printer cover
latch
power switch
manual feed slot
paper path selector
USB
interface
connector
Printer Specifications
Printing
Printing method: Laser beam scanning and dry
electrophotographic process
Resolution:
600 dpi
Printing speed:
Up to 8 pages per minute, depending on
the font and print quality
First print:
Less than 19 seconds with letter/A4
Warm-up time:
About 20 seconds at normal temperature
Paper feed:
Automatic feed
Paper feed
alignment:
Center alignment for all sizes
RAM:
2MB, expandable up to 13MB
Input paper
Up to 150 sheets in the tray
supply
Up to 500 sheets per optional
2
([20 lb] 75 g/m
500-sheet lower cassette unit
paper):
Up to 10 envelopes
ready light
(green)
error light
(red)
output tray
extension
paper tray
AC inlet
parallel interface connector
600 dpi, 300 dpi
300 dpi
Paper output:
Face down or face up optional selection
Paper output
Face down 100 sheets
capacity:
Face up 20 sheets with the optional
Paper
Type
Weight
Plain paper
16 to 24 lb,
60 to 90 g/m
Thick paper
28 to 58.5 lb,
105 to 220 g/m
Envelopes
16 to 28 lb,
60 to 105 g/m
* The minimum margin for all paper sizes is 0.16 inch (4 mm) for all
sides.
Environmental
Specification
Operation
Temperature
50 to 95 F (10 to 35 C)
Humidity
15 to 85% RH
Altitude
8200 feet (2500 meters) maximum
Mechanical
Height
9.9 inches (251 mm)
Width
15.6 inches (397 mm)
Depth
18.2 inches (463 mm)
Weight
Approx. 14.5 lb (7.5 kg), excluding developer cartridge,
photoconductor unit, and options
Durability
5 years or 180,000 sheets, whichever comes first
9/99
EPSON EPL-5700i
face-up tray
Size*
Letter (8.5
11 inches)
2
Legal (8.5
14 inches)
Executive (7.25
10.5 inches)
A5 (148
210 mm)
A4 (210
297 mm)
B4 (257
364 mm)
B5 (182
257 mm)
Half-Letter (5.5
8.5 inches)
Government Letter (8.0
Government Legal (8.5
F4 (210
330 mm)
Custom (3.0
5.0 inches to 8.5
inches)
3.5
5.5 inches to 13
2
Monarch (3.875
7.5 inches)
2
Commercial 10 (4.125
DL (110
220 mm)
C5 (162
229 mm)
C6 (114
162 mm)
International B5 (176
Storage
32 to 95 F (0 to 35 C)
30 to 85% RH
EPSON EPL-5700i
10.5 inches)
13 inches)
14
19 inches
9.5 inches)
250 mm)
- 1
