HP ProLiant BL30p Specification

Server blade
Hide thumbs Also See for ProLiant BL30p:

Advertisement

Quick Links

Download this manual See also: Troubleshooting Manual, Specification
QuickSpecs
Overview
1. ProLiant BL30p Server Blades (16)
2. ProLiant BL p-Class interconnects (2) (patch panel 2 shown)
What's New
What's New
What's New
What's New
The HP BladeSystem Management Suite is delivered in a convenient to purchase pack which includes a BL p-Class Server Blade Enclosure, a single
copy of Systems Insight Manager (SIM) and 8 licenses for each of the following products: Rapid Deployment Pack (RDP), Performance Management
Pack (PMP) and the Vulnerability and Patch Management Pack (VPM).
ProLiant BL30p Server Blades Installed in Server Blade Enclosure
ProLiant BL30p Server Blades Installed in Server Blade Enclosure
ProLiant BL30p Server Blades Installed in Server Blade Enclosure
ProLiant BL30p Server Blades Installed in Server Blade Enclosure
DA - 11958
Worldwide — Version 10 — December 17, 2004
HP ProLiant BL30p Server Blade
HP ProLiant BL30p Server Blade
HP ProLiant BL30p Server Blade
HP ProLiant BL30p Server Blade
Page 1

Advertisement

loading

Related Manuals for HP ProLiant BL30p

Summary of Contents for HP ProLiant BL30p

  • Page 1 What's New The HP BladeSystem Management Suite is delivered in a convenient to purchase pack which includes a BL p-Class Server Blade Enclosure, a single copy of Systems Insight Manager (SIM) and 8 licenses for each of the following products: Rapid Deployment Pack (RDP), Performance Management Pack (PMP) and the Vulnerability and Patch Management Pack (VPM).
  • Page 2 Option kit available for field upgrade of backplanes to existing, deployed blade enclosures Each server blade enclosure is 6U and holds up to 16 ProLiant BL30p server blades (BL30p blade sleeve is required for each pair of BL30p blades installed)
  • Page 3 ProLiant BL30p Server Blade ProLiant BL30p Server Blade + + + + ProLiant BL30p Blade Sleeve (holds 2 BL30p blades) ProLiant BL30p Blade Sleeve (holds 2 BL30p blades) ProLiant BL30p Blade Sleeve (holds 2 BL30p blades) ProLiant BL30p Blade Sleeve (holds 2 BL30p blades)

  • Page 4: Configuration Steps

    BL p-Class server blade enclosure with enhanced backplanes with Rapid Deployment Pack trial (243564-B22) BL p-Class server blade enclosure with the HP BladeSystem Management Suite which is delivered in a convenient to purchase pack that includes a single copy of Systems Insight Manager (SIM) and 8 licenses for each of the following products: Rapid Deployment Pack (RDP). (380625-B21)
  • Page 5 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Overview B21). RJ-45 Patch Panel (230766-B21) BL p-Class C-GbE2 Interconnect Kit (with 12 RJ-45 10/100/1000 T/TX/T external ports) (283192-B21) with or without optional ProLiant BL p-Class...
  • Page 6 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Overview ProLiant BL p-Class Server Blade Enclosures with Enhanced Backplanes Installed in 42U Rack ProLiant BL p-Class Server Blade Enclosures with Enhanced Backplanes Installed in 42U Rack...

  • Page 7: Standard Features (Server Blade)

    Integrated Manageability Integrated Manageability Integrated Manageability Integrated Lights-Out (iLO) Management Advanced Pack with new static IP bay configuration feature iLO integrated HP BladeSystem wizard simplifies iLO, blade server and operating system installation and configuration. Internal Storage Internal Storage Internal Storage...
  • Page 8 Fiber Channel on the Fiber Channel on the Fiber Channel on the Fiber Channel on the The following items are needed to connect the ProLiant BL30p to a SAN via Fibre Channel: ProLiant BL30p ProLiant BL30p ProLiant BL30p ProLiant BL30p 1.
  • Page 9 Server Blade Enclosure Server Blade Enclosure Holds up to: Eight (8) ProLiant BL20p series server blades Sixteen (16) ProLiant BL30p series server blades (BL30p blade sleeves required) Two (2) ProLiant BL40p series server blades A combination of the above NOTE:...
  • Page 10 Power ON, management, and per port status and speed LED indicators Reset/power momentary push-button switch HP ProLiant BL Interconnect Switch Management Utilities and User Documentation CD Fully pre-configured for rapid deployment and immediate operation The GbE Interconnect Kits (C-GbE and F-GbE) are for applications that require network adapter consolidation to 100 Mbps (Fast Ethernet).
  • Page 11 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Standard Features (Server Blade Enclosure and Interconnects) ProLiant BL p-Class GbE2 ProLiant BL p-Class GbE2 ProLiant BL p-Class GbE2...
  • Page 12 62.5/125 µm Multimode Fiber, 160 MHz/Km (220 meters) 62.5/125 µm Multimode Fiber, 200 MHz/Km (275 meters) NOTE: NOTE: NOTE: NOTE: For cabling information, refer to the website at: http://www.hp.com/go/servers/. DA - 11958 Worldwide — Version 10 — December 17, 2004 Page 13...
  • Page 13 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Standard Features (Power System and Rack Information) ProLiant BL p-Class ProLiant BL p-Class ProLiant BL p-Class ProLiant BL p-Class...
  • Page 14 HP Systems Insight Manager (HP SIM) help maximize system uptime and performance and reduce system maintenance costs by providing proactive notification of problems before those problems result in unplanned downtime or reduced productivity. HP SIM is easy to set up to work with the Insight Management Agents, integrated Light-Out and Remote Insight Light-Out Edition, and Version Control Agents to deliver robust fault, configuration, and asset management as well as remote administration.
  • Page 15 Intelligent Manageability Intelligent Manageability Integrated Lights-Out (iLO) Advanced Pack HP BladeSystem wizard - new feature iLO, blade and OS installation and configuration Static IP bay configuration -- new feature for ProLiant BL p-Class blades Virtual Text and Graphical Remote Console...
  • Page 16 Must be capable of supporting 1600 lb (for full rack configuration) Perforated front and rear doors to accommodate front-to-back cooling Must have 65% open perforation on server blade enclosure doors to support airflow requirements Optimized for use with the HP 10000 Series racks NOTE: NOTE: NOTE: NOTE: If using Compaq 7000 Series rack, Rack Extension Kit and High Air Flow Rack Door options are required.
  • Page 17 System Management, Performance Services and Mission Critical Support Solution HP Care Pack services for ProLiant BL p-Class server blades, cover the server blade and the p-Class blade enclosure that the server blade is installed in as well as interconnects, power enclosure with power supplies and power distribution.
  • Page 19 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Options USB Easy Access Keyboard (Carbonite/Silver) Country Key Code USB Easy Access Keyboard (Carbonite/Silver) Country Key Code USB Easy Access Keyboard (Carbonite/Silver) Country Key Code...
  • Page 20 -B22 (shock pallet) used to ship racks with equipment installed (by custom systems, VARs and Channels) -B23 (crated) used for air shipments of empty racks Not all HP equipment is qualified to be shipped in the Rack 10000 series. NOTE: NOTE:...
  • Page 21 CAT5e Cable 20', 4 pack 263474-B24 CAT5e Cable 40', 1 pack 263474-B25 NOTE: NOTE: NOTE: NOTE: For additional information regarding HP KVM Switches and options, please see the following URL: http://h18004.www1.hp.com/products/servers/proliantstorage/rack-options/list.html#console DA - 11958 Worldwide — Version 10 — December 17, 2004 Page 31...
  • Page 22 Service and Support Service and Support NOTE: NOTE: NOTE: NOTE: The HP Care Pack services for ProLiant BL p-Class server blades, cover the server blade and Offerings Offerings Offerings Offerings (HP Care Pack the p-Class blade enclosure that the server blade is installed in as well as interconnects, power Services) enclosure with power supplies and power distribution.
  • Page 23 HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Memory ProLiant BL30p Server Blade (all models) ProLiant BL30p Server Blade (all models) ProLiant BL30p Server Blade (all models) ProLiant BL30p Server Blade (all models)

  • Page 24: Technical Specifications

    QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Technical Specifications ProLiant BL p-Class ProLiant BL p-Class ProLiant BL p-Class ProLiant BL p-Class Dimensions Dimensions Dimensions Dimensions Height 10.5 in (26.67 cm)
  • Page 25 (RFC 1643), 802.1Q Extended Bridge MIB (RFC 2674), Entity MIB (RFC 2037), SNMP Trap Convention (RFC 1215), Bridge Trap (RFC 1493), Remote Monitoring Traps (RFC 1757), and HP Enterprise Switch MIBs and Environmental Traps IGMP v1 (RFC 1112), IGMP v2 (RFC 2236), SNTP (RFC 1361), Telnet (RFC 854), TFTP...
  • Page 26 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Technical Specifications Network Transfer Network Transfer Network Transfer Network Transfer 10 Base-T (half-duplex) 10 Mbps Rate Rate Rate Rate...
  • Page 27 (RFC 2863), Ethernet MIB (RFC 1643), 802.1Q Extended Bridge MIB , Entity MIB (RFC 2037), RADIUS Authentication MIB, 802.3-2002 MIB, SNMP Trap Convention (RFC 1215), Bridge Trap (RFC 1493), Remote Monitoring Traps (RFC 1757) and HP Enterprise Switch MIBs and Environmental Traps RADIUS (RFC 2138), Telnet (RFC 854), TFTP client (RFC 783), SSH v1.5, SCP v1.5, NTP...
  • Page 28 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Technical Specifications Operating and Operating and Operating and Operating and Single-Phase Model Single-Phase Model Single-Phase Model Single-Phase Model 3-Phase Model...
  • Page 29 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Technical Specifications Operating and Operating and Operating and Operating and Single-Phase Model Single-Phase Model Single-Phase Model Single-Phase Model 3-Phase Model...
  • Page 30 QuickSpecs HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade HP ProLiant BL30p Server Blade Technical Specifications Operating and Operating and Operating and Operating and Power Bus Box Power Bus Box Power Bus Box...
  • Page 31 Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
