Fujitsu LifeBook P Series BIOS Guide LifeBook P Series Model: P770 Document Date: 02/03/2010 Document Part Number: FPC58-2641-01 F U J I T S U A M E R I C A , I N C .
5. To return to a menu from a submenu, press the [Esc] 1. Turn on or restart your notebook. key. 2. Press [F2] once the Fujitsu logo appears on the 6. To go to the Exit menu from any other menu, screen. This will open the main menu of the BIOS press the [Esc] key.
Page 3
I n f o M e n u severe, it will give you an opportunity to modify the setup utility settings, as described in the following steps: 1. When you turn on or restart the computer there is a beep and/or the following message appears on the screen: Error message - please run SETUP program Press <F1>...
L i f e B o o k P S e r i e s B I O S INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION The Info Menu is a display only screen that provides the The information, including CPU type and configuration information for your notebook.
Advanced Security Boot Exit Item Specific Help System Time: [XX:XX:XX] System Date: [XX/XX/2010] Adjust calendar clock. <Tab>, <Shift-Tab>, or Drive0 [FUJITSU MJA2160BH G2] <Enter> selects field. Drive1 [MATSHITADVD-RAM UJ892AS] Drive5 [None] Language: [English (US)] Help Select Item -/Space Change Values...
Page 6
L i f e B o o k P S e r i e s B I O S Table 2: Fields, Options and Defaults for the System Menu Note that the parameters listed in the following table may vary depending upon your system’s configuration. Menu Field Options Default...
The Drive0 submenu identifies what SATA device is installed. Phoenix SecureCore(tm) Setup Utility Info System Advanced Security Boot Exit Item Specific Help Drive0 [FUJITSU MJA2160BH G2] [Disabled] Drive0: [Enabled]] The drive is disabled. Type: Hard Disk [Enabled] Model: FUJITSU MJA2160BH G2 The drive is enabled.
L i f e B o o k P S e r i e s B I O S Drive1 Submenu of the System Menu The Drive1 submenu allows you to configure a secondary SATA device. Phoenix SecureCore(tm) Setup Utility Info System Advanced...
Page 9
S y s t e m M e n u Drive5 Submenu of the System Menu The Drive5 submenu allows you to configure eSATA or third SATA devices. Phoenix SecureCore(tm) Setup Utility Info System Advanced Security Boot Exit Item Specific Help Drive5 [None] Drive5: [Enabled]...
L i f e B o o k P S e r i e s B I O S ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: (See Navigating through the Setup Utility on page 2 for more information.) Set the Numlock.
A d v a n c e d M e n u Table 6: Fields, Options and Defaults for the Advanced Menu Menu Field Description USB Features When selected, opens the USB Features submenu to allow you to enable or disable legacy USB devices and SCSI SubClass support.
L i f e B o o k P S e r i e s B I O S Keyboard/Mouse Features Submenu of the Advanced Menu The Keyboard/Mouse Features submenu is for enabling and disabling the Numlock function. Phoenix SecureCore(tm) Setup Utility Info System Advanced...
A d v a n c e d M e n u Video Features Submenu of the Advanced Menu The Video Features submenu is for routing to a variety of different monitors. Phoenix SecureCore(tm) Setup Utility Info System Advanced Security Boot Exit Video Features...
L i f e B o o k P S e r i e s B I O S Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configuration submenu allows the user to enable or disable SATA, Bluetooth, LAN, SD Card slot, and Wireless LAN Controllers as well as the internal camera.
A d v a n c e d M e n u CPU Features Submenu of the Advanced Menu The CPU Features submenu provides options for configuring the Intel Core Multi-Processing, Hyper-Threading, SpeedStep power management, and Virtualization Technology features of the CPU. Phoenix SecureCore(tm) Setup Utility Info System...
L i f e B o o k P S e r i e s B I O S USB Features Submenu of the Advanced Menu The USB Features submenu provides options for enabling or disabling the USB devices. Phoenix SecureCore(tm) Setup Utility Info System Advanced...
A d v a n c e d M e n u Miscellaneous Configurations Submenu of the Advanced Menu The Miscellaneous Configurations submenu provides options for enabling or disabling the power button and the Wake Up On LAN feature, and setting the volume. Phoenix SecureCore(tm) Setup Utility Info System...
Page 18
L i f e B o o k P S e r i e s B I O S Table 12: Fields, Options and Defaults for the Miscellaneous Configurations Submenu of the Advanced Menu Menu Field Options Default Description ■ Volume Setting: [Middle] Selects the initial volume setting for the system.
A d v a n c e d M e n u Intel(R) Management Engine Configurations Submenu of the Advanced Menu The Management Engine Configurations submenu allow you to set features of the Management Engine BIOS Exten- sions and AMT (Active Management Technology) CIRA (Client-Initiated Remote Access) requests. Phoenix SecureCore(tm) Setup Utility Info System...
L i f e B o o k P S e r i e s B I O S Event Logging Submenu of the Advanced Menu The Event Logging submenu configures event logging features for DMI events. Phoenix SecureCore(tm) Setup Utility Info System Advanced...
Remember your passwords! If you set and forget your User and Master hard disk passwords, Fujitsu America, Inc. will not be able to reset it. You may lose data and have to replace your system board or hard disk drive.
L i f e B o o k P S e r i e s B I O S Table 15: Fields, Options and Defaults for the Security Menu Menu Field Options Default Description Supervisor –— Clear A display-only field. Set is displayed when the system supervisor password is set Password is: and Clear when it is not.
S e c u r i t y M e n u Hard Disk Security Submenu of the Security Menu The Hard Disk Security submenu is for configuring hard disk security features. Phoenix SecureCore(tm) Setup Utility Info System Advanced Security Boot Exit Hard Disk Security...
L i f e B o o k P S e r i e s B I O S Owner Information Submenu of the Security Menu The Owner Information submenu is for setting owner information. Note that the owner information cannot be set without having entered a Supervisor Password.
S e c u r i t y M e n u TPM (Security Chip) Setting Submenu of the Security Menu The TPM (Security Chip) Setting submenu is used to enable or disabled the embedded security chip. Phoenix SecureCore(tm) Setup Utility Info System Advanced...
Note that the Boot menu can be set up or modified only after a Supervisor password has been set up. ■ Boot-time Disabled [Disabled] Turns on and off display of test results instead of Fujitsu logo screen Diagnostic Screen: during Power On Self Test. ■ Enabled ■...
Boot Device Priority Item Specific Help Boot priority order: Keys used to view or Floppy Disk Drive configure devices: Drive0 HDD: FUJITSU MJA2160BH G2 Drive5 HDD: None <+>/<Space> or <-> CD/DVD Drive moves the device up or NETWORK: Intel LAN down.
L i f e B o o k P S e r i e s B I O S EXIT MENU – LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow The following table shows the names of the menu fields the instructions for Navigating Through the Setup for the Exit menu, the default settings and a description Utility to make any changes.
