Safety Definitions WARNING This indicates that death or serious injuries may occur as a result of non-observance of this warning. CAUTION This indicates that minor or moderate injuries may occur as a result of non-observance of this warning. NOTICE This indicates that damage to the appliance or property may occur as a result of non-compliance with this advisory. -
Page 4: Safety Instructions
Important Safety Instructions: Please READ and SAVE this information To avoid possible injury or property damage, OBSERVE ALL WARNINGS AND CAUTIONS. WARNING: These instructions are intended for use by qualified installers only. The dishwasher must be installed by a qualified service technician or installer. •... -
Page 5: Avoiding General Hazards
WARNING Avoiding General Hazards To reduce the risk of electric shock, fire, or injury to persons, the installer must ensure that the dishwasher is completely enclosed at the time of installation. Do not use the dishwasher until it is completely installed. When opening the door on an uninstalled dishwasher, carefully open the door while supporting the rear of the unit. -
Page 6: Tools & Materials
Tools and Materials Needed ø1/16 in (2 mm) Tape Measure Hole Saw Drill Adjustable Wrench (x2) Pliers Wire Cutter Wire Stripper Needle Nose Pliers Level Phillips Screwdriver Flat Screwdriver Elbow connection with 3/4” female hose threads on one end and fits your water supply line (copper tubing, compression fitting, or braided hose) on the other. - Page 7 Materials Supplied Vapor Barrier (included with some models) Power Cord Screw Clamp (for drain hose) Mounting Brackets Mounting Bracket Screws Ø 4x13 mm Adhesive Backed Cord Clip For fully integrated models only: Installation Guide for Fully Integrated Door Panel...
- Page 8 Toe Panel Kits (Model Dependent; your dishwasher is supplied with one of the toe panel kits shown below) Slotted Toe Panel 2 - Screws Ø 4x16 mm Non-Slotted Toe Panel 2- Screws Ø 4.2x12.7 mm Toe Panel Mounting Brackets (used with non- slotted toe panel shown above) 2 - Screws Ø...
-
Page 9: Enclosure Requirements
Enclosure Requirements WARNING To Avoid Scalding or Electrical Shock Hazard! Make sure the water supply and electrical supply are shut off before installation or service. To Avoid Electrical Shock/Fire Hazard! Do not allow the electrical and supply lines to touch. min 24"... - Page 10 7" (177.8 mm) • After locating the proper place for your dishwasher, create required openings in your cabinets in order to allow for water, drain and electrical lines on the appropriate side. • The holes should be cut within the 7 x 2.5" area shown. •...
- Page 11 • Certain dishwasher models include a plastic protective barrier. If the dishwasher came with this part, remove it from the back of the unit. • Clean and dry the underside of the counter where the dishwasher will be installed. • Peel off half of the backing and stick the barrier in place.
- Page 12 • Pull the drain hose out of the packaging base as shown. • Set toe panel aside for later use. • Attach elbow joint to dishwasher as shown. Do not overtighten. • Attach hot water line to elbow. Use two wrenches to tighten to avoid putting stress on the water inlet valve.
- Page 13 WARNING DO NOT tip the dishwasher too far forward! This could cause serious injury or death. Always have an adult hold the front side if the unit is tipped. NOTICE Avoid cross-threading! It will cause leaks. After attaching hose, temporarily hook up the water supply then turn on water to check for leaks.
-
Page 14: Electrial Connections
Electrical Connection WARNING Avoid Electrical Shock Hazard! Do not work on an energized circuit. Doing so could result in serious injury or death. Only qualified electricians should perform electrical work. Do not attempt any work on the dishwasher electric supply circuit until you are certain the circuit is de- energized. - Page 15 Electrical Supply The customer has the responsibility of ensuring that the dishwasher electri- cal installation is in compliance with all national and local electrical codes and ordinances. The dishwasher is designed for an electrical supply of 120V, 60 Hz, AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated for 15 or 20 amps.
- Page 16 Strap Leg Adjuster Adhesive backed cord clip • Place adhesive backed cord clip (provided in the installation kit) 2 inches from leg adjuster as shown in the figure above and route power cord through the clip. Note:The length of cord measured from the plastic back strap to the receptacle should be ≤...
-
Page 17: Installation Of Mounting Brackets
Installation of Mounting Brackets WARNING Avoid Tip Over Hazard! Do not use the dishwasher until it is completely installed. When opening the door on an uninstalled dishwasher, carefully open the door while supporting the rear of the unit. Failure to follow this warning can result in serious injury. Note: Before installing the supplied counter top mounting brackets, decide which method of securing the dishwasher into its enclosure will be used. - Page 18 • Side Mount is used for counter tops made of marble, granite, or other very hard materials that cannot be easily drilled. • Grasp mounting bracket (D) with pliers and fold bracket at the perforation over onto itself as shown in 10a. •...
-
Page 19: Positioning The Dishwasher
Positioning the Dishwasher • If your sink is to the right side of where you are installing the dishwasher, you will need to reposition the hoses and power cord behind the dishwasher before installing. • To do so, unhook the strap that the hoses are running through on the back of the dishwasher base and position them per your requirements. - Page 20 • Position the hoses and power cord so they run through the strap on the appropriate side. • Be sure to snap the strap back in place to secure the hoses as shown. NOTICE Be sure to pull the hoses all the way into the adjacent cabinet while pushing the dishwasher in.
- Page 21 • To avoid scratching the floor, use floor protection and caution when sliding the dishwasher into the cabinet. Use hands on both sides of dishwasher to push evenly. • Pull water inlet, drain hose and power cord through the hole in cabinet as shown.
- Page 22 6 mm • Adjust the legs as shown. Make sure the top of the door is no less than 6mm from the underside of the counter. • Use a level to check that your dishwasher is level. • Level side to side by turning feet clockwise to raise or counter- clockwise to lower front of the unit as shown.
-
Page 23: Securing The Dishwasher
Securing the Dishwasher • Drive the mounting screws (E) through the holes in the mounting brackets as shown for Top ( figure 17) or Side Mount (figure 18). • If the dishwasher came with a protective barrier, you should drill the screws through the barrier for the Top Mount. -
Page 24: Water Inlet Connection
Water Inlet Connection WARNING Scalding Hazard! Do not perform any work on a pressured hot water line. Serious injury could result. Only qualified plumbers should perform plumbing work. Do not attempt any work on the dish- washer hot water supply plumbing until you are certain the hot water supply is shut off. -
Page 25: Drain Connection
• Connect the dishwasher water supply line to the water shut off valve. If one isn’t already in the supply line, install one (not provided). • You will need to use an approved dishwasher water supply line with the correct fittings for this connection. •... - Page 26 screws provided • You may use the piece you removed in Step 7 to attach to the inside of the adjacent cabinet and hang the drain hose from as shown (screws are not supplied) in place of using a Nonmetallic Tie as pictured in the next illustrations.
- Page 27 NOTE: Place hose clamp (C) around end of drain hose BEFORE connecting to the plumbing. • The dishwasher drain hose may be connected to the drain plumbing using an air gap in one of two ways: - Connect to the under sink dishwasher drain connection (21a). - Connect to a disposer dishwasher drain connection (21b).
- Page 28 • Use the clamp provided (C) to attach the drain hose to the house plumbing as shown.
-
Page 29: Attaching The Toe Panel
Attaching the Toe Panel If your dishwasher came with a slotted toe panel (G) only, follow these instructions; otherwise skip to 24 now. Note: If using the slotted toe panel shown in 23 above, then metal mounting brackets shown in 24 are not required. •... - Page 30 • If your dishwasher comes with a rubber apron, tuck it behind the tab on the metal brackets as shown. • Slide metal toe panel into position ensuring the bottom of the toe panel is flush with the floor. Use screw (H) to mount the toe panel through the hole it matches up with on the metal brackets (K) as shown.
- Page 31 If your dishwasher came with a plastic toe panel (L) and slotted toe panel (M) follow these instructions: Note: If using the plastic toe panel shown in 31 above, then metal mounting brackets shown in 28 are not required. • Align the plastic toe panel on the base of the dishwasher so the holes line up.
- Page 32 Fully Integrated Door Panel Please see the included instructions and template for installing a fully integrated door panel.
-
Page 33: Customer Service
Customer Service Your dishwasher requires no special care other than that described in the Care and Maintenance section of the Use and Care Manual. If you are having a problem with your dishwasher, before calling for service please refer to the Troubleshooting section in the Use and Care Manual. If service is necessary, contact your dealer or installer or an authorized service center.
