Page 1 FILE NO. 030-200301 SERVICE MANUAL COLOUR TELEVISION ZP38 Chassis 3 6ZP38B, 32ZP38B PUBLISHED IN JAPAN, Mar., 2003 So...
Page 2: Table Of Contents
TABLE OF CONTENTS CHAPTER 1 GENERAL ADJUSTMENTS SAFETY INSTRUCTIONS ............................3 SET-UP ADJUSTMENT ............................4 SERVICE MODE ..............................6 DESIGN MODE ................................ 9 ELECTRICAL ADJUSTMENTS ..........................10 CIRCUIT CHECK ..............................17 CHAPTER 2 SPECIFIC INFORMATIONS SETTING & ADJUSTING DATA ..........................18 LOCATION OF CONTROLS ...........................
Page 3: Chapter 1 General Adjustments
CHAPTER 1 GENERAL ADJUSTMENTS SAFETY INSTRUCTIONS WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” INSTRUCTIONS BELOW. X-RAY RADIATION PRECAUTION 1. Excessive high voltage can produce potentially hazard- 2. The only source of X-RAY RADIATION in this TV receiver ous X-RAY RADIATION.
Page 4: Set-Up Adjustment
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU- TION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF SERVICE MANUAL. SET-UP ADJUSTMENT I The following adjustments should be made when a complete realignment is required or a new picture tube is installed. Perform the adjustments in order as follows : 1.
Page 5 (5)Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set at the initial position) Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets. Xv bow-shaped deviation of convergence red/blue blue...
Page 6: Service Mode
SERVICE MODE 1. ENTERING TO SERVICE MODE 1) Press o button once on 2) Press o button again to 3) While pressing the o button, Remote Control. keep pressing. press MENU button on TV set. Item Data Mute or (Service mode display) 2.
Page 7 4. SELECTING THE ADJUSTING ITEMS 1) Every pressing of CHANNEL s button in the service mode changes the adjustment items in the order of table-2. (t button for reverse order) Refer to table-2 for preset data of adjustment mode. (See SETTING & ADJUSTING DATA on page 18) 5.
Page 8 8. SELF DIAGNOSTIC FUNCTION 1) Press “9” button on Remote Control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC’s are executed properly. 2) During diagnosis, the following displays are shown. Indicated color of mode now selected : Green and Red Indicated color of other modes : White...
Page 9: Design Mode
DESIGN MODE 1. ENTERING TO DESIGN MODE 3) Press MENU button on TV. 1) Select the Service mode. 2) While pressing o or CALL button on Remote and press MENU button on TV. ITEM Press DATA Press (Design mode) (Adjustment mode) When QA02 is initialized, items “OPT0”...
Page 10: Electrical Adjustments
ELECTRICAL ADJUSTMENTS ITEM ADJUSTMENT PROCEDURE FOCUS VR ADJ 1. Enter the service mode, then select any register item. 2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap- pears on the screen. 3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture screen.
Page 11 ITEM ADJUSTMENT PROCEDURE WIDTH 1. Call up the adjustment mode display, then select the item WID. (WID) 2. Press the ; – /+ button to get the picture so the left and rightedges of raster begins to lack. 3. Press the ; – /+ button to advance the data by 7 steps. Note : Check the horizontal picture position is correct.
Page 12 – 12 –...
Page 13 – 13 –...
Page 14 – 14 –...
Page 15 – 15 –...
Page 16 – 16 –...
Page 17: Circuit Check
CIRCUIT CHECK HIGH VOLTAGE CHECK CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps below. 1. Connect an accurate high voltage meter to the second anode of the picture tube. 2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current). 3.
Page 18: Chapter 2 Specific Informations
CHAPTER 2 SPECIFIC INFORMATIONS SETTING & ADJUSTING DATA SAFETY INSTRUCTIONS 32” 36" HIGH VOLTAGE AT ZERO BEAM: 32.2 kV 32.4 kV MAX HIGH VOLTAGE: 35.0 kV 35.0 kV AV VOLTAGE 220~240 V 220~240 V Table-1 SERVICE MODE ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE: Item Adjustment Reference data...
Page 19: Location Of Controls
LOCATION OF CONTROLS (Representaive: 36ZP38B) Front L/MONO MENU S-VIDEO VIDEO AUDIO MAIN SWITCH POSITION UP VIDEO-5 (S-VIDEO/VIDEO) POSITION DOWN HEAD PHONE VOLUME UP VOLUME DOWN EXIT Rear SURROUND OUT (3)/ SURROUND OUT AUDIO AUDIO FIXED AERIAL TERMINAL SCART-1 AUDIO OUT (FIXED) SCART-2 VIDEO-4 (COMPONENT VIDEO) SCART-3...
Page 20 Remote Control TEXT/TV CALL Power on/Standby CALL Index, initial (For Toshiba TV/VCR/DVD only) Number buttons (0-9) 1 or 2 digit channel selection Input source selection (A 1 – A 4) Selectable picture Selectable sound MENU EXIT MENU EXIT DVD MENU MENU •...
Page 21: Chassis And Cabinet Replacement Parts List
CHASSIS AND CABINET REPLACEMENT PARTS LIST WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL. CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate com- ponents which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 22 Location Location Parts No. Description Parts No. Description C505 24794470 ELECTORLYTIC, 16V 47UF M C655 24503042 PLASTIC FILM, 63V 0.12UF J C506 24109103 CERAMIC CHIP, 50V B 0.01UF K C656 24232103 CERAMIC DISC, 50V F 0.01UF Z C507 24100104 CERAMIC CHIP, 25V F 0.1UF Z C657 24797229 ELECTROLYTIC, 50V 2.2UF M...
Page 23 Location Location Parts No. Description Parts No. Description C834 24794470 ELECTORLYTIC, 16V 47UF M CA33 24793470 ELECTROLYTIC CE04G 10V 47UF M C835 24795100 ELECTROLYTIC, 25V 10UF M CA42 24794101 ELECTROLYTIC, 16V 100UF M C836 24794470 ELECTORLYTIC, 16V 47UF M CA43 24109103 CERAMIC CHIP, 50V B 0.01UF K C838...
Page 24 Location Location Parts No. Description Parts No. Description CD185 24100104 CERAMIC CHIP, 25V F 0.1UF Z CV13 24794100 ELECTROLYTIC, 16V 10UF M CD186 24092733 CERAMIC CHIP, 50V B 0.022UF K CV14 24100104 CERAMIC CHIP, 25V F 0.1UF Z CD187 24762221 ELECTROLYTIC, 10V 220UF M CV15 24092743...
Page 25 Location Location Parts No. Description Parts No. Description R342 24011101 CHIP, METAL FILM, 1/20W 100 OHM J R488 24366154 CARBON FILM, 1/6W 150K OHM J R343 24366103 CARBON FILM, 1/6W 10K OHM J R489 24366104 CARBON FILM, 1/6W 100K OHM J R344 24366823 CARBON FILM, 1/6W 82K OHM J...
Page 26 Location Location Parts No. Description Parts No. Description R645 24366229 CARBON FILM, 1/6W 2.2 OHM J R814 24366682 CARBON FILM, 1/6W 6.8K OHM J R646 24011223 CHIP, METAL FILM, 1/20W 22K OHM J R815 24552102 OXIDE METAL FILM, 1/2W 1K OHM J R648 24366229 CARBON FILM, 1/6W 2.2 OHM J...
Page 27 Location Location Parts No. Description Parts No. Description R981 24366471 CARBON FILM, 1/6W 470 OHM J RA25 24011102 CHIP, METAL FILM, 1/20W 1K OHM J R992 24366150 CARBON FILM, 1/6W 15 OHM J RA26 24011102 CHIP, METAL FILM, 1/20W 1K OHM J R2020 24011101 CHIP, METAL FILM, 1/20W 100 OHM J...
Page 28 Location Location Parts No. Description Parts No. Description RB91 24011473 CHIP, METAL FILM, 1/20W 47K OHM J RS03 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J RB92 24011271 CHIP, METAL FILM, 1/20W 270 OHM J RS04 24011562 CHIP, METAL FILM, 1/20W 5.6K OHM J RB93 24011271 CHIP, METAL FILM, 1/20W 270 OHM J...
Page 29 Location Location Parts No. Description Parts No. Description RT19 24000445 CHIP JUMPER, 1608TYPE RV67 24011102 CHIP, METAL FILM, 1/20W 1K OHM J RT20 24011102 CHIP, METAL FILM, 1/20W 1K OHM J RV68 24011101 CHIP, METAL FILM, 1/20W 100 OHM J RT21 24011332 CHIP, METAL FILM, 1/20W 3.3K OHM J...
Page 30 Location Location Parts No. Description Parts No. Description L514 23103852 COIL, FILTER, TEM2028AH LJ901 23200547 COIL, CORRECT COIL,0.4CU-60T, L515 23103845 COIL, TEM2030AY TSB-2418AH (36ZP38B) L516 23103845 COIL, TEM2030AY LR01 23289109 COIL, PEAKING, TRF41R0AF L605 23248073 COIL, CHOKE, TLN3299D LR02 23289109 COIL, PEAKING, TRF41R0AF L671 23103887...
Page 31 Location Location Parts No. Description Parts No. Description Q430 23314141 TRANSISTOR, 2SC3852 Q840B 70391355 SCREW, BIND HEAD TAP-TITE B, Q430B 70391355 SCREW, BIND HEAD TAP-TITE B, BITTB 3X8 SZN BITTB 3X8 SZN Q901 23314780 TRANSISTOR, 2SC4544 Q451 70114396 TRANSISTOR, 2SC3326B Q901B 70391355 SCREW, BIND HEAD TAP-TITE B, Q460...
Page 32 Location Location Parts No. Description Parts No. Description QS14 70114396 TRANSISTOR, 2SC3326B D432 23316670 DIODE, ZENER, MTZJ5.1C QT01 23009169 IC, SAA5665HL/M1/0606 D436 23115599 DIODE, 1N4148 QT02 23314993 TRANSISTOR, 2SC4081 Q D441 23316687 DIODE, ZENER, MTZJ9.1B QT03 70114402 TRANSISTOR, 2SC3437-Y D442 23118094 DIODE, EU2A QT05...
Page 33 Location Location Parts No. Description Parts No. Description D907 23115599 DIODE, 1N4148 G604 24000445 CHIP JUMPER, 1608TYPE D908 23115599 DIODE, 1N4148 G638 24011103 CHIP, METAL FILM, 1/20W 10K OHM J D909 23115599 DIODE, 1N4148 G675 24011333 CHIP, METAL FILM, 1/20W 33K OHM J D911 23357366 DIODE, FR105-B5...
Page 34 COVER, BACK COVER ASSEY 36ZP38 SA04 23145430 SWITCH, PUSH, SKHHLMA010 (36ZP38B) SA05 23145430 SWITCH, PUSH, SKHHLMA010 * A401 23530806 COVER, BACK COVER ASSEY 32ZP38 SJ01 23146958 RELAY, 2C 1A DC12V OMRON (36ZP38B) (32ZP38B) SR82 23146574 RELAY, DLS5D1-O(M) 0.15W A430 23802319...
Page 35: Pc Boards Bottom View
SIGNAL BOARD PD1007 BOTTOM (FOIL) SIDE – 35 – – 36 –...
Page 36 POWER BOARD PD1008-1 BOTTOM (FOIL) SIDE – 37 – – 38 –...
Page 37 DEF BOARD PD1009 BOTTOM (FOIL) SIDE – 39 – – 40 –...
Page 38 INDICATOR BOARD PD1008-2 BOTTOM (FOIL) SIDE CONTROL BOARD PD1008-3 BOTTOM (FOIL) SIDE EXT-SP BOARD PD0206A DIGITAL-IN BOARD PD0549B TEXT-P2 BOARD PD0267 BOTTOM (FOIL) SIDE BOTTOM (FOIL) SIDE BOTTOM (FOIL) SIDE – 41 – – 42 –...
Page 39 CRT DRIVE BOARD PD0491 BOTTOM (FOIL) SIDE – 43 –...
Page 40: Terminal View Of Transistors
TERMINAL VIEW OF TRANSISTORS 2SD2253 2SC3852 2SC752GTM 2SC752 2SA1788 (old) 2SD1763A 2SA562TM 2SC2482 2SC5243 2SC1569 2SA1015 2SC2655 2SC5570 2SC4544 2SC4721P 2SC1815 2SA1788 2SC2878 2SA1306 2SC1740S 2SA1186A 2SC2120 2SA9335 ON4409 RN2203 2SD1554 RN2201 2SD2253 2SD1556 RN2004 RN1203 2SC5143 RN1204 2SD2553 RN2204 RN1205 RN1202 RN1201...
Page 41 SCHEMATIC DIAGRAM MODEL : 36ZP38B / 32ZP38B WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL. CAUTION: The international hazard symbols "*" in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 42 – 46 –...
Page 43: Specifications
SPECIFICATIONS (Representative: 36ZP38) Input Power Rating: AC 220 ~ 240 Volts, 50 Hz Aerial Input Impedance: 75 ohm unbalanced type for VHF, UHF and CATV Receiving Channels: System Channel CATV PAL B/G CCIR 2 ~ 12 21 ~ 69 S1 ~ S41 X ~ Z + 2, SECAM B/G CCIR...
Page 44 TOSHIBA CORPORATION 1-1, SHIBAURA 1- CHOME, MINATO-KU, TOKYO 105-8001, JAPAN...
Page 45 TOSHIBA ASIA OCEANIA SERVICE CENTRE TOSHIBA SINGAPORE PTE LTD FILE NO: TAOSC-CTV-20040206-1 echnical DATE Feb 2004 Product Model 36ZP38B, 32ZP38B, 32ZP38N Symptom : Line noise appear on screen, when playback DVD with Progressive mode. Cause : Capacitor C898 Countermeasures : Change the value of C898, from 0.22uF to 1000pF.
Page 46 TOSHIBA ASIA OCEANIA SERVICE CENTRE TOSHIBA SINGAPORE PTE LTD Change the value of C898, from 0.22uF to 1000pF. 438B Alexandra Road, Block B #06-05 Alexandra Technopark. Singapore 119968 Tel : 65-62762022 Fax : 65-62762322 Email: TAOSC@toshiba.com.sg...
Page 47 FILE NO. 033-200415 SUPPLEMENT SERVICE MANUAL Colour Television 32ZP38B (TJP) 36ZP38B (TJP) - SUMMARY - 32ZP38B(TJP)/36ZP38B(TJP) is the same as 32ZP38B/36ZP38B except for the parts tabled on back of this sheet. Also, models 32ZP38B(TJP) and 36ZP38B(TJP) are producted in the year 2004. Use this service manual together with the service manual of 32ZP38B/36ZP38B (File No.
Page 48 REPLACEMENT PARTS LIST DIFFERENCES Location Parts No. Description Location Parts No. Description RJ01 #2 24366103 CARBON FILM, 1/6W 10K OHM J #1 : [32ZP38B(TJP)] RJ02 #2 24366102 CARBON FILM, 1/6W 1K OHM J #2 : [36ZP38B(TJP)] RJ04 #2 24366102 CARBON FILM, 1/6W 1K OHM J RJ05 #2 24323479 METAL FILM, 2W 4.7 OHM J CAPACITORS...
Page 49 Location Parts No. Description Location Parts No. Description Q2106 23205081 TRANSISTOR, 2SA1980-Y D845 23118859 DIODE, 1SS133 Q2107 23205005 TRANSISTOR, KTA2014Y D855 23118859 DIODE, 1SS133 Q2108 23205005 TRANSISTOR, KTA2014Y D893 23118528 DIODE, ZENER, RD5.6ESA B3 Q2109 23205005 TRANSISTOR, KTA2014Y D894 23118528 DIODE, ZENER, RD5.6ESA B3 Q4465 23205005 TRANSISTOR, KTA2014Y D901...
Page 50 Location Parts No. Description Location Parts No. Description ACCESSORIES A701 #1 23067114 CARTON, CARTON #2 23067076 CARTON, CARTON A702 #1 23946487 PACKING, BOTTOM PACKING #2 23946474 PACKING, BOTTOM PACKING A703 #1 23946488 PACKING, TOP PACKING #2 23946475 PACKING, TOP PACKING A800 23946781 PACKING, PACKING TRAY A801...
Page 52 SCHEMATIC DIAGRAM MODEL : 36ZP38B / 32ZP38B WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" ON THE MANUAL FOR THIS MODEL. CAUTION: The international hazard symbols "*" in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit or specified in the parts list.
Page 53 – 46 –...
Page 54 36ZP38B SIGNAL - CONNECTORS [SHEET-1/10]...
Page 56 36ZP38B SIGNAL - CONNECTORS [SHEET-1/10]...
Page 57 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 36ZP38B SIGNAL - MICRO [SHEET-2/10]...
Page 58 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p...
Page 59 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 36ZP38B SIGNAL - MICRO [SHEET-2/10]...
Page 60 36ZP38B SIGNAL - AV [SHEET-3/10]...
Page 62 36ZP38B SIGNAL - AV [SHEET-3/10]...
Page 63 0.6V(p-p) 0.78V(p-p) 0.53V(p-p) 0.75V(p-p) 0.9V(p-p) 0.7V(p-p) 0.8V(p-p) 0.9V(p-p) 36ZP38B SIGNAL - COMB & MCD [SHEET-4/10]...
Page 64 0.53V(p-p) 0.75V(p-p) 0.9V(p-p)
Page 65 0.6V(p-p) 0.78V(p-p) ) p) 0.8V(p-p) 0.7V(p-p) 0.9V(p-p) 36ZP38B SIGNAL - COMB & MCD [SHEET-4/10]...
Page 66 0.9V(p-p) 9.1 7.3 0.78V(p-p) 0.53V(p-p) 0.75V(p-p) 36ZP38B SIGNAL - BEP [SHEET-5/10] 3.4V(p-p) 3.6V(p-p) 3.5V(p-p)
Page 67 0.9V(p-p) 9.1 7.3 3.4V(p-p) 3.4V(p-p) 3.5V(p-p) 3.6V(p-p) 3.6V(p-p)
Page 68 0.78V(p-p) 0.53V(p-p) 0.75V(p-p) 36ZP38B SIGNAL - BEP [SHEET-5/10]...
Page 69 12.8 13.0 12.8 13.0 26.0 26.0 12.8 12.8 26.0 26.0 13.0 13.0 36ZP38B SIGNAL - AUDIO [SHEET-6/10]...
Page 71 12.8 13.0 26.0 12.8 26.0 13.0 36ZP38B SIGNAL - AUDIO [SHEET-6/10]...
Page 72 32.0 36ZP38B SIGNAL - IF [SHEET-7/10]...
Page 73 32.0...
Page 74 36ZP38B SIGNAL - IF [SHEET-7/10]...
Page 75 36ZP38B SIGNAL - LOW-B REGULATOR [SHEET-8/10]...
Page 77 36ZP38B SIGNAL - LOW-B REGULATOR [SHEET-8/10]...
Page 78 36ZP38B SIGNAL - FREQ_DET [SHEET-9/10]...
Page 80 36ZP38B SIGNAL - FREQ_DET [SHEET-9/10]...
Page 81 36ZP38B SIGNAL - TEXT [SHEET-10/10]...
Page 83 36ZP38B SIGNAL - TEXT [SHEET-10/10]...
Page 84 450Vp-p (AC=220V) 1.5V 36ZP38B POWER_INDI_CONT - POWER [SHEET-1/3]...
Page 85 450Vp-p (AC=220V) 1.5V...
Page 86 36ZP38B POWER_INDI_CONT - POWER [SHEET-1/3]...
Page 87 36ZP38B POWER_INDI_CONT - INDICATOR [SHEET-2/3]...
Page 89 36ZP38B POWER_INDI_CONT - INDICATOR [SHEET-2/3]...
Page 90 36ZP38B POWER_INDI_CONT - CONTROL [SHEET-3/3]...
Page 92 36ZP38B POWER_INDI_CONT - CONTROL [SHEET-3/3]...
Page 93 1050V(p-p)(H) 123V 270V(p-p)(H) 36ZP38B DEF - HORIZONTAL-DEF [SHEET-1/2]...
Page 94 1050V(p-p)(H) 1050V(p-p)(H) 123V 270V(p-p)(H) 270V(p-p)(H)
Page 95 36ZP38B DEF - HORIZONTAL-DEF [SHEET-1/2]...
Page 96 50V(p-p)(V) -15.0 0.8 15.0 1.3V(p-p)(V) 36ZP38B DEF - VERTICAL-DEF [SHEET-2/2]...
Page 98 50V(p-p)(V) 50V(p-p)(V) -15.0 -15.0 0.8 15.0 15.0 1.3V(p-p)(V) 1.3V(p-p)(V) 36ZP38B DEF - VERTICAL-DEF [SHEET-2/2]...
Page 99 104Vp-p 102Vp-p 103Vp-p 11.5 11.5 11.5 122.7 122.3 64.3 36ZP38B CRT-D...
Page 100 11.5 11.5 11.5 11.5 11.5 11.5 122.7 122.7 122.3 122.3 64.3 64.3...
Page 101 104Vp-p 104Vp-p 102Vp-p 102Vp-p 103Vp-p 103Vp-p 36ZP38B CRT-D...
Page 102 32ZP38B SIGNAL - CONNECTORS [SHEET-1/10]...
Page 104 32ZP38B SIGNAL - CONNECTORS [SHEET-1/10]...
Page 105 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 32ZP38B SIGNAL - MICRO [SHEET-2/10]...
Page 106 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p...
Page 107 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 5Vp-p 32ZP38B SIGNAL - MICRO [SHEET-2/10]...
Page 108 32ZP38B SIGNAL - AV [SHEET-3/10]...
Page 110 32ZP38B SIGNAL - AV [SHEET-3/10]...
Page 111 0.6V(p-p) 0.78V(p-p) 0.53V(p-p) 0.75V(p-p) 0.9V(p-p) 0.7V(p-p) 0.8V(p-p) 0.9V(p-p) 32ZP38B SIGNAL - COMB & MCD [SHEET-4/10]...
Page 112 0.53V(p-p) 0.53V(p-p) ( ( H 0.75V(p-p) 0.75V(p-p) 0.9V(p-p) 0.9V(p-p) ( ( H...
Page 113 0.6V(p-p) 0.6V(p-p) 0.78V(p-p) 0.78V(p-p) ) p) ) p) 0.7V(p-p) 0.7V(p-p) 0.8V(p-p) 0.8V(p-p) 0.9V(p-p) 0.9V(p-p) 32ZP38B SIGNAL - COMB & MCD [SHEET-4/10]...
Page 114 0.9V(p-p) 2.5 2.5 0.78V(p-p) 0.53V(p-p) 0.75V(p-p) 32ZP38B SIGNAL - BEP [SHEET-5/10] 3.5V(p-p) 3.4V(p-p) 3.6V(p-p)
Page 115 0.9V(p-p) 0.9V(p-p) 2.5 2.5 3.4V(p-p) 3.4V(p-p) 3.5V(p-p) 3.5V(p-p) 3.6V(p-p) 3.6V(p-p)
Page 116 0.78V(p-p) 0.78V(p-p) 0.53V(p-p) 0.53V(p-p) 0.75V(p-p) 0.75V(p-p) 32ZP38B SIGNAL - BEP [SHEET-5/10]...
Page 117 12.8 13.0 26.0 12.8 26.0 13.0 32ZP38B SIGNAL - AUDIO [SHEET-6/10]...
Page 119 12.8 13.0 12.8 13.0 26.0 26.0 12.8 26.0 13.0 12.8 26.0 13.0 32ZP38B SIGNAL - AUDIO [SHEET-6/10]...
Page 120 32.0 32ZP38B SIGNAL - IF [SHEET-7/10]...
Page 121 32.0...
Page 122 32ZP38B SIGNAL - IF [SHEET-7/10]...
Page 123 32ZP38B SIGNAL - LOW-B REGULATOR [SHEET-8/10]...
Page 125 32ZP38B SIGNAL - LOW-B REGULATOR [SHEET-8/10]...
Page 126 32ZP38B SIGNAL - FREQ_DET [SHEET-9/10]...
Page 128 32ZP38B SIGNAL - FREQ_DET [SHEET-9/10]...
Page 129 32ZP38B SIGNAL - TEXT [SHEET-10/10]...
Page 131 32ZP38B SIGNAL - TEXT [SHEET-10/10]...
Page 132 450Vp-p (AC=220V) 1.5V 32ZP38B POWER_INDI_CONT - POWER [SHEET-1/3]...
Page 133 450Vp-p (AC=220V) 1.5V...
Page 134 32ZP38B POWER_INDI_CONT - POWER [SHEET-1/3]...
Page 135 32ZP38B POWER_INDI_CONT - INDICATOR [SHEET-2/3]...
Page 137 32ZP38B POWER_INDI_CONT - INDICATOR [SHEET-2/3]...
Page 138 32ZP38B POWER_INDI_CONT - CONTROL [SHEET-3/3]...
Page 140 32ZP38B POWER_INDI_CONT - CONTROL [SHEET-3/3]...
Page 141 1050V(p-p)(H) 123V 270V(p-p)(H) 32ZP38B DEF - HORIZONTAL-DEF [SHEET-1/2]...
Page 142 1050V(p-p)(H) 1050V(p-p)(H) 123V 270V(p-p)(H) 270V(p-p)(H)
Page 143 32ZP38B DEF - HORIZONTAL-DEF [SHEET-1/2]...
Page 144 50V(p-p)(V) -15.0 0.8 15.0 1.3V(p-p)(V) 32ZP38B DEF - VERTICAL-DEF [SHEET-2/2]...
Page 146 50V(p-p)(V) 50V(p-p)(V) -15.0 -15.0 0.8 15.0 15.0 1.3V(p-p)(V) 1.3V(p-p)(V) 32ZP38B DEF - VERTICAL-DEF [SHEET-2/2]...
Page 147 104Vp-p 102Vp-p 103Vp-p 11.5 11.5 11.5 122.7 122.3 64.3 32ZP38B CRT-D...
Page 148 11.5 11.5 11.5 11.5 11.5 11.5 122.7 122.7 122.3 122.3 64.3 64.3...
Page 149 104Vp-p 104Vp-p 102Vp-p 102Vp-p 103Vp-p 103Vp-p 32ZP38B CRT-D...
Page 150 36ZP38B 32ZP38B TEXT-P2...
Page 152 36ZP38B 32ZP38B TEXT-P2...
Page 153 36ZP38B 32ZP38B DIGITAL-IN...
Page 155 36ZP38B 32ZP38B DIGITAL-IN...
Page 156 36ZP38B 32ZP38B EXT-SP...
Page 158 36ZP38B 32ZP38B EXT-SP...
