HP Kayak XW U3 & W3 PC Workstation

Technical Information

This section provides technical information about your PC Workstation
and includes details about the system board connectors and switches.

Advertisement

Table of Contents
loading

Related Manuals for HP Kayak XW U3-W3

Summary of Contents for HP Kayak XW U3-W3

  • Page 1: Technical Information

    HP Kayak XW U3 & W3 PC Workstation Technical Information This section provides technical information about your PC Workstation and includes details about the system board connectors and switches.
  • Page 2 HP Kayak XW U3 & W3 PC Workstation Technical Information Features Features Feature: Description: Processor (standard) Pentium II (single or dual) Cache Memory • Level-One: 16 KB code, 16 KB data (integrated in processor package) • Level-Two: 512 KB Main memory (size/speed) Upgradeable to 1 GB (SDRAM) using either: •...
  • Page 3 HP Kayak XW U3 & W3 PC Workstation Technical Information Features Feature: Description: 25-pin parallel connector • Mode: Centronics or bidirectional modes (ECP/EPP) • Parallel port: 1 (378h, IRQ 7), 2 (278h, IRQ 5), or Off. 9-pin serial connectors • Standard: Two UART 16550 buffered serial ports (both RS-232-C).

  • Page 4: System Specifications

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications System Specifications Power Consumption Information Maximum power consumption 260 W Typical consumption with: approx. 85 W • One processor installed approx. 99 W • Two processors installed 2.5 W The power supply in your PC Workstation continues to supply power to the CMOS memory, even when switched off.

  • Page 5: Irqs, Dmas, And I/O Addresses Used By Your Pc Workstation

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications IRQs, DMAs, and I/O Addresses Used by Your PC Workstation The IRQ, DMA, and I/O address mappings shown here are for a basic configuration. The resources used by your PC Workstation may vary, depending on which accessory boards are bundled with the PC Workstation.
  • Page 6 HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications I/O Addresses used by PC 0000 - 000F DMA controller 1 Workstation 0020 - 0021 Master interrupt controller 002E - 002F Configuration registers 0040 - 0043 Timer 1 0060, 0064 Keyboard controller 0061...

  • Page 7: Audio Features

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications Audio Features Feature: Description: Digitized Sounds • Compatible SoundBlaster® Pro Adlib® /OPL3® • 16-bit and 8-bit stereo sampling from 4 kHz to 55.2 kHz • Programmable sample rates with 1 Hz resolution •...

  • Page 8: Scsi Features

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications Feature: Description: MIDI/Joystick Interface • Built-in MIDI interface for connection to external MIDI devices • Sound Blaster and MPU-401 UART mode compatible • MIDI time-stamp for multimedia extension •...

  • Page 9: Disk Striping Features (Fastraid)

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Specifications HP FastRAID • Acceleration of Internal UltraWide 16-bit SCSI only • Top performance with two superfast 4.5 GB or 9.1 GB 10,000 rpm hard disks • SCAM not supported Disk Striping Features (FastRAID) Feature: Description:...

  • Page 10: Network Features

    HP Kayak XW U3 & W3 PC Workstation Technical Information The HP FastRAID Option Network Features Feature: Description: LAN Controller AMD PCNET-Fast Chip RJ45 Connector 10BT/100TX autonegotiation Remote Boot Protocols integrated in System BIOS ExStart Connector • Connection to CPU board •...

  • Page 11: System Connectors And Switches

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches System Connectors and Switches System Board Connectors System Board Switches 16-bit Wide SCSI Power Fan (airflow guide) Status Panel MT VRM 1 LCD Panel VRM 2 Memory Modules Processor 1...

  • Page 12: System Board Switches

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches System Board Switches System Board Switches Switches 1 through 5 are used for processor settings and should not be changed. Replacing the processor with a different processor is not supported by HP.

  • Page 13: Internal Audio Connectors

    HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches Internal Audio Connectors The PC Workstation’s system board has several connectors that allow you to internally connect to other devices. This includes: A CD audio connector •...
  • Page 14 HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches Audio Front Panel The Audio Front Panel Connector, labeled “Audio Front Panel,” is a 10-pin connector that links the system board with the multimedia Front Connector Panel.
  • Page 15 HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches Front Panel Microphone The Front Panel Microphone Connector, labeled “Front Panel Micro,” is a 3-pin connector. The Audio signal from this connector is directly Connector mixed with the signal from the rear panel Microphone jack. The connector has the following pin assignments: Signal MIC signal + power (tip)
  • Page 16 HP Kayak XW U3 & W3 PC Workstation Technical Information System Connectors and Switches English...
