Uputstvo za upotrebu (EN) DELL laptop Precision M5680 (NOT22421) Tehnoteka je online destinacija za upoređivanje cena i karakteristika bele tehnike, potrošačke elektronike i IT uređaja kod trgovinskih lanaca i internet prodavnica u Srbiji. Naša stranica vam omogućava da istražite najnovije informacije, detaljne karakteristike i konkurentne cene proizvoda.
Left......................................7 Top......................................8 Front....................................... 9 Bottom....................................10 Service Tag..................................10 Battery charge and status light ............................11 Chapter 2: Set up your Dell Precision 5680.................. 12 Chapter 3: Specifications of Dell Precision 5680................14 Dimensions and weight..............................14 Processor..................................... 14 Chipset....................................15 Operating system................................15 Memory....................................
Page 5
After working inside your computer........................32 BitLocker..................................32 Recommended tools................................. 32 Screw list.....................................33 Major components of Dell Precision 5680........................34 Chapter 5: Removing and installing Customer Replaceable Units (CRUs)........37 Secure Digital (SD) Card..............................37 Removing the SD card..............................37 Installing the SD card..............................38 Chapter 6: Removing and installing Field Replaceable Units (FRUs)..........
Page 6
Smart-card reader................................73 Removing the smart-card reader..........................73 Installing the smart-card reader..........................75 GPU card..................................... 77 Removing the GPU card............................77 Installing the GPU card.............................. 80 Dummy GPU card................................83 Removing the dummy GPU card..........................83 Installing the dummy GPU card..........................84 System board..................................86 Removing the system board.............................
Page 7
Clearing Chassis Intrusion Alerts..........................135 Chapter 9: Troubleshooting....................... 138 Handling swollen rechargeable Li-ion batteries......................138 Locate the Service Tag or Express Service Code of your Dell computer ..........138 Dell SupportAssist Pre-boot System Performance Check diagnostics.............. 139 Running the SupportAssist Pre-Boot System Performance Check.............. 139 Built-in self-test (BIST)..............................139...
Views of Dell Precision 5680 Right 1. SD-card slot 2. USB 3.2 Gen 2 Type-C port with DisplayPort 1.4 Alt Mode 3. Wedge-shaped lock slot Left 1. HDMI 2.0b port 2. 3.5 mm audio jack 3. Two Thunderbolt 4 (USB Type-C) ports 4.
1. Left and right microphones 2. Power button with fingerprint reader 3. NFC/Contactless smart card reader (optional) 4. Haptics Trackpad Views of Dell Precision 5680...
Bottom 1. Air vents 2. Service Tag location Service Tag The service tag is a unique alphanumeric identifier that allows Dell service technicians to identify the hardware components in your computer and access warranty information. Views of Dell Precision 5680...
Battery charge and status light The following table lists the battery charge and status light behavior of your Dell Precision 5680. Table 1. Battery charge and status light behavior Power Source LED Behavior System Power State Battery Charge Level AC Adapter...
Follow the on-screen instructions to complete the setup. For more information about installing and configuring Ubuntu, search in the Knowledge Base Resource at www.dell.com/support. For Windows: Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you: ● Connect to a network for Windows updates. NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when prompted.
Page 14
SupportAssist proactively checks the health of your system's hardware and software. When an issue is detected, the necessary system state information is sent to Dell to begin troubleshooting. SupportAssist is preinstalled on most of the Dell devices running Windows operating system.
Specifications of Dell Precision 5680 Dimensions and weight The following table lists the height, width, depth, and weight of your Dell Precision 5680. Table 3. Dimensions and weight Description Values Height: Front height 26.17 mm (1.03 in.) Rear height 26.17 mm (1.03 in.) Width 353.68 mm (13.92 in.)
Chipset The following table lists the details of the chipset supported by your Dell Precision 5680. Table 5. Chipset Description Values Chipset Intel PCH Processor Generation Intel Core i5/i7/i9 DRAM bus width 128-bit Flash EPROM 64 MB PCIe bus Up to Gen 4.0...
M.2 cards, search in the Knowledge Base Resource at www.dell.com/support. Wireless module The following table lists the Wireless Local Area Network (WLAN) module that is supported on your Dell Precision 5680. Table 9. Wireless module specifications Description Values...
The version of the Bluetooth wireless card may vary depending on the operating system that is installed on your computer. Audio The following table lists the audio specifications of your Dell Precision 5680. Table 10. Audio specifications Description Values Audio controller...
M.2 2280, Class 40 solid-state drive, PCIe NVMe Gen 4 Up to 1 TB Opal Self-Encrypting solid-state drive Media-card reader The following table lists the media cards supported by your Dell Precision 5680. Table 12. Media-card reader specifications Description Values Media-card type...
Camera The following table lists the camera specifications of your Dell Precision 5680. Table 14. Camera specifications Description Values Number of cameras Camera type FHD IR camera with narrow FHD+IR w/ XYZ ALS (MIPI), Dual- array microphones Camera location Front camera Camera sensor type Intel Camera Sensing Technology (ExpressSign-in 2.0)
Power adapter The following table lists the power adapter specifications of your Dell Precision 5680. Table 16. Power adapter specifications Description Option one Option two Type 100 W Pecos AC adapter, USB-C 165 W ERP AC adapter, USB-C Input voltage 100 VAC—240 VAC...
CAUTION: Dell recommends that you charge the battery regularly for optimal power consumption. If your battery charge is completely depleted, connect the power adapter, turn on your computer, and then restart your computer to reduce the power consumption.
6.32 W 11.14 W Anti-glare vs glossy finish Anti-glare Anti-smudge Fingerprint reader The following table lists the fingerprint-reader specifications of your Dell Precision 5680. NOTE: The fingerprint reader is located on the power button. Table 19. Fingerprint reader specifications Description Values...
The following table lists the sensor of your Dell Precision 5680. Table 20. Sensor Sensor support Accelerometer for adaptive thermal GPU—Integrated The following table lists the specifications of the integrated Graphics Processing Unit (GPU) supported by your Dell Precision 5680. Table 21. GPU—Integrated Controller Memory size...
Contactless Smart Card, NFC, and Control Vault 3 Statement of Non-Volatility Smart-card reader Contactless smart-card reader This section lists the contactless smart-card reader specifications of your Dell Precision 5680. Table 25. Contactless smart-card reader specifications Title Description Dell ControlVault 3 contactless...
Page 26
Circuit Card Interface Device for OS level drivers Windows Certified Device certified by Microsoft WHCK Dell ControlVault support Device connects to Dell ControlVault for usage and processing FIDO2 compliance Dell ControlVault 3 Smart-card reader is compliant with the FIDO SPEC NOTE: 125 Khz proximity cards are not supported.
This section details the Dell Optimizer specifications of your Dell Precision 5680. Dell Optimizer is a software application that intelligently optimizes the performance of your system by using artificial intelligence and machine learning. Dell Optimizer dynamically configures your system settings to optimize the performance of your applications.
You should only perform troubleshooting and repairs as authorized or directed by the Dell technical assistance team. Damage due to servicing that is not authorized by Dell is not covered by your warranty. See the safety instructions that is shipped with the product or at www.dell.com/regulatory_compliance.
Ensure that your computer is shut down and the AC adapter is disconnected. a. Hold <B> key on the keyboard and press the power button for 3 seconds or until the Dell logo appears on the screen. b. Press any key to continue.
Due to the increased density of semiconductors used in recent Dell products, the sensitivity to static damage is now higher than in previous Dell products. For this reason, some previously approved methods of handling parts are no longer applicable. Two recognized types of ESD damage are catastrophic and intermittent failures.
Transporting sensitive components When transporting ESD sensitive components such as replacement parts or parts to be returned to Dell, it is critical to place these parts in anti-static bags for safe transport.
● Plastic scribe Screw list NOTE: When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is restored when the component is replaced.
SD card reader daughterboard M1.4x1.2 FPC/USH and SD card reader daughterboard FPC WLAN antennas Captive screws Power button with fingerprint M1.6x2 reader Major components of Dell Precision 5680 The following image shows the major components of Dell Precision 5680. Working inside your computer...
Page 37
18. USH and SD card reader daughterboard NOTE: Dell provides a list of components and their part numbers for the original system configuration purchased. These parts are available according to warranty coverages purchased by the customer. Contact your Dell sales representative for purchase options.
Removing and installing Customer Replaceable Units (CRUs) The replaceable components in this chapter are Customer Replaceable Units (CRUs). CAUTION: Customers can replace only the Customer Replaceable Units (CRUs) following the safety precautions and replacement procedures. NOTE: The images in this document may differ from your computer depending on the configuration you ordered. Secure Digital (SD) Card Removing the SD card Prerequisites...
Steps 1. Push the SD card to eject it from the slot. 2. Remove the SD card from the computer. Installing the SD card Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task The following image provides a visual representation of the SD card installation procedure.
Page 40
Steps Insert the SD card into its slot until it click into place. Next steps 1. Follow the procedure in After working inside your computer. Removing and installing Customer Replaceable Units (CRUs)
To avoid any potential damage to the component or loss of data, ensure that an authorized service technician replaces the Field Replaceable Units (FRUs). CAUTION: Dell Technologies recommends that this set of repairs, if needed, to be conducted by trained technical repair specialists. CAUTION: As a reminder, your warranty does not cover damages that may occur during the courses of FRU repairs that are not authorized by Dell Technologies.
Page 42
Removing and installing Field Replaceable Units (FRUs)
Page 43
Steps 1. Remove the eight (M2x3) T5 Torx screws that secure the base cover to the computer. 2. Using a plastic scribe, pry open the base cover starting from the SD-card slot on the base cover. CAUTION: Do not fully insert the plastic scribe into the SD-card slot before prying. Only pry the edge of base cover nearest to the SD-card slot opening.
Installing the base cover Prerequisites If you are replacing a component, remove the necessary component before the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following images indicate the location and provide a visual representation of the base cover installation procedure. Removing and installing Field Replaceable Units (FRUs)
Page 45
Removing and installing Field Replaceable Units (FRUs)
Steps 1. Connect the battery FPC cable to the connector on the system board. 2. Tighten the two captive screws to secure the battery connector bracket in place. 3. Align and place the base cover on the palm-rest assembly, and snap the base cover into place. 4.
Steps 1. Remove the single (M2x2) screw that secures the solid-state drive thermal plate in place. 2. Remove the solid-state drive thermal plate from the system board. 3. Remove the M.2 2230 solid-state drive with the solid-state drive bracket from the system board. 4.
Page 48
NOTE: The following procedure is applicable for models shipped with an M.2 2230 solid-state drive in the SSD1 and/or SSD2 slot. Steps 1. Align the screw hole on the M.2 2230 solid-state drive with the screw hole on the solid-state drive bracket. 2.
Removing the M.2 2280 solid-state drive Prerequisites 1. Follow the procedure in Before working inside your computer. NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your computer. 2. Remove the card.
The following image indicates the location of the solid-state drive and provides a visual representation of the installation procedure. NOTE: The following procedure is applicable for models shipped with an M.2 2280 solid-state drive in the SSD1 and/or SSD2 slot. Steps 1.
About this task CAUTION: The information in this removal section is intended for authorized service technicians only. The following image indicates the location of the VPU card and provides a visual representation of the removal procedure. Steps 1. Remove the single (M2x2) screw that secures the VPU card thermal plate in place. 2.
Page 52
About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following image indicates the location of the VPU card and provides a visual representation of the installation procedure. NOTE: The following procedure is applicable for models shipped with a VPU card in the SSD2 slot only. Steps 1.
● If the battery gets stuck inside your computer as a result of swelling, do not try to release it as puncturing, bending, or crushing a rechargeable Li-ion battery can be dangerous. In such an instance, contact Dell technical support for assistance. See www.dell.com/contactdell.
Page 54
Steps 1. Remove the six (M2x4) screws that secure the battery to the plam-rest assembly. 2. Lift the battery away from the computer. 3. Peel off the battery FPC cable from the battery. 4. Disconnect and remove the battery FPC cable from the connector on the battery. NOTE: Pull the pull tab vertically to disconnect the battery FPC cable.
When system battery is disconnected or completely discharged, the system date and time will be reset. When the system is power on under this condition, it will take slightly more time before the Dell logo is displayed, followed by the Time-of-day not set message. Select BIOS-Setup in the caution screen to configure the date and time.
Page 56
Steps 1. Connect the battery FPC cable to the connector on the battery. 2. Adhere the battery FPC cable on the battery. 3. Align and place the battery into the slot on the chassis. 4. Replace the six (M2x4) screws to secure the battery to the plam-rest assembly. Next steps 1.
2. Install the card. 3. Follow the procedure in After working inside your computer. System fan Removing the left fan Prerequisites 1. Follow the procedure in Before working inside your computer. NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your computer.
About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following image indicates the location of the left fan and provides a visual representation of the installation procedure. Steps 1. Align and place the left-fan onto the palm-rest assembly. 2.
Steps 1. Disconnect the right-fan cable from the connector on the system board. 2. Remove the two (M2x4) screws that secure the right fan to the palm-rest assembly. 3. Lift the right fan from the outside and remove it from the palm-rest assembly. Installing the right fan Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure.
Steps 1. Align and place the right-fan onto the palm-rest assembly. 2. Replace the two (M2x4) screws to secure the right fan to the palm-rest assembly. 3. Connect the right fan cable to the connector on the system board. Next steps 1.
Page 61
Steps 1. For systems shipped with an integrated GPU card, loosen the three captive screws in descending order (3>2>1) that secure the heat sink to the system board. 2. For systems shipped with a discrete GPU card, loosen the seven captive screws in descending order (7>6>5>4>3>2>1) that secure the heat sink to the system board.
Installing the heat sink Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. NOTE: For models shipped with a heatsink labeled “VC” (Vapor Chamber), the heatsink covers the display cable: NOTE: Themal pads (thermal conductors) are on the heatsink.
Steps 1. Align the screw holes on the heat sink with the screw holes on the system board. 2. For systems shipped with an integrated GPU card, tighten the three captive screws in ascending order (1>2>3) to secure the heat sink to the system board. 3.
Page 64
Removing and installing Field Replaceable Units (FRUs)
Page 65
Steps 1. Remove the two (M1.4x4) T5 Torx screws that secure the display FPC cover in place. 2. Flip open the display FPC cover. 3. Remove the two (M1.4x4) T5 Torx screws that secure the display FPC cable in place. 4.
6. Remove the eight (M2.5x5) screws that secure the display assembly to the computer. 7. Slightly lift the bottom assembly and slide it to the left and away from the display assembly. Remove the display assembly from the computer. NOTE: The display assembly is a Hinge-Up Design (HUD) assembly and cannot be further disassembled once it is removed from the bottom chassis.
Page 67
Removing and installing Field Replaceable Units (FRUs)
Page 68
Steps 1. Align and place the bottom assembly under the hinges of the display assembly. 2. Replace the eight (M2.5x5) screws to secure the display assembly to the computer. 3. Align and place the interposer board on the computer. CAUTION: The pins on the interposer board are very fragile.
NOTE: Tuck the display FPC into the gap between the system board and the palm-rest before connecting the display FPC to the system board. 5. Replace the two (M1.4x4) T5 Torx screws to secure the display FPC cable in place. 6.
Steps 1. Remove the two (M1.6x1.8) screws that secure the right speaker in place. 2. Slightly lift the right speaker from the palm-rest assembly. CAUTION: Do not completely remove the right speaker, as it is still attached to the tweeter underneath the system board.
Steps 1. Align and place the SD-card reader daugherboard into the slot on the palm-rest assembly. 2. Replace the three (M2x1.5) screws to secure the SD-card reader daugherboard to the palm-rest assembly. 3. Connect the SD-card reader daugherboard FFC cable to the connector on the SD card reader daugherboard. 4.
Page 72
2. Remove the card. 3. Remove the base cover. 4. Remove the battery. About this task CAUTION: The information in this removal section is intended for authorized service technicians only. NOTE: The following procedure is applicable for computers shipped with a USH module only. The following images indicate the location of the USH and SD-card reader daughterboard and provide a visual representation of the removal procedure.
Installing the USH and SD-card reader daughterboard Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. NOTE: The following procedure is applicable for computer shipped with a USH module only.
Next steps 1. Install the battery. 2. Install the base cover. 3. Install the card. 4. Follow the procedure in After working inside your computer. Smart-card reader Removing the smart-card reader Prerequisites 1. Follow the procedure in Before working inside your computer.
Page 75
Steps 1. Remove the two (M1.6x1.8) screws that secure the left speaker in place. 2. Slightly lift the left speaker from the chassis. CAUTION: Do not completely remove the left speaker, as it is still attached to the tweeter underneath the system board.
5. Remove the two (M1.6x1.7) screws that secure the smart-card reader in place. 6. Lift and remove the smart-card reader with the smart-card reader FFC from the chassis. Installing the smart-card reader Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only.
Page 77
Steps 1. Align and place the smart-card reader with the smart-card reader FFC into the slot on the chassis. 2. Replace the two (M1.6x1.7) screws to secure the smart-card reader to the chassis. 3. Adhere the smart-card reader FFC on the palm-rest assembly. 4.
Next steps 1. Install the Battery. 2. Install the base cover. 3. Install the card. 4. Follow the procedure in After working inside your computer. GPU card Removing the GPU card Prerequisites 1. Follow the procedure in Before working inside your computer.
Page 79
Removing and installing Field Replaceable Units (FRUs)
Page 80
Steps 1. Remove the four (M1.4x4) T5 Torx screws sequentially as mentioned on the GPU card FPC that secure the GPU card FPC in place. 2. Remove the GPU card FPC from the system board. 3. Remove the two GPU card FPC interposer boards from the system board. NOTE: The pins on the interposer board are very fragile.
NOTE: 4. Remove the four (M1.6x4.5) screws that secure the GPU card bridge in place. 5. Remove the GPU card bridge from the system board. 6. Remove the two (M2x4) screws that secure the PC bridge bracket in place. 7. Remove the PC bridge bracket from the system board. 8.
Page 82
Removing and installing Field Replaceable Units (FRUs)
Page 83
Steps 1. Align and place the GPU card into the slot on the system board. 2. Replace the two (M2x4) screws to secure the GPU card in place. 3. Align and place the PC bridge bracket into the slot on the system board. 4.
Dummy GPU card Removing the dummy GPU card Prerequisites 1. Follow the procedure in Before working inside your computer. NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your computer. 2.
Steps 1. Remove the two (M2x4) screws that secure the PC bridge bracket in place. 2. Remove the PC bridge bracket from the system board. 3. Remove the two (M2x4) screws that secure the dummy GPU card in place. 4. Remove the dummy GPU card from the system board. Installing the dummy GPU card Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure.
Page 86
About this task NOTE: The following procedure is applicable for systems shipped with an integrated system board only. The following image indicates the location of the GPU card and provides a visual representation of the installation procedure. Steps 1. Align and place the dummy GPU card into the slot on the system board. 2.
Next steps 1. Install the heatsink. 2. Install the Battery. 3. Install the base cover. 4. Install the card. 5. Follow the procedure in After working inside your computer. System board Removing the system board Prerequisites 1. Follow the procedure in Before working inside your computer.
Page 89
1. Touchpad cable connector 2. USH I/O board cable connector The following images indicate the location of the system board assembly and provide a visual representation of the removal procedure. Removing and installing Field Replaceable Units (FRUs)
Page 90
Removing and installing Field Replaceable Units (FRUs)
Page 91
Steps 1. For systems shipped with a GPU card, remove the four (M1.4x4) T5 Torx screws that secure the GPU card FPC in place. 2. For systems shipped with a GPU card, remove the GPU card FPC from the system board. 3.
Page 92
15. For systems shipped without a USH module, disconnect the SD-card reader daughterboard FPC cable from the connector on the SD-card reader daughterboard. 16. For systems shipped with a USH module, disconnect the USH and SD-card reader daughterboard FPC cable from the connector on the USH and SD-card reader daughterboard.
Installing the system board Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following image indicates the location of the system board and provides a visual representation of the installation procedure. NOTE: Replacement of the system board requires further removal of the touchpad FPC and SD Card reader daughter board FPC/USH and SD Card reader daughter board FPC.
Page 95
1. Touchpad cable connector 2. USH I/O board cable connector Removing and installing Field Replaceable Units (FRUs)
Page 96
Removing and installing Field Replaceable Units (FRUs)
Page 97
Steps 1. Align and place the system board on the palm-rest assembly. 2. Replace the nine (M2x4) screws to secure the system board to the palm-rest assembly. 3. Align and place the PC bridge support bracket on the system board. 4.
14. Replace the two (M1.4x4) screws to secure the display FPC cover in place. 15. For systems shipped with a WLAN card, route the antenna cables through the metal clips on the system board. 16. For systems shipped with a WLAN card, connect the antenna cables to the connectors on the WLAN module. 17.
Steps 1. Remove the left and right tweeter speakers from their slots on the computer. 2. Unroute the left and right tweeter speaker cables from the routing guides on the system board. 3. Remove the four (M1.6x1.8) screws that secure the left and right speakers in place. 4.
Page 100
The following image indicates the location of the speakers and provides a visual representation of the installation procedure. Steps 1. Align and place the left and right speakers into the slot on the computer. 2. Route the left and right tweeter speaker cables through the routing guides on the system board. 3.
9. Install the card. 10. Follow the procedure in After working inside your computer. Haptics trackpad FPC Removing the touchpad FPC CAUTION: The information in this section is intended for authorized service technicians only. Prerequisites 1. Follow the procedure in Before working inside your computer.
Page 102
Steps 1. Remove the two screws (M1.4x1.2) that secure the touchpad FPC to the system board. 2. Disconnect and remove the touchpad FPC from the system board. Removing and installing Field Replaceable Units (FRUs)
Installing the touchpad FPC Prerequisites If you are replacing a component, remove the existing component before performing the installation process. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following images indicate the location of the touchpad FPC and provide a visual representation of the installation procedure. Removing and installing Field Replaceable Units (FRUs)
Page 104
Steps 1. Align and place the touchpad FPC into its slot on the system board. 2. Replace the two (M1.4x1.2) screws that secure the touchpad FPC to the system board. 3. Connect the touchpad FPC to the connector on the system board. Next steps 1.
3. Install the right fan. 4. Install the left fan. 5. Install the Battery. 6. Install the card, for systems shipped with a VPU card. 7. Install the M.2 solid-state drive, for systems shipped with a solid-state drive. 8. Install the base cover.
Steps 1. Remove the two (M1.4X1.2) screws that secure the SD card reader daughterboard FPC in place. 2. Disconnect and remove the SD card reader daughterboard FFC cable from the connector on the system board. Installing the SD card reader daughterboard FPC Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure.
Steps 1. Align and place the SD card reader daugherboard FPC in place. 2. Replace the two (M1.4x1.2) screws to secure the SD card reader daugherboard FPC in place. 3. Connect the SD card reader daugherboard FFC cable to the connector on the system board. Next steps 1.
Page 108
NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your computer. 2. Remove the card. 3. Remove the base cover. 4. Remove the M.2 solid-state drive, for systems shipped with a solid-state drive. 5.
Installing the USH and SD card reader daughterboard FPC Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following image indicates the location of the USH and SD card reader daughterboard FPC and provides a visual representation of the installation procedure.
7. Install the M.2 solid-state drive, for systems shipped with a solid-state drive. 8. Install the base cover. 9. Install the card. 10. Follow the procedure in After working inside your computer. Wireless Local Area Network (WLAN) Antennas Removing the WLAN antenna module Prerequisites 1.
Page 111
Steps 1. Remove the left and right tweeter speakers from their slots on the chassis. 2. Peel off the tape that secures the WLAN antenna cables to the palm-rest assembly. 3. Unroute the WLAN antenna cables from the routing guides on the palm-rest assembly. 4.
Installing the WLAN antenna module Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following image indicates the location of the WLAN antenna module and provides a visual representation of the installation procedure.
Page 113
Steps 1. Align and place the WLAN antennas in the slot on the system. 2. Route the WLAN antenna cables through the routing guides on the palm-rest assembly. 3. Replace the four captive screws to secure the WLAN antenna cables to the palm-rest assembly. 4.
Next steps 1. Install the system board. 2. Install the heatsink. 3. Install the right fan. 4. Install the left fan. 5. Install the Battery. 6. Install the card, for systems shipped with a VPU card. 7. Install the M.2 solid-state drive, for systems shipped with a solid-state drive.
Steps 1. Remove the three (M1.6x2) screws that secure the power button with fingerprint reader bracket in place. 2. Lift the power button with fingerprint reader bracket off the system. 3. Peel off and remove the power button with fingerprint reader assembly from the palm-rest assembly. Installing the power button with fingerprint reader assembly Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure.
Page 116
Steps 1. Align, place, and adhere the power button with fingerprint reader assembly on the palm-rest assembly. 2. Place the power button with fingerprint reader bracket on the power button assembly. 3. Replace the three (M1.6x2) screws to secure the power button bracket in place. Next steps 1.
Palm-rest assembly Removing the palm-rest assembly Prerequisites 1. Follow the procedure in Before working inside your computer. NOTE: Ensure that your computer is in Service Mode. For more information see, step 6 in Before working inside your computer. 2. Remove the card.
Installing the palm-rest assembly Prerequisites If you are replacing a component, remove the existing component before performing the installation procedure. About this task CAUTION: The information in this installation section is intended for authorized service technicians only. The following images indicate the location of the palm-rest assembly and provide a visual representation of the removal procedure.
Page 119
Steps Place the palm-rest assembly on a flat surface. Next steps 1. Install the power button with fingerprint reader. 2. Install the WLAN antennas. 3. Install the speakers. 4. Install the system board. 5. Install the GPU card dummy GPU card.
● Windows 11 Pro for Education, 64-bit ● Windows 11 Enterprise, 64-bit ● Ubuntu 22.04 LTS, 64-bit Drivers and downloads When troubleshooting, downloading or installing drivers it is recommended that you read the Dell Knowledge Base article, Drivers and Downloads FAQs 000123347. Software...
BIOS Setup CAUTION: Unless you are an expert computer user, do not change the settings in the BIOS Setup. Certain changes can make your computer work incorrectly. NOTE: Depending on the computer and its installed devices, the items listed in this section may or may not be displayed. NOTE: Before you change the settings in BIOS Setup, it is recommended that you note down the original settings for future reference.
Depending on this computer and its installed devices, the items that are listed in this section may or may not be displayed. Table 32. System setup options—System information menu Overview for Dell Precision 5680 BIOS Version Displays the BIOS version number.
Page 123
Table 32. System setup options—System information menu (continued) Overview for Dell Precision 5680 Microcode Version Displays the microcode version. Intel Hyper-Threading Capable Displays whether the processor is Hyper-Threading (HT) capable. 64-Bit Technology Displays whether 64-bit technology is used. MEMORY Memory Installed Displays the total computer memory installed.
Page 124
By default, Enable USB Boot Support is selected. By default, Enable External USB Ports is selected. Type-C Dock Override Enables to use connected Type-C Dell Dock to provide data stream with external USB ports disabled. When Type-C Dock override is enabled, the Video/Audio/Lan submenu is activated.
Page 125
Table 35. System setup options—Storage menu Storage SATA Operation Configures operating mode of the integrated SATA hard drive controller. Default: RAID On. SATA is configured to support RAID (Intel Rapid Restore Technology). Storage Interface Displays the storage interface. Drive Information Displays the information of various onboard drives.
Page 126
By default, Optimized is selected. USB Wake Support Wake on Dell USB-C Dock Enables connecting a Dell USB-C Dock to wake the computer from Standby, Hibernate, or Power off. Default: ON Block Sleep Blocks the computer from entering Sleep (S3) mode in the operating system.
Page 127
Table 38. System setup options—Power menu (continued) Power Intel Speed Shift Technology Enables or disables the Intel Speed Shift Technology support. Setting this option to enable allows the operating system to select the appropriate processor performance automatically. Default: ON Table 39. System setup options—Security menu Security TPM 2.0 Security On Select whether or not the Trusted Platform Model (TPM) is visible to the OS.
Page 128
Table 39. System setup options—Security menu (continued) Security UEFI Boot Path Security Controls whether the system will prompt the user to enter the admin password (if set) when booting to a UEFI boot path device from the F12 boot menu. By default, Always Except Internal HDD is selected. Firmware Device Tamper Detection By default, the Silent option is enabled.
Page 129
Auto OS Recovery Threshold setup option. Default: ON Dell Auto OS Recovery Threshold Controls the automatic boot flow for SupportAssist System Resolution Console and for Dell operating system Recovery tool. By default, 2 is selected. Table 42. System setup options—System Management menu System Management Service Tag Displays the Service Tag of the computer.
Page 130
Table 42. System setup options—System Management menu (continued) System Management Wake on LAN/WLAN Wake on LAN/WLAN Enables or disables the computer to turn on by a special LAN/WLAN signal. By default, Disabled is selected. Auto on Time Enable to set the computer to turn on automatically every day or on a preselected date and time.
Page 131
Table 44. System setup options—Pre-Boot Behavior menu (continued) Pre-Boot Behavior Default: ON Warnings and Errors Warnings and Errors Selects an action on encountering a warning or error during boot. By default, Prompt on Warnings and Errors is selected. NOTE: Errors deemed critical to the operation of the computer hardware will always halt the computer.
Page 132
Table 45. System setup options—Virtualization menu (continued) Virtualization DMA Protection Enable Pre-Boot DMA Support By default, the option is enabled. Enable OS Kernel DMA Support By default, the option is enabled. Table 46. System setup options—Performance menu Performance Multi-Core Support Active Cores Changes the number of CPU cores available to the operating system.
Updating the BIOS in Windows to download the latest BIOS setup program file. 2. Create a bootable USB drive. For more information, search in the Knowledge Base Resource at www.dell.com/support. 3. Copy the BIOS setup program file to the bootable USB drive.
One-Time boot menu on the computer. Most of the Dell computers built after 2012 have this capability, and you can confirm by booting your computer to the F12 One-Time Boot Menu to see if BIOS FLASH UPDATE is listed as a boot option for your computer. If the option is listed, then the BIOS supports this BIOS update option.
System and setup password Table 48. System and setup password Password type Description System password Password that you must enter to log in to your system. Setup password Password that you must enter to access and make changes to the BIOS settings of your computer. You can create a system password and a setup password to secure your computer.
Clearing BIOS (System Setup) and System passwords About this task To clear the system or BIOS passwords, contact Dell technical support as described at www.dell.com/contactdell. NOTE: For information on how to reset Windows or application passwords, refer to the documentation accompanying Windows or your application.
Page 137
● If Block Boot Until Cleared is set to OFF, select Continue to boot up normally or BIOS-Setup to clear the alert. NOTE: If Continue is selected, the user will continue to see the alert each time the system is powered on until the alert is cleared.
● Using a non-Dell or incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased from Dell that is designed to work with your Dell computer. Do not use a battery from other computers with your computer.
Check diagnostics About this task SupportAssist diagnostics (also known as system diagnostics) performs a complete check of your hardware. The Dell SupportAssist Pre-boot System Performance Check diagnostics is embedded with the BIOS and is launched by the BIOS internally. The embedded system diagnostics provides a set of options for particular devices or device groups allowing you to: ●...
LCD Built-in Self Test (BIST) Dell laptops have a built-in diagnostic tool that helps you determine if the screen abnormality you are experiencing is an inherent problem with the LCD (screen) of the Dell laptop or with the video card (GPU) and PC settings.
System diagnostic lights Battery-status light Indicates the power and battery-charge status. Solid white—Power adapter is connected and the battery has more than 5 percent charge. Amber—Computer is running on battery and the battery has less than 5 percent charge. ● Power adapter is connected, and the battery is fully charged. ●...
It enables you to diagnose hardware issues, repair your computer, back up your files, or restore your computer to its factory state. You can also download it from the Dell Support website to troubleshoot and fix your computer when it fails to boot into their primary operating system due to software or hardware failures.
Page 144
6. Install the battery. 7. Install the base cover. 8. Connect the power adapter to your computer. 9. Turn on your computer. NOTE: For more information about performing a hard reset, search in the Knowledge Base Resource at www.dell.com/ support. Troubleshooting...
Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 51. Self-help resources Self-help resources Resource location Information about Dell products and services www.dell.com My Dell app...
Page 146
