- Page 1 Full Automatic Washing Machine This manual is for HWM120-01/XQB120-01 Please read this manual carefully before using. Retain it for future reference.
-
Page 2: Table Of Contents
CONTENTS Names of the parts.............1 Safety precautions ..............2 Installation and adjustment ..........4 Install the water inlet hose........... 6 Preparation before washing ..........8 Put in the laundries .............. 9 Usage of the detergent ....... -
Page 3: Names Of The Parts
Names of the parts Top lid, I Water absorption cushion Water inlet valve Drain hose hanging hole Top lid, II Detergent box Power cord Location of lint filter Handle Control panel seat Drain hose Level meter Inner tub Control panel film Back cover Pulsator Cabinet... -
Page 4: Safety Precautions
Safety precautions In normal usage of the washing machine, Please plug the power plug on special the power plug shall be ready to be pulled receptacle. Be sure to use three-pins or plugged with hand. Be sure to pull the power receptacle. - Page 5 Safety precautions Do not decompose, repair or alter the machine Do not stretch hands into the working machine. by yourself. It is dangerous even if the rotation is slow. Take special care of the children. Do not put any hot or heavy items (such as the kettle Do not wash laundries with volatile materials with hot water) on the washing machine (such as thinner, petrol etc.).
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter After opening the package, please take out the lint filter from the document bag and install it Filter frame into the Filter frame of the inner tub. -
Page 7: Usage Of The Drain Hose
How to change the direction of the drain hose 1.Lean the machine down gently with the front 3.Extend the drain hose from the left side. Push the surface facing the ground. drain hose into the groove with hands. Back Front Soft item 2.Pull out the drain hose from the groove at the left side. -
Page 8: Install The Water Inlet Hose
Install the water inlet hose Confirm the water faucet water faucet, suitable water faucet, not suitable The exit end face of the faucet It is required that the front end shall be longer than 10mm. The exit end face of the faucet shall be flat and smooth. If not please file it to avoid leakage. Connection between the water inlet hose jointer and the water faucet 1.Press the lower end of the lock lever and push down the slider. -
Page 9: Connection Between The Water Inlet Hose And The Washer
Connection between the water inlet hose and the washer 1.Do not take off the water absorption cushion. Please check if the cushion is dropped or damaged before each usage. If it happens nut of the water inlet hose please contact our after-sale department immediately. 2 Put the nut of the water inlet hose on the valve jointer. -
Page 10: Preparation Before Washing
1 Preparation before washing Preparation before washing 1.Connect the water inlet hose. Open the water faucet. 2.Confirm that the washing machine is earthed reliably. Then insert the power plug into the receptacle. The earth terminal shall not link to gas pipeline and faucet water pipeline. -
Page 11: Put In The Laundries
2 Put in the laundries The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition . that can be washed or spinning in one time. One time washing quantity shall be lower than the rated capacity. The largest capacity of this machine is 12.0kg. -
Page 12: Usage Of The Detergent
3 Usage of the detergent First turn the detergent box down before adding detergent. Add the concentrated composite washing powder into the box directly as indicated in the left figure. See to following table for water level, water quantity and selection of powder. -
Page 13: Use The Operation Buttons
4 Use the operation buttons Description of the function of the knobs and buttons Mode and meaning of the VFD indicator The frame of indicator is not lighted. the frame of the indicator is flashing : indicate the running program. the frame of the indicator is on : indicate the program about to run, or indicate the selected mode the frame of the indicator is flashing rapidly: indicate abnormal condition. - Page 14 PROCESS button POWER ON/OFF button one or more one programs among soak wash rinse spin Push the "On/Off" button to switch on the power. can be selected. When the power is on, push it again to switch off the power. After the power is switched on , if the washing machine is idle for 10 minutes, it will switch off the power automatically.
- Page 15 Steps of using the operation buttons and description of the steps POWER ON/OFF WATER PROCESS PROGRAM RESERVE START LEVEL PAUSE Push the POWER ON/OFF button to switch on the power. POWER ON/OFF PROGRAM Push the PROGRAM button to select the suitable automatic program.
- Page 16 Selection method of the procedure programs Times of pushing Contents (the lighted indicators Selected procedure Applicable procedure the PROCESS indicate the programs about to run) program button Wash, rinse, spin When the common laundries need Soak Wash Rinse Spin (standard program) washing , rinsing and spinning Wash (the washing liquid Repeat using the washing liquid...
-
Page 17: Close The Top Lid
* Total time: including the normal water filling time, drain time. * Spin time: the time from intermittent running to finishing. * The normal and jeans automatic programs can be fitted with soak procedure selection. After water inlet, it will first soak for 15-45 minutes, then do washing, rinsing and spinning. * If quick procedure is selected, the machine will set the complete washing program of water level, wash, rinse, spin automatically. -
Page 18: Disposal After Washing
7.Disposal after washing After using, please clean the lint and foreign materials of the lint filter etc. in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Clean the detergent box, then set it on The lint filter must be used during washing. -
Page 19: Trouble Shooting Answer To Question
Trouble-shooting Answer to question (If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 20: Packing List
Packing list Name Quantity User's manual Lint filter Components of the water inlet hose The end connecting to the washing machine Jointer connecting the water inlet hose and the water faucet The end connecting to the water inlet hose jointer Full Automatic washing machine Specification Water level/Water quantity (about)
