Sony CDP-M11 Service Manual

SERVICE MANUAL
Photo : CDP-M21
SPECIFICATIONS
Compact disc player
Frequency response
Signal to noise ratio
Dynamic range
Harmonic distortion
Channel separation
Outputs
LINE OUT (phono jacks)
PHONE S(for CDP-195)
HEADPHONES (for COP-M1 1)
(stereo phone jack)
General
Power
requirements
2 Hz - 20 kHz + 0.5 dB
More than 100 dB
More than 97 dB
Less than 0.005%
More than 95 dB
Output level 2 V (at 50 kiiohms)
Load impedance over 10 kilohms
Output level max. 10 mW
Load impedance 32 ohms
Model for Continental Europe
(CDP-M11,M12,M21)
220-230V AC, 50/60Hz
Model for the United Kingdom
(CDP-M21,M41)
240V AC, 50/60Hz
Power 12W
consumption
Dimensions
(approx. , including
Projections)
355>95x305 mm
(w/h/d)
(14x33/4x1218 inches)
Weight (approx.) 3.2kg (7 Ibs 1 02)
MICROFILM
AEP Model
UK Model
E Model
Australian Model
Model Name Using Similar Mechanism | CDP-291/391
CD Mechanism Type CDM14-5BD1
Optical Pick-Up Block Type
BU-5BD1
Supplied accessories
Audio cord
1
(2 phono plugs - 2 phono plugs)
Design and specifications subject to change without notice.
For the United Kingdom and
European countries
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
This Compact Disc player is
classified as a CLASS 1
LASER product.
The CLASS 1 LASER
PRODUCT Iabel isJocated
on the rear exterior.
COMPACT DISC PLAYER
SON Y.
