Summary of Contents for Lenovo S15 Gen 3
- Page 1 User Guide Lenovo S14 Gen 3 and Lenovo S15 Gen 3...
- Page 2 • Setup Guide First Edition (April 2022) © Copyright Lenovo 2022. LIMITED AND RESTRICTED RIGHTS NOTICE: If data or software is delivered pursuant to a General Services Administration “GSA” contract, use, reproduction, or disclosure is subject to restrictions set forth in Contract No. GS-...
-
Page 3: Table Of Contents
Interact with your computer ..Call Lenovo ....Keyboard hotkeys ... . - Page 4 User Guide...
-
Page 5: About This Guide
About this guide • This guide applies to Lenovo product model(s) listed below. Illustrations in this guide may look slightly different from your product model. Model name Machine type (MT) Lenovo S14 G3 IAP 82TW Lenovo S14 G3 IAP 1... - Page 6 User Guide...
-
Page 7: Chapter 1. Meet Your Computer
Move the slider to cover or uncover the camera lens. Note: The camera cover helps you better protect your privacy. 4. Camera light If the light is on, the camera is in use. 5. Screen Display text, graphics, and videos. © Copyright Lenovo 2022... -
Page 8: Base
Base Figure 2. Base view—14–inch models Figure 3. Base view—15–inch models User Guide... - Page 9 1. Wireless antennas Send and receive radio waves for the built-in wireless LAN (local area network) and Bluetooth module. Notes: • The antennas are not visible from the outside of the computer. • If the location of the antennas is close to the user’s body (< 20 cm), you can find the Specific Absorption Rate (SAR) values in the Setup Guide that comes with your computer.
-
Page 10: Left
Left Figure 4. Left-side view—14–inch models Figure 5. Left-side view—15–inch models 1. Power connector Connect to power with the included power cord and ac power adapter. 2. Charging light • Solid white: Connected to ac power; battery capacity 91%–100% • Solid amber: Connected to ac power; battery capacity 1%–90% •... - Page 11 ™ 4. HDMI connector Connect to a compatible digital audio device or video monitor, such as an HDTV. ® 5. USB-C connector • Connect to power with the included power cord and ac power adapter. • Connect external display, storage, or data devices. Note: An appropriate adapter may be needed for connecting external devices.
-
Page 12: Right
Right Figure 6. Right-side view—14–inch models Figure 7. Right-side view—15–inch models 1. Speaker Produce sound. 2. Power light • On: The computer is turned on. • Blinking: The computer is in sleep mode. • Off: The computer is turned off or in hibernation mode. 3. - Page 13 4. SD card slot Insert an SD card or a MultiMediaCard (MMC) into the slot for data transfer or storage. 5. USB 2.0 connector Connect to a USB-compatible device, such as a USB keyboard, a USB mouse, a USB storage device, or a USB printer. Chapter 1 Meet your computer...
-
Page 14: Bottom
Bottom Figure 8. Bottom view—14–inch models Figure 9. Bottom view—15–inch models 1. Ventilation slots (inlet) Maintain the incoming airflow to dissipate internal heat. Note: Do not block the ventilation slots. Otherwise, the computer might overheat. 2. Speakers Produce sound. User Guide... -
Page 15: Features And Specifications
Features and specifications Dimensions • 14-inch models – Width: 324.2 mm (12.76 inches) – Depth: 215.2 mm (8.47 inches) – Thickness: 17.9 mm (0.70 inches) • 15-inch models – Width: 359.2 mm (14.14 inches) – Depth: 235.8 mm (9.28 inches) –... -
Page 16: Statement On Usb Transfer Rate
Connectors and slots • Combo audio jack • Power connector • USB (3.2 Gen 1) Type-A – Power output up to 5 V and 0.9 A (does not support charging function) • USB 2.0 connector – Power output up to 5 V and 0.5 A (does not support charging function) •... -
Page 17: Avoid Constant Body Contact With Specific Hot Sections
Temperature • At altitudes up to 2438 m (8000 ft) – Operating: 5°C to 35°C (41°F to 95°F) – Storage: 5°C to 43°C (41°F to 109°F) • At altitudes above 2438 m (8000 ft) – Maximum temperature when operating under the unpressurized condition: 31.3°C (88°F) Note: When you charge the battery, its temperature must be no lower than 10°C (50°F). - Page 18 User Guide...
-
Page 19: Chapter 2. Get Started With Your Computer
If night light mode is turned on, you can adjust the color temperature of the Night light temperature screen. Note: Selected Lenovo computers are low blue light certified. These computers are tested with night light turned on and color temperature set to the default value of 48. Windows... -
Page 20: Windows Help Information
To open it, type its name in the Windows Search box and select the matched result. If neither of the apps is pre-installed, you may install one on your own. Lenovo Vantage is available for download free of charge from the Microsoft Store. -
Page 21: Interact With Your Computer
End a Microsoft Teams call. Open the Windows Calculator app. Display an app launcher for quick access to Lenovo apps and services. Note: For some models, you may need to connect to the Internet and complete system update for this function to take effect. -
Page 22: Numeric Keypad
+ ESC. Numeric keypad Some Lenovo computers includes a dedicated numeric keypad on the far right of the keyboard. The keypad is used for entering numbers and operators quickly. Press the NumLock key to enable or disable the numeric keypad. -
Page 23: Chapter 3. Explore Your Computer
To extend your battery’s lifespan, the battery may optimize its full charge capacity based on your usage. After prolonged periods of limited use, full battery capacity may not be available until you discharge to as low as 20% and recharge completely. For more information, refer to the power section of Lenovo Vantage. -
Page 24: Set Performance Mode
• Turn off the display: after 10 minutes • Put the computer to sleep: – after 10 minutes (Lenovo S14 G3 IAP and Lenovo S15 G3 IAP) – after 30 minutes (Lenovo S14 G3 ABA and Lenovo S15 G3 ABA) Note: To wake the computer from the sleep state, press the power button or any key on the keyboard. -
Page 25: Set Passwords In Uefi/Bios Setup Utility
Attention: If you forget the administrator password, a Lenovo authorized service personnel cannot reset your password. You must take your computer to a Lenovo authorized service personnel to have the system board replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 26: Set User Password
Lenovo authorized service personnel cannot reset your password or recover data from the hard disk. You must take your computer to a Lenovo authorized service personnel to have the hard disk drive replaced. Proof of purchase is required and a fee will be charged for parts and service. -
Page 27: Change Or Remove Hard Disk Password
Note: If you start the setup utility using the user password, you cannot set hard disk password. Step 3. Follow on-screen instructions to set both master and user passwords. Note: The master and user hard disk passwords must be set at the same time. Select Exit ➙... - Page 28 User Guide...
-
Page 29: Chapter 4. Help And Support
Where can I get the latest device • Lenovo Vantage or Lenovo PC Manager drivers and UEFI/BIOS? • Lenovo Support Web site at https://support.lenovo.com... -
Page 30: What Is A Cru
If you intend to install a CRU, Lenovo will ship the CRU to you. You might be required to return the defective part that is replaced by the CRU. When return is required: (1) return instructions, a prepaid shipping label, and a container will be included with the replacement CRU;... -
Page 31: Crus For Your Product Model
Notes: • CRU replacement instruction is provided in one or more of the following publications and are available from Lenovo at any time upon your request. the product User Guide the printed publications that came with the product •... -
Page 32: Call Lenovo
Call Lenovo If you have tried to correct the problem yourself and still need help, you can call Lenovo Customer Support Center. Before you contact Lenovo Record product information and problem details before you contact Lenovo. Product information Problem symptoms and details •... -
Page 33: Purchase Additional Services
Purchase additional services During and after the warranty period, you can purchase additional services from Lenovo at https:// pcsupport.lenovo.com/warrantyupgrade Service availability and service name might vary by country or region. Chapter 4 Help and support... - Page 34 User Guide...
-
Page 35: Appendix A. Notices And Trademarks
Lenovo representative for information on the products and services currently available in your area. Any reference to a Lenovo product, program, or service is not intended to state or imply that only that Lenovo product, program, or service may be used. Any functionally equivalent product, program, or service that does not infringe any Lenovo intellectual property right may be used instead. - Page 36 Actual results may vary. Users of this document should verify the applicable data for their specific environment. This document is copyrighted by Lenovo and is not covered by any open source license, including any Linux agreement(s) which may accompany software included with this product. Lenovo may update this document at any time without notice.
