mi, 250mi, 500mi, 1000mi).
  • Page 40 Viewing the information of the mark displayed on the map You can check the information such as address, about the mark (POI, your home, your favourite location, or an icon of TMC traffic information) specified by the cross pointer. 1 Place the cross pointer on the mark shown on the map, and click the OK button. The Shortcut menu appears.
  • Page 41 Finding a destination on the map When you select “Map search” as the search method, or when you select “Destination” in the Shortcut menu, you can specify your destination on the map. 1 Select “Map Search” from the list and click the OK button. The map display appears.

  • Page 43: Setting A Route To Your Destination

    Chapter Setting a Route to Your Destination Basic Flow of Route Calculation Based on the information you know about your destination, your Navigation System searches for your destination on the map, and calculates the route. Caution For safety reasons, these functions are not available while your vehicle is in motion.

  • Page 44: Selecting The Country Where You Want To Search

    ➲ By using the Settings menu, you can change the conditions for route calculation. For the details, see Chapter 6 “Route No.”, “Fastest/Shortest”, “Avoid Motorway”, “Avoid Ferry”, “Avoid Toll Road” on on pages 86 to 87. sSelecting the country where you want to search Information on the disc is arranged according to each country.
  • Page 45 Distance to your destination Condition of route calculation On this display, you can select the following items: Route Profile : You can view the list of the roads you drive through. Route List : You can view the list of the conditions for route calculation of all the route options and of the distances to your destination.
  • Page 46 ➲ It may take some time until a route profile is shown after a route calculation. In addition, when a long distance route is calculated, your Navigation System may not be able to list all the roads. (In this case, the remaining roads will be shown in the list as you drive on.)

  • Page 47: Route Calculation To Your Home Location Or To Your Favourite Location

    Route Calculation to Your Home Location or to Your Favourite Location If your home location is registered, the route home can be calculated, by a single press of the button from the Main menu. Also, you can register one location, such as your workplace, as your favourite location, and the route is calculated in a similar way.

  • Page 48: Searching For Your Destination By Address

    Searching for your Destination by Address You can specify the address of your destination. The route to a specific intersection or street, or for the central part of the city, can be also calculated. (For the details of the operation, “Basic Operation”...
  • Page 49 6 Enter house number and select “OK”. If you enter the house number and click the OK button, route calculation starts. If there are several locations corresponding to the entered house number, or there is no house number in that location, a list of house number range appears. In this case, select the range you want to set as your destination, and click the OK button to start the route calculation.

  • Page 50: Specifying An Intersection As Your Destination

    Specifying an Intersection as Your Destination By selecting two streets, route calculation for the intersection can be performed. Its basic opera- tion is the same as explained above. “Searching for your Destination by Address” 1 Select “New Destination” from the Main menu and then select “Address Search”. Click the OK button.

  • Page 51: Finding Your Destination By Selecting The Type Of Facility

    Finding Your Destination by Selecting the Type of Facility Information about various facilities (Points Of Interest - POI), such as stations, amusement parks or restaurants is available. By selecting the category, you can search for a Point Of Inter- est. sSearching for Points of Interest (POI) 1 Select “New Destination”...

  • Page 52: Finding Poi In Your Surroundings Or Around The Cross Pointer

    6 Enter the name of POI and select “OK”. Click the OK button. ➲ If you select “Show All” and click the OK button, the list of all the facilities included in the category you selected appears. 7 Select POI for your destination, and click the OK button. Route calculation starts if you click the OK button.

  • Page 53: Finding Your Destination By Specifying The Postal Code

    Finding Your Destination by Specifying the Postal Code If you know the postal code of your destination, you can use it to find your destination. 1 Select “New Destination” from the Main menu, and then select “Postal code Search”. Click the OK button. ➲...

  • Page 54: Setting An Entrance Or Exit Of A Motorway As Your Destination

    Setting an Entrance or Exit of a Motorway as Your Destination You can set the entrance or exit of motorway as your destination. 1 Select “New Destination” from the Main menu, and then select “Motorway Search”. Click the OK button. The display for entering the name of the motorway appears.

  • Page 55: Guidance To Your Destination

    Chapter Guidance to Your Destination Route Guidance by Your Navigation System After setting the route, once you start your vehicle, route guidance by display and voice begins. When you arrive at your destination, a message indicating the completion of route guidance appears, and the normal map display returns.

  • Page 56: When Receiving Traffic Information Ahead On The Set Route

    If you stray from the route If, for any reason, you stray from the suggested route, you can automatically search the route to get back on track. This function is called “Auto Reroute”, and you can set it On or Off in the Settings menu.
  • Page 57 When receiving an alert When receiving an alert, the message “Alert message has just arrived. Do you want to check?” appears. On this display, you can select the following items: Yes : Detailed information appears. No : The message disappears, and the map display reappears. When confirming no traffic information manually If you press the GUIDE button on the Remote Controller for more than three seconds, you can check traffic information about your route.

  • Page 58: Checking The Suggested Route

    Checking the Suggested Route You can check information about the route between your current location and your destination. 1 Press the DETOUR button on the Remote Controller for over two seconds. 2 Check the contents on the display. In Route Profile display, the names of the streets you drive through, and the driving dis- tance of each street can be checked in order.

  • Page 59: Recalculating The Route To Your Destination

    Recalculating the Route to Your Destination You can recalculate the route to avoid the traffic jam or road works ahead. You can set the length of the area, and avoid just that area, or you can even search a new route from the current loca- tion to your destination.

  • Page 60: Cancelling The Route Guidance

    Cancelling the Route Guidance If you no longer need to go to your destination, or you want to set another location as your des- tination, carry out the following operations: sDelete the current route, and cancel the route guidance If you no longer need route guidance, delete the current route, and cancel the route guidance. 1 Press the CANCEL ROUTE button on the Remote Controller.

  • Page 61: Adding Via Points To The Current Route

    Adding Via Points to the Current Route You can select via points (locations you want to visit on the way to your destination) and you can recalculate the route to pass this location. sAdding a via point You can set up to five via points. This is achieved as follows : 1 Specify the location you want to visit.

  • Page 62: Skipping A Via Point

    sSkipping a via point You can opt for the next via point to be skipped, and the new route to be calculated accord- ingly. 1 Press the CANCEL ROUTE button on the Remote Controller for more than two sec- onds. A message asking whether you want to skip the next via point appears.
  • Page 63 5 Select “Done” and click the OK button. A new route to your destination via the remaining via points is calculated.

  • Page 64: Displaying Certain Points Of Interest On The Map

    Displaying Certain Points Of Interest on the Map Selected Points Of Interest (POI) in a certain category can be shown on the map, and you can check the location on the display while driving. 1 Select “Information” on Main menu, and then select “Overlay POI”. Click the OK but- ton.

  • Page 65: Utilising Various Information

    Chapter Utilising Various Information Editing the Address Book The Address Book stores information about the following types of location. You can edit the contents of the Address Book. • Last Destination - the destination whose route was set most recently. •...
  • Page 66 4 Select “Yes” and click the OK button. Alternative option: No : If you do not need to rename, select “No”. The name of the location registered in the Address Book is unchanged, and the Address Book menu appears. 5 Enter a new name; select “OK” and click the OK button. The name of the current location appears in the text box.

  • Page 67: Editing A Location's Information

    sEditing a location’s information Select a location in the Address Book menu and move the joystick to the left: the Address Book Operate menu appears. If you edit the information of the locations stored in Last Desti- nation or Destination History, it is registered in Address Book as Registered Location. To edit the information about the location: 1 Select “Address Book”...

  • Page 68: Deleting The Data In The Address Book

    Entering or changing a phone number 1 Select “Edit Phone Number” and click the OK button. 2 Enter a phone number; select “OK” and click the OK button. The Address Information menu appears. ➲ To change a registered phone number, delete the existing number and then enter a new one.

  • Page 69: Confirming The Location Contained In The Address Book On The Map

    A message confirming deletion appears, if you click the OK button. On this display, you can select the following options: Delete this item : Delete the location selected in Step 1. Delete all Destinations : All the items stored in Last Destination and Destination His- tory are deleted.

  • Page 70: Registering Your Home And Your Favourite Location

    Registering Your Home and Your Favourite Location By registering your home and your favourite location, you can easily calculate the route by sin- gle press of the button from the Main menu. You might find it useful to register your workplace or a relative’s home as your favourite location.
  • Page 71 5 Select “Yes” and click the OK button. ➲ If renaming is not necessary, at this step, select “No” and click the OK button. The location is registered, and the Others menu appears. 6 After entering a new name, select “OK” and click the OK button. A message confirming the entered name appears, and a voice message confirming the pronunciation is played.

  • Page 72: Changing Or Deleting Your Home Or Your Favourite Location

    sChanging or deleting your home or your favourite location Changing your favourite location is described next. 1 Select “Settings” in the Main menu, then select “Others” and “<favourite location name>”. Click the OK button. If you click the OK button, a message confirming that you want to change a registered location appears.

  • Page 73: Registering A Password

    Registering a Password If you register a password, only those who know the password can use your Navigation System. 1 Select “Settings” in the Main menu, then select “Others” and “Password”. Click the OK button. 2 Enter a password. Carefully enter each character. A password must be between 6 and 24 characters (alpha- betic or numeric).

  • Page 74: Setting Areas To Avoid

    Setting Areas to Avoid If you register Areas to Avoid, such as crowded intersections or congested areas, routes can be calculated that avoid those areas. Areas to Avoid can be set from the Settings menu. Caution If you register or delete an Area to Avoid after setting a route, the contents of route guidance may be changed due to activation of Auto Reroute function.

  • Page 75: Changing Or Deleting An Area To Avoid

    5 After specifying an Area to Avoid, click the OK button. The Area to Avoid is enclosed in a red frame. Scroll the map to adjust the position of the red frame. 6 Select “Register” and click the OK button. The specified area is registered as an Area to Avoid, and the display shown in Step 2 appears.

  • Page 76: Using Traffic Information

    Using Traffic Information You can confirm the traffic information transmitted from the FM radio service through Radio Data System (RDS) on the display. Such traffic information is updated periodically. When you receive traffic information about your route, the Navigation System automatically displays the popup message informing you of the traffic information.
  • Page 77 Confirming verbalised information regarding traffic The following information appears: • Street name • Site name (The first and the last names of the cities involved in the traffic jam and the direc- tion of the traffic jam are shown.) • Traffic information (Example: “3km slow-going traffic”) ➲...

  • Page 78: Selecting The Radio Station

    sSelecting the radio station The RDS-Tuner of this unit automatically tunes to the radio station to receive available traffic information. If reception is poor, you can switch to another station manually. Once the receiv- ing radio station is selected, the system automatically tunes to stations that provide traffic information according to the trace of a driving vehicle.
  • Page 79 ➲ If there are already five stations registered on the list, select one to be overwritten by the details of the newly selected radio station. When you click the OK button, a mes- sage confirming that you want to overwrite the data appears. Select “Yes” and click the OK button to overwrite the unwanted station.

  • Page 80: Using A Pc Card

    Using a PC Card You can store data in the Address Book in a PC card, which can also be read by this unit. It is very useful when you want to share the data in the Address Book with your friends or to store the data for backup.

  • Page 81: Loading Data From A Pc Card

    3 After finishing the selection of locations, select “OK” and click the OK button. The list of the stored group appears. 4 Select “New group” and click the OK button. The display to enter a new group name appears. ➲ If the data is to be stored in a group already registered in the PC card, select the group name in the list and click the OK button.

  • Page 82: Deleting Pc Card Data

    Selected items are ticked. To load the data from other locations, repeat this step. Alternative option: Select All : A whole group can be selected. 4 Select “OK” and click the OK button. After the data of the selected locations is stored in the Address Book, a map of your sur- roundings appears.

  • Page 83: Checking The Navigation Status

    Checking the Navigation Status The navigation status, including the driving status of a vehicle, positioning status by satellite, learning status of the sensor, and cable connection status can be checked. sChecking positioning information by satellite Your Navigation System uses positioning data transmitted from GPS satellites. GPS recep- tion status can be checked on the screen.

  • Page 84: Checking Sensor Learning Status And Driving Status

    sChecking sensor learning status and driving status To improve the precision of navigation, the system learns the driving status of your vehicle and stores the data in the internal memory. The learning status of the sensor can also be checked on the screen. The current driving status, including vehicle speed and inclination of a road, can be checked on the screen.

  • Page 85: Checking The Connections Of Leads And Installation Positions

    2 Push the BACK button. The previous screen appears. To clear the memory... If you want to delete the memorised learning contents of “Distance”, “Speed Pulse Counter”, or “Learning Status”, perform the following procedure: 1 Select the item you want to delete, and click the OK button. 2 While “Clear”...
  • Page 86 7. Back Signal When the selector lever is shifted to “R”, the signal switches to “High” or “Low”. Check that it is properly displayed when the selector lever is shifted with the brake pedal depressed if the reversegear signal input lead (see “Installation Manual”) is con- nected.

  • Page 87: Customising Your Navigation System

    Chapter Customising Your Navigation System Modifying the Default Settings You can tailor default settings such as navigation functions and information display for ease of use. The following example describes how to change settings. In this example, the “Avoid Motor- way” function under “Route Guidance” settings is turned on. 1 Select “Settings”...

  • Page 88: Items Users Can Change

    Items Users can Change The Settings menu contains the Route Guidance, Map Display, Hardware, Others, RDS-TMC, and PC Card menus. If you select a menu name in the Settings menu, an equivalent menu appears. In the menu screen, the contents of the current setting is shown on the right-hand side of each item.
  • Page 89 Avoid Toll Road This setting controls conditions for calculating a route. On : Calculate a route that avoids toll roads. Off* : Calculate a route that may include toll roads. KM/Mile Setting This setting controls the unit of distance displayed on your Navigation System. KM* : Show distances in kilometres.

  • Page 90: Map Display Menu

    Demo Mode is set off. Mute on Voice Recognition This can be set when your Navigation System is combined with the Pioneer Head Unit with a muting function (one that has an Yellow/black lead). This setting controls whether the volume of the Head Unit is automatically muted during voice operation.

  • Page 91: Voice Recognition Help

    Mute on Voice Guidance This can be set when your Navigation System is combined with the Pioneer Head Unit with a muting function (one that has an Yellow/black lead). This setting controls whether the volume of the Head Unit is automatically muted during voice guidance.

  • Page 92: Rds - Tmc Menu

    Language Selection The language displayed can be set ( see “Setup 3: Installing the Program” on page 22 Once you change the language, installation of the program starts. Caution Once the installation of the program starts, do not stop the engine of your vehicle until the installation is completed.

  • Page 93: Operating Your Navigation System With Voice

    Operating Your Navigation System with Voice Basics of Voice Operation Your Pioneer Navigation System comes with the latest in voice recognition technology. You can use voice commands to operate many of its functions. This chapter describes where you can use voice commands, and also what commands the system accepts.

  • Page 94: Available Voice Commands

    sAvailable voice commands When your car is parked with the handbrake on, press the TALK button to display a list of available voice commands (Voice Help menu). Display of the Voice Help menu can be turned on /off with “Voice Recognition Help” in the Settings menu. When you speak one of the commands in the list;...
  • Page 95 2 Say “New Destination”. Speak all commands towards the microphone. If the voice command is recognised, the command appears on the screen, and the system voice repeats it. Then, a message to prompt the next operation is given. 3 Say “Local search”. You say the contents you want to operate.
  • Page 96 To spell out characters and symbols When entering city names, names of POIs, or postcodes, speak one character at a time. For example, if you want to enter “A”, say “Alpha”. Pronunciation Pronunciation Pronunciation Pronunciation Pronunciation 1 One A Alpha K Kilo U Uniform _ Space...

  • Page 97: Tips For Voice Operation

    If the microphone is properly positioned, there is no need to raise your voice when giving commands. ➲ If you have a Pioneer Head Unit with a muting function (one that has an Yellow/black lead), the volume will automatically be reduced when you give a voice command.

  • Page 99: Appendix

    Appendix Positioning Technology The Navigation System accurately measures your current location by combining the positioning by GPS and by Dead Reckoning. Positioning by GPS The Global Positioning System (GPS) uses a network of satellites orbiting the Earth. Each of the satel- lites, which orbit at a height of 21,000 km, continually broadcasts radio signals giving time and position information.
  • Page 100 How do GPS and dead reckoning work together? For maximum accuracy, your Navigation System continually compares GPS data with your estimated position as calculated from the data of 3D Hybrid Sensor. However, if only the data from the 3D Hybrid Sensor is available for a long period, positioning errors are gradually compounded until the estimated position becomes unreliable.

  • Page 101: Handling Large Errors

    Handling Large Errors Positioning errors are kept to a minimum by combining GPS, Dead Reckoning, and map matching. How- ever, in some situations, these functions may not work properly, and the error may become bigger. When the positioning by GPS is impossible •...

  • Page 102: Conditions Likely To Cause Noticeable Positioning Errors

    Conditions likely to cause noticeable positioning errors Certain conditions are more likely to cause discrepancies between your actual position and the location shown on the map display. • If you make a slight turn • If there is a parallel road •...

  • Page 103: Handling And Care Of The Disc

    Handling and Care of the Disc Some basic precautions are necessary when handling your discs. Discs you can use • Use only the disc provided for use with this unit. You cannot use ordinary DVDs, CD-ROMs, or music CDs. • Do not try to use a disc that is cracked, scratched or bent. •...

  • Page 104: Resetting The System

    Resetting the System On occasion, you may need to reset your Navigation System. When a reset is necessary You should reset the system in the following situations: • After installation of this unit in your vehicle. • If there appear to be problems with the operation of the system. •...

  • Page 105: Troubleshooting

    While this list is not comprehensive, it should answer your most pressing problems. If a solution to your problem cannot be found here, contact your dealer or the nearest authorised Pioneer service facility. You cannot position your vehicle on the map or the positioning error is large.
  • Page 106 The daylight display is used even when the vehicle lights are on. Possible causes: (1) “Day Display” is selected on “Map Display.” (2) The Orange/white lead is not connected. Solutions: (1) Check the “Map Display” setting (see “Map Display” on page 88) and make sure “Illumination” is selected.
  • Page 107 When the screen is frozen... Park your vehicle at a safe place, and cut the engine off. Turn the ignition key back to “Acc off”. Then start the engine again, and turn the power to the main unit back on. If this does not solve the problem, press the reset button on the main unit.

  • Page 108: Messages And How To React To Them

    If the Navigation unit does not receive the vehicle speed pulse. What to do: Consult your Pioneer dealer. (4) “Speed pulse wire is not connected. Please be sure to connect the system to the speed pulse wire. Accuracy is not fully ensured without speed pulse.”...
  • Page 109 When: Abnormal output of Gyrosensor is detected. What to do: Note down the error code shown on the screen; turn off the power, and then contact your nearest Pioneer service facility. (8)“Your route could not be found.” When: If the distance to the destination is too far and cannot be set.
  • Page 110 (16)“An error has occurred. Please note the following error code and power off.” When: In the case of a system failure. What to do: Note down the error code shown on the screen; turn off the power, and then contact your nearest Pioneer service facility. (17)“Player overheating. Discontinue until temperature drops.” When: The DVD-ROM drive has overheated.

  • Page 111: Route Setting Information

    Route Setting Information Route search specifications Your Navigation System sets a route to your destination by applying certain built-in rules to the map data. This section provides some useful information about how a route is set. Caution When a route is calculated, the route and voice guidance for the route is auto- matically set.

  • Page 112: Route Highlighting

    • Pioneer does not bear responsibility for the accuracy of the information transmitted. • Pioneer does not bear responsibility for changes to information services provided by broadcast- ing stations or by related companies, such as cancellation of the services or changing to pay-...

  • Page 113: Copyright

    Copyright ©1993-2000 Navigation Technologies B. V. All rights reserved France: ® Sourcé: Géoroùte ® IGN France & BD Carto IGN France Germany: Die Grundlagendaten wurden mit Genehmigung der zuständigen Behörden entnommen. Great Britain: Based upon Ordnance Survey electronic data and used with the permission of the Controller of Her Maj- esty’s Stationary Office ©...

  • Page 114: Specifications

    Specifications Main unit (GPS receiver) System : L1, C/Acode GPS SPS (Standard Positioning Service) Reception system : 8-channel multi-channel reception system Reception frequency : 1,575.42 MHz Sensitivity : -130 dbm Position update frequency : Approx. once per second (Common) Max. output impedance : 1Vp-p, 75Ω...

  • Page 115: Glossary

    Glossary This glossary explains some of the terms used in the manual. 3D Hybrid sensor The built-in sensor which enables the system to estimate your vehicle’s position. A learning function increases its accuracy and two sets of learning data can be stored in memory. Address Book A list of previously searched destinations, via points and locations registered manually.
  • Page 116 Route setting The process of determining the ideal route to a specific location; route setting is done automatically by the system when you specify a destination. Set route The route marked out by the system to your destination. It is highlighted in bright green on the map. Tracking Marks on the map indicating the route you have travelled.

  • Page 117: Display Information

    Display Information Main menu New Destination Address Book Return Home (P.45, 68) Go to ~ (P.45, 68) Settings Information New Destination menu Address Search (P.28, 46) POI Search (P.49) Motorway Search (P.52) Postal code Search (P.51) Vicinity Search (P.50) Address Book menu Last Destination (P.63) Registered Location (P.63) Destination History (P.63)
  • Page 118 Settings menu Route Guidance (P.86) Map Display (P.88) Hardware (P.88) Others (P.88) RDS-TMC (P.90) PC-Card (P.78) Route Guidance menu (1) Auto Reroute (P.86) Areas to Avoid (P.72) Route No. (P.42, 86) Fastest/Shortest (P.43, 86) Avoid Motorway (P.43, 86) Avoid Ferry (P.86) Route Guidance menu (2) Avoid Toll Road (P.87) KM/Mile Setting (P.87)
  • Page 119 Others menu (2) Help Menu (P.89) Voice Recognition Help (P.89) Language selection (P.22, 90) Return Home (P.45, 68) Go to~ (P.45, 68) Modify Current Location (P.90) Adjust Display Position (P.90) RDS-TMC menu Real Time Reroute Alert (P.90) Avoid Traffic Route (P.90) PC Card menu Store on PC card (P.78) Read from PC card (P.79)
  • Page 122 ✁ MEMO Write your registered password here; remove this page from the manual, and store it in a safe place. CAUTION:Never leave any note of your password in your vehicle.
  • Page 124 300 Allstate Parkway, Markham, Ontario L3R OP2, Canada Copyright © 2001 by Pioneer Corporation. TEL: (905) 479-4411 All rights reserved. PIONEER ELECTRONICS DE MEXICO, S.A. de C.V. Publication de Pioneer Corporation. San Lorenzo 1009 3er. Piso Desp. 302 Copyright © 2001 Pioneer Corporation.

Table of Contents
