HT904TA-DH_BTURDL_ENG_2097
6/17/09
Model : HT904TA (HT904TA-DH, SH94TA-F/S/C/W)
HT904SA (HT904SA-DH, SH94SA-S/C/W)
HT904PA (HT904PA-DH, SH94PA-F/S/C/W)
Full HD up-scaling (1080p)
(Go to page 6)
USB Direct Recording
(Go to page 17)
As an E
S
NERGY
TAR
®
LG has determined that this
product or product models meet
the E
S
®
guidelines for
NERGY
TAR
energy efficiency.
E
S
®
is a U.S. registered mark.
NERGY
TAR
P/NO : MFL62242097
12:04 PM
Page 1
HDMI In
(Go to page 7)
Portable In
(Go to page 18)
Partner,
Home theater Speaker ez Set-up
(Go to page 15)
Advertisement
Table of Contents
Related Manuals for LG HT904TA-DH
Summary of Contents for LG HT904TA-DH
- Page 1 HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 1 Model : HT904TA (HT904TA-DH, SH94TA-F/S/C/W) HT904SA (HT904SA-DH, SH94SA-S/C/W) HT904PA (HT904PA-DH, SH94PA-F/S/C/W) Full HD up-scaling (1080p) HDMI In Home theater Speaker ez Set-up (Go to page 6) (Go to page 7) (Go to page 15)
- Page 2 Shall the unit European representative : require maintenance, contact an authorized service center. LG Electronics Service Europe B.V. Use of controls, adjustments or the performance of procedures other than those Veluwezoom 15, 1327 AE Almere, The Netherlands specified herein may result in hazardous radiation exposure.
-
Page 3: Table Of Contents
LG TV with SIMPLINK are connected through HDMI connection. • Controllable functions by LG TV’s remote control; Play, Pause, Scan, Skip, Stop, Specifications ....... . .22 Power Off, etc. -
Page 4: Setting Up
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 4 Setting up Connect the wires to the DVD receiver. Match each wire’s coloured band to the same coloured connection terminal on the rear of the DVD receiver. To connect the cable to the DVD The speakers are detached from the speaker stands. -
Page 5: Hooking Up The Unit
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 5 Hooking up the unit a Connect jacks on the unit and your TV (DVD player or Digital Device etc.) using the cables. Check the jacks of your TV, and choose the A, B or C connection. Picture quality improves in order from A to C. Component Video connection ( SCART connection ( Connect the COMPONENT... - Page 6 HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 6 Hooking up the unit Available resolution according to connection Displayed resolution in display window and outputted resolution may different Resolution Setting according to connection type. You can change the resolution for component video and HDMI output. [HDMI OUT]: 1080p, 1080i, 720p and 480p (or 576p) and 480i (or 576i) Press RESOLUTION repeatedly to select the desired resolution - 480i (or 576i), [COMPONENT VIDEO OUT]: 480p (or 576p) and 480i (or 576i)
-
Page 7: Main Unit
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 7 Hooking up the unit Main Unit 3 4 5 HDMI In connection Connect the HDMI INPUT jack on the unit to the HDMI output jack on your Set-Top box (or Digital Device etc.) using an HDMI cable. Set the external source to HDMI IN by pressing FUNCTION. -
Page 8: Remote Control
TUN. (-/+) : Tunes in the desired radio station. U U u u I I i i (up/ down/ left/ right): Used to navigate on- TV Control buttons : Controls the TV. (LG TV only) screen displays. ENTER : Acknowledges menu selection. -
Page 9: Osd Initial Language Settings - Optional
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 9 OSD Initial language settings - Optional Adjusting the general settings During the first use of this unit, the initial language setup menu ON REMOTE appears on your TV screen. You must complete initial language 1 Display setup menu : SETUP selection before using the unit. -
Page 10: 5.1 Speaker Setup
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 10 Adjusting the display settings 5.1 Speaker Setup TV Aspect – Select which screen aspect to use based on the shape of your TV screen. ON REMOTE [4:3] : Select when a standard 4:3 TV is connected. 1 Open the settings menu: SETUP [16:9] : Select when a 16:9 wide TV is connected. -
Page 11: Enjoying A Preprogrammed Sound Field
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 11 Adjusting the lock settings Enjoying a pre-programmed sound field To access the lock options, you must enter the 4-digit password. If you have not yet entered a password you are prompted to do so. Enter a 4-digit password This system has a number of pre-set surround sound fields. -
Page 12: Displaying Disc Information
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 12 Displaying Disc Information Playing a Disc or file ON REMOTE ON REMOTE 1 Press DISPLAY : 1 Insert a disc on unit : Z Z OPEN/CLOSE DISPLAY 2 Select a DVD/CD : FUNCTION 2 Select an item : U U u u U U u u I I i i I I i i... - Page 13 HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 13 Fast forward or fast reverse Viewing the DVD MENU Press MENU to display the disc menu, if available. Press SCAN (m or M) to play fast forward or fast reverse during playback. You can change the playback speed by pressing SCAN (m or M) Changing the character set to display DivX ®...
-
Page 14: Viewing Photo Files
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 14 Creating your own program Viewing photo files You can play the contents of a disc in the order you want by arranging the order of the musics on the disc. To add a music(s) on the program list, press ON REMOTE PROG./MEMO. -
Page 15: Listening To The Radio
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 15 Seeing information about a radio station Listening to the radio The FM tuner is supplied with the RDS (Radio Data System) facility. This shows Be sure that FM aerials are connected. information about the radio station being listened to. Press RDS repeatedly to cycle through the various data types. -
Page 16: Using An Usb Device
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 16 Compatible USB Devices Using an USB device • MP3 Player : Flash type MP3 player. • USB Flash Drive : Devices that support USB2.0 or USB1.1. You can enjoy media files saved on an USB device by connecting the •... -
Page 17: Recording To Usb
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 17 When you are recording, look out for the following Recording to USB • You can check the recording percentage rate for the USB record on the ON REMOTE screen during the recording.(AUDIO CD or MP3/ WMA CD only) •... -
Page 18: Listening To Music From Your Portable Player Or External Device
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 18 Other operations Listening to music from your portable player or external device Fall asleep while listening to your player Press SLEEP one or more times to select delay time between 10 and 180 The unit can be used to play the music from many types of portable player or minutes, after the player will turn off. -
Page 19: Language Codes
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 19 Language Codes Use this list to input your desired language for the following initial settings: Disc Audio, Disc Subtitle, Disc Menu. Language Code Language Code Language Code Language Code Language Code Language Code Afar 6565 Croatian 7282... -
Page 20: Troubleshooting
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 20 Troubleshooting PROBLEM CAUSE CORRECTION No power Plug the power cord into the wall outlet securely. The power cord is disconnected. No picture Select the appropriate video input mode on the TV so the The TV is not set to receive the DVD signal. picture from the DVD Receiver appears on the TV screen. -
Page 21: Types Of Playable Discs
LG players when formatting rewritable discs. When setting Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; the option to Live File System, you cannot use it on LG players. 5,974,380; 5,978,762; 6,487,535 & other U.S. and worldwide patents issued &... -
Page 22: Specifications
HT904TA-DH_BTURDL_ENG_2097 6/17/09 12:04 PM Page 22 Specifications Specifications General Speakers (HT904PA) Power supply Refer to main label. Front Rear Power consumption Refer to main label. Speaker speaker Net Weight 3.9 kg External dimensions (W x H x D) 430 x 73 x 327 mm Type 2 Way 3 Speaker 1 Way 1 Speaker...
