- Page 1 I NS TRUCTI ON BOOK L ET 132 991 220 W A S H I N G M A C H I N E E W 560 F E W 660 F V I ET...
-
Page 2: Table Of Contents
Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. The symbols you will see on some paragraphs of this booklet have the following meaning: The warning triangle and/or the key words (Warning!, Caution!) emphasize information that is particularly important for your safety or correct functioning of the appliance. -
Page 3: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • All internal packing must be removed before using the appliance. Serious damage may be caused to the machine or adjacent furniture if the protective transit devices are not removed or are not completely removed. -
Page 4: Disposal
Synthetics Delicates Woollens Minimum Maximum 85 cm 60 cm 59 cm 5.5 kg 2.5 kg 2.5 kg 550 rpm max. (EW 560 F) 650 rpm max. (EW 660 F) 220-230 V/50 Hz 2200 W 10 A 50 kPa 800 kPa... -
Page 5: Installation
Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. Using a spanner, unscrew and remove the rear right-hand bolt and lay the machine on its back, taking care not to squash the hoses. -
Page 6: Water Drainage
The inlet hose must not be lengthened. If it is too short and you do not wish to move the tap, you will have to purchase a new, longer hose specially designed for this type of use. Important! Before connecting up the machine to new pipework or to pipework that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes. -
Page 7: Your New Washing Machine
Your new washing machine This new machine meets all modern needs for effective treatment of laundry with low water, energy and detergent consumption. • The temperature selector dial will allow you to choose the most suitable temperature for your laundry. •... -
Page 8: Use
Control panel 1 Detergent dispenser drawer and programme chart 2 Mains-on light This light comes on when the On-Off button is pressed, and goes out when it is pressed again. 3 On-Off button Press this button to start the machine. The same button is used to switch the machine off. -
Page 9: Washing Hints
Washing hints Sorting the laundry Follow the wash code symbols on each garment label and the manufacturer’s washing instructions. Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. Temperatures 95° for normally soiled white cottons and linen (e.g. tea cloths, towels, tablecloths, sheets...) 60°... -
Page 10: Detergents And Additives
residual marks with bleach. Ink: depending on the type of ink, moisten the fabric first with acetone (*), then with acetic acid; treat any residual marks on white fabrics with bleach and then rinse thoroughly. Tar stains: first treat with stain remover, methylated spirits or benzine, then rub with detergent paste. -
Page 11: Operating Sequence
Operating sequence Before the first wash we recommend that you pour 2 litres of water into the main wash compartment of the detergent drawer in order to activate the ECO valve. Then run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. -
Page 12: At The End Of The Programme
7. At the end of the programme The machine stops automatically. If you have selected the Rinse Hold button or the Spin Suppress. one, the machine will stop with the water left in the tub, to prevent the fabric from creasing. -
Page 13: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash temperature temperature 95°C Delicate wash Bleaching Bleach in cold water Ironing Hot iron max 200°C Dry cleaning Dry cleaning... -
Page 14: Washing Programmes
Programme table Washing programmes for cotton and linen Max. load 5.5 kg Programme Temp. 60°-95° WHITES WITH PREWASH, for example work garments, sheets, household linen, underwear, towels WHITES WITHOUT PREWASH, 60°-95° for example household linen, sheets, shirts, underwear 30°-60° COLOUREDS WITHOUT PREWASH, for example shirts, blouses, terry cloths, underwear 30°-40°... -
Page 15: Washing Programmes
Programme table Washing programmes for synthetics, mixed fabrics, delicates and wool Max. load 2.5 kg, wool 1 kg Programme Temp. 30°-60° SYNTHETICS WITH PREWASH, for example underwear, coloured items, shirts, blouses 30°-60° SYNTHETICS WITHOUT PRE- WASH, for example shirts, blouses, mixed fabrics -40°... -
Page 16: Maintenance
Maintenance 1. Door seal Check from time to time the door seal and eliminate eventual possible objects that could be trapped in the fold. 2. Bodywork Clean the outside of the machine with warm water and a detergent used to handwash dishes. Rinse with clean water and dry with a soft cloth. -
Page 17: Water Inlet Filter
• Remove any objects from the pump impeller by rotating it. • Put the cap back on the emergency emptying hose and place the latter back in its seat. • Screw the pump fully in. • Close the pump door. 5. -
Page 18: Drain Pump
Something not working? Problems which you can resolve yourself. Problem • The machine does not start up: • The machine does not fill: • The machine fills then empties immediately: • The machine does not empty and/or does not spin: •... -
Page 19: Laundry Is Not Spun Enough
Problem • Spinning starts late or the laundry is not spun enough: If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information. - Page 20 The Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in...
