Unpacking the Computer & Display
1
1
Remove the computer
and the display from
their shipping boxes.
When you have
completely unpacked
the boxes, you will find
the items shown here.
COMPUTER
Choosing a Comfortable Work Space
2
2
Choose a work space for your computer near a grounded electrical wall outlet.
If you have a tilt-swivel, attach it to the display as described in the display manual. Refer to your display documentation to make
sure it is firmly attached.
Position the display on your desk.
Position the computer to allow proper ventilation and access to the cables.
SAFETY W
ARNING
SAFETY W
ARNING
If you are in any doubt about whether you can lift the equipment safely, do not try to move it without help.
Please read carefully the relevant sections in your HP Brio PC's documentation for safety instructions relating to:
unpacking and setting up your display, electrical connections and/or telephone connections.
REGULA
T
ORY
, W
ARR
ANTY AND SOFTW
REGULA
T
ORY
, W
ARR
ANTY AND SOFTW
Please read carefully the relevant sections in your HP Brio PC's documentation.
Connecting Mouse, Display & Keyboard
3
3
Insert the display connector into the back
of the computer, as shown. You may also
have to connect the display cable to the
display, depending on your model.
Please note that all connectors are shaped
to go in one way only.
Insert the mouse and keyboard
connectors into the back of the computer,
as shown in the illustration.
4
Connecting Your Printer
4
Insert the printer connector into the
back of the computer, as shown in
the illustration.
If you have a serial printer, connect it
to the socket labeled SERIAL.
If you have a parallel printer, connect
it to the socket labeled PARALLEL.
Page 1
