Bosch DS940Q Installation Instructions

1.0 Description
The DS940Q is a high performance Passive Infrared (PIR) Motion Detector which uses advanced signal processing to provide outstanding
catch performance and unsurpassed false alarm immunity. It is designed to detect movement in the interior of a structure by sensing the
Infrared energy emitted from the human body as it moves across the detector's field of view. When motion is detected, the detector sends an
alarm signal to the Control Panel.
2.0 Specifications
• Input Power: 9-15 volts DC
• Current Draw: 12 mA @ 12 VDC standby and alarm
• Standby Power: No internal standby power. For UL Listed Product
Installations, 4 hours (48 mA-h) standby power
must be provided.
• Relay Form "A" Normally Closed (NC) contact set rated
for 125 mA @ 28 volts maximum DC or 18 volts
maximum AC for resistive loads.
• Tamper: Normally Closed (with cover on). Contacts rated
at 28 VDC, 125 mA max. Connect tamper circuit
to a 24-hour protection circuit.
3.0 Installation
3.1 Remove the cover using a
small flat-blade screwdriver.
Insert screwdriver here or here
3.3 Avoid:
Direct Hot or
Cold
Drafts
Air
Windows
Conditioning
and
Outlets
Uninsulated
Walls
Moving Objects
Heat
Sources
Passive Infrared Detector
Installation Instructions
3.2 Press the vertical adjust tab
toward the side of the case and
lift out the board.
Bottom of Detector
Direct Sunlight
DS940Q
• Temperature:
• Humidity:
• Dimensions:
• Options:
Reading Bosch Security Systems, Inc. Product Date Codes
•
For Product Date Code information, refer to the Bosch Security
Systems, Inc. Web site at:
datecodes/
LED
ON
OFF
7.5-9ft
3.4 Position detector at correct height.
Mounting
Outdoors
Pets
Mount the detector 7.5 - 9 feet
(2.3 - 2.7 meters) above the floor
-20°F to +120°F (-29°C to +49°C). For UL Listed
Product Installations, the temperature range is
+32°F to +120°F (0°C to +49°C).
0 - 95% non-condensing.
3.75 in. x 2.25 in. x 1.5 in. (HxWxD)
(9.5 cm x 5.7 cm x 3.8 cm)
B335 Swivel Mount Bracket. Use of this bracket
may decrease the PIR range and increase dead
zones.
http://www.boschsecurity.com/
3.3 Select a mounting location.
Mount the sensor where an intruder
will most likely cross through the
coverage pattern.
(2.3- 2.7 m)
7.5-9 ft.
