Epson ELPDC05 Specifications

When it comes to sharing intricate blueprints, charts, or 3-D
objects with a room full of students or executives, the Epson ELPDC05
high-resolution document imager is clearly a remarkable solution.
Eliminating the need to prepare overhead transparencies or gather
audience members around a crowded demonstration table, this powerful
accessory is perfect for the most demanding imaging applications.
With XGA resolution, it's the ideal way to display anything with clarity
and precision. Its built-in base light provides optimum image quality for
transparencies, slides, negatives, and X-rays, while a live camera with
optical and digital magnification enables users to zoom in up to 35
times. Special functions like Clear Screen mode, white balance and
gamma selection are also available to enhance every detail.
Compatible with a full line of Epson PowerLite
ELPDC05 joins Epson's family of high-performance accessories that make
presentations easier than ever. The unit's RGB function allows for
seamless switching between different sources. And, there's even a
wireless remote control. Epson's innovative push-button feature makes it
easy to rotate and capture images. Then, save them to a PC using Image
Mate so they can be retrieved later, distributed, and/or added to
™
another presentation.
Whether it's used in the classroom, courtroom, or board room, the
versatile Epson ELPDC05 is the perfect complement to any
presentation system.
Superior Image Quality and Performance
• XGA resolution for incredible clarity
• 1/3" 850,000 pixel CCD for capturing fine details in images, text
and 3-D objects
• 18x optical zoom for capturing minute features
• 2x digital magnification (with live camera), which works together
with the optical zoom to enlarge images up to 35 times
• Built-in base light for optimum image quality for transparencies,
negatives, slides, and X-rays
• Motion at 20 frames per second
• Built-in white balance for enhancing contrast
• Gamma selection for low-light situations
• Clear Screen/Image mode to eliminate random noise
• Color and black-and-white selection for X-rays and dark
blueprint images
• Built-in image rotation (90, 180 and 270 degrees)
High-Resolution Document Imager
Deliver and demonstrate every detail
® projectors, the Epson
6 watt lighting unit
Epson ELPDC05
Advanced Presentation Features
• RGB switching function for seamless transitions between
two applications
• Built-in RS-232C interface for communication with a remote
control system
• Easy-to-use wireless remote control and front panel operation
• On-screen display menu (accessed via the included mouse) for
easy control
• Arrow pointer to guide audience members during
critical presentations
• Image Mate software to rotate and save images onto a PC
(requires Windows ® 98, Me, or XP and a USB connection)
• Eight picture memory presets
• One-touch freeze function to stabilize motion on the screen and
display it as a still image
• Tilting camera head so images can be captured both on and off
the stage
• Negative/positive conversion that's ideal for viewing film photography
• Built-in scrolling for more extensive image coverage
• Convenient handle and compact design so it is easy to take the
document imager to your next presentation
Epson Service and Support
• Comprehensive two-year warranty
• 90-day bulb warranty for added dependability
• Epson PrivateLine SM dedicated toll-free support line available from
6 a.m. to 6 p.m. PST Monday - Friday (This service is free for the
duration of the warranty. Calls are answered live, typically in
under a minute.)
Stage
Mouse
EPSON
Tilting camera head
Control panel
Remote control
Remote control holder
®
