- Page 1 EN User Manual | Steam oven COB8S39Z EOB8S39X EOB8S39Z KOBBS39X LOB8S39Z...
-
Page 2: Table Of Contents
WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time. -
Page 3: Safety Information
SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. -
Page 4: Safety Instructions
similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable. • Do not use the appliance before installing it in the built-in structure. • Disconnect the appliance from the power supply before carrying out any maintenance. - Page 5 • Before mounting the appliance, check if • Do not use multi-plug adapters and the appliance door opens without restraint. extension cables. • The appliance is equipped with an electric • Make sure not to cause damage to the cooling system. It must be operated with mains plug and to the mains cable.
- Page 6 • Do not use the appliance as a work • Before maintenance, deactivate the surface or as a storage surface. appliance and disconnect the mains plug • Open the appliance door carefully. The from the mains socket. use of ingredients with alcohol can cause •...
-
Page 7: Product Description
2.7 Service • Contact your municipal authority for information on how to dispose of the • To repair the appliance contact the appliance. Authorised Service Centre. • Disconnect the appliance from the mains • Use original spare parts only. supply. •... -
Page 8: Control Panel
Grill- / Roasting pan To bake and roast or as a pan to collect fat. Food sensor To measure the temperature inside food. Telescopic runners For inserting and removing trays and wireshelf more easily. Steam set One unperforated and one perforated food container. - Page 9 ON / OFF Press and hold to turn the appliance on and off. Menu Lists the appliance functions. Favourites Lists the favourite settings. Display Shows the current settings of the appliance. Lamp switch To turn the lamp on and off. Fast Heat Up To turn on and off the function: Fast Heat Up.
-
Page 10: Before First Use
5. BEFORE FIRST USE WARNING! Refer to Safety chapters. 5.1 Initial Cleaning Step 1 Step 2 Step 3 Remove all accessories and remov‐ Clean the appliance and the acces‐ Place the accessories and the re‐ able shelf supports from the appli‐ sories only with a microfibre cloth, movable shelf supports in the appli‐... -
Page 11: Daily Use
Put the test paper into Shake the test paper to re‐ After 1 min, check water Set the water hardness lev‐ water for about 1 sec. Do move the excess of water. hardness with the table el: Menu / Settings / Setup / not put the test paper un‐... - Page 12 Step 1 Turn on the oven. Select the symbol of the heating function and press it to enter the submenu. Step 2 Press . Set the steam heating function. Step 3 Press: . The display shows the temperature settings. Step 4 Set the temperature.
- Page 13 6.3 How to set: Assisted Cooking Every dish in this submenu has a recommended function and temperature. You can adjust the time and the temperature. For some of the dishes you can also cook with: • Weight Automatic • Food Sensor The degree to which a dish is cooked: •...
- Page 14 Heating function Application To bake cakes with crispy bottom and to preserve food. Bottom Heat SPECIALS Heating function Application To preserve vegetables (e.g., pickles). Preserving To dry sliced fruit, vegetables and mushrooms. Dehydrating To preheat plates for serving. Plate Warming To defrost food (vegetables and fruit).
-
Page 15: Clock Functions
Heating function Application Food reheating with steam prevents surface drying. Heat is distributed in a gentle and even way, which allows to recover taste and aroma of food as just prepared. This function can be used to reheat food directly on a plate. You can reheat more than one Steam Regenerating plate at the same time, using different shelf positions. - Page 16 Clock function Application Time extension To extend cooking time. Reminder To set a countdown. Maximum is 23 h 59 min. This function has no effect on the operation of the appliance. Uptimer Monitors how long the function operates. Uptimer - you can turn it on and off. 7.2 How to set: Clock functions How to set the clock Step 1...
-
Page 17: Using The Accessories
How to delay start of cooking Step 7 Press: . Repeat the action until the display shows the main screen. How to extend cooking time When 10% of cooking time is left and the food seems not to be ready, you can extend cooking time. You can also change the heating function. - Page 18 Baking tray / Deep pan: Push the tray between the guide bars of the shelf support. 8.2 Food Sensor Food Sensor - measures the temperature inside the food. You can use it with every heating function. There are two temperatures to be set: The oven temperature: minimum 120 °C.
-
Page 19: Additional Functions
Step 4 Plug Food Sensor into the socket at the front of the oven. The display shows the current temperature of: Food Sensor. Step 5 - press to set the core temperature of the sensor. Step 6 - press to set the preferred option: •... -
Page 20: Hints And Tips
Step 5 Press + to add the setting to the list of: Favourites. Press - press to reset the setting. - press to cancel the setting. 9.2 Function lock This function prevents an accidental change of the heating function. Step 1 Turn on the appliance. - Page 21 (°C) (min) Sweet rolls, 16 baking tray or dripping pan 25 - 35 pieces Swiss Roll baking tray or dripping pan 15 - 25 Whole fish, 0.2 kg baking tray or dripping pan 15 - 25 Cookies, 16 pieces baking tray or dripping pan 20 - 30 Macaroons, 24 baking tray or dripping pan...
- Page 22 °C Fatless sponge cake Conventional Cooking 45 - 60 Apple pie, 2 tins Ø20 cm True Fan Cooking 55 - 65 Apple pie, 2 tins Ø20 cm Conventional Cooking 55 - 65 Short bread True Fan Cooking 25 - 35 Short bread Conventional Cooking 25 - 35...
-
Page 23: Care And Cleaning
Information for test institutes Tests for the function: Full Steam. Tests according to IEC 60350-1. Set the temperature to 100°C. Container (Gastronorm) Broccoli, preheat 1 x 2/3 perforated 0.3 8 - 9 Put the baking tray the empty oven on the first shelf position. - Page 24 11.2 How to remove: Shelf supports Remove the shelf supports to clean the oven. Step 1 Turn off the oven and wait until it is cold. Step 2 Carefully pull the shelf supports up and out of the front catch. Step 3 Pull the front end of the shelf support away from the side wall.
- Page 25 11.5 How to use: Descaling Before you start: Turn off the oven and wait until it is Remove all accessories. Make sure that the water drawer is cold. empty. Duration of the first part: around 100 min Step 1 Place the deep pan on the first shelf position. Step 2 Pour 250 ml of the descaling agent in the water drawer.
- Page 26 Step 1 Place the deep pan on the first shelf position. Step 2 Fill the water drawer with water to the maximum level until the signal sounds or the display shows the message. Step 3 Select: Menu / Cleaning / Rinsing. Duration: around 30 min Step 4 Turn on the function and follow the instruction on the display.
- Page 27 CAUTION! Carefully handle the glass, especially around the edges of the front panel. The glass can break. Step 1 Fully open the door. Step 2 Lift and press the clamping levers (A) on the two door hinges. Step 3 Close the oven door to the first opening position (approximately 70° angle). Hold the door at both sides and pull it away from the oven at an upwards angle.
-
Page 28: Troubleshooting
Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until the Disconnect the oven from the Put a cloth on the bottom of the cav‐ oven is cold. mains. ity. Top lamp Step 1 Turn the glass cover to remove it. - Page 29 The appliance does not turn on or does not heat up Possible cause Remedy The clock is not set. Set the clock, for details refer to Clock functions chap‐ ter, How to set: Clock functions. The door is not closed correctly. Fully close the door.
-
Page 30: Energy Efficiency
......... 13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name Electrolux COB8S39Z 944032076 EOB8S39X 944032073 Model identification EOB8S39Z 944032075 KOBBS39X 944032072 LOB8S39Z 944032098 Energy Efficiency Index 61.9 Energy efficiency class Energy consumption with a standard load, conventional mode 1.09 kWh/cycle... -
Page 31: Menu Structure
When possible, do not preheat the appliance cooking. The residual heat inside the before cooking. appliance will continue to cook. Keep breaks between baking as short as Use the residual heat to warm up other possible when you prepare a few dishes at dishes. - Page 32 Submenu Application Descaling Cleaning of the steam generation circuit from residual limestone. Rinsing Procedure for rinsing and cleaning the steam generation circuit after frequent use of the steam functions. 14.3 Submenu for: Options Submenu Application Light Turns the lamp on and off. Child Lock Prevents accidental activation of the appliance.
-
Page 33: S Easy
15. IT'S EASY! Before the first use you have to set: Display bright‐ Language Key tones Buzzer volume Water hardness Time of day ness Familiarize yourself with the basic icons on the control panel and the display: ON / OFF Menu Favourites Timer... -
Page 34: Environmental Concerns
Use quick functions to set the cooking time 10% Finish assist To extend the cooking time press +1min. Use 10% Finish assist to add extra time when 10% of the cooking time is left. Clean the appliance with Steam cleaning Step 1 Step 2 Step 3... - Page 36 867371085-C-132023...
