OPERATING AND MAINTENANCE INSTRUCTIONS
POWER
SWITCH
PREPARATION
•
CHECK DRAIN PLUG IS PUSHED FIRMLY IN PLACE AND FILTERS ARE PROPERLY SECURED WITH THE FILTER NUT.
•
CHECK DETERGENT ( RED ) AND RINSE AID ( CLEAR ) SUPPLY TUBES, WITH FOOT VALVES - ARE
SUBMERGED IN SUFFICIENT PRODUCT.
•
CHECK THE DOOR IS CLOSED AND PRESS THE POWER SWITCH - THE POWER GREEN LAMP WILL COME ON.
•
ALLOW 20 MINUTES FOR THE MACHINE TO REACH THE CORRECT WASHING TEMPERATURE.
OPERATION
•
REMOVE ALL DEBRIS FROM THE GLASSES TO BE WASHED, BEFORE PLACING THEM INTO THE BASKET.
•
CLOSE THE DOOR, PRESS THE CYCLE SWITCH - THE CYCLE LAMP WILL COME ON.
•
AT THE END OF THE CYCLE THE CYCLE LAMP WILL GO OUT.
•
IF REQUIRED USE THE COLD RINSE SWITCH TO COOL DOWN THE GLASSES FOR IMMEDIATE SERVICE.
•
OPEN THE DOOR AND PULL OUT THE BASKET, ALLOW EXCESS WATER TO RUN OFF BEFORE REMOVING.
ROUTINE MAINTENANCE
•
AT THE END OF A SESSION TURN OFF THE POWER SWITCH - DO NOT REMOVE ANY FILTERS AT THIS STAGE.
•
REMOVE THE DRAIN PLUG - THE WASH TANK WILL EMPTY.
•
IF YOUR MACHINE IS FITTED WITH A WASTE PUMP - TURN OFF THE POWER SWITCH AND REMOVE THE
DRAIN PLUG - THEN PRESS AND HOLD THE WASTE PUMP SWITCH UNTIL THE WASH TANK IS EMPTY.
•
CLEAN AROUND THE WASH TANK, DOOR SURROUNDS AND HINGES WITH AN 'ADDIS'' TYPE WASHING UP BRUSH.
•
COLLECT THE DEBRIS AND REMOVE FROM THE WASH TANK.
•
UNSCREW THE FILTER NUT - TAKE OUT THE FILTER - CLEAN THOROUGHLY AND REPLACE - SECURING WITH THE
FILTER NUT.
•
DO NOT ALLOW DEBRIS TO GO DOWN THE OUTLET HOLES AS THIS MAY DAMAGE YOUR MACHINE.
•
REGULARLY CHECK RINSE JETS AND WASH JETS ARE CLEAR OF DEBRIS OR LIME SCALE - REMOVE IF NECESSARY BY
UNSCREWING THE RINSE ARM NUT - REMOVE WASH ARM CLEANING CAPS - CLEAN THOROUGHLY AND REASSEMBLE.
•
YOUR WATER SOFTENER ( IF FITTED ) SHOULD BE REGENERATED ONCE A WEEK OR ACCORDING TO INSTRUCTIONS.
RINSE ARM NUT
RINSE JETS
SERVICE CALLS TO RECTIFY FAULTS CAUSED BY `THE LACK OF ROUTINE MAINTENANCE` WILL BE CHARGED FOR
SERVICE TEL.
CYCLE
SWITCH
WASH JETS
CLEANING CAP
AND YOUR WARRANTY MAY BE AFFECTED
DC35
(OPTIONAL)
WASTE PUMP SWITCH
FOOT VALVES
FILTER (OPTIONAL)
FOR WASTE PUMP
MACHINES ONLY
directcateringproducts.co.uk
COLD RINSE BOILER READY
SWITCH LAMP
DRAIN PLUG
FILTER NUT
FILTER
OUTLET HOLES
