- Page 1 Form No. 3429-967 Rev B Tiller TXL 2000 Tool Carrier Model No. 22542—Serial No. 318000001 and Up *3429-967* B Register at www.Toro.com. Original Instructions (EN)
- Page 2 Figure 1 1. Model and serial number location This tiller is intended to be used on a Toro tool carrier for breaking through hard soil conditions on residential or commercial properties. Using this product for purposes other than its intended use could prove Model No.
-
Page 3: Table Of Contents
Contents Safety Safety ............... 3 DANGER General Safety ........... 3 Slope Safety ............4 There may be buried utility lines in the work Tiller Safety............4 area. Digging into them may cause a shock Maintenance and Storage Safety......4 or an explosion. Safety and Instructional Decals ...... -
Page 4: Slope Safety
Slope Safety Tiller Safety • • Operate the machine up and down slopes with Keep bystanders at least 15 m (50 feet) away from the heavy end of the machine uphill. Weight the machine. distribution changes with attachments. This • Run the tiller so that debris is thrown away from attachment makes the front of machine the heavy the traction unit. -
Page 5: Safety And Instructional Decals
387 kg (854 lb) Number of tines To ensure optimum performance and continued safety certification of the machine, use only genuine Toro replacement parts and accessories. Replacement parts and accessories made by other manufacturers could be dangerous, and such use could void the product warranty. -
Page 6: Operation
Operation CAUTION Hydraulic couplers, hydraulic lines/valves, Determine the left and right sides of the machine from and hydraulic fluid may be hot. If you contact the normal operating position. hot components, you may be burned. • Wear gloves when operating the hydraulic Installing and Removing couplers. -
Page 7: Transport Position
Transport Position Operating Tips • Clean the area of trash, branches, and rocks When transporting the attachment, keep it as close before tilling to prevent equipment damage. to the ground as possible, no more than 15 cm (6 inches) above the lowest position. Tilt it rearward. •... -
Page 8: Maintenance
Maintenance Determine the left and right sides of the machine from the normal operating position. CAUTION If you leave the key in the switch, someone could accidently start the engine and seriously injure you or other bystanders. Remove the key from the switch before you perform any maintenance. Recommended Maintenance Schedule(s) Maintenance Service Maintenance Procedure... -
Page 9: Replacing The Rotor Assembly
Install the new tine, orienting it the same direction as the old tine (Figure Torque the bolt to 183 to 223 N∙m (135 to 165 ft-lb). Replacing the Rotor Assembly Removing the Rotor Assembly Remove the tiller from the traction unit. Use a hoist to lay the tiller back on the attachment plate. -
Page 10: Checking The Hydraulic Lines
Installing the Rotor Assembly Storage Install the rotor assembly with the 2 bearing guards and bearings using 4 locknuts (5/8 inch), Before long-term storage, wash the attachment 4 washers, and 4 bolts (5/8 x 2-1/2 inches) for with mild detergent and water to remove dirt and both sets of guards and bearings (Figure grime. -
Page 11: Troubleshooting
Troubleshooting Problem Possible Cause Corrective Action The tiller does not operate. 1. A hydraulic coupler is not completely 1. Check and tighten all couplers. connected. 2. One or more hydraulic couplers are 2. Check the couplers and replace any damaged. that are damaged. - Page 12 While the exposure from Toro products may be negligible or well within the “no significant risk” range, out of an abundance of caution, Toro has elected to provide the Prop 65 warnings. Moreover, if Toro does not provide these warnings, it could be sued by the State of California or by private parties seeking to enforce Prop 65 and subject to substantial penalties.
