MFC‑L8900CDW
Quick Setup Guide
Unpack the machine and check the components
Inbox Toner Cartridges*
(Black, Cyan, Magenta and
Brother Installation Disc
1
Remove the packing materials and install the drum unit and toner cartridge assembly
Remove the packing tape.
1
2
2
Load paper in the paper tray
3
Connect the power cord and turn the machine on
Back
4
Select your language (if needed)
1.
On the machine's Touchscreen, press
[初始设置](Initial Setup) > [语言](Local Language).
2.
Press your language.
3.
Press .
Drum Unit* Waste Toner Box*
Telephone Line Cord
Yellow)
Quick Setup Guide
3
4
Front
[所有设置](All Settings) >
Read the Product Safety Guide first, then read this Quick
Setup Guide for the correct installation procedure.
The latest manuals are available at the Brother Solutions
Center: www.95105369.com.
* Already installed in the machine
Belt Unit*
AC Power Cord USB Interface Cable
Product Safety Guide
Do not exceed this mark.
Adjust the paper
guides.
NOTE:
• The available connection interfaces vary depending on the
model.
• Interface cables are not included. You must purchase the
correct interface cable if you require one.
USB cable
We recommend using a USB 2.0 cable (Type A/B) that is
no more than 2 metres long.
Network cable
Use a straight-through Category 5e (or greater) twisted-
pair cable.
• The illustrations in this Quick Setup Guide show the
MFC-L8900CDW.
Secure Network Access
Your machine's default password is on the label on the back
of the machine (preceded by "Pwd").
We strongly recommend you change it to protect your
machine from unauthorised access.
CHN-ENG
Version B
