DISHWASHER OPERATION MANUAL
EN
DW12-TFE5
PLEASE READ THIS OPERATION MANUAL BEFORE USING THE DISHWASHER.
0120504965D

Advertisement

Table of Contents
loading

Related Manuals for Haier DW12-TFE5

Summary of Contents for Haier DW12-TFE5

  • Page 1 DISHWASHER OPERATION MANUAL DW12-TFE5 PLEASE READ THIS OPERATION MANUAL BEFORE USING THE DISHWASHER. 0120504965D...
  • Page 2 Electrical Connection (Uk Only) For your safety please read the following information. Warning: This appliance must be earthed. The appliance must be connected to a 220-240 volts 50 cycle AC supply by means of a three pin socket, suitably earthed and should be protected by a 13 amp fuse in the plug. The appliance is supplied with a rewireable 13 amp 3-pin plug fitted with a 13-amp fuse.

  • Page 3: Important Safety Information

    Important safety information This appliance must be earthed. It is intended for use on a 220-240Volt 50Hz mains supply. Check that the voltage marked on the rating plate matches that of your local supply before plugging in for the first time. Improper connection of the grounding conductor can result in the risk of an electric shock.

  • Page 4: Table Of Contents

    Index Safety information Installation Getting to know your dishwasher How to fill the salt How to fill rinse aid How to fill the detergent dispenser Not suitable for the dishwasher Arranging crockery, glasses, etc. in the dishwasher Programme overview Washing dishes How to keep your dishwasher in shape Care and maintenance Trouble Shooting...

  • Page 5: Safety Information

    Safety information At time of delivery Check packaging and dishwasher immediately for signs of transport damage. If the appliance is dam- aged, do not put it into use but contact your supplier or customer service without delay. Please dispose of packaging materials properly. During installation Site the dishwasher and connect it up in accordance with the installation instructions.

  • Page 6: If A Fault Occurs

    If your family includes children This appliance is not intended for use by persons (including children) with reduced physical,sensory or mental capcabilities, or lack of experience and knowledge,unless they have been given supervi- sion or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they to not play with the appliance.

  • Page 7: Installation

    Installation Positioning the appliance Positioning the appliance in the desired location. The back of the appliance should rest against the wall, and the sides, along the adjacent cabinets or wall. The dishwasher is equipped with water supply and drain hoses that can be positioned to the right or the left to facilitate proper installation. Levelling the appliance Once the appliance is positioned, adjust the feet (screwing them in or out) to adjust the dishwasher, making it level.

  • Page 8: Drain Hose Connection

    Drain hose connection Insert the drain hose into a drain pipe with a minimum diameter of 4cm, or let it run into the sink, making sure to avoid bending or crimping it. If necessary, fit a syphon trap (U-bend) with a connecting piece for the electrical drain hose (fig.C).

  • Page 9: Getting To Know Your Dishwasher

    Getting to know your dishwasher Close-up view (control panel) Delayed Start Button State Indicator Time-remaining Indicator ON-OFF Button Low Rinse Aid Indicator "1/2" Indicator Low Salt Indicator "1/2" Button Knob For Selecting Cycle Delayed Start Indicator Dishwasher interior Upper Rack Washing Filter Lower Rack Detergent and Rinse Aid Dispenser...

  • Page 10: How To Fill The Salt

    How to fill the salt Salt The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes and utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.

  • Page 11: How To Fill Rinse Aid

    How to fill rinse aid Rinse aid This product makes dishes sparkle and helps them to dry without spotting. The dispenser is located on the inside panel of the door . When the low rinse aid indicator "H"on the control panel and the me- chanical indicator "H1"...

  • Page 12: How To Fill The Detergent Dispenser

    How to fill the detergent dispenser Detergent Detergent specifically intended for use with dishwashers must be used. The dispenser must be refilled before the start of each wash cycle fol- lowing the instructions provided in the "Programme overview". The de- tergent dispenser is located on the inside panel of the door.

  • Page 13: Not Suitable For The Dishwasher

    Not suitable for the dishwasher What you should not put into the dishwasher Cutlery and tableware manufactured in whole or part from wood.They become faded and unsightly in appearance.Furthermore,the adhesives that are used are not suitable for the temperature that occur inside the dishwasher.Delicate decorative glassware and vases,special antique or irreplaceable china.

  • Page 14: Arranging Crockery, Glasses, Etc. In The Dishwasher

    Arranging crockery, glasses, etc. in the dishwasher Before placing the dishes in the dishwasher, remove larger food particles to prevent the filter from be- coming clogged, which results in reduced performance. If the pots and pans have baked-on food that is extremely hard to remove, we recommend that they are soaked before washed.
  • Page 15 How to use the upper rack The upper rack is designed to hold more delicate and lighter dishware, such as glasses, cups and saucers, plates, small bowls and shallow pans (as long as they are not too dirty). Position the dishes and cookware so that they do not get moved by the spray of water.

  • Page 16: Programme Overview

    Programme overview Type of Condi- Type of Amount of crokery e.g. Wash tion of china, pots/ food food Description of cycle pans, food programme Load remains remains cutlery, remains glasses, etc Pre-wash with warm water. Extended wash at 70°C. Soups, Non- Rinses with cold water.
  • Page 17 Detergent Delayed Energy Water Duration in Rinse Aid Start consump- consump- Extended minutes Prewash tion in kWh tion in litres Wash 1.62 1.48 1.24 1.15 1.02 1.00 1.12 1.10 0.40 0.30 0.90 0.78 0.02 0.02...

  • Page 18: Washing Dishes

    Washing dishes Programme selection The most appropriate programme can be identified by comparing the type of crockery, cutlery, etc., as well as the amount and condition of food remains, with the details contained in the wash cycle table.The corresponding programme sequence, duration and consumption details are shown in the right half of the overview.

  • Page 19: End Of Programme

    End of programme Six beeps will indicate that the wash cycle has finished and the state indicators "A" light. Switching the dishwasher OFF Several minutes after the programme has ended: Set On-Off button to Off Open the door . Turn the water tap off. Remove dishes, etc.
  • Page 20 After 3 seconds the delayed start indicator “ E ” blinks, the time-remaining indicator “ G ” will blink and decrease , the programme will start until the delayed start indicator “ G ” goes out . Cancelling or modifying a cycle A cycle that is underway can be modified if it has only been running for a short time.

  • Page 21: How To Keep Your Dishwasher In Shape

    How to keep your dishwasher in shape After Every Wash After every wash, turn off the water supply the appliance and leave the door slightly ajar so that moisture and odors are not trapped inside. Remove the plug Before cleaning or performing maintenance, always switch off the remove the plug from the socket. Do not run risks.

  • Page 22: Care And Maintenance

    Care and maintenance Regular inspection and maintenance of your appliance helps to prevent problems from occurring.This saves time and aggravation.You should therefore carefully inspect the inside of your dishwasher from time to time. Overall condition of appliance Check that no grease or scale has accumulated on the inside of the dishwasher. If you discover any deposits: Clean the interior of the dishwasher thorughly with a dishwasher detergent solution.

  • Page 23: Trouble Shooting

    Spray arms Lime and remnants of food in the washing water can block the nozzles in the spray arms “ 9 ” and “ 10 ” and the arm mountings. Inspect the nozzles in the spray arms for blocked holes due to remnants of food.
  • Page 24 Caution Do not forget that repairs should only be carried out by a qualified specialist. Improper repairs can lead to considerable equipment dam- age as well as danger to the user. Error display on the time-remaining indicator When the buzzer emits 10 short warning signal every 30 seconds and the time-remaining indicator display "E1"...
  • Page 25 When the buzzer emits 10 short warning signals every 30 seconds and the time remain- ing indicator display "E2" or "E6", Contact the nearest authorized service center. If you take all these checks and the dishwasher still does not function or your dish- washer have any other error display, you can power the dishwasher OFF, and wait a few minutes.
  • Page 26 Water remains inside appliance after programme has ended Blockage or kind in drainage hose. Pump is jammed. Filters are blocked. The programme is still running. Wait for the programme to end ..during washing Unusual amount of foam is creased Normal washing up liquid has been poured into the rinse-aid container.
  • Page 27 Plastic items are discoloured Not enough detergent was added to dispenser. Detergent has insuffcient bleaching properties. Use a detergent containing a chemical bleaching agent. White stains are left on crockery, glasses have a milky appearance Not enough detergent was added to dispenser compartment. Amount of rinse-aid was set too low.

  • Page 28: Technical Data

    Technical data 60 cm Width Depth 60 cm Height 85 cm Capacity 12 standard place settings 0.03-1.0Mpa Mains water pressure 220-240V~50Hz Power voltage Fuse 1950W Total absorbed power Important information Notes on waste disposal Old appliances still have some residual value. An environment-friendly method of disposal will ensure that valuable raw materials can be recovered and used again.

  • Page 29: General Information

    General information Measures must be taken to ensure that built-under and built-in units that are subsequently re-sited as free-standing appliances cannot topple over. This can be achieved by bolting the dishwasher to the wall or fitting it under a continuous work surface which is screwed to the adjacent cupboards. Information on comparability tests implemented in compliance with EN 50242 Appliance loaded in accordance with standard specifications.
