Page 1 Projector CP-X268A User's Manual – Operating Guide Thank you for purchasing this projector. WARNING Before using this product, please read the "User's Manual - Safety Guide" and related manuals to ensure the proper use of this product. After reading them, store them in a safe place for future reference. About this manual Various symbols are used in this manual.
Page 2 Read this Safety Guide first. Projector User's Manual - Safety Guide Thank you for purchasing this projector. WARNING • Before using, read these user's manuals of this projector to ensure correct usage through understanding. After reading, store them in a safe place for future reference.
Page 3: Safety Precautions
Safety Precautions WARNING Never use the projector if a problem should occur. Abnormal operations such as smoke, strange odor, no image, no sound, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. can cause a fire or electrical shock. In such case, immediately turn off the power switch and then disconnect the power plug from the power outlet.
Page 4 Safety Precautions (continued) WARNING Be cautious of High temperatures of the projector. High temperatures are generated when the lamp is lit. It could result in fire or burn. Use special caution in households where children are present. Do not touch about the lens, air fans and ventilation openings during use or immediately after use, to prevent a burn.
Page 5 Safety Precautions (continued) WARNING Be careful in handling the light source lamp. The projector uses a high-pressure mercury glass lamp made of glass. The lamp can break with a loud bang, or burn out. When the bulb bursts, it is possible for shards of glass to fly into the lamp housing, and for gas containing mercury to escape from the projector’s vent holes.
Page 6 Safety Precautions (continued) CAUTION Be careful in moving the projector. Neglect could result in an injury or damage. • Do not move the projector during use. Before moving, disconnect the power cord and all external connections, and close the slide lens door or attach the lens cap.
Page 7 Safety Precautions (continued) CAUTION Remove the power cord for complete separation. • For safety purposes, disconnect the power cord if the projector is not to be used for prolonged periods of time. Disconnect the • Before cleaning, turn off and unplug the projector. Neglect could result in plug from the fire or electrical shock.
Page 8 Safety Precautions (continued) NOTE About consumables. Lamp, LCD panels, polarizors and other optical components, and air filter and cooling fans have a different lifetime in each. These parts may need to be replaced after a long usage time. • This product isn’t designed for continuous use of long time. In the case of continuous use for 6 hours or more, or use for 6 hours or more every day (even if it isn’t continuous), or repetitious use, the lifetime may be shortened, and these parts may need to be replaced even if one year has not passed since the beginning of using.
Page 9 Lamp WARNING HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
Page 10: Regulatory Notices
Regulatory Notices FCC Statement Warning WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
Page 11: Table Of Contents
Content Content About this manual..1 EASY Menu ....27 Aspect, Auto keystone Execute, Content .
Page 12: Content
Contents of package Contents of package VIDEO SEARCH ASPECT AUTO BLANK MAGNIFY HOME PAGE UP VOLUME (1) Projector PAGE DOWN MUTE FREEZE MY BUTTON KEYSTONE (2) Remote control MENU POSITION ENTER RESET with two AA batteries (3) Power cord (4) RGB cable (5) Audio/Video cable (6) Soft case (7) User’s manuals...
Page 13: Projector Features
Projector features / Preparations Projector features This projector is used to project various computer signals as well as NTSC/PAL/ SECAM, Component (SD, HD) video signals onto a screen. It requires just a little space for installation and gets a large image from short distance. High Brightness Newly developed 200W UHB (Ultra High Brightness) lamp gives you a higher brightness image on a screen.
Page 14: Part Names
Part names Part names Projector Control buttons ( Lamp cover ( Remote sensor ( (Lamp unit is inside.) Speaker Zoom ring ( Security bar ( Focus ring ( (Use for attaching a commercial anti-theft chain or wire.) Vent Elevator button ( Lens ( Front-Right side Elevator foot (...
Page 15 Part names Power switch ( AC inlet ( Elevator button ( Ports (See below.) Elevator foot ( Rear-Left side Vent AUDIO IN1 port ( (In the default setting, the AUDIO IN1 port is the audio port for the RGB IN1 port, however, it is possible to AUDIO IN3 L/R port ( change the settings.
Page 16: Control Buttons
Part names Control buttons 64, 65) LAMP indicator ( 64, 65) TEMP indicator ( Cursor buttons POWER indicator ( STANDBY/ON button INPUT button ( NOTE • INPUT button is function as ENTER key when the projector is in the PC-LESS presentation mode. Use the RGB button or VIDEO button on remote control to change the input port.
Page 17: Setting Up
Setting up Setting up WARNING Place the projector in a stable position horizontally. A fall or a turnover could cause an injury and/or damage to the projector. Then using • Do not place the projector on an unstable, slant or vibrant surface such as a wobbly or inclined stand.
Page 18: Arrangement
Setting up Arrangement Refer to the illustrations and tables below to determine the screen size and projection distance. The values shown in the table are calculated for a full size screen: 1024×768 (a) The screen size (diagonal) (b) Distance from the projector to the screen (±10%) (c) The height of the screen (±10%) (c) up 16:9...
Page 19: Adjusting The Projector's Elevator
Setting up Adjusting the projector's elevator CAUTION result in malfunction. To prevent damaging the projector and injuring yourself, always hold the projector whenever using the elevator buttons to adjust the elevator feet. Do not incline the projector rightward or leftward. Also do not incline it backward or forward exceeding 30 degrees.
Page 20: Using The Security Bar
Setting up Using the Security Bar WARNING falling. Dropping or knocking over the projector may cause damage or injury. CAUTION measure. It is intended to be used as an extra theft prevention measure. A commercial anti-theft chain or wire can be attached to the security bar on the projector.
Page 21: Connecting Your Devices
Setting up Connecting your devices CAUTION Attempting to connect a live device to the projector may generate extremely loud noises or other abnormalities that may result in malfunction and/or damage to the device and/or projector. Some cables have to be used with core set. A too long cable may cause a certain picture degradation.
Page 22: Examples Of Connection With A Computer
Setting up Examples of connection with a computer * In the default setting, the AUDIO IN1 port is the audio port for the RGB IN1, and the AUDIO IN2 port is the audio port for the RGB IN2 ports. To change the settings, refer to the AUDIO item in the SETUP menu. ( USB cable RGB cable SD CARD...
Page 23: Video Out
Setting up Examples of connection with a VCR/DVD player * In the default setting, the AUDIO IN3 L/R port is the audio port for the VIDEO, S-VIDEO and COMPONENT VIDEO ports. To change the settings, refer to the AUDIO item in the SETUP menu.
Page 24: Connecting Power Supply
Setting up Connecting power supply WARNING Please use extra caution when connecting the power cord, as • Only use the power cord that came with the projector. If it is damaged, contact your dealer to newly get correct one. • Only plug the power cord into an outlet rated for use with the power cord's •...
Page 25: Inserting An Sd Card And Usb Memory
Setting up Inserting an SD Card and USB Memory When using the projector with a wireless LAN please insert the included Wireless Network Card. When using a commercial SD Memory card in order to view images insert the SD Memory card in the same manner. And when using a commercial USB MEMORY in order to view images insert the USB MEMORY to the AUX I/O port.
Page 26: Remote Control
Remote control Remote control Putting batteries WARNING Always handle the batteries with care and use them only as directed. Battery may explode if mistreated. Do not recharge, disassemble or And also improper use may result in cracking or leakage, which could result in •...
Page 27: Using The Remote Control
Remote control Using the remote control CAUTION Be careful in handling the remote control. • Do not drop or expose the remote control to physical impact. • Do not get the remote control wet or place it on wet objects. It may result in malfunction.
Page 28: Power On/Off
Power on/off Power on/off WARNING When the power is on, a strong light is emitted. Do not look into the lens of projector. Also do not peep at the inside of projector through a hole. NOTE • Turn the power on/off in right order. Please power on the projector prior to the connected devices.
Page 29: Operating
Operating Operating Adjusting the volume Press the VOLUME button on the remote control. SEARCH A dialog will appear on the screen to aid you in adjusting the volume. VIDEO BLANK ASPECT AUTO MAGNIFY HOME PAGE UP VOLUME To close the dialog and complete the operation, press the VOLUME button again.
Page 30: Searching An Input Signal
Operating Selecting an input signal (continued) Press the VIDEO button on the remote control to select an input for video signal. SEARCH VIDEO Each time you press the button, the projector switches its BLANK ASPECT AUTO video input port as below. COMPONENT VIDEO S-VIDEO VIDEO...
Page 31: Using The Automatic Adjustment Feature
Operating Using the automatic adjustment feature Press the AUTO button on the remote control. SEARCH VIDEO For an RGB signal BLANK ASPECT AUTO The vertical position, the horizontal position, the horizontal MAGNIFY PAGE UP VOLUME HOME phase and the horizontal size will be automatically adjusted. And the aspect ratio will be automatically set to default.
Page 32: Correcting The Keystone Distortions
Operating Correcting the keystone distortions Press the KEYSTONE button on the MAGNIFY PAGE UP HOME VOLUME remote control. A dialog will appear on the PAGE DOWN MUTE screen to aid you in correcting the distortion. FREEZE MY BUTTON KEYSTONE perform the following. 1) AUTO executes automatic vertical keystone correction.
Page 33: Freezing The Screen
Operating Freezing the screen Press the FREEZE button on the remote control. MAGNIFY HOME PAGE UP VOLUME The “FREEZE” indication will appear on the screen, and the PAGE DOWN MUTE projector will enter the FREEZE mode. FREEZE MY BUTTON KEYSTONE To exit the FREEZE mode and restore the screen to normal, press the FREEZE button again.
Page 34: Operating The Computer Screen
Operating Operating the computer screen CAUTION your equipment. • While using this function, please connect only with a computer. • Before connecting, read the manuals of the computer you will connect. NOTE • It may not be possible to control notebook PC, and other computers with built-in pointing device (e.g.
Page 35: Multifunctional Settings
Multifunctional settings Multifunctional settings Using the menu function This projector has the following menus: PICTURE, IMAGE, INPUT, SETUP, SCREEN, OPTION, MIU, and EASY MENU. EASY MENU consists of functions often used, and using the same methods. The basic operations of these menus are as follows. MENU button VIDEO SEARCH...
Page 36: Easy Menu
EASY Menu EASY Menu With the EASY MENU, items shown in the table below can be performed. projector or remote control. Then perform it referring to the following table. Item Description ASPECT 32). See the ASPECT item in the IMAGE menu ( AUTO 37).
Page 37 EASY Menu EASY Menu (continued) Item Description CONTRAST 29). See the CONTRAST item in the PICTURE menu ( COLOR 30). See the COLOR item in the PICTURE menu ( TINT 30). See the TINT item in the PICTURE menu ( 30).
Page 38: Picture Menu
PICTURE Menu PICTURE Menu With the PICTURE menu, the items shown in the table below can be performed. on the projector or remote control, or the ENTER button on the remote control to execute the item. Then perform it referring to the following table. Item Description BRIGHTNESS...
Page 39 PICTURE Menu PICTURE Menu (continued) Item Description HIGH DEFAULT HIGH CUSTOM MID DEFAULT MID CUSTOM LOW DEFAULT LOW CUSTOM Hi-BRIGHT-1 DEFAULT Hi-BRIGHT-1 CUSTOM Hi-BRIGHT-2 DEFAULT Hi-BRIGHT-2 CUSTOM To adjust CUSTOM Selecting the CUSTOM and then pressing the ENTER : displays a dialog OFFSET GAIN to aid you in adjusting the OFFSET and/or GAIN...
Page 40: My Memory
PICTURE Menu PICTURE Menu (continued) Item Description LOAD1 LOAD2 LOAD3 LOAD4 SAVE4 SAVE3 SAVE2 SAVE1 This projector has 4 numbered memories for adjustment data. Performing the LOAD1, LOAD2, LOAD3 or LOAD4 loads the data on the memory whose number corresponds to the command’s number, and adjusts the picture automatically depending on the data.
Page 41: Image Menu
IMAGE Menu IMAGE Menu With the IMAGE menu, items shown in the table below can be performed. on the projector or remote control, or the ENTER button on the remote control to execute the item. Then perform it referring to the following table. Item Description For an RGB and MIU signal...
Page 42 IMAGE Menu IMAGE Menu (continued) Item Description Large Small • This item can be selected only for an RGB signal. H SIZE • When this adjustment is excessive, the picture may not be displayed correctly. In such a case, please reset the adjustment by pressing the RESET button on the remote control during this operation.
Page 43: Input Menu
INPUT Menu INPUT Menu With the INPUT menu, the items shown in the table below can be performed. on the projector or remote control, or the ENTER button on the remote control to execute the item. Then perform it referring to the following table. Item Description FILM...
Page 44 INPUT Menu INPUT Menu (continued) Item Description VIDEO port. COMPONENT SCART RGB When the SCART RGB is selected, the COMPONENT VIDEO port COMPONENT function as a port for a SCART RGB signal input and VIDEO port function as a port for SCART RGB sync input. A SCART adapter and SCART cable realize a SCART RGB input to the projector.
Page 45 INPUT Menu INPUT Menu (continued) Item Description The resolution for the RGB1 and RGB2 input signals can be set on this projector. The RESOLUTION menu will be displayed. (2) In the RESOLUTION menu select the buttons. Selecting AUTO will set a resolution appropriate to the input signal.
Page 46: Setup Menu
SETUP Menu SETUP Menu With the SETUP menu, the items shown in the table below can be performed. on the projector or remote control, or the ENTER button on the remote control to execute the item. Then perform it referring to the following table. Item Description Selecting this item performs the Automatic keystone distortion...
Page 47 SETUP Menu SETUP Menu (continued) Item Description NORMAL H:INVERT V:INVERT MIRROR If Transition Detector is TURN ON and MIRROR status is changed, 50) will be displayed when projector is Transition Detector Alarm ( restarted after the power switch is turned off. VOLUME High Allocates the audio ports.
Page 48: Screen Menu
SCREEN Menu SCREEN Menu With the SCREEN menu, the items shown in the table below can be performed. on the projector or remote control, or the ENTER button on the remote control to execute the item. Then perform it referring to the following table. Item Description language.
Page 49 SCREEN Menu SCREEN Menu (continued) Item Description The start-up screen is a screen displayed when no signal or an unsuitable signal is detected. MyScreen ORIGINAL TURN OFF MyScreen is a screen you can register as a desired screen.The ORIGINAL screen is the existing standard screen. When TURN OFF is selected, the BLACK screen is used.
Page 50 SCREEN Menu SCREEN Menu (continued) Item Description TURN ON TURN OFF When the TURN ON is selected, the following message function works. “AUTO IN PROGRESS” while automatically adjusting ”NO INPUT IS DETECTED” ”SYNC IS OUT OF RANGE” "Searching….” while searching for the input ”Detecting….”...
Page 51: Option Menu
OPTION Menu OPTION Menu With the OPTION menu, the items shown in the table below can be performed. or remote control, or the ENTER button on the remote control to execute the item, except for the items LAMP TIME and FILTER TIME.
Page 52 OPTION Menu OPTION Menu (continued) Item Description automatically turn the projector off. Long (max. 99 minutes) Short (min. 0 minute = DISABLE) AUTO OFF AUTO OFF ENABLE DISABLE When the time is set to 0, the projector is not turned off automatically. AUTO OFF When the time is set to 1 to 99, and when the passed time with no- signal or an unsuitable signal reaches at the set time, the projector...
Page 53 OPTION Menu OPTION Menu (continued) Item Description Selecting this item displays the SERVICE menu. the ENTER button on the remote control to execute the item. FAN SPEED AUTO ADJUST GHOST FILTER MESSAGE KEY LOCK FACTORY RESET INFORMATION REMOTE FREQ. FAN SPEED fans.
Page 54 OPTION Menu OPTION Menu (continued) Item Description REMOTE FREQ. 18). setting ( 1:NORMAL 2:HIGH Items with a checkmark are on. The factory default setting is for both 1:NORMAL and 2:HIGH to be on. If the remote control does not function correctly set the this to either only 1 or only 2 as 18).
Page 55 OPTION Menu OPTION Menu (continued) Item Description This projector is equipped with security functions. User registration is required before using the security functions. Please contact your local dealer. 1. Using Security Features 1.1 Inputting the PASSWORD button. The ENTER PASSWORD box will be displayed.
Page 56 OPTION Menu OPTION Menu (continued) Item Description 1.3 If you have forgotten your PASSWORD 1.3-1 Follow the procedure in 1.1-1 to display the ENTER PASSWORD BOX. 1.3-2 While the ENTER PASSWORD BOX is displayed, press and hold the RESET button on the remote control for about 3 seconds or Inquiring Code the projector for about 3 seconds.
Page 57 OPTION Menu OPTION Menu (continued) Item Description 2.2-4 Move the cursor to the right side of the CHECK display the PASSWORD for about 20 seconds, please make note of the PASSWORD during this time. After the PASSWORD has displayed for about 20 seconds the screen will return to PASSWORD BOX the MyScreen PASSWORD on/off menu.
Page 58 OPTION Menu OPTION Menu (continued) Item Description /RGB and INPUT buttons. A CONFIRMATION BOX will appear. Reenter the same PIN Code. This will complete the PIN Code registration. PIN BOX NOTE: If there is no key input for about 55 seconds while the PIN BOX or the CONFIRMATION BOX are displayed the menu will close.
Page 59: Using The Transition Detector Function
OPTION Menu OPTION Menu (continued) Item Description 4. Using the Transition Detector Function While the Transition Detector function is ON, when power switch is started to supply to the projector, it might react as below. • Transition Detector alarm shown below might appear on screen, if the projector has been moved or re-installed.
Page 60 OPTION Menu OPTION Menu (continued) Item Description 4.3 Setting the Transition Detector off 4.3-1 Follow the procedure in 4.1-1 to display the Transition Detector on/off menu. 4.3-2 Select TURN OFF to display the ENTER PASSWORD BOX (large). Enter the registered PASSWORD and the screen will return to the Transition Detector on/off menu.
Page 61: Miu Menu
MIU Menu MIU Menu Select [MIU] from the main menu to access the following functions. NOTE • The factory default setting for DHCP is “TURN OFF”. If your network has DHCP enabled , and need to set [IP ADDRESS], [SUBNET MASK] and [DEFAULT GATEWAY] automatically, please set [DHCP] to “TURN ON”.
Page 62 MIU Menu MIU Menu (continued) Item Operation e-SHOT display : or ENTER buttons to display the image. Image1 Image2 Image3 Image4 File names of registered images are displayed by 16 characters or less. Example: DEMONSTRATION-01 Once an image is displayed, you can use return to the menu.
Page 63 MIU Menu MIU Menu (continued) Item Description IP ADDRESS Input the IP ADDRESS : Use the ADDRESS. This function is available as long as DHCP is set to “TURN OFF”. ~Note~ network. You cannot have two devices with the same IP ADDRESS on the same network.
Page 64 MIU Menu MIU Menu (continued) Item Description MODE Select the communication connection control method to use between the PC and projector. Match to your PC’s settings. used. ADHOC INFRASTRUCTURE Select the channel when using a wireless LAN connection. (Channels 1 to 11 are available) *The available channels would be various depending on a country.
Page 65 MIU Menu MIU Menu (continued) Item Description INFORMATION display : See [INFORMATION] in [User’s Manual] – Network Functions] for more information. ~Note~ • • • When the voltage level of battery for built in clock decreases, set time may become incorrect even though accurate date and time are input. Replace a battery through the following the instructions.
Page 66: Maintenance
Maintenance Maintenance Lamp WARNING HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE The projector uses a high-pressure mercury glass lamp. The lamp can break with a loud bang, or burn out, if jolted or scratched, handled while hot, or worn over time. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them.
Page 67 Maintenance Lamp (continued) cause the pictures darker or the color tone poor. Note that each lamp has a different lifetime, and some may burst or burn out soon after you start using them. Preparation of a new lamp and early replacement are recommended. To prepare a new lamp, contact your dealer and tell the lamp type number.
Page 68 Maintenance WARNING Before caring, make sure the power switch is off and the care in a high temperature state of the projector could cause an electric shock, a burn and/or malfunction to the projector. to the projector. and/or malfunction to the projector. NOTE also when you replace the lamp.
Page 69 Maintenance pressing each of the six locations. Make sure there is no dust or dirt remaining after the cover is in place. If any dust or dirt remains use a vacuum cleaner knob on the projector. While holding the handle, mark Filter cover time using the FILTER TIME function in the...
Page 70: Replacing Internal Clock Battery
Press the metal claw of the battery holder. Then the battery Metal claw will come up. Remove the battery. Put a new battery in. Replace battery with HITACHI MAXELL, Part No.CR2032 explosion. “+” marking Insert a new battery in the battery holder according to its minus terminal as indicated in the battery holder, so that the side marked by + is Close the battery cover.
Page 71: Other Care
Maintenance Other care WARNING The care in a high temperature state of the projector could cause a burn and/or malfunction to the projector. dangerous. • Do not put a container containing water, cleaner or chemicals near the projector. • Do not use aerosols or sprays. CAUTION such as discoloration, peeling paint, etc.
Page 72: Troubleshooting
Troubleshooting Troubleshooting Related messages When the unit's power is on, messages such as those shown below may be displayed. When any such message is displayed on the screen, please follow the instructions described below. If the same message is displayed after the remedy, or if a message other than the following appears, please contact your dealer or service company.
Page 73: Regarding The Indicator Lamps
Troubleshooting Regarding the indicator lamps indicator have the meanings as described in the table below. Please follow the instructions within the table. If the same indication is displayed after the remedy, or if an indication other than the following is displayed, please contact your dealer or service company.
Page 74 Troubleshooting Regarding the indicator lamps (continued) POWER LAMP TEMP Description indicator indicator indicator The cooling fan is not operating. Please turn the power off, and allow the projector to Blinking cool down at least 20 minutes. After the projector has Turned Blinking that no foreign matter has become caught in the fan,...
Page 75: Phenomena That May Be Easy To Be Mistaken For Machine Defects
Troubleshooting Phenomena that may be easy to be mistaken for machine defects WARNING Never use the projector if abnormal operations such as smoke, strange odor, excessive sound, damaged casing or elements or cables, penetration of liquids or foreign matter, etc. should occur. In such cases, immediately turn off the power switch and then disconnect the power plug from the power outlet.
Page 76 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page The signal cables are not correctly connected. 13, 14 Correctly connect the audio cables. The MUTE function is working. Restore the sound pressing the MUTE or VOLUME button on the remote control.
Page 77 Troubleshooting Phenomena that may be easy to be mistaken for machine defects (continued) Reference Phenomenon Cases not involving a machine defect page The brightness and/or contrast are adjusted to an extremely low level. 27, 28 Adjust BRIGHTNESS and/or CONTRAST settings to a higher level using the menu function.
Page 78: Warranty And After-Service
Warranty And After-Service Warranty and after-service through the suggested checks. If this does not resolve the problem, please contact your dealer or service company. They will tell you what warranty condition is applied. NOTE Item Product name Liquid crystal projector Panel size 1.6 cm (0.63 type) Liquid...
Page 79 306 mm...
Page 80 Projector CP-X268A User’s Manual – Network Functions This manual is only intended to explain Network Functions. For safety, operations or any other issues, refer to the User’s Manual for projector or Safety Guide. WARNING • Before using the network functions, read the User’s Manual carefully to ensure your projector is set up correctly.
Page 81 Contents Contents Caution ………………………………………………………………………… 3 1. Main Functions …………………………………………………………… 5 1.1 Project images from PC ……………………………………………… 5 1.2 Display the images stored in SD card/USB memory …………… 6 2. Equipment connection and network setting ………………… 8 2.1 Required equipment preparation …………………………………… 8 2.2 Network connection using “One-Click-Communication”...
Page 82: Caution
Caution Caution [Restriction in terms of inserts or pulls memory card and wireless LAN card] Do not pull out memory card and wireless card while power is on. Memory card can be pulled out only while card access LED (Red) is off. CAUTION The accompanying 802.11g wireless LAN card uses the 2.4GHz radio frequency band.
Page 83 Caution 0560 The manufacturer (Gemtek) hereby declare that this equipment (SD wireless LAN card), model SD-Link11g is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
Page 84: Main Functions
1. Main functions 1. Main functions 1.1 Project images from PC (“Live Mode”) Main function of MIU (Multi Image Unit) is “MIU Live Viewer”. (Fig. 1.1.a) it to projector through wired LAN or wireless LAN connection. (Refer to section 3.4 in detail.) Fig.
Page 85: Display The Images Stored In Sd Card/Usb Memory
1. Main functions 1.2 Display the images stored in SD card/USB memory. (“PC-LESS Presentation”) Other main function is “PC-LESS Presentation”. (Fig. 1.2.a) “PC-LESS Presentation” has 4 kinds of display modes. 1) Thumbnail display: Display many stored images in SD card and USB memory at once.
Page 86 1. Main functions 1.2 Display the images stored in SD card/USB memory. (“PC-LESS Presentation”) (Continued) Fig. 1.2.b Remote Control NOTE PC-LESS Presentation. (1) The projector's language setting is Japanese. Only alpha-numeric characters and Japanese are supported. (2) The projector's language setting is not Japanese. Only alpha-numeric characters and Latin-1 characters are supported.
Page 87: Equipment Connection And Network Setting
2. Equipment connection and network setting 2. Equipment connection and network setting 2.1 Required equipment preparation Followings are required for 1 projector and 1 PC connection. Multiple PC connection is described in section 4.1. Projector: 1 unit PC: 1 set (“MIU Live Viewer” installation is required for “MIU Live Viewer” usage.) IEEE802.g wireless LAN equipment is required.
Page 88 2. Equipment connection and network setting 2.2 Network connection using “One-Click-Communication” function (Continued) Press the Reset key on remote control. Then Reset Menu will be displayed. NOTE • SSID, WEP KEY will be set to factory default settings. • If you like to set these items, please set again from WEB ( 19).
Page 89: Manual Network Connection Setting - Wired Lan
2. Equipment connection and network setting 2.2 Network connection using “One-Click-Communication” function (Continued) button is pushed and real time display is started automatically. [Wireless LAN connection] 1) When projector network settings such as IP address and subnet mask are changed, need to return to the projector factory default settings. ( 2) In case 802.11b/g wireless LAN device is built-in the PC, make the LAN valid and other network connections invalid.
Page 90: Network Settings
2. Equipment connection and network setting 2.3 Manual network connection setting – In case of wired LAN - (Continued) 2.3.2. Network settings This is the explanation of network connection settings for Windows XP and Internet Explorer. 1) Log on to Windows XP as administrator authority. (*) 2) Open “Control Panel”...
Page 91 2. Equipment connection and network setting 2.3 Manual network connection setting – In case of wired LAN - (Continued) 5) When more than 2 usable network devices exist, make only one device “valid” that you want to use and the rest of devices “invalid”. (In this case, “Local Area Connection”...
Page 92 2. Equipment connection and network setting 2.3 Manual network connection setting – In case of wired LAN - (Continued) [About IP address] Network address portion of PC IP address should be common with projector’s one but the PC total IP address should not be overlapped with other networked equipments.
Page 93: Internet Option" Setting
2. Equipment connection and network setting 2.3 Manual network connection setting – In case of wired LAN - (Continued) 2.3.3 “Internet Option” setting 1) Click “Internet Options” in “Network and Internet Connections” window (Fig. 2.3.3.a) to open “Internet Properties” window. (Fig. 2.3.3.b) Click Fig.
Page 94: Check Connection
2. Equipment connection and network setting 2.3 Manual network connection setting – In case of wired LAN - (Continued) Fig. 2.3.3.c “Local Area Network (LAN) Settings” window 3) Uncheck all boxes in “Local Area Network (LAN) Settings” window. (Fig. 2.3.3.c) 2.3.4 Check connection Check PC and projector are connected properly here.
Page 95: Manual Network Setting - For Wireless Lan
2. Equipment connection and network setting 2.4 Manual network connection setting – For wireless LAN By installing SD-Link11g card, PC and wireless LAN are able to communicate in both Adhoc and Infrastructure modes. How to set up wireless LAN connection manually. 2.4.1 Preparation for wireless LAN connection Fig.
Page 96: Wireless Lan Connection Set Up
2. Equipment connection and network setting 2.4 Manual network connection setting – In case of wireless LAN - (Continued) 2.4.2 Wireless LAN connection set up Using wireless LAN utility for Windows XP standard. Wireless LAN initial settings for the projector is as follows. Connection Control : Ad-Hoc SSID...
Page 97 2. Equipment connection and network setting 2.4 Manual network connection setting – In case of wireless LAN - (Continued) 4) Set used protocol as “TCP/IP” and open TCP/IP property. Set IP address and other settings as same as wired LAN connection set up. ( 5) Open “Wireless Networks”...
Page 98 2. Equipment connection and network setting 2.4 Manual network connection setting – In case of wireless LAN - (Continued) 8) Set each item as follows. Network name (SSID): wireless Data encryption: Invalid (Default setting is invalid.) * This explanation meets the projector default setting. If access point is used or data encryption is used, if needs to change settings properly.
Page 99 2. Equipment connection and network setting password are required. There are two types of IDs, Administrator IDs and User IDs. The following chart describes the differences between user and administrator IDs. Item Description Administrator ID User ID Displays the projector’s current Network Information Network Settings settings.
Page 100 2. Equipment connection and network setting Example: If the IP address of the projector is set to 192.168.1.10: 1) Enter [http://192.168.1.10] into the address bar of the web browser and the screen in Fig. 2.5.a will be displayed. 2) Enter your ID and password and click [Logon].
Page 101: Network Information
2. Equipment connection and network setting Network Information All screen images displayed in this manual are screens of a logon using an administrator ID. Any administrator only functions will not be displayed when using a user ID. Refer to the descriptions in each table.
Page 102 2. Equipment connection and network setting Network Settings Item Description NETWORK MODE Select Network mode "wired" or "wireless". DHCP ON Enables DHCP. DHCP OFF Disables DHCP. IP Address Subnet Mask Default Gateway Projector Name SysLocation (SNMP) SysContact (SNMP) using SNMP. DNS Server Address...
Page 103 2. Equipment connection and network setting Network Settings (Continued) Item Description Wireless LAN Mode Select "AD-HOC" or "Infrastructure". Select using channel between "1" and "11". NOTE • Depending on the country where you are the channels may vary. In addition, depending on the (Communication country or region where you are may be required to use channel)
Page 104: Port Settings
2. Equipment connection and network setting Port Settings Item Description Network Control Port1 (Port:23) Port open Click the [Enable] check box to use port 23. Click the [Enable] check box when authentication is required Authentication for this port. Network Control Port2 (Port:9715) Port open Click the [Enable] check box to use port 9715.
Page 105: Mail Settings
2. Equipment connection and network setting Mail Settings Item Description Click the [Enable] check box to use the e-mail function. Send Mail [Alert Settings]. SMTP Server IP Address Sender E-mail address The length of the sender e-mail address can be up to 255 alphanumeric characters.
Page 106: Alert Settings
2. Equipment connection and network setting Alert Settings Item Description Cover Error Click the [Enable] check box to enable SNMP Trap alerts for SNMP Trap this item. Click the [Enable] check box to enable e-mail alerts for this Send Mail item.
Page 107 2. Equipment connection and network setting Alert Settings (Continued) Item Description Lamp Error Click the [Enable] check box to enable SNMP Trap alerts for SNMP Trap this item. Click the [Enable] check box to enable e-mail alerts for this Send Mail item.
Page 108 2. Equipment connection and network setting Alert Settings (Continued) Item Description Lamp Time Error Click the [Enable] check box to enable SNMP Trap alerts for SNMP Trap this item. Click the [Enable] check box to enable e-mail alerts for this Send Mail item.
Page 109 2. Equipment connection and network setting Alert Settings (Continued) Item Description Other Error Click the [Enable] check box to enable SNMP Trap alerts for SNMP Trap this item. Click the [Enable] check box to enable e-mail alerts for this Send Mail item.
Page 110 2. Equipment connection and network setting Alert Settings (Continued) Item Description Filter Time Alarm Alarm Time Click the [Enable] check box to enable SNMP Trap alerts for SNMP Trap this item. Click the [Enable] check box to enable e-mail alerts for this Send Mail item.
Page 111: Schedule Settings
2. Equipment connection and network setting Schedule Settings Item Description Daily Schedule Click the [Enable] check box to enable daily scheduling. Schedule List Displays the current daily schedule. Sunday Schedule Click the [Enable] check box to enable Sunday scheduling. Schedule List Displays the current Sunday schedule.
Page 112 2. Equipment connection and network setting Schedule Setting (Continued) Item Description Click the [Enable] Schedule scheduling. Month/Day Schedule List Click the [Enable] Schedule scheduling. Month/Day Schedule List Click the [Enable] Schedule scheduling. Month/Day Schedule List Click the [Enable] Schedule scheduling. Month/Day Schedule List Click the [Enable]...
Page 113 2. Equipment connection and network setting Schedule Setting (Continued) To add additional functions and events click the [Add] button and set the following items. Item Description Time Command Power Parameter Input Source Parameter Display Image Parameter Click the [Register] button to add new commands to the Schedule List. Click the [Delete] button to delete commands from the Schedule list.
Page 114 2. Equipment connection and network setting Date/Time Settings (Continued) Item Description Click the [ON] check box to enable daylight savings time and Daylight Savings Time set the following items. Start Month Week begins (First, 2, 3, 4, Last). (Sun, Mon, Tue, Wed, Thu, Fri, Sat). Hour Minute Month...
Page 115: Security Settings
2. Equipment connection and network setting Security Settings Item Description Administrator authority Administrator ID The length of the text can be up to 32 alphanumeric characters. Administrator The length of the text can be up to 255 alphanumeric Password characters. Re-enter Administrator Password User authority...
Page 116 2. Equipment connection and network setting Security Settings (Continued) Item Description Network Control control. Authentication The length of the text can be up to 16 alphanumeric Password characters. Re-enter Authentication Password SNMP Community Name The length of the text can be up to 64 alphanumeric characters.
Page 117: Projector Control
2. Equipment connection and network setting Projector Control The items shown in the table below can be performed using the [Projector Control] menu. Select an item using the up and down arrow keys on the PC. Most of the items have a submenu. Refer to the table below for details.
Page 118 2. Equipment connection and network setting Item Description Image Aspect Selects the Aspect setting. Over Scan Selects the Over Scan setting. V Position Adjusts the V Position. H Position Adjusts the H Position. H Phase Adjusts the H Phase. H Size Adjusts the H Size.
Page 119 2. Equipment connection and network setting Item Description Screen Language Selects the Language for the OSD. Menu Position V Adjusts the vertical Menu Position. Menu Position H Adjusts the horizontal Menu Position. Blank Selects the Blank mode. Startup Selects the Startup screen mode. MyScreen Lock Turns MyScreen Lock On/Off.
Page 120: Projector Status
2. Equipment connection and network setting Projector Status Item Description Error Status Displays the current error status Lamp Time Displays the usage time for the current lamp. Filter Time Power Status Displays the current power status. Input Status Displays the current input signal source. Blank On/Off Displays the Blank On/Off status.
Page 121: Utilize Web Remote Control
2. Equipment connection and network setting 2.6 Utilize Web Remote Control You can use your Web browser to remote control the projector once the projector wired LAN. NOTE • Do not attempt to control the projector with the projector's remote control and via your Web browser at the same time.
Page 122 2. Equipment connection and network setting Click “Remote Control” in this window to display Web Remote Control as shown in The same operation as the bundled remote control will done. UP/LEFT/RIGHT/DOWN respectively. Each mode will be activated by clicking these buttons. •...
Page 123: How To Use Projector Software - Basics
3. How to use Projector software – Basics - 3. How to use Projector software – Basics - 3.1 How to use “MIU Live Viewer” This section explains how to use the “MIU Live Viewer”. 3.1.1. Install “MIU Live Viewer” the accompanying software on all the PCs you will be using.
Page 124: Software Installation Procedure
3. How to use Projector software – Basics - 3.1.2. Software Installation Procedure 1) Turn on the PC. 2) Shut down all applications. 3) Insert the accompanying CD-ROM into the PC's CD-ROM drive. 4) After a moment, the Welcome to MIU Utilities Setup dialog will appear as shown on the right.
Page 125: Explanation Of "Miu Live Viewer
3. How to use Projector software – Basics - 7) After a moment, installation will complete and the Setup Complete dialog will appear as shown on the right. Click Finish. This completes the software installation. properly installed, press the Start button on the toolbar, select All Programs and then select the MIU Utility folder.
Page 126 3. How to use Projector software – Basics - [“MIU Live Viewer” window: Fig. 3.1.3.a] 1) “File” button 2) “Help” button Display “MIU Live Viewer” information. 3) Stop button Disconnect projector connection. 4) Capture start button Start real time display. ~NOTE~ Pictures are not displayed correctly when the start/stop buttons are clicked repeatedly.
Page 127 3. How to use Projector software – Basics - [“Options” window] [“General” tab, Fig. 3.1.3.b] Fig.3.1.3.b “Options”, “General” tab 1) CPU Share Set up any capturing performance on the PC screen by using control bar Low (At the far left): Set this position when many CPU resources are required by applications other than “MIU Live Viewer”.
Page 128 3. How to use Projector software – Basics - [JPEG tab] Fig. 3.1.3.c “Options”, “JPEG” tab 1) JPEG Quality When “MIU Live Viewer” is used, it captures PC screen image. Then that is compressed as JPEG and sent to projector. By control bar in this tab, you can set compression rate.
Page 129: Utilize "Miu Live Viewer" - Basic
3. How to use Projector software – Basics - 3.1.4 Utilize “MIU Live Viewer” – Basic - This section explains basic of how to use “MIU Live Viewer” functions. • Before start up the MIU Live Viewer, you have to set the projector into LIVE MODE by either of following way.
Page 130 3. How to use Projector software – Basics - 2) Start Web Remote Control (refer to 2.6 Utilize Web Remote Control), and click “LIVE MODE” button on Web Remote Control to change projector mode to “MIU Live Viewer”. After changing, screen of the output monitor connected with projector turn all blue.
Page 131: Utilize "Pc-Less Presentation" - Basic
3. How to use Projector software – Basics - (3) Click Capture start button. Fig. 3.1.4.d Start capturing Based on the above operation, if captured picture of PC screen is displayed real time on monitor connected with projector, it is succeeded. Much easier to connect if you utilize “One-Click-Communication”...
Page 132 3. How to use Projector software – Basics - 3.2 Utilize “PC-LESS Presentation” –Basic - (Continued) If thumbnail appears by above operation, it is succeeded. (Fig.3.2.a) This is basic usage. There are varieties of usage for “PC-LESS Presentation”. Refer to section 4.2 for further detailed explanation.
Page 133: Utilize Projector - Advanced
4. Utilize projector – Advanced - 4. Utilize projector – Advanced - 4.1. Utilize “MIU Live Viewer” – Advanced - This section explains how to connect multiple PCs. 4.1.1. Connect multiple PCs with one projector (Multiple PCs connection) A projector can be connected with up to 4 PCs to display multiple windows. Fig.
Page 134 4. Utilize projector – Advanced - [Connection] 4.1.1.a. Connect projector and output monitor with RGB cable. 2) Start up “MIU Live Viewer” in each PC. Check the IP address in PCs and 3) Click “Find” button in “MIU Live Viewer” and search projector. 4) When projector is found, click “Option”...
Page 135: Utilize "Pc-Less Presentation" - Advanced
4. Utilize projector – Advanced - 4.2 Utilize “PC-LESS Presentation” – Advanced - “PC-LESS Presentation” reads image data from memory cards inserted into SD or USB slot and perform followings. SD Memory and SD Wireless card can not be inserted at the same time. - Thumbnail display (Section 4.2.1) - Display in full screen (Section 4.2.2) - Slide show (Section 4.2.3)
Page 136: Thumbnail Display
4. Utilize projector – Advanced - • JPEG (.jpeg, .jpg) * Progressive is not corresponded. • BMP (.bmp) • PNG (.png) • MPEG4 (.mp4) * Supported bit resolution rate is less than 1Mbps in Simple Supported resolution is less than VGA. Supported Audio format is only AAC.
Page 137 4. Utilize projector – Advanced - Following operations can be accessible while thumbnail is displayed. Move cursor. Remote control/Keypad PAGE UP PAGE DOWN Switch pages. Remote control ENTER Remote control Display selected image in full screen. INPUT Keypad MENU Remote control Displays PC-LESS PRESENTATION Menu.
Page 138: Display In Full Screen
4. Utilize projector – Advanced - 4.2.2 Display in full screen screen display, click [MENU] button in the Web Remote Control menu on the screen. When select [PC-LESS Presentation], then [Full Screen] from the menu or thumbnail, click [ENTER] so that moves to be full-screen display. Full-screen Display Fig.4.2.2 Full-screen Display While displaying in full screen, following operation can be accessible from the...
Page 139 4. Utilize projector – Advanced - 1) Select the DISPLAY SIZE in PC-LESS PRESENTATION Menu. 2) Press the Enter button on the remote 3) Then DISPLAY SIZE menu appears. 4) Select your desired DISPLAY SIZE. • REAL : Displays the image at original size. Displays the image at the center of screen if original size is smaller than the screen size.
Page 140: Slide Show
4. Utilize projector – Advanced - 4.2.3. Slide show Click the “SLIDE SHOW” button in Web Remote Control, then Slide show will be played. Display time can be set by the playlist (refer to section 4.3) and menu. Full-screen Display Fig.
Page 141 4. Utilize projector – Advanced - You can also play the Slide show with the projector Menu. Select “SLIDE SHOW” on PC-LESS PRESENTATION Menu. And press the Enter 1) START # : Set the beginning number of Slide show. 2) STOP # : Set the end number of Slide show.
Page 142: Directory Display
4. Utilize projector – Advanced - 4.2.4 Directory display “DIRECTORY” button in the Web Remote Control, then the directory tree will be be displayed in the thumbnail. Image display preview File information Tree structure directory Fig. 4.2.4 Directory display screen...
Page 143 4. Utilize projector – Advanced - Following operations can be accessible while directory is displayed. Moving selected item upward or downward. Open the closed folder. Close the folder. PAGE UP PAGE DOWN Show undisplayed portion if the tree display is not fit inside the screen.
Page 144 4. Utilize projector – Advanced - You can also display the directory with the projector Menu. Select “DIRECTORY” in PC-LESS PRESENTATION Menu. And press the Enter [File information display] File information display shows following information. - File format (JPEG, PNG and BMP) - File size (Size of File) - Image size (File resolution) - File format (MP4)
Page 145: Pc-Less Presentation" Error Message
4. Utilize projector – Advanced - 4.2.5 “PC-LESS Presentation” error message mode. It appears at the bottom and the blue area of screen. Fig. 4.2.5 “PC-LESS Presentation” error message “PC-LESS Presentation” error message list Error message Error content Display mode File not found Displayable file does not exist.
Page 146: Playlist
4. Utilize projector – Advanced - 4.3 Playlist Presentation” is displayed. The timing of playlist creation is when “PC-LESS The playlist is created in the displayed directory. NOTE • Playlist can not be overwritten. Once it is created, data remains. Therefore, the image can not displayed if it is additionally saved to the memory Playlist is editable on the PC.
Page 147: Failure & Warning Alerts Via E-Mail
4. Utilize projector – Advanced - 4.4 Failure & Warning Alerts via E-mail the projector requires maintenance or has encountered an error. NOTE • The projector may be not able to send e-mail if the projector suddenly loses power. Mail Settings web browser.
Page 148 4. Utilize projector – Advanced - Mail Settings (Continued) [Alert Settings] on the main menu. [Alert Settings] in and Controlling the Projector via a Web Browser] for further information. 10) Click the [Apply] button to save the settings. Failure/Warning e-mails are formatted as follows: Subject line : <Mail title>...
Page 149: Projector Management Via Snmp
4. Utilize projector – Advanced - 4.5 Projector management via SNMP When SNMP is enabled, the projector is able to send Failure/Warning Alerts to a NOTE • It is recommended that SNMP functions be carried out by a network administrator. •...
Page 150: Controlling The Projector Via Scheduling
4. Utilize projector – Advanced - 4.6 Controlling the Projector via Scheduling The projector can be automatically controlled via scheduling. NOTE • You can schedule the following control events: Power ON/OFF, Input Source and Transferred Image Display. week 3) daily. those with the lower numbers when more than one event has been scheduled day No.
Page 151 4. Utilize projector – Advanced - Date/Time Settings The Date/Time setting can be adjusted via a web browser. Example: If the IP address of the projector is set to 192.168.1.10: 1) Enter [http://192.168.1.10] into the address bar of the web browser. Enter the Administrator ID and Password and click [Logon].
Page 152 4. Utilize projector – Advanced - Schedule Settings Example: If the IP address of the projector is set to 192.168.1.10: 1) Enter [http://192.168.1.10] into the address bar of the web browser. 2) Enter the Administrator ID and Password and click [Logon]. 3) Click [Schedule Settings] on the main menu and select the required schedule item.
Page 153: E-Shot (Still Image Transfer) Display
The projector can display a still image that is transferred via the network. e-Shot transmission requires an exclusive application for your PC. You can download it from the Hitachi web site. Refer to the manual for the application for instructions.
Page 154: Command Control Via The Network
4. Utilize projector – Advanced - 4.8 Command Control via the Network commands. Communication Port The following two ports are assigned for the command control. TCP #23 TCP #9715 NOTE • Command control is not available via communication port (TCP #9716) that is used for the e-Shot transmission function.
Page 155 4. Utilize projector – Advanced - Command Control Settings (Continued) When the authentication setting is enabled, the following settings are required. 7) Click [Security Settings] on the main menu. 8) Click [Network Control] and enter the desired authentication password. * See Note1.
Page 156 4. Utilize projector – Advanced - Command format Command formats differ among the different communication ports. TCP #23 You can use the RS-232C commands without any changes. The reply data format is the same as the RS-232C commands. However, the following reply will be sent back in the event of authentication failure when authentication is enabled.
Page 157 4. Utilize projector – Advanced - Reply Data format The connection ID (the data is same as the connection ID data on the sending data format) is attached to the RS-232C commands reply data. <ACK reply> Connection Reply 0x06 1 byte <NAK reply>...
Page 158 4. Utilize projector – Advanced - Automatic Connection Break The TCP connection will be automatically disconnected after there is no communication for 30 seconds after being established. Authentication The projector does not accept commands without authentication success when authentication is enabled. The projector uses a challenge response type authentication with an MD5 (Message Digest 5) algorithm.
Page 159: Troubleshooting
5. Troubleshooting 5. Troubleshooting Reference Problem Likely Cause Things to Check Page Number The projector is not turned Is the projector's lamp on? No image The projector's input source Is the projector switched to isn't switched to MIU. MIU? Others Communication between - Information from the the projector and PC is not...
Page 160 5. Troubleshooting Reference Problem Likely Cause Things to Check Page Number The projector isn't capable Try increasing the Capture of relaying dynamic images Performance priority level. such as PowerPoint® It may improve the speed a The projected animation at full speed. little.
Page 161 Item Specifications Product name Liquid crystal projector File format JPEG, PNG, BMP and MPEG4 Control software Dedicated PC application and Web browser Corresponding protocol TCP/IP, DHCP client and HTTP server Firmware OS Wireless LAN (IEEE802.11g) Network (Adhoc and Infrastructure modes) Ethernet (100Base-TX/10Base-T) Security WEP(64/128bit), WPA-PSK/PSK2(TKIP/AES), SSID...
Page 162: Warranty And After-Sales Service
7. Warranty and After-sales service 7. Warranty and After-sales service section and run through the suggested checks. If this does not resolve the problem, contact your dealer or service company. They will tell you what warranty condition is applied.
Page 163 Projector CP-X268A User's Manual – Operating Guide Technical Example of computer signal Resolution (H x V) H. frequency (kHz) V. frequency (Hz) Rating Signal mode 720 x 400 37.9 85.0 VESA TEXT 640 x 480 31.5 59.9 VESA VGA (60Hz) 640 x 480 37.9 72.8...
Page 164 Example of computer signal Initial set signals The following signals are used for the initial settings. The signal timing of some computer models may be different. In such case, adjust the items V POSITION and H POSITION in the IMAGE menu. Back porch (B) Front porch (D) Back porch (b)
Page 165 Connection to the ports Connection to the ports SD CARD AUX I/O AUDIO IN3 RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 AUDIO IN2 CONTROL VIDEO S-VIDEO RGB IN1, RGB IN2, RGB OUT D-sub 15pin mini shrink jack •...
Page 166: Component Video
Connection to the ports SD CARD AUX I/O AUDIO IN3 RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 AUDIO IN2 CONTROL VIDEO S-VIDEO COMPONENT VIDEO RCA jack x3 • System: 525i(480i), 525p(480p), 625i(576i), 750p(720p), 1125i(1080i) Port Signal Component video C Component video C S-VIDEO Mini DIN 4pin jack...
Page 167 Connection to the ports SD CARD AUX I/O AUDIO IN3 RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 AUDIO IN2 CONTROL VIDEO S-VIDEO AUDIO IN-1 ( Ø3.5 stereo mini jack), J AUDIO IN-2 , K L AUDIO 3 L/R (RCA jack) AUDIO OUT ( Ø3.5 stereo mini jack) Signal...
Page 168 Connection to the ports SD CARD AUX I/O AUDIO IN3 RGB IN1 RGB IN2 RGB OUT AUDIO OUT AUDIO IN1 AUDIO IN2 CONTROL VIDEO S-VIDEO RJ-45 jack Signal Signal Signal 1 TX+ 2 TX- 3 RX+ 6 RX- AUX I / O USB A type jack Signal 1 +5V...
Page 169: Communications Setting
RS-232C Communication (continued) RS-232C Communication CONTROL port RS-232C cable (Cross) RS-232C port of the projector of the computer - (1) (1) CD RD (2) (2) RD TD (3) (3) TD - (4) (4) DTR GND (5) (5) GND - (6) (6) DSR RTS (7) (7) RTS...
Page 170 RS-232C Communication (continued) Requesting projector status (Get command) (1) Send the request code Header + Command data (‘02H’+‘00H’+ type (2 bytes)+ ‘00H’ +‘00H’) from the computer to the projector. (2) The projector returns the response code ‘1DH’+ data (2 bytes) to the computer. Changing the projector settings (Set command) (1) Send the setting code Header + Command data (‘01H’+‘00H’+ type (2 bytes) + setting code (2 bytes)) from the computer to the projector.
Page 171 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code Power Turn off BE EF 06 00 2A D3 01 00 00 60 00 00 Turn on BE EF 06 00 BA D2 01 00 00 60 01 00 BE EF 06 00...
Page 172 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code User Gamma Pattern BE EF 06 00 FB FA 01 00 80 30 00 00 9 step gray scale BE EF 06 00 6B FB 01 00 80 30 01 00 15 steps gray scale...
Page 173 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code COLOR TEMP GAIN G BE EF 06 00 70 F4 02 00 B2 30 00 00 Increment BE EF 06 00 16 F4 04 00 B2 30 00 00 Decrement BE EF...
Page 174 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code ASPECT BE EF 06 00 9E D0 01 00 08 20 00 00 16:9 BE EF 06 00 0E D1 01 00 08 20 01 00 14:9 BE EF 06 00 CE D6...
Page 175 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code FRAME LOCK TURN OFF BE EF 06 00 CB D6 01 00 14 30 00 00 TURN ON BE EF 06 00 5B D7 01 00 14 30 01 00 BE EF 06 00...
Page 176 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code MUTE TURN OFF BE EF 06 00 46 D3 01 00 02 20 00 00 TURN ON BE EF 06 00 D6 D2 01 00 02 20 01 00 BE EF 06 00...
Page 177 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code BLANK My Screen BE EF 06 00 FB CA 01 00 00 30 20 00 ORIGINAL BE EF 06 00 FB E2 01 00 00 30 40 00 BLUE BE EF 06 00...
Page 178 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code REMOTE FREQ Disable BE EF 06 00 FF 3D 01 00 30 26 00 00 NORMAL Enable BE EF 06 00 6F 3C 01 00 30 26 01 00 BE EF 06 00...
Page 179 RS-232C Communication (continued) Command Data Names Operation Type Header Action Type Setting Code VOLUME-RGB1 BE EF 06 00 CD CC 02 00 60 20 00 00 Increment BE EF 06 00 AB CC 04 00 60 20 00 00 Decrement BE EF 06 00 7A CD...
Page 180 Hitachi, Ltd. Japan 292 Yoshida-cho Totsuka-ku, Yokohama-city Kanagawa 244-0817 HITACHI EUROPE LTD. HITACHI EUROPE S.A. Consumer Affairs Department 364, Kifissias Ave. & 1, Delfon Str. PO Box 3007 152 33 Chalandri Maidenhead Athens GREECE SL6 8ZE Tel: 1-6837200 UNITED KINGDOM...

Hitachi CP-X268A User's Manual And Operating Manual

Table of Contents

Content

Contents of Package

Projector Features

Preparations

Part Names

Setting up

Remote Control

Power On/Off

Operating

Multifunctional Settings

Maintenance

Troubleshooting

Warranty and After-Service

Install "Miu Live Viewer

1 Main Functions

2 Equipment Connection and Network Setting

3 How to Use Projector Software - Basics

4 Utilize Projector - Advanced

5 Troubleshooting

7 Warranty and After-Sales Service

Quick Links

Chapters

Troubleshooting

Related Manuals for Hitachi CP-X268A

Summary of Contents for Hitachi CP-X268A

Table of Contents
