ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. This limit also applies to ASUS’ suppliers and its reseller. It is the maximum for which ASUS, its suppliers, and your reseller are collectively responsible.
Table of Contents About this manual ..................... 6 Conventions used in this manual ............... 7 Icons ....................... 7 Typography ......................7 Safety precautions ..................... 8 Using your Notebook PC................8 Caring for your Notebook PC ............... 9 Airplane mode ....................10 Proper disposal ....................10 Chapter 1: Hardware Setup Getting to know your Notebook PC ............12...
Page 4
Function keys for ASUS Apps ..............41 Windows®8 keys ....................41 Multimedia control keys ................42 Numeric keypad (on selected models) ...........42 Using the optical drive (on selected models) ........4 Chapter 3: Working with Windows® 8 Starting for the first time ................46 ®...
Page 5
USB Charger+ ....................71 Instant On ......................73 Chapter 5: Upgrading your Notebook PC Installing a Random Access Memory (RAM) module ......76 Replacing the Hard Disk Drive (HDD) ............78 Replacing the battery pack ................80 Chapter 6: Troubleshooting your Notebook PC Appendices Notebook PC E-Manual...
This chapter provides an overview of using Windows® 8 in your Notebook PC. Chapter 4: ASUS Apps This chapter features the ASUS apps included with your Notebook PC. Chapter 5: Upgrading your Notebook PC This chapter guides you through the process of replacing and upgrading parts of your Notebook PC.
Conventions used in this manual To highlight key information in this manual, some text are presented as follows: IMPORTANT! This message contains vital information that must be followed to complete a task. NOTE: This message contains additional information and tips that can help complete tasks.
Safety precautions Using your Notebook PC This Notebook PC should only be used in environments with ambient temperatures between 5°C (41°F) and 35°C (95°F). Refer to the rating label on the bottom of your Notebook PC and ensure that your power adapter complies with this rating.
Caring for your Notebook PC Disconnect the AC power and remove the battery pack (if applicable) before cleaning your Notebook PC. Use a clean cellulose sponge or chamois cloth dampened with a solution of nonabrasive detergent and a few drops of warm water.
Airplane mode You can send your Notebook PC through airport x-ray machines (used on items placed on conveyor belts), but do not expose them to magnetic detectors and wands. Contact your airline provider to learn about related inflight services that can be used and restrictions that must be followed when using your Notebook PC in-flight.
Getting to know your Notebook PC Top View NOTE: The keyboard's layout may vary per region or country. The top view may also vary in appearance depending on the Notebook PC model. Notebook PC E-Manual...
Microphone The built-in microphone can be used for video conferencing, voice narrations, or simple audio recording. Camera The built-in camera allows you take pictures or record videos using your Notebook PC. Camera indicator The camera indicator lights up when the built-in camera is in use.
Page 14
Keyboard The keyboard provides full-sized QWERTY keys with a comfortable travel depth for typing. It also enables you to use the function keys, allows quick access to Windows®, and controls other multimedia functions. NOTE: • The keyboard layout differs by model or territory. •...
Page 15
Two-color battery charge indicator The two-color LED provides a visual indication of the battery’s charge status. Refer to the table below for details: Color Status Solid Green Battery power is between 95% and 100% Solid Orange Battery power is less than 95% Blinking Orange Battery power is less than 10% Lights off Battery power is more than 10%...
Bottom NOTE: The bottom side may vary in appearance depending on model. WARNING! The bottom of the Notebook PC can get very hot while in use or while charging the battery pack. When working on your Notebook PC, do not place it on surfaces that can block the vents. IMPORTANT! Battery time varies by usage and by the specifications for this Notebook PC.
Page 17
Spring battery lock The spring battery lock automatically locks the battery pack in place once it is inserted into the battery slot. IMPORTANT! This lock should be held in an unlocked position when removing the battery pack. Battery pack The battery pack is automatically charged when your Notebook PC is connected to a power source.
Right Side Headphone output jack port The headphone output jack port allows you to connect your Notebook PC to amplified speakers or headphones. Microphone input jack port The microphone input jack port is used to connect your Notebook PC to an external microphone. USB 2.0 port The USB (Universal Serial Bus) port is compatible with USB 2.0 or USB 1.1 devices such as keyboards, pointing devices, flash disk...
Page 19
Optical disc drive eject button Press this button to eject the optical drive tray. Manual eject hole The manual eject hole is used to eject the drive tray in case the electronic eject button does not work. WARNING! Use the manual eject hole only when the electronic eject button does not work.
Left Side Kensington® lock port The Kensington® lock port allows you to secure your Notebook PC using Kensington® compatible Notebook PC security products. Air vents The air vents allow cool air to enter and warm air to exit the Notebook PC. WARNING! Ensure that paper, books, clothing, cables, or other objects do not block any of the air vents or else overheating may occur.
Page 21
LAN port Insert the network cable into this port to connect to a local area network (LAN). USB 3.0 ports These Universal Serial Bus 3.0 (USB 3.0) ports are backward compatible to USB 2.0 and USB 1.0 devices such as keyboards, pointing devices, flash disk drives, external HDDs, speakers, cameras and printers.
Front View Memory card reader This Notebook PC has a single built-in memory card reader slot that supports MMC, SD, and SDHC card formats. Status indicators The status indicators help identify the current hardware status of your Notebook PC. NOTE: For more details, refer to the Top View section in this manual.
Getting started NOTE: If your Notebook PC does not have its battery pack installed, use the following procedures for installation. Install the battery pack. Move the manual battery lock to the unlocked position. Align and insert the battery pack into the Notebook PC’s battery slot.
Charge your Notebook PC. Connect the AC power cord to the AC/DC adapter. Plug the AC power cord into a 100V~240V power source. Connect the DC power connector into your Notebook PC’s power (DC) input port. Charge the Notebook PC for 3 hours before using it in battery mode for the first time.
The Power-on Self Test (POST) When you turn on the Notebook PC, it runs through a series of software-controlled diagnostic tests called the Power-on Self Test (POST). The software that controls the POST is installed as a permanent part of the Notebook PC’s architecture. If the POST discovers a difference between the record and the existing hardware, it will display a message on the screen prompting you to correct the conflict by running BIOS Setup.
BIOS Settings NOTE: The BIOS screens in this section are for reference only. The actual screens may differ by model and territory. Boot This menu allows you to set your boot option priorities. You may refer to the following procedures when setting your boot priority. On the Boot screen, select Boot Option #1.
Security This menu allows you to set up the administrator and user password of your Notebook PC. It also allows you to control access to your Notebook PC’s hard disk drive, input/output (I/O) interface, and USB interface. NOTE: If you install a User Password, you will be prompted to input this •...
Page 30
To clear the password: On the Security screen, select Administrator Password or User Password. Type in the current password then press Leave the Create New Password field blank then press Select Yes in the confirmation box then press I/O Interface Security In the Security menu, you can access I/O Interface Security to lock or unlock some interface functions of your Notebook PC.
Page 31
USB Interface Security Through the I/O Interface Security menu, you can also access USB Interface Security to lock or unlock ports and devices. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Security If LOCKED, all USB USB Interface Security devices will be disabled USB Interface...
Page 32
Set Master Password In the Security menu, you can use Set Master Password to set up a password-enabled access to your hard disk drive. Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc. Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc. Main Advance Boot...
Version 2.15.1226. Copyright (C) 2012 American Megatrends, Inc. To update the BIOS: Verify the Notebook PC’s exact model then download the latest BIOS file for your model from the ASUS website. Connect your flash disk drive to the Notebook PC and turn on your Notebook PC.
Page 34
Locate the latest BIOS file then start updating the BIOS. ASUSTek Easy Flash Utility FLASH TYPE: W25Q64BV New BIOS Current BIOS Platform: Unknown Platform: Q500A Version: Unknown Version: 202 Build Date: Unknown Build Date: Jul 16 2012 Build Time: 14:53:46...
Gestures for the touchpad Gestures allow you to launch programs and access the settings of your Notebook PC. Refer to the following illustrations when using hand gestures on your touchpad. Moving the pointer You can tap or click anywhere on the touchpad to activate its pointer, then slide your finger on the touchpad to move the pointer onscreen.
One-finger gestures Tap/Double tap • In the Metro Start screen, tap an app to launch it. • In Desktop mode, double-tap an item to launch it. Left-click Right-click • In the Metro Start screen, • In the Metro Start screen, click an app to launch it.
Page 37
Drag and drop Double-tap an item, then slide the same finger without lifting it off the touchpad. To drop the item to its new location, lift your finger from the touchpad. Top edge swipe • In the Metro Start screen, swipe from the top edge to launch the All Apps bar.
Two-finger gestures Rotate Tap two fingers on the touchpad To rotate an image, place two to simulate the right-click fingers on the touchpad then function. turn one finger clockwise or counterclockwise while the other stays still. Two-finger scroll (up/down) Two-finger scroll (left/right) Slide two fingers to scroll up or Slide two fingers to scroll left or down.
Drag and drop Select an item then press and hold the left mouse button. Using your other finger, slide down the touchpad to drag and drop the item to a new location. Three-finger gestures Swipe up Swipe down Swipe three fingers upward to Swipe three fingers downward to show all running applications.
Using the keyboard Function keys The function keys on your Notebook PC’s keyboard can trigger actions inside the Metro Start screen and desktop mode of Windows®. Puts the Notebook PC into Sleep mode Turns Airplane mode on or off NOTE: When enabled, the Airplane mode disables all wireless connectivity.
Turns the speaker volume up Function keys for ASUS Apps Your Notebook PC also comes with a special set of function keys that can be used to launch ASUS apps. Toggles the ASUS Splendid Video Enhancement Technology app to switch between these display...
Multimedia control keys The multimedia control keys allow you to control multimedia files, such as audios and videos, when played in your Notebook PC. Press in combination with the arrow keys on your Notebook PC, illustrated as below. Stop Skip to Skip to Play or previous...
Using the optical drive (on selected models) NOTE: The actual location of the electronic eject button may vary depending on your Notebook PC model. Inserting an optical disc While the Notebook PC is on, press the drive’s eject button to partially eject the drive’s tray.
Page 44
Push the drive tray gently to close the optical drive. NOTE: While data is being read, it is normal to hear some spinning and vibrating in the optical drive. Manual eject hole The manual eject hole is located on the optical drive door and is used to eject the optical drive tray in case the electronic eject button does not work.
Starting for the first time When you start your computer for the first time, a series of screens appear to guide you in conifguring the basic settings of your Windows® 8 operating system. To start your Notebook PC for the first time: Press the power button on your Notebook PC.
Metro style UI The Metro style user interface (UI) is the tile-based display used in Windows® 8. It includes the following features you can use while working on your Notebook PC. Metro Start screen The Metro Start screen appears after successfully signing in to your user account.
Hotspots Onscreen hotspots allow you to launch programs and access the settings of your Notebook PC. The functions in these hotspots can be activated using the touchpad. Hotspots on a running app Hotspots on the Metro Start screen Notebook PC E-Manual...
Page 49
Hotspot Action upper left corner Hover your mouse pointer then tap on the recent app’s thumbnail to revert back to that running app. If you launched more than one app, slide down to show all running apps. lower left corner From a running app screen: Hover your mouse pointer then tap on the Metro Start screen’s thumbnail to go back to...
Working with Metro Style apps Use your Notebook PC’s touchpad or keyboard to launch and customize your apps. Launching apps Position your mouse pointer over the app then left-click or tap once to launch it. Press twice then use the arrow keys to browse through the apps.
Closing apps 1. Move your mouse pointer on the top side of the launched app then wait for the pointer to change to a hand icon. 2. Drag then drop the app to the bottom of the screen to close it. From the running app’s screen, press Notebook PC E-Manual...
Accessing the Apps screen Aside from the apps already pinned on your Metro Start screen, you can also open other applications through the Apps screen. Horizontal scroll bar Launching the Apps screen Launch the Apps screen using your Notebook PC's touchpad, or keyboard.
Page 53
Pinning more apps on the Metro Start screen You can pin more apps on the Metro Start screen using your touchpad. Position the mouse pointer over the app you want to pin on the Metro Start screen. Right-click on the app to activate its settings. Click on the icon.
Charm bar The Charm bar is a toolbar that can be triggered on the right side of your screen. It consists of several tools that allow you to share applications and provide quick access for customizing the settings of your Notebook PC. Charm Bar Launching the Charm bar NOTE: When called out, the Charm bar initially appears as a set of...
Inside the Charm bar Search This tool allows you to look for files, applications, or programs in your Notebook PC. Share This tool allows you to share applications via social networking sites or email. Start This tool reverts the display back to the Metro Start screen.
Snap feature The Snap feature displays two apps side-by-side, allowing you to work or switch between apps. IMPORTANT! Ensure that your Notebook PC’s screen resolution is set to 1366 x 768 pixels or higher before using the Snap feature. Snap bar Using Snap Perform the following steps to activate Snap using your Notebook PC’s touchpad or keyboard.
Page 57
Launch an app then Press To switch between apps, press Notebook PC E-Manual...
Other keyboard shortcuts Using the keyboard, you can also use the following shortcuts to help you launch applications and navigate Windows®8. Switches between the Metro Start screen and the last running app Launches the desktop Launches the Computer window on Desktop mode Opens the File search pane Opens the Share pane...
Launches the magnifier icon and zooms in your screen Zooms out your screen Opens the Narrator Settings Enables the print screen function Wi-Fi connection Access emails, surf the Internet, and share applications via social networking sites using your Notebook PC’s Wi-Fi connection. IMPORTANT! Ensure the Airplane mode is turned off to enable the Wi-Fi function of your Notebook PC.
Page 60
Tap Connect to start the network connection. NOTE: You may be prompted to enter a security key to activate the Wi-Fi connection. If you want to enable sharing between your Notebook PC and other wireless-enabled systems, tap Yes, turn on sharing and connect to devices. Tap No, don't turn on sharing or connect to devices if you do not want to enable the sharing function.
Bluetooth connection Use Bluetooth to facilitate wireless data transfers with other Bluetooth-enabled devices. IMPORTANT! Ensure the Airplane mode is turned off to enable the Bluetooth function of your Notebook PC. For more details, refer to the Airplane mode section in this manual. Pairing with other Bluetooth-enabled devices You need to pair your Notebook PC with other Bluetooth-enabled devices to enable data transfers.
Page 62
Select a device from the list. Compare the passcode on your Notebook PC with the passcode sent to your chosen device. If they are the same, tap Yes to successfully pair your Notebook PC with the device. NOTE: For some bluetooth-enabled devices, you may be prompted to key in the passcode of your Notebook PC.
Airplane mode The Airplane mode disables wireless communication, allowing you to use your Notebook PC safely while in-flight. Turning Airplane mode on Launch the Charm bar. and tap Move the slider to the right to turn the Airplane mode Press Turning Airplane mode off Launch the Charm bar.
Remove everything and reinstall Windows Restoring your Notebook PC to its original factory settings is done using the Remove everything and reinstall option in PC Settings. Refer to the steps below to enable this option: IMPORTANT! Back up all your data before performing this option. NOTE: This process may take a while to complete.
Turning your Notebook PC off You can shut down your Notebook PC by doing either of the following: • from the Charm bar then tap > Shut down to do a normal shutdown. > Shut down. • From the log-in screen, tap •...
Featured ASUS Apps LifeFrame Enhance your webcam functions through the LifeFrame app. Create snapshots, edit photos, record videos, record audio files, use your webcam as a security monitoring device, and play games using this app. To launch LifeFrame Press The archive toolbar displays a function's saved files in thumbnail view.
Page 69
LifeFrame functions Camera Use this function to take pictures using your webcam. Camcorder Use this function to take videos through your webcam. Monitor This function lets you use your webcam as a security video monitor as it automatically detects movement then captures it on photo.
Power4Gear Hybrid Optimize the performance of your Notebook PC using the power saving modes in Power4Gear. NOTE: Unplugging the Notebook PC from its power adapter automatically switches Power4Gear Hybrid to Battery Saving mode. To launch Power4Gear Hybrid Press Select from these power saving modes. Allows you to hide the desktop icons Use these options to customize onscreen and turns the presentation...
Using the USB Charger+ Settings The USB Charger+ Settings lets you set the charge limit when your ASUS Notebook PC is running on battery power and allows you to charge devices while your Notebook PC is on sleep, hibernate, or shutdown mode.
Page 72
Select one or both of these charging options: Enable quick charge when the system is running or Enable quick charge when the system is in sleep/hibernate/ shutdown mode. Move the percentage slider to the left or to the right to set the limit for charging devices.
(Deep S3) using Instant On. NOTE: Deep S3 is a technology that lets you save more battery power while your ASUS Notebook PC is on sleep mode. IMPORTANT! The standby time varies according to your Notebook PC's remaining battery capacity, computer model, configuration, and operating conditions.
Installing a Random Access Memory (RAM) module NOTE: Visit an authorized service center or retailer for information on memory upgrades for your Notebook PC. Only purchase expansion modules from authorized retailers of this Notebook PC to ensure maximum compatibility and reliability. Notebook PC E-Manual...
Replacing the Hard Disk Drive (HDD) WARNING! Disconnect all the connected peripherals, any telephone or telecommunication lines and power connector (such as external power supply, battery pack, etc.) before removing the hard disk cover. IMPORTANT! When replacing or upgrading the hard drive, always visit an authorized service center or retailer for this Notebook PC.
Page 79
new hard disk drive Notebook PC E-Manual...
ASUS website. My built-in camera is not Try reinstalling the webcam driver. working properly. You can also try updating the BIOS to the latest version. If the problem still exists, contact your local ASUS service center for assistance. Notebook PC E-Manual...
Page 83
Service Center for assistance. My Notebook PC displays Download the latest Power4Gear an “Open policy file error” utility from the ASUS website and message when I turn it on. reinstall it in your Notebook PC. My Notebook PC gets too •...
DVD-ROM Drive Information (on selected models) The DVD-ROM drive allows you to view and create your own CDs and DVDs. You can purchase an optional DVD viewer software to view DVD titles. Regional Playback Information Playback of DVD movie titles involves decoding MPEG2 video, digital AC3 audio and decryption of CSS protected content.
Region Definitions Region 1 Canada, US, US Territories Region 2 Czech, Egypt, Finland, France, Germany, Gulf States, Hungary, Iceland, Iran, Iraq, Ireland, Italy, Japan, Netherlands, Norway, Poland, Portugal, Saudi Arabia, Scotland, South Africa, Spain, Sweden, Switzerland, Syria, Turkey, UK, Greece, Former Yugoslav Republics, Slovakia Region 3 Burma, Indonesia, South Korea, Malaysia, Philippines, Singapore,...
Page 88
Blu-ray ROM Drive Information (on selected models) The Blu-ray ROM Drive allows you to view high definition (HD) videos and other disc file formats such as DVDs and CDs. Region Definitions Region A North, Central and South American countries, and their territories; Taiwan, Hong Kong, Macao, Japan, Korea (South and North), South East Asian countries and their territories.
Internal Modem Compliancy The Notebook PC with internal modem model complies with JATE (Japan), FCC (US, Canada, Korea, Taiwan), and CTR21. The internal modem has been approved in accordance with Council Decision 98/482/EC for pan-European single terminal connection to the public switched telephone network (PSTN).
Page 90
Network Compatibility Declaration Statement to be made by the manufacturer to the user: “This declaration will indicate the networks with which the equipment is designed to work and any notified networks with which the equipment may have inter-working difficulties. The manufacturer shall also associate a statement to make it clear where network compatibility is dependent on physical and software switch settings.
Page 91
This table shows the countries currently under the CTR21 standard. Country Applied More Testing Austria Belgium Czech Republic Not Applicable Denmark Finland France Germany Greece Hungary Not Applicable Iceland Ireland Italy Still Pending Still Pending Israel Lichtenstein Luxemburg The Netherlands Norway Poland Not Applicable...
This information was copied from CETECOM and is supplied without liability. For updates to this table, you may visit http://www.cetecom. de/technologies/ctr_21.html 1 National requirements will apply only if the equipment may use pulse dialling (manufacturers may state in the user guide that the equipment is only intended to support DTMF signalling, which would make any additional testing superfluous).
Page 93
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help.
FCC Radio Frequency (RF) Exposure Caution Statement WARNING! Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. “The manufacture declares that this device is limited to Channels 1 through 11 in the 2.4GHz frequency by specified firmware controlled in the USA.
CE Marking CE marking for devices without wireless LAN/Bluetooth The shipped version of this device complies with the requirements of the EEC directives 2004/108/EC “Electromagnetic compatibility” and 2006/95/EC “Low voltage directive”. CE marking for devices with wireless LAN/ Bluetooth This equipment complies with the requirements of Directive 1999/5/ EC of the European Parliament and Commission from 9 March, 1999 governing Radio and Telecommunications Equipment and mutual recognition of conformity.
Wireless Operation Channel for Different Domains N. America 2.412-2.462 GHz Ch01 through CH11 Japan 2.412-2.484 GHz Ch01 through Ch14 Europe ETSI 2.412-2.472 GHz Ch01 through Ch13 France Restricted Wireless Frequency Bands Some areas of France have a restricted frequency band. The worst case maximum authorized power indoors are: •...
Page 97
Departments in which the use of the 2400–2483.5 MHz band is permitted with an EIRP of less than 100mW indoors and less than 10mW outdoors: 01 Ain 02 Aisne 03 Allier 05 Hautes Alpes 08 Ardennes 09 Ariège 11 Aude 12 Aveyron 16 Charente 24 Dordogne...
UL Safety Notices Required for UL 1459 covering telecommunications (telephone) equipment intended to be electrically connected to a telecommunication network that has an operating voltage to ground that does not exceed 200V peak, 300V peak-to-peak, and 105V rms, and installed or used in accordance with the National Electrical Code (NFPA 70).
REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. Nordic Lithium Cautions (for lithium-ion batteries) CAUTION! Danger of explosion if battery is incorrectly replaced.
Page 100
VORSICHT! Explosionsgefahr bei unsachgemäßen Austausch der Batterie. Ersatz nur durch denselben oder einem vom Hersteller empfohlenem ähnlichen Typ. Entsorgung gebrauchter Batterien nach Angaben des Herstellers. (German) ADVARSELI! Lithiumbatteri - Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren.
Optical Drive Safety Information Laser Safety Information Internal or external optical drives sold with this Notebook PC contains a CLASS 1 LASER PRODUCT. WARNING! Making adjustments or performing procedures other than those specified in the user’s manual may result in hazardous laser exposure.
Page 102
CTR 21 Approval (for Notebook PC with built-in Modem) Danish Dutch English Finnish French German Greek Italian Portuguese Notebook PC E-Manual...
Department of Energy helping us all save money and protect the environment through energy efficient products and practices. All ASUS products with the ENERGY STAR logo comply with the ENERGY STAR standard, and the power management feature is enabled by default. The monitor and computer are automatically set to sleep after 15 and 30 minutes of user inactivity.
Page 104
European Union Eco-label This Notebook PC has been awarded the EU Flower label, which means that this product has the following characteristics: Decreased energy consumption during use and stand-by modes. Limited use of toxic heavy metals. Limited use of substances harmful to the environment and health.
ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements.
