Service Manual Model No.: 32D2000 CONTENTS Chapter 1. General Information 1-1. Document Information ..............3 1-2. General Guidelines..............3 1-3. Important Notice.................3 1-3-1. Follow the regulations and warnings ............. 3 1-3-2. Be careful to the electrical shock ............3 1-3-3. Electro static discharge (ESD)..............3 1-3-4.
Page 3
Service Manual Model No.: 32D2000 4-3-2. Connector definition ................15 4-4. LCD Panel ..................16 Chapter 5. Installation Instructions 5-1. Accessories ................18 5-2. External Equipment Connections..........19 Chapter 6. Operation Instructions 6-1. Front Panel Controls..............20 6-2. Back Panel Controls ..............21 6-3. Setting Up Your Remote Control ..........22 Chapter 7.
Service Manual Model No.: 32D2000 Chapter 1. General Information 1-1. Document Information Document format: Adobe PDF Author: Zhu Yapeng Compiler: 1-2. General Guidelines When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.
Service Manual Model No.: 32D2000 components commonly are called Electrostatically Sensitive (ES) Devices. The following techniques should be used to help reduce the incidence of component damage caused by electros static discharge (ESD). Electrostatically Sensitive (ES) Devices Some semiconductor (solid-state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices.
Page 6
Service Manual Model No.: 32D2000 1. Always unplug the receiver AC power cord from the AC power source before: a. Removing or reinstalling any component, circuit board module or any other receiver assembly. b. Disconnecting or reconnecting any receiver electrical plug or other electrical connection.
Service Manual Model No.: 32D2000 12. Use only a grounded-tip soldering iron to solder or unsolder ES devices. 13. Use only an anti-static type solder removal device. Some solder removal devices not classified as "anti-static" can generate electrical charges sufficient to damage ES devices.
Page 8
Service Manual Model No.: 32D2000 Caution: A “caution ” is used when there is danger that the reader, through incorrect manipulation, may damage equipment, loose data, get an unexpected result or has to restart(part of) a procedure. Warning: A “warning” is used when there is danger of personal injury.
Service Manual Model No.: 32D2000 Chapter 2. Specification 2-1. Specification list Model 32D2000 Screen Size 32" Aspect Ratio 16:9 Resolution 1366x768 Brightness (cd/m² ) Contrast 800:1 Response Time (ms) Angel of View H:160° , V:150° Color Display 16.7M OSD Language English,French,Spanish.
Service Manual Model No.: 32D2000 Chapter 3. Disassemble and Assemble 3-1. 32D2000 3-1-1. Remove the Stand 3-1-3. Remove the Mainboard 1. Remove the six screws indicated with red circles. 2. Remove the Mainbord. 1. Lay down the TV set .
Service Manual Model No.: 32D2000 3-1-6. Remove the Remote Control Board And the Key Board Remove the Remote Control Board and the Key Board indicated by red circle in below picture.
Service Manual Model No.: 32D2000 Chapter 4. Location of Controls and Components 4-1. Board Location B Panel A Board Model Description DH1TK4M0101M A Board Mainboard 712-315C3-X8221 B Panel LCD Panel...
Service Manual Model No.: 32D2000 4-2. Mainboard 4-2-1. Function Description Process signal which incept from exterior equipment then translate into signal that panel can Display. 4-2-2. Connector definition CN18 IR & Key Interface Pin number Signal name Speaker connector CN18...
Service Manual Model No.: 32D2000 5-2. External Equipment Connections Antenna Connection Connect a DVD Player or VCR to Your TV Connect your aerial to the back of the TV into the ANTENNA IN socket. There are two ways in which you can connect a DVD player or VCR to your TV.
Service Manual Model No.: 32D2000 Chapter 6. Operation Instructions 6-1. Front Panel Controls TV channel up. POWER Press to turn the TV on and off. VOL- Press to decrease the volume. 2 INPUT Toggles between all the vailable input sources.
Service Manual Model No.: 32D2000 Chapter 8. Measurements and Adjustments 8-1. Service Mode 8-1-1.How to enter into Service Mode The way to the factory mode menu: Step 1: Press Menu, Step 2: Input “8893”, System will be into the factory mode menu when 2 steps above are done.
Service Manual Model No.: 32D2000 8-2-2. GENERAL SETTING 1)Init Flash; 2)Uart Enable:Choose on or off in Uart Enable; 3)Dbg Message Enable: Choose on or off in Dbg Message Enable; 4)Test Pattern: Choose the Pattern picture; 5)Dynamic Contrast: Choose on or off in Dynamic Contrast;...
Service Manual Model No.: 32D2000 8-2-4. SOUND Adjust the values of Sound Mode, Volume Curve,Audio Output and True Volume in different source. 8-2-5. Panel Setting 1)LVDS Bit Mode: choose the Bit; 2)LVDS MAP: choose the MAP; 3)LVDS ODD/Even: choose ODD or Even;...
Service Manual Model No.: 32D2000 8-3. Software Update 8-3-1. MSD3393LU software update 1. Copy the software files to a USB disk on the root directory; 2. Insert the USB disk when the AC power is off; 3. Turn on the AC power in turn to begin;...
Service Manual Model No.: 32D2000 Chapter 9. Trouble shooting 9-1. Simple check Verify if the television is properly plugged Verify if the television is properly supplied power No picture/ No sound Verify if electricity is available. Verify if correct signals are input...
Service Manual Model No.: 32D2000 9-3. Mainboard Failure Check No picture but have sound Check the power output Change the Power Board There’s something wrong Check the CN2 (BLO) with FRC Backlight on/off Verify if the DC/DC convertor can output the...
Page 40
Service Manual Model No.: 32D2000 No sound but have picture Verify if the speakers are Change the speakers broken Verify if the main board has the Check the corresponding audio right input ,according to the source input circuit you connect.
Page 41
Service Manual Model No.: 32D2000 No sound No picture Verify if the Power has Change the 5Vstb output Power supply Verify if CN4 Pin3/4 has 5V Change Power board input Verify if CN2 Pin1 has 12V Change Power board input...
Page 42
Service Manual Model No.: 32D2000 Poor sound Poor sound Verify if sound system is Change sound correct . system For ease of use, recommend that customer format the picture and sound settings in the automatic option. Updata the software and Still having make the reboot;...
Page 43
Service Manual Model No.: 32D2000 No color for some channel program (black and white) No color for some chann el program (black and w hite) Verify if the same Check out of picture and sound problem exists in other system of this channel...
Page 44
Service Manual Model No.: 32D2000 How to know whether the Power board is broken? Check if the power cord co Reconnect the power cord with the nnect well? outlet or Power board. Check if the Power board Replace the Power board pls.
