Thank you for purchasing this Panasonic product.
■ To ensure correct use of this lens, please read the operating instructions supplied
with the lens and the projector carefully.
■ Before using this product, be sure to read "Read this first!" (
■ Please save this manual for future use.
Operating Instructions
Zoom Lens
Model No.
Commercial Use
ET-D3LEW300
Page 3).
DPQX1664ZA/X1
ENGLISH
FRANÇAIS
日本語
Advertisement
Table of Contents
Related Manuals for Panasonic ET-D3QW300
Summary of Contents for Panasonic ET-D3QW300
- Page 1 Model No. ENGLISH FRANÇAIS 日本語 Thank you for purchasing this Panasonic product. ■ To ensure correct use of this lens, please read the operating instructions supplied with the lens and the projector carefully. ■ Before using this product, be sure to read “Read this first!” ( ...
-
Page 2: Table Of Contents
█ Contents Read this first! ..................3 Before Use.....................4 Preparation....................5 Before replacing the projection lens ............5 Attaching and Detaching the Lens ............5 Peripheral focus adjustment function ............5 Lens calibration ..................5 Projection relationships...............6 Lens shift ranges ..................9 Specifications ..................11 Dimensions ..................11 Projected image size and Projection distance..Appendix / Annexe / 付録... -
Page 3: Read This First
Read this first! Always follow these precautions WARNING: Do not look at or place your skin into the light emitted from the lens while the projector is being used. Doing so can cause burns or loss of sight. z Strong light is emitted from the projector’s lens. Do not look at or place your hands directly into this light. -
Page 4: Before Use
Models other than the above may also be supported. Refer to the operating instructions for your projector or the following website. https://panasonic.net/cns/projector/ z If the projector you are using is PT-RQ32K / PT-RZ31K / PT-RS30K / PT-RZ21K / PT-RS20K, you may not be able to use the projection lens depending on main version of the firmware. -
Page 5: Preparation
Preparation Before replacing the projection lens Return the projection lens to the home position before replacing or removing it. For details on how to return the lens to the home position, refer to the operating instructions of the projector. Attention z Make sure that the projector power supply is switched off before attaching or detaching the projection lens. -
Page 6: Projection Relationships
Projection relationships The dimensional relationship between the screen and the projector is shown below. ■ Dimensional relationship diagram Projected image Screen L (LW/LT) L (LW/LT) Screen Note z This diagram assumes that the size and position of the projected image will be adjusted so that the image fills the entire screen. - Page 7 Projection relationships (continued) ■ Dimensional relationship For details on the projection distance (L), refer to “Projected image size and Projection distance” and “Projection distance formulas” in the Appendix. ■ [GEOMETRY] projection range [VERTICAL KEYSTONE] (viewed from the side) [HORIZONTAL KEYSTONE] (viewed from above) Screen Screen Vertical arc correction (viewed from the side)
- Page 8 Projection relationships (continued) Only [KEYSTONE] [KEYSTONE] and [CURVED CORRECTION] Only [CURVED used used together CORRECTION] used Projector Vertical Horizontal Vertical Horizontal Model No. keystone keystone keystone keystone Min. value Min. value Min. value Min. value correction correction correction correction of R2/L2 of R3/L3 of R2/L2 of R3/L3...
-
Page 9: Lens Shift Ranges
Lens shift ranges Perform the lens position shift within the adjustment range. Perform lens shift adjustment within the ranges shown in the following illustrations. The focus may change when the lens position is shifted out of the adjustment range. This is because the movement of the lens is restricted to protect the optical parts. Projection position can be adjusted with the optical axis shift based on the home position in the respective range. - Page 10 Lens shift ranges (continued) Projected image width H 0.19 H 0.19 H PT-RQ32K / PT-RQ22K Optical axis center Standard projection position Projected image width H 0.2 H 0.2 H PT-RS30K / PT-RS20K Optical axis center Standard projection position Note z The home position of the projector is a point of origin position for the lens shift (i.e., vertical and horizontal positions of the lens) based on the results of lens calibration.
-
Page 11: Specifications
Specifications Model No. ET-D3LEW300 F value Focal Length (f) 16.36 mm (21/32") - 19.63 mm (25/32") Supported screen size 70" to 1 000" Width 183 mm (7-7/32") Dimensions Height 170 mm (6-11/16") Depth 411 mm (16-3/16") Net Weight Approx. 8.0 kg (17.6 lb) Dimensions (Unit: mm) 411 (16-3/16") - Page 12 Panasonic Connect Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Panasonic Testing Centre Winsbergring 15, 22525 Hamburg, Deutschland Importer for UK; Panasonic Connect UK, a branch of Panasonic Connect Europe GmbH, Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT Italiano Français Fabbricato da: Fabriqué...
- Page 13 Čeština Hrvatski Vyrobil: Proizvodi: Panasonic Connect Co., Ltd. Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japonsko Japan Dovozce: Uvoznik: Panasonic Connect Europe GmbH Panasonic Connect Europe GmbH Hagenauer Strasse 43, 65203 Wiesbaden, Německo Hagenauer Strasse 43, 65203 Wiesbaden, Njemačka...
- Page 14 Nederlands Română Geproduceerd door: Fabricat de: Panasonic Connect Co., Ltd. Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japan Japonia Importeur: Importator: Panasonic Connect Europe GmbH Panasonic Connect Europe GmbH Hagenauer Strasse 43, 65203 Wiesbaden, Duitsland...
- Page 15 Suomi Valmistaja: Panasonic Connect Co., Ltd. 4-1-62 Minoshima, Hakata-ku, Fukuoka 812-8531, Japani Maahantuoja: Panasonic Connect Europe GmbH Hagenauer Strasse 43, 65203 Wiesbaden, Saksa Valtuutettu edustaja EU:ssa: Panasonic Connect Europe GmbH Panasonic Testing Centre Winsbergring 15, 22525 Hampuri, Saksa Svenska Tillverkad av: Panasonic Connect Co., Ltd.
- Page 16 Product Information (for Turkey only) AEEE Yönetmeliğine Uygundur. Environment care information for users in China This symbol is only valid in China. Panasonic Connect Co., Ltd. Web Site : https://panasonic.net/cns/projector/ Panasonic Connect North America Two Riverfront Plaza, Newark, NJ 07102 TEL: (877) 803 - 8492 Panasonic Canada Inc.
-
Page 17: Projected Image Size And Projection Distance
Appendix / Annexe / 付録 Appendix / Annexe / 付録 （continued / suite / つづき） ■ Projected image size and Projection distance ■ Taille de l'image projetée et Distance de projection ■ 投写画面サイズと投写距離 （Unit / Unités / 単位 : m） When the screen aspect ratio is 16:10 PT-RQ35K / PT-RZ34K / PT-RQ25K / PT-RZ24K /... - Page 18 Appendix / Annexe / 付録 （continued / suite / つづき） （Unit / Unités / 単位 : m） When the screen aspect ratio is PT-RQ35K / PT-RZ34K / PT-RQ25K / PT-RZ24K / 16:9 PT-RQ32K / PT-RQ22K PT-RZ31K / PT-RZ21K / PT-RQ18K / PT-RZ17K / PT-RS30K / PT-RS20K Lorsque le rapport dʼaspect de PT-RZ16K...
- Page 19 Appendix / Annexe / 付録 （continued / suite / つづき） Note z A ±5 % error in listed projection distances may occur. In addition, when [KEYSTONE] is used, distance is corrected to become smaller than the specified screen size. z The throw ratio is based on the value during projection with the projected image size of 3.81 m (150"). z The periods used in the numbers in the tables are decimal points.
- Page 20 Appendix / Annexe / 付録 （continued / suite / つづき） z Projection distance formulas z Formules de distance de projection z 投写距離計算式 The dimensions of the following table contain a slight error. Periods are used to represent decimal points in the calculation formulas in the following table. Les dimensions du tableau suivant peuvent présenter un léger écart.
- Page 21 MEMO Appendix / Annexe / 付録 （continued / suite / つづき） Appendix / Annexe / 付録...
- Page 22 Two Riverfront Plaza, Newark, NJ 07102 TEL: (877) 803 - 8492 Panasonic Canada Inc. 5770 Ambler Drive, Mississauga, Ontario L4W 2T3 TEL: (905) 624 - 5010 パナソニック コネクト株式会社 〒 571-8503 大阪府門真市松葉町２番 15 号 電話 0120-872-601 © Panasonic Connect Co., Ltd. 2023 FJ0423JG1073 -PT Printed in Japan...
