- Page 1 GEBRAUCHSANWEISUNG NOTICE D’UTILISATION GEBRUIKSAANWIJZING OPERATING INSTRUCTION GLASKERAMIK-KOCHFLÄCHE PLAN DE CUISSON VITROCÉRAMIQUE KERAMISCH KOOKPLATEAU EHC 010 X GLASS CERAMIC HOB EHC 010 X...
- Page 2 Dear costomer We thank you for choosing a ceramic hob of ELECTROLUX. Thus you chose quality, innovation and durability. These operating and assembly instructi- ons will allow you to become acquainted with the appliance and to do everything within its possibilities. This appliance conforms with EC-Directive 72/23/EEC, 89/336/EEC, 93/68/EEC...
-
Page 3: Table Of Contents
Description of the hob ....35 EHC 010 X ....35 Cooking zones . -
Page 4: Inbouw Van Het Kookplateau
Inbouw van het kookplateau Use only pans with flat bases without rough edges Before using the hob for the first to avoid remaining scratches time, read the operating and as- sembly instructions carefully.You The ceramic hob surface is resistant to extreme protect yourself and avoid damage temperatures. -
Page 5: Before The First Use
When you use the ceramic hob for the first time it can temporarely emit an odeur caused by a vaporation of water in the isolation. Description of the hob EHC 010 X Cooking zone Ø 180 mm, 1800 W Cooking zone Ø... -
Page 6: Cooking Zones
Cooking zones The cooking zones are indicated by markings on the ceramic top. The cooking zones are operated via the corresponding switch box or built-in oven and this is in the respective manuals. The dimensions of the cooking zones are such that they accommodate standard sized sauce pans. -
Page 7: Cooking Equipment
Cooking equipment Specially tested cooking and frying pans for ceramic hobs exist.The following advice should be considered to achieve an optimal energy consumption as well as to avoid that overboiling food can be burnt onto the coo- king zones. Cooking pans with aluminium or copper bottoms are unsuitable for use. -
Page 8: Maintenance
Maintenance Ceramic hobs are treated and cleaned the same way as glass. Never use aggressive detergents or sponges with abrasive surface. Cleaning after each use Slight, not burnt soiling has to be wiped off with a damp cloth without using detergents. The use of detergents may lead to disco-louring. -
Page 9: Installation
Installation Specifications 941 592 708 Prod-nr: Outside Dimensions: Serie 6.94 230 V ~ 50 Hz Width: 1000 mm EHC 010 X Typ 086.0.A Depth: 520 mm Cut-out Dimensions: Width: 984 mm Depth: 504 mm Supply Voltage: 230 V Frequency: 50 Hz Total Connected Load: 6.94 kW... -
Page 10: Important For The Disassembly Of The Hob
Installation Furthermore attention should be paid to the assembly instructions for the built-in switch box or stove to which the hob is connected! Protection against accidental contact must be ensu- red by assembly. If the hob is operated from a switch box then it is necessary to have an intermediate bottom to ensure min. - Page 11 EHC 010 X EPM 410 X...
- Page 12 374 2587-00 / 02.96...
