WARNING - This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. BASIC NOTE • The accessories provided with your product may vary depending on the model or region. • Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions.
Learning the Buttons The illustrations may differ depending on the model. 98UM5K-B 110UM5K-B • : Adjusts up and down. • : Moves left and right. • : Displays the current signal and mode. • : Accesses the main menus, or saves your input and exits the menus.
Kensington Lock Device (This feature applies only to some models.) The Kensington lock device connector is located on the back of the monitor. For more information on installation and use, refer to the user manual provided with the locking device. Connect the Kensington security system cable between the monitor and a table.
CHECKING BEFORE INSTALLATION We are not responsible for product damage caused by failure to follow the guide. Installation Orientation Using Vertically (98UM5K-B Only) When installing vertically, rotate the monitor 90 degrees clockwise while facing the front of the screen. Tilt Angle 15˚...
Installation Location We are not responsible for product damage caused by failure to follow the guide. Indoor Installing on a Wall A: 40 mm or more • The warranty will not cover any damage caused by using the product in direct sunlight on the front panel.
Take caution, and ensure that the wall mount holder (optional) is securely fixed to the monitor and to the wall. The Wall Bracket dimensions of the wall mount by model are as follows. 98UM5K-B 110UM5K-B Wall Bracket Standard Length (Maximum)
PRECAUTIONS FOR USE Dust The warranty will not cover any damage caused by using the product in an excessively dusty environment. Afterimage • After-image appears when the product is turned off. - Pixels may be damaged rapidly if a still image is displayed on the screen for a long period of time. Use the screen- saver function.
Page 11
Change the background colour and text colour at equal intervals. - Afterimages occur less when the colours to be changed are complementary to one another. ITO or MoTi Pixel Layer Switch the screen at equal time intervals. - Take caution, and ensure that text or images from before the screen change are not left in the same location after the screen change.
* Product box packaging storage conditions On Mode 430 W (Typ.) Power Consumption Sleep Mode / Standby Mode ≤ 0.5 W 110UM5K-B Input/Output Ports HDMI1,2 / DisplayPort: 3840 x 2160 @ 60 Hz Recommended Resolution HDMI3: 3840 x 2160 @ 30 Hz Resolution DVI-D: 1920 x 1080 @ 60 Hz - This may not be supported on some OS or graphics card Max Resolution types.
Page 13
Model Name Size (Width x Height x Depth) (mm) Weight (kg) 98UM5K-B 2198 x 1253 x 79.5 110UM5K-B 2474 x 1408 x 99 HDMI / DVI-D / DisplayPort (PC) Support mode Resolution Horizontal frequency (kHz) Vertical frequency (Hz) Remark 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 720 44.772...
Page 14
Wireless module (LGSBWAC92) Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 5150 to 5725 5725 to 5850 Bluetooth Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 • As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
Page 15
(Only Vietnam) Wireless module (LGSBWAC92) Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 17.5 5150 to 5350 17.5 5725 to 5850 Bluetooth Frequency range (MHz) Output power (Max.) (dBm) 2400 to 2483.5 • As band channels can vary per country, the user cannot change or adjust the operating frequency. This product is configured for the regional frequency table.
Dolby Laboratories Licensing Corporation. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by LG Electronics Inc. is under license. Other trademarks and trade names are those of their respective owners.
Page 17
The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Temporary noise is normal when powering ON or OFF MODEL this device. SERIAL NO.
