❒ This is displayed only when the microphone
for voice recognition is connected.
➲ The voice operation of the navigation system
➞ Chapter 9
(9) Current time
(10) Estimated time of arrival (or travel time
to your destination)*
The display changes with each touch.
(11) Tracking mark
The tracking mark shows the route your vehicle
has traveled.
➲ Select the tracking setting ➞ Page 56
(12) Map of your surroundings (Side map)
Touching this takes you to the map scroll screen.
(13) Distance to an intersection*
Displayed on the enlarged intersection map. The
green bar gets shorter as your vehicle
approaches an intersection.
(14) Next direction of travel*
(15) Area to Avoid*
➲ About detour area ➞ Page 49
(16) Direction line
The direction towards the location set in (4) is
indicated with a straight line.
(17) Memory navi indicator
➲ About memory navi indicator ➞ Page 100
❒ Information with the mark (*) appears only
when the route is set.
❒ Depending on the conditions and settings,
some items may not be displayed.

Changing the scale of the map

Touching the "Map scale" key displayed on the
upper right of the screen displays the scale
gauge and "Map scale" key. Directly touching the
"Map scale" key changes the map to the selected
scale. Touching or
allows you to specify the scale in greater detail
within a range of 25 yards - 1000 miles (25 meters
- 2000 kilometers).
❒ Selection of the scales is limited during the
memory navi mode.
32
on the scale gauge
❒ The icon of a registered location is indicated
when the map scale is 10 miles (20 km) or
lower.
❒ POI icon is indicated when the map scale is
0.75 mile (1 km) or lower.
❒ The Direct scale key may not appear depend-
ing on the map display mode.
Moving the map to the location
you want to see
If you touch the display briefly, the shortcut menu
appears.
Touching anywhere on the map for at least 2 sec-
onds changes the map to Scroll mode and the
map begins scrolling in the direction you
touched. The scrolling stops when you remove
your finger from the screen. At this time, the
cross pointer appears at the center of the screen.
Also a line connecting between the current loca-
tion and cross pointer appears.
Pressing the POS button returns you to the map
of your surroundings.
❒ Touch the area close to the center of the
screen to scroll slowly; touch near the sides of
the screen to scroll through quickly.
(2) (1)
(3)
(1) Scroll location
The position of cross pointer shows the location
selected on the current map.
Direct scale key
(4)
