- Page 1 FLEXIDOME IP micro 3000i ‑ outdoor | FLEXIDOME IP turret 3000i IR ‑ outdoor NDE‑3502‑F02 | NDE‑3502‑F03 | NDE‑3503‑F02 | NDE‑3503‑F03 | NTE‑3502‑F02L | NTE‑3502‑F03L | NTE‑3503‑F02L | NTE‑3503‑F03L User manual...
-
Page 3: Table Of Contents
Encoder Profile 4.4.6 Encoder Streams 4.4.7 Encoder Statistics 4.4.8 Encoder Regions 4.4.9 Privacy Masks 4.4.10 Audio 4.4.11 Pixel Counter Recording 4.5.1 Storage Management 4.5.2 Recording Profiles 4.5.3 Maximum Retention Time Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... - Page 4 4.7.3 Advanced 4.7.4 Network Management 4.7.5 Multicast 4.7.6 IPv4 filter Service 4.8.1 Maintenance 4.8.2 Licenses 4.8.3 Certificates 4.8.4 Logging 4.8.5 System Overview Troubleshooting Physical reset button Appendices Copyright notices 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual...
-
Page 5: Browser Connection
If you cannot connect, the unit may have reached its maximum number of connections. Depending on the device and network configuration, each unit can have up to 50 web browser connections, or up to 100 connections via Bosch Video Client or BVMS. Password protection in the device The device is password protected across various authorization levels. -
Page 6: Password Network
To configure the unit, connect it directly to a computer using a network cable and configure the two parameters, Identity and Password. Only after these have been configured can communication with the unit via the network occur. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 7: System Overview
Dashboard Click this icon to see detailed system information. Links Click this icon to navigate to the Bosch download store. Logout Click this icon to log out of the device. Click this icon to get context-sensitive help for the page you are browsing. -
Page 8: Dashboard
The Dashboard is only visible in the application bar if the Show 'Dashboard' option is enabled by a service-level user in the Configuration -> Web Interface -> Appearance page. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 9: Operation Via The Browser
The alarm output allows the operation of an external device (for example, a light or a door opener). – To activate the output, click the checkmark symbol. – The symbol lights when the output is activated. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... - Page 10 – if the CPU load is too big, change the VCA settings, – if the network load is too big, change the encoder profile to reduce bitrate. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual...
-
Page 11: Playback Page
On the left side of the browser, expand the Connection group if necessary. To view a recording stream: Click the Recording arrow to see the options. Select recording stream 1 or 2. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 12: Searching For Recorded Video
The Dashboard page shows information on 4 topics: – Device status – Recording status – Connection Status – Services You can also download a .JSON file with information about the device: 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 13 IP turret 3000i IR - outdoor At the bottom of the page, locate the Export button Click the Export button Select a location in your hard drive to store the file Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 14: Configuration
Certificate. A check mark in this check box indicates that at least one certificate is loaded onto the device. The Trusted certificate is a root certificate for Bosch Security Systems that proves that the device meets the following criteria: 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. -
Page 15: Date/Time
It originates from a Bosch factory that is a secure environment. – It has not been tampered with. The Trusted certificate is issued by Escrypt. Escrypt is a Bosch company and Certificate Authority (CA). – Active Directory server (AD FS). A check mark in this check box indicates that the device uses an active directory server. -
Page 16: Display Stamping
To place a logo on the image, select and upload an uncompressed .bmp file with a maximum size of 300x300 pixels and 256 colors to the camera. Its position on the image can then be selected. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 17 (live or saved) has been manipulated. If you want to add a digital signature to the transmitted video images to ensure their integrity, select one of the cryptographic algorithms for this signature. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 18: Gb/T 28181
To use the original graphics, delete the entries in the Company logo and Device logo fields. Website language Select the language for the user interface. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 19 Low delay: Default mode. Provides marginal buffering to display fluent video under normal network conditions. – Smooth video: Allows the buffer to automatically adjust to cover network jitter, inducing higher latency. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 20: Live' Functions
Video sequences can only be saved locally on your hard disk if this icon is visible. I-frames-only stream When this checkbox is enabled, the I-frames stream option on the Connection tab of the Live page becomes available. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 21: Connectivity
Click Set to apply the changes. Connectivity 4.3.1 Cloud services Bosch Remote Portal Operation The operation mode determines how the camera communicates with the Bosch Remote Portal. – Select On to poll the server constantly. – Select Off to block polling. -
Page 22: Dyndns
Adjust this setting as necessary. Image rotation Select the required angle (0°, 90°, 180° or 270°) to output the correct image orientation. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 23 The flatter the tilt angle is set, the less accurate the estimate of object sizes and speeds will be. The settings must be between 0° and 90°. Estimates are no longer possible when you have reached 0°. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
- Page 24 A line on ground corresponds to a line that is on the ground plane, such as a road marking. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual...
- Page 25 Latitude is the north-south position of the camera in the spherical coordinate system WGS 84. Longitude Longitude is the east-west position of the camera in the spherical coordinate system WGS 84. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 26: Color
In Manual RGB white balance mode, adjust the blue gain slider to offset the factory white point alignment (reducing blue introduces more yellow). Note: It is only necessary to change the white point offset for special scene conditions. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 27: Alc
Off: the IR illumination is always off. Intensity level (Only applicable to FLEXIDOME IP turret 3000i IR - outdoor) Set the intensity of the IR beam (0 to 30). Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 28: Enhance
Enable or disable the automatic adjustment of the encoder. Priority encoder stream Select stream 1, 2 or Auto as the priority stream for the encoder. Auto automatically selects the optimal stream. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 29: Encoder Profile
Allow enhanced prediction This function allows for multiple references in H.264 and H.265 streams, which can reduce bitrate. Some decoders do not support this feature and therefore can be disabled. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 30: Encoder Streams
Profile 3 For a high resolution image, the video bit rate and frame quality are adjusted to ensure that the bit rate is the priority. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 31: Encoder Statistics
If required, select another region and repeat the steps. To remove a region, select the area and click the waste bin icon. Click Set to apply the region settings. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 32: Privacy Masks
The number of horizontal and vertical pixels covered by the highlighted area is displayed below the picture. With these values you can check whether the requirements for specific functions, for example, identification tasks, are fulfilled. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 33: Recording
Note: SD card recording performance is highly dependent on the speed (class) and performance of the SD card. It is recommended to use an industrial SD card with health monitoring. Local storage Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 34: Recording Profiles
– If you change a profile’s settings, click Set to save. – If necessary, click Default to return all settings to their factory defaults. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 35 Select an account from the drop-down box to export to an account. If an account has not yet been defined, click Configure accounts to jump to the Accounts page where the server information can be entered. Click Set to apply the changes. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 36: Maximum Retention Time
Click Start to activate the recording schedule. Click Stop to deactivate the recording schedule. Recordings that are currently running are interrupted and the configuration can be modified. Click Set to apply the changes. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 37: Recording Status
Configure accounts to do so. Click Set to apply the changes. 4.5.8 SD Card Status This section identifies the details about the SD card installed in the device: – Manufacturer Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 38: Alarm
If the unit is operated behind a firewall, select TCP (HTTP port) as the transfer protocol. For use in a local network, select UDP. To enable multicast operation, select UDP for the Video transmission parameter here and on the Network Access page. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 39: Video Content Analysis (Vca)
If there is not enough computing power, priority is given to live images and recordings. This can lead to impairment of the VCA system. Observe the processor load and optimize the encoder settings or the VCA settings if necessary, or turn off VCA completely. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... - Page 40 Setting up VCA Notice! You should configure VCA using the Bosch Configuration Manager application. If you do not have the application, download it by clicking Links in the application bar. You can also configure VCA in a browser with MPEG-ActiveX installed and by disabling Secure cookies in Web Interface ->...
- Page 41 Appearing edges Select this option if the selected area of the reference image includes a largely homogenous surface. If structures appear in this area, then an alarm is triggered. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
- Page 42 To delete a user-defined holiday, click on the trashcan of the respective holiday. Event triggered This configuration allows you to stipulate that the video content analysis is only to be activated when triggered by an event. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual...
-
Page 43: Audio Alarm
This makes it possible to notify a recipient who does not have a video receiver. Send alarm e-mail Select On for the device to automatically send an alarm e‑mail in the event of an alarm. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 44: Alarm Inputs
A supervised alarm transmits both the alarm condition and the tamper condition. Depending on how the alarm is configured, a short or a break in the alarm’s circuit can trigger the tamper signal. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 45: Alarm Outputs
When finished, click Set to transmit the scripts to the device. If the transfer was successful, the message Script successfully parsed. is displayed over the text field. If it was not successful, an error message is displayed with further information. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 46: Network
Internet connection to the camera, it is sufficient to enter the name given to the device on the DNS server as a URL in the browser. Enter the DNS server's IP address. Servers are supported for secure and dynamic DNS. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 47 Set the maximum segment size for the IP packet's user data here. This gives the option to adjust the size of the data packets to the network environment and to optimize data transmission. In UDP mode, comply with the MTU value set below. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 48: Advanced
The unit supports SNMP MIB II in the unified code. Select either of the options that follow for the SNMP parameter: – SNMP v1 legacy – SNMP v3 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... - Page 49 Consult with your network administrator for assistance configuring the Audio, Video, Control, and the Alarm video settings, and to select the appropriate Post-alarm time. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual...
-
Page 50: Multicast
You can enable multicast audio for different encoders here. The configuration follows the same pattern as for video multicast, but without the streaming option. Define a multicast address and define a port for the different encoders. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 51: Ipv4 Filter
Reconnecting in ... seconds. When the upload is completed successfully, the device reboots automatically. Upload history Click Show to view the firmware upload history. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 52: Licenses
In the Add certificate window choose either: – Upload certificate to select a file that is already available: – Click Browse to navigate to the required file. – Click Upload. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 53: Logging
This window is for information only and cannot be modified. Keep this information at hand when seeking technical support. Select the text on this page with a mouse and copy it so that it can be pasted into an e-mail if required. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... -
Page 54: Troubleshooting
For FLEXIDOME IP turret 3000i IR - outdoor, the reset button is in a slot in the back of the camera module. To access the reset button, remove the cover. 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual... -
Page 55: Appendices
This software is based in part on the work of the Independent JPEG Group. Stratocast is a trademark of Genetec, Inc. Dropbox is a trademark of Dropbox, Inc. Bosch Security Systems B.V. 2020-12 | V01 | F.01U.385.759 User manual... - Page 56 FLEXIDOME IP micro 3000i - outdoor | FLEXIDOME | Appendices IP turret 3000i IR - outdoor 2020-12 | V01 | F.01U.385.759 Bosch Security Systems B.V. User manual...
- Page 58 Bosch Security Systems B.V. Torenallee 49 5617 BA Eindhoven Netherlands www.boschsecurity.com © Bosch Security Systems B.V., 2020 202012091737...
