Leveling Instructions ... 7 Door Removal Instructions ... 8 Electronic Control ... 8 Electronic Control Features... 9 www.frigidaire.com USA 1-800-944-9044 & Care TA B L E O F C O N T E N T S Sabbath Mode ... 10 Alerts ...
Read product labels for warnings regarding fl ammability and other hazards. • DO NOT operate the refrigerator in the presence of explosive fumes. • Remove all staples from the carton. Staples can cause severe cuts, and also destroy fi...
Junked or abandoned refrigerators or freezers are still dangerous – even if they will sit for “just a few days”. If you are getting rid of your old refrigerator or freezer, please follow the instructions below to help prevent accidents.
FEATURE OVERVIEW Understanding Features and Terms Your Frigidaire refrigerator is designed for optimal convenience and storage fl exibility. The illustration below is provided to assist you with familiarizing yourself with product features and terminology. NOTE Features may vary according to model.
If possible, place the refrigerator out of direct sunlight and away from the range, dishwasher or other heat sources. • The refrigerator must be installed on a fl oor that is level and strong enough to support a fully loaded refrigerator. CAUTION DO NOT install the refrigerator where the temperature will drop below 55°F (13°C) or rise above 110°F...
The fl oor must be strong enough to support a fully loaded refrigerator. It is VERY IMPORTANT for your refrigerator to be level in order to function properly. If the refrigerator is not leveled during installation, the door may be misaligned and not close or seal properly, causing cooling, frost or moisture problems.
(4) leg levelers installed at each corner. These leg levelers will be used to level the refrigerator and to adjust the height. Use a carpenter’s level to level the refrigerator from front to back and side to side. ...
Page 8
°F to °C. To turn the refrigerator OFF, press the UP (▲) key until the warmest temperature setting of 46F° (8C°) shows in the display. Then press the UP (▲) key three (3) times within three (3) seconds to turn the refrigerator OFF. The display will then show “OF”.
fi lter needs to be replaced. The control will signal for air fi lter replacement after 3600 hours of refrigerator operation. After replacing the air fi lter, Resetting Air Filter Alarm reset the air fi lter timer by pressing the AIR FILTER key for 3 seconds.
SABBATH MODE SABBATH MODE The Sabbath Mode is a feature that disables portions of the freezer and its controls in accordance with the observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community. To initiate or cancel Sabbath Mode, press the CONTROL LOCK and TEMP MODE keys at the same time and hold for three (3) seconds.
The display will alternate between “E7” and 33°F (1°C) at ½ second intervals. The control will then enter a mode that runs the refrigerator in a manner that maintains the factory set cabinet temperature until the condition is resolved.
In general, you should change the air fi lter with Part Number “EAFCBF” every six months to ensure optimal fi ltering of freezer odors. The replacement air fi lter can be purchased on the Frigidaire website (http://frigidaire.stores.yahoo.net) or call toll free in the U.S.
Upper Level Lighting The upper level lighting comes on automatically when the door is opened. To replace the light bulbs: IMPORTANT To disconnect power to the unit, unplug the unit or switch the breaker that supplies power to the unit to the off position.
1. Remove the glass cover from the drawer to be removed. 2. With both hands, lift up on the front of the drawer until it releases from the side supports. 3. Carefully remove the drawer from the refrigerator. NOTE Leafy vegetables keep best when stored with the humidity control set on HIGH HUMIDITY, or in a drawer without a humidity control.
• Leave the refrigerator operating during vacations of less than three weeks. Long Vacations: If the refrigerator will not be used for several months: • Remove all food and unplug the power cord. • Clean and dry the interior thoroughly.
NOTE • Turning the refrigerator temperature control to “OFF” (See page 8) turns off the compressor, but does not disconnect electrical power to the lights or other electrical components. Unplug the unit or switch the breaker that supplies power to the unit to the off position.
BEFORE YOU CALL TROUBLESHOOTING GUIDE Before calling for service, review this list. It may save you time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this refrigerator. Problem Refrigerator Operation...
Page 19
* This is normal. When the surrounding noise level is low, you might hear the compressor running while it cools the interior. * This is normal. Sound will level off or disappear as refrigerator continues to run. * This is normal. Sound will level off or disappear as refrigerator continues to run.
