D-Link DI-604 Quick Installation Manual

Hide thumbs Also See for DI-604:

Advertisement

Quick Links

Download this manual
This product can be set up using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 6.2.3.
Before You Begin
1. If you purchased this router to share your high-speed Internet connection with
other computers, you must have either an Ethernet-based Cable or a DSL modem
with an established Internet account from an Internet Service Provider (ISP).
2. It's best to use the same computer that is connected to your modem for
configuring the DI-604 router. The DI-604 Router acts as a DHCP server and will
assign all the necessary IP address information on your network. See Appendix
at the end of this Quick Installation Guide or the Manual on the CD-ROM
for setting each network adapter to automatically obtain an IP address.
Check Your Package Contents
These are the items included with your DI-604 purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
DI-604 Ethernet Broadband Router
CD-ROM (containing Manual and Warranty)
Ethernet (Straight Through) Cable
5V 2A DC Power Adapter
specifications subject to change without notice. DI-604. 08122003
1
DI-604
Express EtherNetwork™
Broadband Router
Using a power supply
with a different voltage
rating will damage and void
the warranty of this product.

Advertisement

loading

Related Manuals for D-Link DI-604

Summary of Contents for D-Link DI-604

  • Page 1 If any of the above items are missing, please contact your reseller. ©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and specifications subject to change without notice. DI-604. 08122003...
  • Page 2 Connecting The DI-604 Broadband Router To Your Network First, connect the power adapter to the receptor at the back panel of the DI-604 and then plug the other end of the power adapter to a wall outlet or power strip.

  • Page 3: Restart Your Computer

    Connecting Additional Computers To The DI-604 Using additional Ethernet (CAT5 UTP) cables, connect your Ethernet-equipped computers to the remaining Ethernet LAN ports on the back panel of the DI-604. WAN LED – a solid light indicates connection on the WAN port. This LED blinks during data transmission.

  • Page 4: Using The Setup Wizard

    When you have completed the steps in this Quick Installation Guide, your connected network should look similar to this: Using The Setup Wizard Open your Web browser and type “http://192.168.0.1” into the URL address box. Then press the Enter or Return key. The logon pop-up screen will appear.
  • Page 5 The Setup Wizard (continued) Once you have logged in, the Home screen will appear. Click Run Wizard You will see the following screens Click Next Set up your new password. You have the option to establish a password. Click Next...
  • Page 6 The Setup Wizard (continued) Choose your time zone from the drop down list. Click Next A this point, the setup wizard will try to auto-detect your Internet connection type. If you have a Dynamic or PPPoE connection, you will be brought to the corresponding page.
  • Page 7 The Setup Wizard (continued) If you selected Dynamic IP Address, this screen will appear: (Used mainly for Cable Internet service.) Click the “Clone MAC Address” button to automatically copy the MAC address of the network adapter in your computer. You can also manually type in the MAC address.
  • Page 8 Your Setup is Complete! Click Restart Click Close...

  • Page 9: Test Internet Connection

    Test Internet Connection. You will be returned to the Home tab. Click to Exit Then relaunch your Web browser (i.e., Internet Explorer or Netscape Navigator), to link to your favorite Web site to test your Internet connection. For additional settings or information, refer to the Advanced, Tools, or Status tabs on the web-...
  • Page 10 Here’s how to configure the network adapter to obtain an IP address automatically for the DI-604 Broadband Router. Microsoft Windows XP: Go to Start > right click on My Network Places >...
  • Page 11 Apple Macintosh OS X: Go to the Apple Menu Click System Preferences Click on Select Network Network Select Built-in Ethernet in the show pull down menu Select Using DHCP the Configure pull down menu Click on Apply Now The IP address information, the Subnet Mask, the Router’s IP address and the Ethernet adapter address will appear...

  • Page 12: Technical Support

    Technical Support You can find software updates and user documentation on the D-Link website. D-Link provides free technical support for customers within the United States and within Canada for the duration of the warranty period on this product. U.S. and Canadian customers can contact D-Link technical support through our website, or by phone.
