Summary of Contents for Electrolux ESF6162
-
Page 1: Instruction Book
D i s h w a s h e r Model ESF 6162 Instruction book... -
Page 2: Table Of Contents
Contents Safety instructions Disposal Economical and ecological dishwashing Installation instructions Fitting under a counter Levelling Water supply connections Water inlet hose with safety valve Water outlet hose connection Electrical connection Description of the appliance The control panel "3 in 1" function Prior to using for the first time The water softener Filling with dishwasher salt... -
Page 3: Safety Instructions
Safety instructions It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information. -
Page 4: Installation Instructions
Installation instructions Any electrical and/or plumbing work required to install The water inlet hose must not be kinked, crushed, or entangled this appliance should be carried out by a qualified when it is being connected. electrician and/or plumber or competent person. The dishwasher features fill and drain hoses which can be Remove all packaging before positioning the machine. -
Page 5: Electrical Connection
The sink plug must not be in place when the machine is Electrical connection draining as this could cause the water to syphon back into the Information concerning the electrical connection is given on the machine. rating plate on the edge of the dishwasher’s door. If you use a drain hose extension it must be no longer than 2 Before plugging the appliance into the wall socket, make sure metres and its internal diameter must be no smaller than the... -
Page 6: The Control Panel
The control panel Digital display On/Off indicator light Function buttons Programme selection buttons Indicator lights On/Off button Delay start button Function buttons: Indicator lights: in addition to the dishwashing have the following meanings: programme selected, the following functions can also be set Programme in progress: illuminates when a with the help of these buttons: washing programme has been set and remains... -
Page 7: In 1" Function
"3 in 1" function NOTE: if the drying results are not satisfactory we suggest that you activate only the rinse aid dispenser. This appliance is equipped with the "3 in 1" function, that The activation/deactivation of the rinse aid dispenser can only allows the use of the "3 in 1"... -
Page 8: Prior To Using For The First Time
Prior to using for the first time Before using your dishwasher for the first time: b) Setting electronically (The dishwasher must be switched off) 1. Ensure that the electrical and water connections comply with the installation instructions NOTE: the electronic setting of the water softener is 2. -
Page 9: Filling With Dishwasher Salt
Filling with dishwasher salt Rinse aid Only use salt specifically designed for use in Rinse aid is automatically added during the last rinse, ensuring dishwashers. thorough rinsing, and spot and streak free drying. All other types of salt not specifically designed for use in The dispenser, which is positioned inside the door, holds about a dishwasher, especially table salt, will damage the water 110 ml of rinse aid, which is sufficient for between 16 and 40... -
Page 10: In Daily Use
In daily use Check if it’s necessary to refill with dishwasher salt or rinse Loading cutlery and dishes Sponges, household cloths and any object that can Load cutlery and dishes into the dishwasher. absorb water may not be washed in the dishwasher. Fill with dishwasher detergent . -
Page 11: Removable Knife Basket
The cutlery basket The upper basket The upper basket is designed for plates (dessert plates, Long bladed knives stored in an upright position are a saucers, dinner plates of up potential hazard. to 24 cm in diameter), salad Long and/or sharp items of cutlery such as carving knives bowls, cups and glasses. -
Page 12: Adjusting The Height Of The Upper Basket
Adjusting the height of the upper basket Use of detergent If washing very large plates you can load them in the lower Only use detergents specifically designed for use in basket after moving the upper basket to the higher position. dishwashers. -
Page 13: Different Kinds Of Detergent
Different kinds of detergent Detergent tablets Detergent tablets from different manufactures dissolve at different rates. For this reason, some detergent tablets do not attain their full cleaning power during short washing programmes. Therefore please use long washing programmes when using detergent tablets, to ensure the complete removal of detergent residuals. -
Page 14: Washing Programmes
Washing programmes Programme Degree of soil Press the Cycle (2) Consumption values programme description Energy Water type of load button consumption consumption (in kWh) (in litres) Hot prewash Main wash up to 70°C Heavy soil. 2 warm rinses Crockery, cutlery, 1,7 - 1,9 23 - 25 Intensive 70°... -
Page 15: Starting A Washing Programme
Starting a washing programme 1. Check that the baskets have been Interrupt a washing programme in progress loaded correctly and that the spray a) Open the dishwasher door; the programme will stop. Close the door; the programme will start from the point arms can rotate freely at which it was interrupted. -
Page 16: Maintenance And Cleaning
Maintenance and cleaning Clean the external surfaces of the machine and control panel Attention! with a damp soft cloth. If necessary use only neutral Under no circumstances may the dishwasher be used without detergents. Never use abrasive products, scouring pads or filters. -
Page 17: Something Not Working
Something not working Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the instructions given here, without calling out an engineer..a flashing fault code appears The dishwasher will not start or stops during operation. The intervention of an alarm is indicated by: - the continuous flashing of the indicator light of the running programme, - a fault code (as described in the chart) is visible in the digital display. -
Page 18: The Wash Results Are Not Satisfactory
...the wash results are not satisfactory The dishes are not clean The wrong washing programme has been selected. The dishes were arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded. The spray arms do not rotate freely due to wrong arrangement of the load. -
Page 19: Service And Spares
Service and Spares This guarantee is given on condition that only genuine Electrolux parts and accessories are used at all times in In the event of your appliance requiring service, or if you wish the appliance. to purchase spare parts, contact our local Electrolux Service Centre by telephoning: Electrolux shall not be responsible for damage of any kind resulting from electricity fluctuations, faults in the building... - Page 20 The Electrolux Group. The World’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. 14 billion USD in more than 150 countries around the world.
