SERVICE MANUAL
Ver. 1.1 2008.07
Revision History
Revision History
Internal memory
Internal memory
ON BOARD
ON BOARD
Revised-1
Replace the previously issued
SERVICE MANUAL 9-852-289-11
with this Manual.
Link
Link
SPECIFICATIONS
SERVICE NOTE
The components identified by
mark
or dotted line with
mark
are critical for safety.
Replace only with part num-
ber specified.
In case of the lens block assy, main board, or main frame assy failure,
contact your local Sony Service Headquarter for the measures.
DSC-S780
9-852-289-12
DISASSEMBLY
BLOCK DIAGRAM
Les composants identifiés par une
marque
sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
DSC-S780
DIGITAL STILL CAMERA
Sony EMCS Co.
US Model
Canadian Model
AEP Model
UK Model
E Model
Korea Model
Argentine Model
REPAIR PARTS LIST
Published by Kohda TEC
2008G0200-1
© 2008.07

Advertisement

Table of Contents
loading

Related Manuals for Sony DSC-S780

Summary of Contents for Sony DSC-S780

  • Page 1 Ne les remplacer que par une pièce ber specified. portant le numéro spécifié. In case of the lens block assy, main board, or main frame assy failure, contact your local Sony Service Headquarter for the measures. DIGITAL STILL CAMERA 2008G0200-1 DSC-S780 ©...
  • Page 2 26.5 mm (3 5/8 2 1/4 1/16 inches) (W/H/D, excluding protrusions) Mass: Approx. 150 g (5.3 oz) (including NP-BK1 battery pack and strap, etc.) Microphone: Monaural Speaker: Monaural Exif Print: Compatible PRINT Image Matching III: Compatible PictBridge: Compatible DSC-S780 — 2 —...
  • Page 3 CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU PUBLISHED BY SONY.

  • Page 4: Table Of Contents

    3-1. Overall Block Diagram ··················································· 3-1 REPAIR PARTS LIST 4-1. Exploded Views ······························································· 4-1 4-1-1. Overall Section ······························································ 4-1 4-1-2. Main Frame Block ························································· 4-2 4-1-3. Cabinet (Rear) Block ····················································· 4-3 4-1-4. Lens Block ····································································· 4-2. Accessories ······································································ DSC-S780 — 4 —...

  • Page 5: Service Note

    Select [OK] with on the control button, then press The message "All data in internal memory will be erased Ready?" appears. Select [OK] with , then press The format is complete. To cancel formatting Select [Cancel] in step , then press DSC-S780...
  • Page 6 SCREW TP _1.7_3_A_0.4_D=3 MIDDLE COVER R SCREW_TP_1.7_2.7_A_0.4_D=3 SCREW_TP_1.7_3.5_A_0.4_D=3 JACK COVER MIDDLE COVER L CABINET (FRONT) ASSY (To 2-2 Page) SCREW_TP_1.7_7.5_A_0.5_D=2.5 CABINET (REAR) ASSY SCREW_TP_1.7_3_A_0.4_D=3 FFC1 (SW) SCREW_TP_1.7_2_A_0.4_D=3 SCREW_TP_1.4_3_A_0.3_D=2.5 LCD PLATE MODE DIAL SP SHEET METAL SW BLOCK ASSY SW BUTTON DSC-S780...
  • Page 7 (1kΩ / 1W) SCREW_TP_1.7_3_A_0.4_D=3 SCREW_TP_1.7_3.5_A_0.4_D=3 BT LID RL BLOCK MAIN MOUNT SCREW_TP_1.4_3_A_0.3_D=2.5 FFC2 (RL) LENS BLOCK ASSY ST BLOCK ASSY MAIN FRAME ASSY HELP01 HELP02 HELP02 BLOCK ASSY PROTECTION SHEET SCREW_TP_1.4_3_A_0.3_D=2.5 SCREW_TP_1.4_3_A_0.3_D=2.5 HELP01 CCD ASSY LOW PASS FILTER SET HELP03 DSC-S780...
  • Page 8 Be careful of the weld HELP02 Keep clean these Pins. HELP03 Attach the Block assy protection sheet as shown. Attach the Block assy protection sheet avoiding three screw holes. Attach the Block assy protection sheet avoiding four screws. Block assy protection sheet DSC-S780 HELP...

  • Page 9: Memory

    DGND GREEN GREEN FA20 FA2 0 FA21 FA2 1 FA22 FA2 2 FA23 MEMORY FA2 3 MS_INS# STICK MS_INS# MS_CLK MS_CLK +3.1VC +3.1VC DGND DGND JACK +3.1VD +3.1VD USB_DET USB_DET A/V_DET A/V_DET VIDEO_OUT VIDEO_OUT LINE_OUT LINE_OUT DGND DGND JACK DSC-S780...

  • Page 10: Repair Parts List

    Ref. No. Part No. Description X-2190-117-1 CABINET (FRONT) ASSY 3-286-718-01 BLOCK, RL 3-295-133-01 SCREW_TP_1.7_3_A_0.4_D=3 3-286-719-01 FFC2 (RL) 3-286-720-01 LCD (Note) 3-295-131-01 SCREW_TP_1.7_7.5_A_0.5_D=2.5 3-295-134-01 SCREW_TP_1.7_3.5_A_0.4_D=3 3-874-572-01 SCREW_TP_1.7_2.7_A_0.4_D=3 3-286-713-01 MIDDLE COVER L 3-295-132-01 SCREW_TP_1.7_2_A_0.4_D=3 3-286-712-01 COVER, JACK 3-286-714-01 MIDDLE COVER R DSC-S780...

  • Page 11: Main Frame Block

    (Note 3) (Note 1) (Note 1) Note 1 : In case of the main board or main frame assy failure, contact your local Sony service Headquarter for the measures. Lens Block (See page 4-4) Note 2 : The adjustment is not required after replacing the ST block assy.

  • Page 12: Cabinet (Rear) Block

    4. REPAIR PARTS LIST 4-1-3. CABINET (REAR) BLOCK Ref. No. Part No. Description 3-295-130-01 SCREW_TP_1.4_3_A_0.3_D=2.5 A-1444-059-A SW BLOCK ASSY 3-286-717-01 FFC1 (SW) 3-286-716-01 DIAL, MODE 3-398-568-01 BUTTON, SW X-2190-118-1 CABINET (REAR) ASSY DSC-S780...

  • Page 13: Lens Block

    4-1-4. LENS BLOCK ns : not supplied (TP1.4X3) (CCD Assy) (Note) (TP1.4X3) Note : In case of the CCD assy failure, contact your local Sony service Headquarter for the measures. Ref. No. Part No. Description A-1557-161-A LENS BLOCK ASSY (SERVICE)

  • Page 14: Accessories

    3-285-743-21 (ARABIC) 3-285-744-61 (TURKISH) 3-285-743-31 (PERSIAN) 3-285-744-71 (GREEK) 3-285-743-41 (KOREAN) 3-285-744-81 (UKRAINIAN) CD-ROM (Cyber-shot application software/ "Cyber-shot Handbook"/ "Cyber-shot Step-up Guide") 3-285-741-01 NOTE: Refer to cover for mark Abbreviation CND : Canadian model : Argentine model : Korea model DSC-S780...
  • Page 15 】 Regarding Fuse and etc. ・ MAIN BOARD Q13 4-120-071-01 DTC144WM3T5G Ref. No. : Part No. : 1-576-913-11 Description : FUSE, MICRO (1608 TYPE) (1.6A/36V) Ref. No. : Part No. : 1-576-363-11 Description : FUSE, MICRO (1005 TYPE) (1A/30V) DSC-S780...
  • Page 16 — — 2008.07 Revised-1 • Addition of DISASSEMBLY for Lens Assy • Addition of HELP • Addition of REPAIR PARTS LIST • Revision of Regarding Fuse S.M. Revised : Page 4, 2-2, HELP, 4-2, 4-4, Regarding Fuse and etc. DSC-S780...
