US Model
CDP-209ES
Canadian Model
AEP Model
UK Model
E Model
CDP-790
CDM14-5BD1
BU-5BD1
Compact disc player
Frequency response
Signal to noise ratio
Dynamic range
Harmonic distortion
Channel separation
Outputs
LINE OUT (FIXED)
(phono jacks)
LINE OUT (VARIABLE)
(phono jacks)
DIGITAL OUT (OPTICAL) .
(optical output connector)
PHONES
(stereo phone jack)
Generai
Power requirements
SPECIFICATIONS
2Hz — 20 kHz + 0.3. dB
More than 110 dB
More than 97 dB
Less than 0.003%
More than 100 dB
Output level 2 V (at 50 kilonms)
Load impedance over 10 kilonms
Output level max. 2V (at 50 kilohms)
Load impedance over 50 kilohms
Wave length 660 nm
Output level —18 dBm
Output level max. 15 mW
Load impedance 32 ohms
US, Canadian model:
120V AC, 60Hz
AEP model:
220V AC, 50/60Hz
UK, Australian model:
240V AC, 50/60Hz
E model:
110, 120V/220, 240V AC
adjustable 50/60 Hz
Power consumption
Dimensions
(approx., including
projections)
Weight (approx.)
Supplied accessories
Audio cord
Remote commander
R6 (size AA) batteries
Remote commander
Remote control system
Power requirements
Dimensions
Weight
US model:
17W
EXCEPT US model:
14W
430 X 110 X 280 mm (w/h/d)
(17 X 4°/eX 11'/s inches)
4.5 kg (9 Ibs 1502)
1 (2 phono plugs — 2 phono plugs)
4
2
Infrared control
3 V DC with two R6 (size AA) batteries
Approx. 67 X 18 X 175 mm (w/h/d)
(2°/4X */32X 7 inches)
Approx. 150 g (5.3 oz)
Including batteries
Design and specifications subject to. change without notice.
Optional accessory
Optical cable POC-15
COMPACT DISC PLAYER
