AR-150 SERIES FACSIMILE OPERATION MANUAL c INSTALLATION c INITIAL SETTINGS c CHOOSING SUITABLE MEDIA c HOW TO USE THE FAX FUNCTION c TROUBLESHOOTING c SPECIFICATIONS c GLOSSARY c QUICK REFERENCE c INDEX Cover page(SUK).p65 21/09/99, 16:16...
Page 2
This product contains a lithium-ion battery, and must be disposed of properly. Contact your local environmental officials for disposal instructions. Important safety information • If any of your telephone equipment is not operating properly, you should immediately remove it from your telephone line, as it may cause harm to the telephone network.
TABLE OF CONTENTS INSTALLATION Introduction ......................1-1 Choosing a Location ..................1-1 Parts Identification ..................... 1-2 Connections ....................... 1-3 Connecting theTelephone Line Cord ..............1-3 Final Preparations ....................1-4 Connecting Other Devices ................. 1-4 INITIAL SETTINGS A Look at the Operation Panel ................2-1 About the Liquid Crystal Display ................
Page 4
Table of contents HOW TO USE THE FAX FUNCTION Sending Documents ..................4-1 Setting the Document ..................4-1 Optional Transmission Settings ..............4-3 Resolution ..................... 4-3 Contrast ......................4-3 Cover Sheet ....................4-4 Auto Cover Sheet ..................4-5 Dialing and Transmitting ................4-6 Direct Keypad Dialing ..................
1. INSTALLATION Introduction This manual describes how to use the fax function of the AR-150 series. Part names and functions shared with the copy function (for example, the misfeed indicator and add paper indicator), are described in the copier operation manual. For more information, please read the copier operation manual.
Connections Connecting the Telephone Line Cord Plug one end of the telephone line cord into the jack on the unit marked “TEL LINE.” Plug the other side into the wall jack (using the provided adaptator, if necessary). For Germany, please connect the cable from the fax unit with the wired plug connector code (F) with the wire down into the wall socket (TAE 6) code (F).
Final Preparations Connecting Other Devices If desired, an answering machine or external telephone can be connected to the unit by plugging the external line cord in the external jack of the wall jack (wall socket code “N” for Germany) or in the provided adaptator. •...
2. INITIAL SETTINGS A Look at the Operation Panel Left arrow key ( ) and right arrow key ( ) LCD contrasts dial Press these keys to scroll through a menu. During input mode, these keys are also sometimes used Turn this dial to adjust to move the cursor.
About the Liquid Crystal Display The unit is equipped with a two-line liquid crystal display (LCD) on the operation panel for displaying various messages and settings during operation. This LCD can display up to 20 characters on each line. When the unit is idle, the LCD shows the date, time, and the stand-by memory available.
Adjusting the Ringing Volume Adjust the ringing volume of the unit using the procedure below. Factory setting: 3 (MEDIUM) Step Press these keys Comments “OPTION SETTING” will appear FUNCTION in the display. “RINGING VOLUME” will appear in the display. Press the key to lower or raise the volume to the desired level.
Turning Key Beeps Off If you prefer, you can choose to turn the key beeps off. To do this, follow the proce- dure below: Factory setting: 1 (ON) Step Press these keys Comments “OPTION SETTING” will appear in FUNCTION the display. PQRS “KEY BEEPS”...
Fax Setup How to Enter Characters You can enter letters with the number keys. Letters are marked above each of the number keys “2” through “9”. To enter a letter, press the appropriate key repeatedly until the desired letter appears (the number of the key appears first, followed by letters in the order marked above the key).
1 key twice. To switch between lower case and capital letters, press PQRS PQRS the REDIAL PAUSE key once. (example: SHARP) “STORED” will appear in the ENTER display. STOP STOP Press the STOP key twice to exit.
Fax Setup Setting the Date and Time The date and time that appear in the display are printed at the top of each page you transmit. Set the date and time by pressing the keys on the operation panel as shown below.
Auto Summer Time Setting The unit can be set to adjust to time changes during the year, so that its internal clock and all subsequent notations of time (fax headers, programmed times, etc.) are automatically adjusted. When the Auto Summer Time Setting is on, the adjustments take place as shown below: On the last Sunday of every March: 01:00 02:00...
Fax Setup Selecting the Reception Mode Your unit has three modes for receiving incoming calls and faxes: • AUTO mode: Select this mode when you only want to receive faxes on your telephone line. The unit will automatically answer all calls and receive incoming faxes. •...
Fax Setup Setting the Number of Rings for Auto Reception You can set the number of rings before the unit answers in AUTO mode using the procedure below. Factory setting: 2 Step Press these keys Comments FUNCTION “OPTION SETTING” will appear in the display.
Fax Setup Selecting the Reception Paper Size On the control panel, you can select the paper size that you want received faxes to be printed on (AUTO, A4, Letter, Legal). If you select the AUTO setting the unit automatically prints the fax out on the most appropriate size paper. Follow the procedure below: Factory setting: 4 (AUTO) Step...
Fax Setup Setting the Tray Paper Size You must program the size of paper you have loaded in the unit so that Receive Reduce functions can properly adjust the size of documents printed out. Follow the steps below. Note: If you are using A4 size paper, you do not need to make any changes, as this is the factory setting.
Fax Setup Setting the Number of Recall Times You can select the number of times the unit will try to recall a busy number. If you enter 00, the unit will not try to recall. Follow this procedure: Factory setting: 02 Step Press these keys Comments...
Fax Setup Setting the Recall Interval The recall interval, the time the unit waits in between attempts to re-send a fax to a busy number, can be set from 1 to 15 minutes. Follow this procedure: Factory setting: 05 (5 minutes) Step Press these keys Comments...
Fax Setup Setting the Index Function You can print an index mark along the edge of the pages in each job. This makes it easy to separate different jobs on the output tray. Use the following procedure to set the index function. Separate faxes with index marks Factory setting: 1 (ON)
Fax Setup Setting Fine Resolution Priority For most faxing jobs, you will most likely want to specify the resolution. However, you can also set a default resolution when no setting is made using the RESOLU- TION key. When Fine Resolution Priority is turned on, all faxes will be sent in Fine Mode unless otherwise specified.
Fax Setup Using the Remote Reception Function The unit’s Remote Reception feature is designed to allow you to activate fax reception from an extension telephone. The Remote Reception function operates even when the FAX Signal Receive function is turned off. When you hear the fax tone, simply press the one-digit Fax Remote Number (Factory setting: 5) and .
Fax Setup Setting a Fax Remote Number: Factory setting: 5 Step Press these keys Comments “OPTION SETTING” will appear FUNCTION in the display. “FAX REMOTE NUMBER” will appear in the display. Enter the number you would WXYZ like to use as the Fax Remote Number.
Fax Setup Storing Numbers for Automatic Dialing Automatic Dialing is a quick and convenient way to dial by using only a Rapid key (Rapid Key Dialing), or pressing the SPEED/SEARCH key and select the SPEED and entering a two digit number (Speed Dialing). To use Automatic Dialing, you must first store the full number.
Page 28
Fax Setup Press “1” if you want to specify the number as a Chain Dialing number (see “Chain Dialing for Long Numbers” in this section). Otherwise, press “2”. Return to Step 4 to store another number, or press the STOP key a number of times until you exit.
Fax Setup Chain Dialing for Long Numbers The maximum number of digits which may be entered when storing a fax number is 20. If you need to store a number which is longer than 20 digits, use Chain Dialing. Chain Dialing allows you to combine two or more Automatic Dialing numbers, or use an Automatic Dialing number followed by additional digits entered manually with the number keys, to dial a single number.
Fax Setup Storing Numbers Under Group Keys Group keys allow you to dial a group of fax numbers by simply pressing the appropriate Group key once. They are convenient for the Broadcasting function, which is used to transmit a document to a group of fax machines. All Rapid keys can be programmed as Group keys.
Page 31
Fax Setup Enter the name of the group (maximum of 20 digits including pauses) by pressing number keys as described in “How to Enter Characters” in this chapter. If you do not want to enter a name, skip this step. (example) Setting: “GROUP SET”...
Using the Unit with an Answering Machine Quiet Detect Time Quiet Detect Time is the function that enables the unit to be used along with an answering machine for both phone messages and faxes. After the answering machine has answered, any duration of silence longer than a certain threshold time will prompt the unit to take over the line and prepare to receive a fax.
Using the Unit with an Answering Machine If Quiet Detect Time is not working properly... With some answering machines, there is simply no Quiet Detect Time that will allow both reception of faxes and uninterrupted voice messages. Even in this case, however, you can set up the unit to receive both phone and fax messages from callers on touch-tone lines.
3. CHOOSING SUITABLE MEDIA Originals Suitable for Faxing Make sure that the documents you want to fax meet specifications and guidelines listed in this section. Size and Weight The size and weight of documents that you can load in the SPF (Single Pass Feeder) depend on whether you load one sheet at a time or several sheets at once.
• Originals with plastic or metallic coatings Notes: • Sharp does not accept any responsibility for the loss or damage of originals. • It is a good idea to copy valuable originals on a flat-bed copier before using them with the unit.
4. HOW TO USE THE FAX FUNCTION The standalone fax component of your unit offers a range of sophisticated features that allow you to control image quality, reception mode, broadcasting, polling, and transmission priorities. Functions such as sending documents from memory and substituting reception into memory are greatly enhanced by the large memory capacity.
Page 38
Sending Documents When placing the Original on the Table: Confirm that there are no documents in the SPF, and open the original cover. Place the document face down on the original table. Align the document according to the original scale in the illustration below.
Sending Documents Optional Transmission Settings There are several transmission settings that you can make before dialing and transmitting a document. Resolution Your fax has four resolution settings: • HALF TONE Use HALF TONE for photographs and illustrations. The original will be reproduced in 256 shades of gray.
Sending Documents Cover Sheet You can have your fax generate a cover sheet and send it as the last page of the transmission. The cover sheet includes the date and time, the sender’s name and number, and the receiver’s name and number if an automatic dialing number is used. The total number of pages sent is indicated on the bottom.
Sending Documents Auto Cover Sheet If you want to send a cover sheet with your fax transmissions regularly, this function is very useful. This function differs from the Cover Sheet function in two ways. First, the Cover Sheet function must be programmed before every fax you want to use it with;...
Sending Documents Dialing and Transmitting Once you have set the document (either in the automatic document feeder or on the original table), and have selected the desired transmission settings, you are ready to dial the number of the receiving fax machine and transmit the document. You can choose from one of the several ways of dialing that best suit your needs.
Sending Documents Rapid Key Dialing If the number you want to dial has been stored as a Rapid key number (see “Storing Numbers for Automatic Dialing” in Chapter 2), you can dial it by pressing the appropriate Rapid key as shown: 20/POLL Speed Dialing If the number you want to dial has been stored as a Speed Dial number, you can dial...
Sending Documents Chain Dialing The Chain Dialing function allows you to combine an Automatic Dialing number set for Chain Dialing (see “Storing Numbers for Automatic Dialing” in Chapter 2) with another Automatic Dialing number or digits entered manually with the number keys to dial one phone number up to 50 digits long.
Sending Documents Using the SEARCH Key If you do not remember the Rapid key or Speed Dial number in which you have stored a particular fax number, you can search for the number by following the steps below: SPEED/ Press the SPEED/SEARCH key SEARCH twice.
Receiving Faxes You can set the unit to one of three modes of reception, AUTO, MANUAL, or A.M. (Answering Machine). To select the reception mode, press the RECEPTION MODE key until the light next to the desired mode comes on. ENTER AUTO BOOK SEND...
Optional Reception Settings The unit has various optional settings for the reception of faxes. Receive Reduce You may on occasion receive faxes that are larger than the paper loaded in the unit. To ensure that you do not lose any part of the original, you should use the Receive Reduce function, which scales the fax to the printing paper size.
Optional Reception Settings Footer Printing You can choose whether or not to have a footer with the sending machine’s ID information (name, number, etc.) printed out. Factory setting: 2 (OFF) Step Press these keys Comments “OPTION SETTING” will FUNCTION appear in the display. WXYZ “FOOTER PRINT”...
Special Functions Memory Your unit has a memory area that can be used to store both incoming and outgoing documents. • Approximately 120 pages of average content can be held in memory for transmission. Less can be held if any of the pages were scanned using fine or superfine resolution. Memory Backup •...
Special Functions Data Transfer If there is a problem with the unit, you can use the Data Transfer function to have received faxes read into memory and then sent to a different fax machine for printing. This function is used when you cannot print received faxes, for example when the unit runs out of toner, a misfeed occurs.
Special Functions Transmission Reservation When your fax is busy receiving a document or transmitting a document from memory, you can “reserve” a transmission by setting the document on the original table, reading it into memory, and entering the fax number. Once the current operation is completed, your fax will automatically dial the number and transmit the document saving you from having to wait.
Page 52
Special functions When using the original table : Confirm that there are no documents in the SPF and that copying is not in progres, then gently close the original cover. Place the document face down on the original table. Align the document according to the original scale in the illustration below.
Special Functions Broadcasting This function allows you to send the same document to as many as 50 different locations with just one operation. Once the document is loaded, it is scanned and stored in memory. The fax numbers you have entered are then automatically dialed in succession, and the document is transmitted to each location.
Page 54
Special Functions Press the FAX START key. Transmission will begin. FAX START Broadcasting using a Group key If the fax machines to which you want to broadcast have all been programmed into one Group key, you can perform the broadcasting operation using the following simplified procedure.
Special Functions Polling Polling allows you to request another fax machine to send a document to your fax machine. In other words, the receiving fax machine, not the transmitting fax machine, activates the transmission. You can use your fax to both poll and be polled by others. Setting the Polling Key To use the polling function, you must first set Rapid key 20/POLL for use as a polling key.
Special Functions Being Polled (Memory Polling) To allow multiple fax machines to poll your fax, or in cases where you want to free up the Document Tray for other operations, use Memory Polling instead of Polling Standby. Programming a Memory Polling Operation You can choose whether to allow polling only once, or an unlimited number of times.
Page 57
Special Functions Adding to Documents If you have a document stored in memory for polling, and you want to add pages to it, use the following procedure. If you allow polling only once, the document will be automatically cleared from memory after polling.
Special Functions Timer Operations The timer function allows you to set a transmission or polling operation to be performed automatically at a time you specify. Up to three transmission operations or polling operations can be set at any one time, and the times they will be performed can be specified up to a week in advance.
Page 59
Special Functions To set a timer operation: Step Press these keys Comments FUNCTION “TIMER MODE” will appear in the display. Select SET. “TIMER COMM. #=1”, “TIMER COMM. #=2” or “TIMER COMM. #=3” will appear in the display. Select “SEND MODE” or ENTER “POLLING MODE”.
Special Functions To cancel a timer operation: If you need to cancel a timer operation after it has been set, follow the steps below: If the timer operation is a transmission operation, you will need to know the number assigned to it. If you do not remember the number (it appears in the display when you set the operation), print out the Timer List.
Page 61
Special Functions To store junk fax numbers, use the following procedure: Step Press these keys Comments FUNCTION “ANTI JUNK FAX” will appear in the display. “JUNK FAX # MODE” will appear in the display. ENTER “ENTER JUNK FAX #” will appear in the display.
Printing Out Reports The unit is capable of printing a range of reports on faxing activities as well as various settings you have made. The reports are described below. 1. TRANSMISSIONS ACTIVITY REPORT: Faxes sent from the unit. P. 01 ACTIVITY REPORT (SENDING) SEP-21-1999-TUE 9:36 DATE...
Printing Out Reports 5. OPTIONAL SETTING LIST: Currently activated optional settings. OPTIONAL SETTING LIST SEP-21-1999-TUE 9:37 SW # ITEM SETTING PRINT PAPER SIZE AUTO PAPER SIZE (MAIN CASSETTE) FINE PRIORITY # OF RINGS AUTO RX 2 RINGS # OF RINGS MANUAL RX AUTO LISTING PRINT SELECTION ERROR/TIMER...
Printing Out Reports Activity Report Auto Listing It is also possible to have the unit automatically print out Transmission and Reception Activity Reports at designated times (for example, daily, every two days, weekly, etc.) and every 50 operations. Factory setting : 5 (NO) Step Press these keys Comments...
FAX SERVICE ERROR (X) The fax will not function.Contact your Sharp dealer. Note: If your problem cannot be solved by carrying out the instructions in the Check and Remedy column above, please contact your Sharp dealer. TROUBLESHOOTING 05 TROUBLE a(SUK) A5.P65 11/10/99, 14:23...
Messages and Signals Display Messages Message Meaning DOCUMENT JAM The original document is jammed. FAX RX IN MEMORY A fax has been received in memory because the imaging cartridge needs replacement, the fax machine has run out of printing paper, or the paper is jammed. The fax will be printed out automatically once the problem is fixed.
Messages and Signals Audible Signals Meaning Sound Type Duration Indicates the end of Continuous tone 3 seconds transmission, reception, or line error. Warning tone Continuous tone 1 second TROUBLESHOOTING 05 TROUBLE a(SUK) A5.P65 11/10/99, 14:23...
(using SHARP standard document) The time should be slightly different when the line is busy. Memory: 2 megabytes of RAM (120 pages, when using SHARP document with a standard resolution) Sending document size: Maximum B4, minimum A5 (When using the SPF: One sheet at a time: Max.257mm x 500mm,...
Page 70
Anti Junk Fax numbers, timer, group, phone number, optional setting As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.
GLOSSARY A.M. mode: When set to A.M. (Answering Machine) mode, the unit directs all incoming calls to an answering machine connected to the same line. Anti Junk Fax: A faxing feature that enables the user to program up to ten fax numbers from which he/she does not want to receive faxes.
Page 72
Glossary Rapid Key Dialing: A form of Automatic Dialing by which only a single fax number programmed key (a Rapid key) has to be pressed in order to dial a number. Receive Reduce: A faxing function that automatically scales received faxes to the size of the paper loaded in the unit.
QUICK REFERENCE This page summarizes the operations you can perform with this unit. For detailed information about each operation, refer to the appropriate section of this manual. Set RESOLUTION/CONTRAST Load the document BROADCASTING then following operation Normal Broadcasting BROADCAST Enter Speed Dial number/Press Rapid keys FAX START Using Group Key...
Page 74
Quick reference FUNCTION MODE STEP 1 Press FUNCTION key STEP 2 Press the menu number from the list below STEP 3 Press the option number from the list below 1. TIMER MODE 1. OPERATION SET 2. OPERATION CLEAR (SEND/POLLING) 2. LISTING MODE 1.
INDEX Group Keys ......... 2-22 A.M. Mode .......... 4-10 Group List ........... 4-27 Activity Report Auto Listing ....4-28 Alarm Beep Length ......2-3 Answering Machine Backup ....2-25 Anti Junk Fax ........4-24 Index Function ........2-15 Arrow Keys ........... 2-2 Audible Signals ........
Page 76
Index Reception into Memory ...... 4-13 Reception Mode ........2-9 Redialing ..........4-9 Remote Reception ......2-17 Resolution ..........4-3 Ringing Volume ........2-3 SEARCH Key ........4-9 Sending Documents ......4-1 Setting Date & Time ......2-7 Setting the Language ......2-4 Specifications ........
(Name and Telephone Number) U.S.A Sharp Electronics Corporation Telephone number for information : 1-800-237-4277 Emergency telephone number : 1-800-255-3924 Canada Sharp Electronics of Canada Ltd. Telephone number for information : 905-890-2100 Emergency telephone number : 1-800-255-3924 United Sharp Electronics (U.K.) Ltd. Kingdom Telephone number for information : 01923-474013 Section 3.
Page 78
License Agreements Section 5. Health Hazard Data Route(s) of Entry : Inhalation? Skin? Ingestion? Possible but very unusual. Health Hazards : Acute oral toxicity—LD50 of this toner is over 2,000mg/kg. Mutagenicity—The result of Ames test is negative. Carcinogenicity : In 1996 the IARC reevaluated carbon black as a Group 2B carcinogen (possible human carcinogen).
Page 79
License Agreements Section 7. Fire and Explosion Data Flash Point (Method Used) : Not applicable Ignition Temperature : No data available Flammable Limits : (LEL); Not applicable (UEL); Not applicable Extinguishing Media : CO , dry chemical, foam or water Special Fire Fighting Procedure : None Unusual Fire and Explosion Hazard : This material has no unusual fire or...
Page 83
License Agreements This equipment complies with the requirements of Directives 98/13/EC, 89/336/EEC and 73/23/ EEC as amended by 93/68/EEC. Dieses Gerät entspricht den Anforderungen der EG-Richtlinien 98/13/EWG, 89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG. Ce matériel répond aux exigences contenues dans les directives 98/13/CEE, 89/336/CEE et 73/ 23/CEE modifiées par la directive 93/68/CEE.
