Cisco 860 Series
Platform Overview
Models WAN Interface
Cisco 861 10/100 Mbps Fast Ethernet
Cisco 861W 10/100 Mbps Fast Ethernet
Cisco 867 ADSL
Cisco 867W ADSL
Physical Specifications
Dimensions (H x W x D) Nonwireless Models:
12.8 x 9.8 x 1.9 in. (325 x 249 x 48 mm) (includes rubber feet)
12.8 x 9.8 x 1.75 in. (325 x 249 x 44 mm) (without rubber feet)
Wireless Models:
12.8 x 10.4 x 1.9 in. (325 x 264 x 48 mm) (includes rubber feet)
12.8 x 10.4 x 1.75 in. (325 x 264 x 44 mm) (without rubber feet;
excluding antennas)
Weight 5.5 lb (2.5 kg) maximum
Power Dissipations
AC Input Voltage 100–240 VAC
Frequency 50–60 Hz
Maximum Output Power 60W
12V DC
Output Voltages
Environmental Specifications
Operating Temperature 32 to 104°F (0 to 40°C)
Non-operating Temperature -4 to 149°F (-20 to 65°C)
Relative Humidity (non-condensing) 5 to 95%
Operating Altitude 0 to 10,000 ft. (0 to 3000m)
Regulatory Compliance
Approvals and Compliance • IEC 60950-1:2005, Second Edition, with all country deviations
• AS/NZS 60950-1:2003, First Edition
• CAN/CSA 22.2 No. 60950-1-05, Second Edition
• UL 60950-1, Second Edition, 2005
• EN55024
• Industry Canada CS-03'
• TIA-968-A, Addendum 1, 2, 3, 4, 5
• EMI
• VCCI Class II
• IEC 1000-3-2
• California Energy Commission (CEC) Compliant
• Australia and New Zealand:
• Australia AS/ACIF S031: 2001
• Australia AS/ACIF S043. 1 : 2003
• Australia AS/ACIF S043.2: 2006
• New Zealand PTC220: 2003
22
LAN Interface 802.11b/g
4-port 10/100 Mbps Managed Switch No
4-port 10/100 Mbps Managed Switch Yes
4-port 10/100 Mbps Managed Switch No
4-port 10/100 Mbps Managed Switch Yes
Series Specifications
128 MB
Flash Memory
256 MB
System DRAM Memory
Universal 100–240 VAC
External Power Supply
Console Port RJ-45
802.11b/g WLANs Optional on both models
LEDs PPP, VPN, ADSL, WLAN, LAN
Auxiliary Port Virtual AUX port
Ordering Information
Product Name Product Number
Cisco 861 CISCO861-K9
CISCO861W-GN-A-K9
CISCO861W-GN-E-K9
CISCO861W-GN-P-K9
Cisco 867 CISCO867-K9
CISCO867W-GN-A-K9
CISCO867W-GN-E-K9
Note: For Cisco 860 Series wireless router part numbers, the following letters are associated with specifications
meeting wireless regulations in the respective regions: A = FCC Compliant, E = ETSI Compliant, P = Japan Compliant.
Cisco 860 Series
Product Description
Cisco 861 Ethernet Security Router
Cisco 861 Ethernet Security Router with
802. 1 1n FCC Compliant
Cisco 861 Ethernet Security Router with
802. 1 1n ETSI Compliant
Cisco 861 Ethernet Security Router with
802. 1 1n Japan Compliant
Cisco 867 ADSL2/2+ Annex A Router
Cisco 867 ADSL2/2+ Annex A Router with
802. 1 1n FCC Compliant
Cisco 867 ADSL2/2+ Annex A Router with
802. 1 1n ETSI Compliant
23
